№		Номер детали	Наименование запчасти
-		1397 350169 [Angle]	Angle
-		199114550021 [Connector]	Connector
-		AZ9112550120 [Return line]	Return line
-		Q150B0630 [Screw]	Screw
-		Q340B06 [Nut]	Nut
-		Q72314T5F [Gasket]	Gasket
-		WG9100360134 [Space]	Space
-		WG9725550002-1 [Prefilter element]	Prefilter element
1		AZ9718559001 [200L Fuel AL-tank]	200L Fuel AL-tank
2		AZ9718559001-1 [Fuel gauge]	Fuel gauge
3		AZ9718559001-2 [Cover]	Cover
4		199100550006 [Support]	Support
5		199100550009 [Base]	Base
6		Q150B1440 [Screw]	Screw
7		19000388458 [Nut]	Nut
8		Q40314 [Spring washer]	Spring washer
9		WG9100550011 [Strap]	Strap
10		WG9100550081 [Base]	Base
11		Q33210 [Nut]	Nut
12		Q5101075 [Bolt]	Bolt
13		Q40110 [Washer]	Washer
14		Q5003214 [Split pin]	Split pin
15		WG9014230017 [Hose connector]	Hose connector
16		190003962621 [Female screw]	Female screw
17		Q33210 [Nut]	Nut
18		AZ9112550120 [Suction line]	Suction line
18		Q40106 [Washer]	Washer
19		WG972555000-2 [Feul prefilter C]	Feul prefilter C
20		190003171393 [Cable binder]	Cable binder
21		199000770296 [Clamp]	Clamp

COOLING SYSTEM (C1-4) для Sinotruk 4x2 Tractor (371) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
-		AZ9716530505 [Bracket]	Bracket
-		AZ9716530521 [Bracket]	Bracket
-		AZ9719530202 [Bracket right for radiator]	Bracket right for radiator
-		AZ9719530206 [Supporting plate right]	Supporting plate right
-		AZ9725538066 [Bottom supporter for radiator]	Bottom supporter for radiator
-		AZ9725538099 [Bracket]	Bracket
-		AZ9725538125 [Bottom bracket]	Bottom bracket
-		Q150B01816 [Screw]	Screw
-		Q150B1025 [Screw]	Screw
-		Q33210 [Nut]	Nut
-		Q340B10 [Nut]	Nut
-		Q40010 [Washer]	Washer
-		Q40308 [Spring washer]	Spring washer
-		Q40310 [Spring washer]	Spring washer
1		190003989315 [Clamp]	Clamp
2		WG9719530108 [Hose]	Hose
2		WG9725538041 [Hose]	Hose
5		WG9719530107 [Hose connector]	Hose connector
5		WG9725538043 [Hose]	Hose
8		WG9719530108 [Hose]	Hose
8		WG9725530070 [Hose]	Hose
8		WG9725538042 [Hose]	Hose
9		WG1600840029 [Hose]	Hose
9		WG1620840060 [Hose]	Hose
10		1900043989301 [Clamp]	Clamp
11		WG9719530250 [Aftercooler]	Aftercooler
11		WG9725530020 [Aftercooler]	Aftercooler
11		WG9725530090 [Aftercooler]	Aftercooler
11		WG9725538060 [Aftercooler]	Aftercooler
12		WG9719530010 [Radiator]	Radiator
12		WG9719530230 [Radiator]	Radiator
12		WG9725537070 [Radiator]	Radiator
12		WG9725538050 [Radiator]	Radiator
13		Q150B0816 [Screw]	Screw
14		Q40008 [Washer]	Washer
15		Q41208 [Spring washer]	Spring washer
16		Q150B0820 [Screw]	Screw
17		Q40308 [Spring washer]	Spring washer
18		Q40108 [Washer]	Washer
19		1780530009 [Fastening sheet]	Fastening sheet
20		Q150B1018 [Screw]	Screw
21		Q40310 [Spring washer]	Spring washer
22		Q40110 [Washer]	Washer
23		Q33208 [Nut]	Nut
24		190003980204 [Clamp]	Clamp
25		190003989300 [Clamp]	Clamp
26		WG9114530138 [Hose]	Hose
27		AZ9003980010 [Clamp]	Clamp
28		WG9719530111 [Inletwater pipe]	Inletwater pipe
28		WG9725537005 [Inletwater pipe]	Inletwater pipe
28		WG9725538008 [Inletwater pipe]	Inletwater pipe
30		AZ9719530122 [Outlet air pipe]	Outlet air pipe
30		WG9725537004 [Outlet air pipe]	Outlet air pipe
30		WG9725538044 [Outlet air pipe]	Outlet air pipe
31		WG9114530139 [Hose]	Hose
32		WG9716530307 [Hose]	Hose
33		WG9716530305 [Hose]	Hose
34		WG9716530510 [Junction pipe]	Junction pipe
35		WG9112530468 [Hose]	Hose
36		WG9719530228 [Hose]	Hose
45		WG9719530003 [Outlet water pipe]	Outlet water pipe
45		WG9719530212 [Outlet water pipe]	Outlet water pipe
45		WG9719537007 [Outlet water pipe]	Outlet water pipe
45		WG9725538014 [Outlet water pipe]	Outlet water pipe
46		WG9719530227 [Hose]	Hose
46		WG9725537021 [Hose]	Hose
46		WG9725538063 [Hose]	Hose
49		AZ9112530333 [Expansion tank]	Expansion tank
49		WG9719530260 [Expansion tank]	Expansion tank
61		AZ9719530132 [Shroud]	Shroud
61		AZ9725530401 [Shroud]	Shroud
61		AZ9725533037 [Shroud]	Shroud
61		AZ9725538055 [Shroud]	Shroud
61		WG9725537001 [Shroud]	Shroud
65		AZ9719530272 [Rubber support]	Rubber support
70		AZ9719530201 [Bracket left for radiator]	Bracket left for radiator
75		AZ9719530205 [Supporting plate left]	Supporting plate left
80		AZ9725538065 [Top supporter for radiator]	Top supporter for radiator
81		AZ9725538073 [Left bracket for radiator]	Left bracket for radiator
85		AZ9725538076 [Right bracket for radiator]	Right bracket for radiator

EXHAUST PIPING (C1-5) для Sinotruk 4x2 Tractor (371) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
-		AZ9725540012 [Heat shield]	Heat shield
-		Q150B0835 [Screw]	Screw
-		Q150B0845 [Screw]	Screw
-		Q33208 [Nut]	Nut
-		Q40108 [Washer]	Washer
-		Q40308 [Spring washer]	Spring washer
1		AZ9719540019 [Gasket]	Gasket
1		WG9112540015 [Gasket]	Gasket
2		181560110187 [Stud]	Stud
2		Q150B1045 [Screw]	Screw
3		190003888470 [Nut]	Nut
3		Q33210 [Nut]	Nut
4		WG9719540009 [Exhaust line]	Exhaust line
4		WG9719540012 [Exhaust line]	Exhaust line
4		WG9725540001 [Exhaust line]	Exhaust line
4		WG9731540001 [Exhaust line]	Exhaust line
5		Q150B0830 [Screw]	Screw
6		WG9719540016 [Clamp]	Clamp
6		WG9725540009 [Clamp]	Clamp
7		Q33208 [Nut]	Nut
8		WG9719540021 [Corrugated flexible metal tube]	Corrugated flexible metal tube
8		WG9725540007 [Corrugated flexible metal tube]	Corrugated flexible metal tube
8		WG9731540002 [Corrugated flexible metal tube]	Corrugated flexible metal tube
9		Q150B0830 [Screw]	Screw
10		AZ9719540018 [Clamp]	Clamp
11		Q33208 [Nut]	Nut
12		WG9725540002 [Muffler]	Muffler
12		WG9725540010 [Muffler]	Muffler
13		AZ9719540008 [Strap]	Strap
14		WG9719540025 [Garnish plate]	Garnish plate
15		Q150B0620 [Screw]	Screw
16		Q40306 [Spring washer]	Spring washer
17		Q150B0610 [Screw]	Screw
18		WG9719540026 [Heat shield]	Heat shield
19		AZ9719540007 [Stop plate]	Stop plate
20		AZ9719540002 [Rear bracket]	Rear bracket
21		AZ9719540003 [Front bracket]	Front bracket
22		Q33208 [Nut]	Nut
23		Q33212 [Nut]	Nut
24		Q150B1235 [Screw]	Screw
30		WG9731540003 [Exhaust line]	Exhaust line
31		Q150B1025 [Screw]	Screw
32		Q40310 [Spring washer]	Spring washer
33		WG84D410007 [Rubber pad]	Rubber pad
34		Q40210 [Washer]	Washer
35		AZ9731540004 [Bracket]	Bracket
36		Q150B1016 [Screw]	Screw
37		Q40310 [Spring washer]	Spring washer
40		AZ9731540005 [Clamp]	Clamp
41		AZ9731540006 [Clamp]	Clamp
42		Q150B1035 [Screw]	Screw
43		Q150B1025 [Screw]	Screw
44		Q33210 [Nut]	Nut
45		WG9719540021 [Corrugated flexible metal tube]	Corrugated flexible metal tube

AIR FILTER (C1-6) для Sinotruk 4x2 Tractor (371) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
-		AZ9725190079 [Bracket]	Bracket
-		WG1200190040 [Sensor]	Sensor
-		WG9719190001-1 [Filter element]	Filter element
-		WG9725190045-1 [Filter element]	Filter element
-		WG9725190063-1 [Filter element]	Filter element
1		AZ9725190001 [Supporter]	Supporter
1		AZ9725190065 [Supporter]	Supporter
1		WG9719190002 [Supporter]	Supporter
2		WG9100190026 [Strap]	Strap
3		WG9719190001 [Airfilter]	Airfilter
3		WG9725190045 [Airfilter]	Airfilter
3		WG9725190063 [Airfilter]	Airfilter
4		AZ9003980025 [Clamp]	Clamp
5		AZ9725190062 [Hose]	Hose
5		WG9719190046 [Hose]	Hose
5		WG9725190042 [Hose]	Hose
6		WG9719190033 [Rubber block]	Rubber block
7		AZ9719190036 [Bracket]	Bracket
7		WG9719190030 [Bracket]	Bracket
8		Q1840825 [Screw]	Screw
9		Q33208 [Nut]	Nut
10		WG9719190013 [Air intake line I]	Air intake line I
11		WG9719190016 [Strap]	Strap
12		WG9719190015 [Siphon]	Siphon
13		WG9719190014 [Air intake line II]	Air intake line II
13		WG9725190061 [Air intake line II]	Air intake line II
14		Q150B0810 [Screw]	Screw
15		Q150B0825 [Screw]	Screw
16		Q40108 [Washer]	Washer
17		Q33008 [Nut]	Nut
18		WG9719190009 [Hose]	Hose
19		Q150B1030 [Screw]	Screw
20		Q40610 [Spring washer]	Spring washer
21		1113 010043 [Spacer]	Spacer
22		AZ9725190081 [Bracket]	Bracket
22		WG9719190040 [Bracket]	Bracket
23		WG9719190050 [Pipe]	Pipe
24		WG9719190008 [Hose]	Hose
24		WG9725190041 [Hose]	Hose
25		199100190065 [Sheet]	Sheet
26		1280 550028 [Bolt]	Bolt
27		1280 550029 [Screw]	Screw
28		1280 550027 [Bolt]	Bolt
29		Q33212 [Nut]	Nut
30		Q150B1235 [Screw]	Screw

SUSPENSION FOR ENGINE (C1-7) для Sinotruk 4x2 Tractor (371) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
-		AZ9725590006 [Bracket right]	Bracket right
-		AZ9725590023 [Connecting plate]	Connecting plate
-		AZ9725590045 [Aux.support left]	Aux.support left
-		AZ9725590048 [Aux.support right]	Aux.support right
-		AZ9725590082 [Bracket left]	Bracket left
1		Q40308 [Spring washer]	Spring washer
2		Q150B0816 [Screw]	Screw
3		1480A360058 [Washer]	Washer
4		Q40312 [Spring washer]	Spring washer
5		190003802622 [Screw]	Screw
6		AZ9725590007 [Crossbar]	Crossbar
6		AZ9725590029 [Crossbar]	Crossbar
6		WG9719590001 [Crossbar]	Crossbar
6		WG9731590001 [Crossbar]	Crossbar
7		AZ9725592000 [Rubber support]	Rubber support
7		WG1680590095 [Rubber support]	Rubber support
8		Q151B1645 [Screw]	Screw
9		190003888459 [Nut]	Nut
10		Q150B1245 [Screw]	Screw
11		Q33212 [Nut]	Nut
12		AZ9731590015 [Bracket left]	Bracket left
12		AZ9731590017 [Bracket]	Bracket
13		Q151C1235 [Screw]	Screw
14		AZ9731590016 [Bracket right]	Bracket right
14		AZ9731590017 [Bracket]	Bracket
15		Q151B1440 [Screw]	Screw
16		Q40314 [Spring washer]	Spring washer
17		AZ9725590031 [Bearing]	Bearing
18		AZ9725590002 [Bracket left]	Bracket left
18		AZ9725590081 [Bracket right]	Bracket right
18		AZ9731590020 [Support]	Support
20		AZ9725590046 [Support left]	Support left
20		AZ9725596020 [Support left]	Support left
21		AZ9725590047 [Support right]	Support right
21		AZ9725596030 [Support right]	Support right
22		WG9100590082 [Stop block]	Stop block
23		Q40312 [Washer]	Washer
24		Q34012 [Nut]	Nut
30		AZ9725590020 [Bearing]	Bearing

SPECIAL PARTS OF WD615 FOR HOWO (C1-8) для Sinotruk 4x2 Tractor (371) (список запасных частей)

Таблица запасных частей

№		Номер детали	Наименование запчасти
1		612600130125 [Air compressor]	Air compressor
2		612600130127 [Water pipe]	Water pipe
3		AZ9719570027 [Bracket]	Bracket
4		612600120103 [Bracket]	Bracket
5		612600120122 [Bracket]	Bracket
6		612600120121 [Air intake manifold]	Air intake manifold
7		612600111141 [Connecting pipe]	Connecting pipe
8		612600111144 [Air intake manifold]	Air intake manifold
9		612600111136 [Exhaust manifold rear]	Exhaust manifold rear
10		612600111137 [Exhaust manifold front]	Exhaust manifold front
11		612600111182 [Oil intake pipe]	Oil intake pipe
12		612600010898 [Oil dipstick]	Oil dipstick
13		612600010899 [Jauge]	Jauge
14		612600111197 [Screw]	Screw
15		612600010919 [Nozzle]	Nozzle
16		612600111196 [Air intake pipe]	Air intake pipe
17		612600111138 [Heat shield]	Heat shield
18		612600111139 [Heat shield]	Heat shield
19		612600111200 [Screw]	Screw
20		612600111051 [Oil pipe]	Oil pipe
21		612600120100 [Air intake manifold of aftercooler]	Air intake manifold of aftercooler
22		612600111213 [Bracket]	Bracket
23		612600111078 [Connecting pipe]	Connecting pipe
24		612600120101 [Bottom air intake pipe of aftercooler]	Bottom air intake pipe of aftercooler
27		612600830080 [Cover]	Cover
28		612600070155 [Washer]	Washer
29		612600010909 [Washer]	Washer
30		AZ9719530035 [Air intake pipe of compressor]	Air intake pipe of compressor
31		612600111052 [Screw for exhaust manifold]	Screw for exhaust manifold
32		612600130121 [Rubber hose]	Rubber hose
33		61560116227D [Turbochager]	Turbochager
34		61560118227D [Turbochager]	Turbochager
35		612600111413 [Pipe of aftercooler]	Pipe of aftercooler
36		612600111419 [Air intake pipe of aftercooler]	Air intake pipe of aftercooler
37		612600111424 [Bracket]	Bracket
38		612600111425 [Bracket]	Bracket
39		612600060659 [Water intake pipe]	Water intake pipe
40		61560118227 [Turbochager]	Turbochager
41		61560110227 [Turbochager]	Turbochager
42		612600081161 [Injection pump]	Injection pump
43		612600081162 [Injection pump]	Injection pump
44		612600080446 [Injection pump, Bosch]	Injection pump, Bosch
45		612600083151 [Injection pump]	Injection pump
46		612600082115 [Injection pump, Bosch]	Injection pump, Bosch
47		61560080302 [Injection pump, Bosch]	Injection pump, Bosch
48		612600060215 [Ф620 fan]	Ф620 fan
49		612600060166 [Ф750 fan]	Ф750 fan
50		612600060445 [Ф590 ring fan]	Ф590 ring fan
51		612600060446 [Ф640 ring fan]	Ф640 ring fan
52		81500060228 [V-belt (speed ratio 3.39)]	V-belt (speed ratio 3.39)
53		61500060217 [V-belt (speed ratio 3.15)]	V-belt (speed ratio 3.15)
54		612600090065 [V-belt(altemater)]	V-belt(altemater)
55		AZ1500098058 [1 kw altemater]	1 kw altemater
56		612600098155 [1.5kw altemater]	1.5kw altemater
