CAB  10-41

JUMP SEAT BELT



  REMOVAL AND INSTALLATION

Removal Steps

1. Hinge cover
2. Hinge cover ; center
3. Bolt

Installation Steps

▲

3. Bolt
2. Hinge cover ; center
1. Hinge cover

Important Operation - Installation

3. Bolt

Torque

N

⋅

m(kgf

⋅

m/lb

⋅

ft)

39.2

±

 9.8 (4

±

 1 / 28.9

±

 7.2)

TFCAB-WE-981
