HOOD ORNAMENT AY/P-S REMOVAL (FIG. 2) (1) Remove grille. ing panel header. (3) Compress hood ornament spring enough to clear hooks on end of retaining wire. (4) Squeeze retainer wire hooks together and push hooks inside spring. (5) Rotate spring counterclockwise to separate spring from retainer. (6) Separate hood ornament from grille opening panel. INSTALLATION Reverse the preceding operation. GRILLE OPENING PANEL AY/P BODY For service procedures for headlamp related compo- nents refer to Group 8L, Lamps. REMOVAL (FIG. 3) (1) Remove front bumper and grille. gain access to behind fenders. (3) Remove nuts holding GOP mouldings to front fenders. (4) Remove nuts holding grille opening panel to front fenders. (6) Disconnect concealed headlamp motor wire con- nector. (7) Disconnect all lamp wire connectors. radiator closure panel and center brace. (9) Separate grille opening panel from vehicle. INSTALLATION Reverse the preceding operation. GRILLE OPENING PANEL AY/S BODY For service procedures for headlamp related compo- nents refer to Group 8L, Lamps. REMOVAL (FIG. 4) (1) Remove front bumper and grille. gain access to behind fenders. (3) Remove nuts holding mouldings to front fend- ers. (4) Remove bolts holding mouldings to bottom of grille opening panel and separate mouldings from ve- (5) Remove nuts holding grille opening panel to front fenders. (6) Disconnect concealed headlamp motor wire con- nector. (7) Disconnect headlamp wire connectors. radiator closure panel mount brackets and center (9) Separate grille opening panel from vehicle. INSTALLATION Reverse the preceding operation. HOOD AND HINGES HOOD REMOVAL (FIG. 5) (1) Raise hood to full up position. the windshield washer bottle and disconnect the un- (3) Mark all bolt and hinge attachment locations with a grease pencil or other suitable device to pro- Fig. 3 Grille Opening Panel—AY/P Body Fig. 4 Grille Opening Panel—AY/S Body 23 - 134 AY-BODY Ä |
