REAR RETAINER
1. Apply 3 mm (1/8 in.) wide bead of Mopar
T
Gasket
Maker, or equivalent silicone adhesive sealer, to
mounting surface of rear retainer. Allow sealer to
set-up slightly before proceeding.
2. Install rear retainer on rear case. Tighten retainer
bolts to 27-34 N·m (20-25 ft. lbs.).
3. Install new output shaft bearing snap-ring (2). Lift
mainshaft slightly to seat snap-ring in shaft groove,
if necessary.
4. Apply 3 mm (1/8 in.) wide bead of Mopar
T
Gasket
Maker, or equivalent silicone adhesive sealer, to
mounting surface of extension housing. Allow
sealer to set-up slightly before proceeding.
5. Install extension housing on rear retainer.
6. Install extension housing bolts and tighten to 27-34
N·m (20-25 ft. lbs.).
INSTALLATION
1. Mount transfer case on a transmission jack.
2. Secure transfer case to jack with chains.
3. Position transfer case under vehicle.
4. Align transfer case and transmission shafts and
install transfer case (2) onto the transmission (1).
5. Install and tighten transfer case attaching nuts (3)
to 27-34 N·m (20-25 ft. lbs.) torque.
21 - 904
TRANSFER CASE - NV233
ND
