TETHER STRAP - QUAD CAB
WARNING: To avoid personal injury or death, during and following any seat belt or child restraint anchor
service, carefully inspect all seat belts, buckles, mounting hardware, retractors, tether straps, and anchors
for proper installation, operation, or damage. Replace any belt that is cut, frayed, or torn. Straighten any
belt that is twisted. Tighten any loose fasteners. Replace any belt that has a damaged or inoperative buckle
or retractor. Replace any belt that has a bent or damaged latch plate or anchor plate. Replace any child
restraint anchor or the unit to which the anchor is integral that has been bent or damaged. Never attempt to
repair a seat belt or child restraint component. Always replace damaged or faulty seat belt and child
restraint components with the correct, new and unused replacement parts listed in the DaimlerChrysler
Mopar Parts Catalog.
NOTE: The following procedure applies only to the rear seat upper child tether straps used on quad cab
models.
1. Position the child tether strap (1) onto the cab back
trim panel (2).
2. Install and tighten the screw (4) that secures the
child tether strap to the upper cab back panel rein-
forcement (3). Tighten the screw to 14 N·m (10 ft.
lbs.).
3. Reinstall the rear seat into the vehicle. (Refer to 23
- BODY/SEATS/SEAT - REAR - INSTALLATION).
REAR SEAT LOWER ANCHOR BRACKET - CLUB CAB
WARNING: To avoid personal injury or death, during and following any seat belt or child restraint anchor
service, carefully inspect all seat belts, buckles, mounting hardware, retractors, tether straps, and anchors
for proper installation, operation, or damage. Replace any belt that is cut, frayed, or torn. Straighten any
belt that is twisted. Tighten any loose fasteners. Replace any belt that has a damaged or inoperative buckle
or retractor. Replace any belt that has a bent or damaged latch plate or anchor plate. Replace any child
restraint anchor or the unit to which the anchor is integral that has been bent or damaged. Never attempt to
repair a seat belt or child restraint component. Always replace damaged or faulty seat belt and child
restraint components with the correct, new and unused replacement parts listed in the DaimlerChrysler
Mopar Parts Catalog.
NOTE: The following procedure applies only to the lower anchor bracket used in the right rear seating posi-
tion of club cab models.
8O - 420
RESTRAINTS - SERVICE INFORMATION
ND
