NOTE: Before final assembly of transmission cen- 9. Install the 2C reaction plate (4) into the transmis- sion case. 10. Install the 2C clutch pack (2, 3) into the transmis- sion case. 11. Install the flat 2C clutch snap-ring (1) into the transmission case. 12. Install the 4C retainer/bulkhead (2) into the trans- mission case. Make sure that the oil feed holes 13. Install the 4C retainer/bulkhead tapered snap-ring (1) into the transmission case. Make sure that the 14. Using a feeler gauge through the opening in the rear of the transmission case, measure the 2C 15. Remove the 4C retainer/bulkhead and all of the 2C clutch components from the transmission case. 21 - 704 AUTOMATIC TRANSMISSION 545RFE - SERVICE INFORMATION ND |
