37

Table cont'd

Telephone

Mute function for handsfree telephone: If the mobile phone adapter is factory-fitted, muting is via
the infotainment CAN bus.A direct wiring plug contact is provided for retrofit solutions.

LF input for handsfree telephone: when the radio is switched on, the vehicle loudspeakers are used
as loudspeakers for the handsfree telephone.
The handsfree telephone cannot be operated via the radio.

Control

Control via optional multifunction steering wheel

Display on the driver information display

Sound

Integrated 2 x 20 W amplifiers, connectivity for auxiliary amplifier

Speed-dependent volume control (GALA) via infotainment CAN bus

Sound coding according to body type (saloon/Avant/Cabrio), interior trim (fabric/leather) and engine
type (petrol/diesel engine)..

Service

Comfort coding: after the power supply to the radio has been disconnected, it is not necessary to
enter a PIN if the radio is restored to operation in the same vehicle.

Diagnosis via CAN bus (TT, A3 8P) or L-wire (A4 8E)

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
 permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
     with respect to the correctness of information in this document. Copyright by AUDI AG.

38

Infotainment

concert radio

The concert radio has all the features of the chorus
radio. The single-CD drive is also MP3 compatible,
i.e. MP3 CDs can be played.

The diagram shows the arrangement of the folders
on the MP3 CD in the radio. Folders which do not
contain MP3 files are not shown on the radio
display. When selecting a folder, the previous folder,
the folder currently selected and the next folder are
shown on the display.

The first 16 letters of the CD folder name are shown
on the radio display.

In MP3 playback mode, the ID3 tag of the MP3 file
can be viewed by pressing the INFO key. The Info
key can be used to scroll from one display to
another.
The file name, title, artist and album can be
displayed.
Menu texts are displayed in English.
The display language of the radios cannot be
changed.

382_070

Note

In the case of the concert and symphony radios, only the internal CD drive is MP3 compatible.
The optional auxiliary CD changer cannot play MP3 CDs. The CD changer featured in the Audi A3
8P and Audi A4 8E is fitted in the Audi TT Coupé ’07.

The amplifier in the concert radio is not used in the Audi TT Coupé ‘07. A 5-channel DSP amplifier is installed
in combination with the concert radio as standard.An auxiliary BOSE sound amplifier is optional.

File name

Title

Artist

Name of album

Folder

382_071

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
 permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
     with respect to the correctness of information in this document. Copyright by AUDI AG.

39

symphony radio

The symphony radio has all the features of the concert radio.
The symphony radio is additionally equipped with an internal MP3 compatible 6-disc CD changer.

In addition, the radio has the ability to record Traffic information Messages (TIM key = Traffic Information
Message). Traffic Information Messages stored by the radio can be played back by briefly pressing the TIM
key. Holding the TIM key down activates a function which allows two time periods to be programmed during
which Traffic Information Messages are recorded by the radio even when it is switched off.

Note

The radio has a higher power consumption in TIM record standby mode than when completely
switched off. Please deactivate the TIM function to perform static current measurements on the
vehicle.

Technical variants

In addition to the Audi TT Coupé ‘07, these radios will in future also be used in other Audi models equipped
with the infotainment CAN bus. The necessary adjustments are basically the type of front trim panel and the
diagnosis path (CAN, L-wire, etc.)

Country spec versions

The concert and symphony radios are modified for the North American market.

The modifications are:

●

different function key lettering and functions

–   SAT: the radio can also be used to control the Sirius satellite tuner
–   INFO: the Info key can be used to read information on the set radio station when the radio is in

operation. In MP3 mode, the name of the album (ALBUM), the name the artist (ARTIST) and the CD title
(TITLE) are read off the ID3 tag of the MP3 file.

–   MIX: the Mix key can be used to select a track mix from audio CDs or MP3 CDs.

●

Optimisation of the FM/AM tuner for the North American market

–   RDBS in lieu of RDS
–   Station seek adapted to the frequency spacings of the radio stations

The concert radio will also be available in a variant for Japan at a later date.

382_054

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
 permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
     with respect to the correctness of information in this document. Copyright by AUDI AG.

40

Aerial system

Radios with phase diversity have two aerial inputs
which can be diagnosed individually. The radios
differ in this respect from the previous radios or the
current radio navigation systems.

Radios with phase diversity do not have a separate
diversity switch.The Diversity function is integrated
in the radio. Only one aerial is connected to each of
the two radio aerial inputs, thus simplifying
diagnosis. Each aerial signal can be read out in
a separate data block.

Although only two aerials are used, reception
quality and interference immunity are better than
those of the previous systems.

Infotainment

382_063

Note

Different aerials are used by the new radios and navigation systems. For this reason, radios
cannot be replaced with navigation systems in the unchanged FM aerial system. Reception is
much poorer when the wrong aerial system is used.
Although different FM aerials are used, the radios and navigation systems have the same aerial
connectors. The differences between the aerials are described on page 52.

FM2

FM1 / AM
