Activating and deactivating the heated
windscreen

•

(p. 217)

•

Activating and deactivating the heated
rear window and door mirrors (p. 218)

Pinch protection for windows and

sun blinds

All power windows and sun blinds

have

pinch protection which is deployed if they are
blocked by any object while opening or clos-
ing.

In the event of blocking, the movement stops
and then reverses automatically to approx.
50 mm (approx. 2 inches) from the blocked
position (or to full ventilation position).

It is possible to force pinch protection when
closing has been cancelled, e.g. when ice is
formed, by continuing to press the control in
one and the same direction.

If any fault arises with the pinch protection, a
reset sequence can be tested.

WARNING

If the starter battery is disconnected, the

automatic opening and closing function

must be reset to work properly. A reset

must take place for pinch protection to

work.

Related information

•

Operating power windows (p. 168)

•

Does not apply to the windscreen, which is always laminated and thus does not have this symbol.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

167

•

Using the sun blind

(p. 170)

•

Operating the sunroof

(p. 175)

Reset sequence for pinch

protection

If a problem occurs with the electrical func-
tions for the electric windows, a reset
sequence can be tested.

Electrically-operated sun blinds

have a reset

sequence that can be tested if necessary.

WARNING

If the starter battery is disconnected, the

automatic opening and closing function

must be reset to work properly. A reset

must take place for pinch protection to

work.

In the event of problems with the sunroof,
contact a workshop.

Reset the power window

1. Start with the window in closed position.

2. Then operate the controls in the manual

position 3 times upwards to closed posi-
tion.
> The system is initialised automatically.

If problems persist, contact a workshop.

Reset sun blind

1. Start with the sun blind retracted.

2. Press the control against retracting mode

for approx. 15 seconds.
> The system is initialised automatically.

Related information

•

Pinch protection for windows and sun
blinds (p. 166)

•

Operating power windows (p. 168)

•

Using the sun blind

(p. 170)

An authorised Volvo workshop is recommended.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

168

Power windows

Each door has a control panel for the electri-
cally-driven power windows. The driver's
door has controls for operating all windows
and also to activate the child safety locks.

Driver's door control panel.

Electric child safety locks

that deactivate

the controls in the rear doors to prevent
doors or windows from being opened
from the inside.
Controls for rear windows.

Controls for front windows.

WARNING

Children, other passengers or objects may

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the
power supply to the power windows
by setting the car's electrical system in
ignition position

, and then take the

key with you when leaving the car.

•

Never put an object or part of the body
through the windows, even if the car's
electrical system is fully disconnected.

Related information

•

Operating power windows (p. 168)

•

Pinch protection for windows and sun
blinds (p. 166)

•

Operating power windows

Using the driver's door control panel, all
power windows can be operated - using the
control panels in the other doors operates the
power window in the individual door.

The power windows are equipped with pinch
protection. If any fault arises with the pinch
protection, a reset sequence can be tested.

WARNING

Children, other passengers or objects may

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the
power supply to the power windows
by setting the car's electrical system in
ignition position

, and then take the

key with you when leaving the car.

•

Never put an object or part of the body
through the windows, even if the car's
electrical system is fully disconnected.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

169

Operating the power windows.

Operating without auto. Move one of the
controls gently up or down. The power
windows move up or down as long as the
control is held in position.
Operating with auto. Move one of the con-
trols up or down to the end position and
release it. The window runs automatically
to its end position.

In order for the power windows to be used,
the ignition position must be

. The power

windows can be operated for a few minutes
after the car has been switched off and after
the ignition has been switched off - although
not after a door has been opened. It is only
possible to operate one control at a time.

It can also be operated using a remote control
key or keyless opening

with the door handle.

WARNING

Check that children or other passengers

are not at risk of crushing when all the win-

dows are closed with a remote control key

or keyless opening

with a door handle.

One way to reduce the pulsating wind
noise when the rear windows are open is
to also open the front windows slightly.

The windows cannot be opened at speeds
above approx. 180 km/h (approx.
112 mph), but they can be closed.

The driver always bears responsibility for
following traffic regulations in force.

Pinch protection for windows and sun
blinds (p. 166)

It may not be possible to operate windows
at low temperatures.

Related information

•

Power windows (p. 168)

•

•

Keyless locking and unlocking

•

(p. 270)

•

Locking and unlocking with the remote
control key (p. 242)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

170

Using the sun blind

The sun blinds are built into each of the rear
doors, and there is a sun blind built into the
rear parcel shelf.

Rear door – manually operated

The figure is schematic - the version may vary.

Hook with associated catch

–

Pull up the sun blind and attach it to the
hook in the upper door frame.

The window can still be opened and closed
with the sun blind up.

Rear window parcel shelf

There is an electrically operated sun blind built
on the rear window shelf.

In order that the sun blind can be operated,
the car's electrical system must be in ignition
position

Pinch protection for windows and sun
blinds (p. 166)

It may not be possible to operate the sun
blind in low temperatures.

Operating via the centre display

Give a short tap on the

Rear

Sun Curtain

button in the

function view in the centre
display - the sun blind is
operated automatically to its
end position, up or down.

Related information

•

•

Adjusting rearview mirror dimming
(p. 171)

•

Power windows (p. 168)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

171

Rearview and door mirrors

The rearview mirrors and door mirrors can be
used to give the driver better visibility to the
rear.

Interior rearview mirror

The interior rearview mirror is equipped with
HomeLink

, automatic dimming

and com-

pass

The interior rearview mirror is adjusted by
angling it manually.

Door mirrors

WARNING

Both mirrors are bent to provide optimal

vision. Objects may appear to be further

away than they actually are.

The door mirror positions are adjusted with
the joystick in the driver's door control panel.

There are also a number of automatic settings
that can be linked to the memory function but-
tons for the power seat

Related information

•

•

•

•

Angling adjustment of the door mirrors
(p. 172)

•

Storing position for seat, door mirrors and
head-up display

(p. 184)

•

Activating and deactivating the heated
rear window and door mirrors (p. 218)

Adjusting rearview mirror dimming

Bright light from behind could be reflected in
the rearview mirrors and dazzle the driver.
Use dimming when disturbed by light from
behind.

Manual dimming

The interior rearview mirror can be dimmed
with a control in the mirror's lower edge.

Control for manual dimming.

1. Use dimming by moving the control in

towards the passenger compartment.

2. Return to normal mode by moving the

control towards the windscreen.

The control for manual dimming is not availa-
ble on mirrors with automatic dimming.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

172

Automatic dimming

If bright light comes from behind, the rearview
mirrors automatically dim when it is dark out-
side or when the light is limited, for example
when driving in tunnels. Automatic dimming is
always active while driving, apart from when
gearbox reverse position is selected.

When sensitivity is changed there is no
immediately noticeable change in dim-
ming, but the change takes place gradu-
ally.

Dimming sensitivity will affect both the interior
rearview mirror and the door mirrors.

To change dimming sensitivity:

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

My Car

Mirrors and

Convenience

3. Under

Rearview Mirror Auto Dimming

select

Normal

Dark

Light

The interior rearview mirror contains two sen-
sors - one forward facing and one rearward
facing - that work together to identify and
eliminate dazzling light. The forward facing
sensor detects ambient light, while the rear-

ward facing sensor detects the light from vehi-
cle headlights behind.

For the door mirrors to be equipped with auto-
matic dimming, the interior rearview mirror
must also be equipped with automatic dim-
ming.

Rearview and door mirrors (p. 171)

If the sensors are obscured by e.g. parking
permits, transponders, sun visors or
objects in the seats or on the parcel shelf in
such a way that light is prevented from
reaching the sensors, then the dimming
function of the interior rearview and door
mirrors is reduced.

Related information

•

•

Angling adjustment of the door mirrors
(p. 172)

Angling adjustment of the door

mirrors

To ensure better visibility to the rear, the door
mirrors need to be set to the preferences of
the driver.

There are a number of automatic settings that
can also be linked to the memory function
buttons for the power seat

Using controls for door mirrors

Controls for door mirrors.

The door mirror positions are adjusted with
the joystick in the driver's door control panel.
Ignition position must be at least

1. Press the

button for the left-hand door

mirror or the

button for the right-hand

door mirror. The light in the button illumi-
nates.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

173

2. Adjust the position with the joystick in the

centre.

3. Press the

button again. The light

should no longer be illuminated.

Folding in rearview mirrors
electrically

The mirrors can be retracted for parking/driv-
ing in narrow spaces.

1. Depress the

and

buttons simultane-

ously.

2. Release them after approximately 1 sec-

ond. The mirrors automatically stop in the
fully retracted position.

Fold out the mirrors by pressing down the

and

buttons simultaneously. The mirrors

automatically stop in the extended position
with the previous setting.

Resetting to neutral

Mirrors that have been moved out of position
by an external force must be reset electrically
to their original position for electric retracting/
extending

to work correctly.

1. Fold in the door mirrors by pressing down

the

and

buttons simultaneously.

2. Fold them out again by pressing the

and

buttons simultaneously.

3. Repeat the above procedure as necessary.

The mirrors are returned to the original posi-
tion.

Angling during parking

A door mirror can be angled down for the
driver to view the side of the road when park-
ing, for example.

–

Engage reverse gear and press the

button.

Note that the button may need to be pressed
twice, depending on whether it was already
preselected. The button flashes when the door
mirror is angled down. When reverse gear is
disengaged, the door mirror automatically
starts to return after approx. 3 seconds and
then reaches its original position after approx.
8 seconds.

Automatic angling during parking

With this setting, the door mirror is automati-
cally angled down when reverse gear is
selected. The folded position is preset and
cannot be adjusted.

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Mirrors and

Convenience

3. Under

Exterior Mirror Tilt at Reverse

select

Off

Driver

Passenger

Both

activate/deactivate and to select which
review mirror should be angled.

You can make the door mirror return to its
original position by pressing the

button

twice.

Automatic retraction when locking

In the centre display, you can set all the rear-
view and door mirrors to retract/extend auto-
matically when the car is locked/unlocked
using the key.

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Mirrors and

Convenience

3. Select

Fold Mirror When Locked

to acti-

vate/deactivate.

Rearview and door mirrors (p. 171)

If you manually fold the mirrors with the

and

buttons and then lock the car, they

will not fold out automatically when you
unlock the car, even if this setting has been
made. They must be manually folded out.

Only in combination with power seat with memory buttons

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

174

Related information

•

•

Adjusting rearview mirror dimming (p. 171)

•

Storing position for seat, door mirrors and
head-up display

(p. 184)

•

Activating and deactivating the heated
rear window and door mirrors (p. 218)

Sunroof

The sunroof can be opened vertically at the
rear edge (ventilation position) or horizontally
(open position).

The sunroof has a wind deflector. There is
also an inner sunscreen that is closed man-
ually.

The sunroof is operated with a control located
in the roof. The control is activated when the
car's electrical system is in ignition position

WARNING

Children, other passengers or objects may

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the
power supply to the power windows
by setting the car's electrical system in
ignition position

, and then take the

key with you when leaving the car.

•

Never put an object or part of the body
through the windows, even if the car's
electrical system is fully disconnected.

•

Do not open the sunroof when load
carriers are fitted.

•

Do not place any heavy objects on the
sunroof.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

175

Pinch protection for windows and sun
blinds (p. 166)

•

Remove ice and snow before opening
the sunroof. Take care not to scratch
surfaces or damage strips.

•

Do not operate the sunroof if it has fro-
zen closed.

Wind deflector

The sunroof has a wind deflector that is folded
up when the sunroof is in the open position.

Related information

•

Operating the sunroof

(p. 175)

•

•

Keyless locking and unlocking

(p. 270)

•

Locking and unlocking with the remote
control key (p. 242)

Operating the sunroof

When operating with the control that is fitted
in the roof, the sunroof is first opened hori-
zontally to a comfort position.

In ventilation position, the sunroof is raised at
the rear edge.

WARNING

Children, other passengers or objects may

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the
power supply to the power windows
by setting the car's electrical system in
ignition position

, and then take the

key with you when leaving the car.

•

Never put an object or part of the body
through the windows, even if the car's
electrical system is fully disconnected.

•

Do not open the sunroof when load
carriers are fitted.

•

Do not place any heavy objects on the
sunroof.

•

Remove ice and snow before opening
the sunroof. Take care not to scratch
surfaces or damage strips.

•

Do not operate the sunroof if it has fro-
zen closed.

Opening, manual

Opening, automatic

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

176

Closing, manual

Closing, automatic

The movement of the sunroof is stopped if the
control is released during manual operation, or
when the sunroof reaches the comfort posi-
tion or the maximum opening or closing posi-
tion. The movement is also stopped if the con-
trol is operated again while the movement is in
progress.

In order that the sunroof can be operated, the
car's electrical system must be in ignition
position

It can also be operated using a remote control
key or keyless opening

with the door handle.

WARNING

Check that children or other passengers

are not at risk of crushing when all the win-

dows are closed with a remote control key

or keyless opening

with a door handle.

Check that the sunroof is properly closed
when closing.

Manual operation

–

To open the sunroof, press the control
rearward to the position for manual open-
ing. The sunroof first reaches comfort
position.

In order to open to maximum

opening position – press the control back-
wards a second time.

Close the sunroof by repeating the preceding
procedure in reverse order - press the control
forward/downward to the manual closing
position instead.

Automatic operation

–

To open the sunroof, press the control
backwards to the position for automatic
opening and release. The sunroof first rea-
ches comfort position.

To open to the

maximum opening position – press the
control a second time backward to the
position for automatic opening and
release.

Close the sunroof by repeating the preceding
procedure in reverse order - press the control
forward/downward to the automatic closing
position instead.

The sunroof does not stop at comfort position
during closing.

Pinch protection for windows and sun
blinds (p. 166)

It may not be possible to operate windows
at low temperatures.

Ventilation position

Ventilation position, vertically at the rear edge.

Open by pressing the control upward.

Close by pressing the control forward/
downward.

When ventilation position is selected, the sun-
roof is raised at the rear edge.

Sunscreen

The sunroof features a manual, sliding interior
sunscreen. The sunscreen slides back auto-
matically when the sunroof is opened. Grip the

Comfort position is an open position for the sunroof, where wind noise and resonance noise are at a comfortably low level while driving.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

177

handle and slide the sunscreen forward to
close it.

Related information

•

Sunroof

(p. 174)

•

•

Keyless locking and unlocking

(p. 270)

•

Locking and unlocking with the remote
control key (p. 242)

Wiper blades and washer fluid

Together with the washer fluid, the wipers
aim to improve visibility as well as headlamp
pattern.

The washer nozzles are heated

automatically

in cold weather to prevent the washer fluid
from freezing.

Information indicating that the washer fluid
needs topping up appears in the driver display
when there is approx. 1 litre (1 qt) of washer
fluid remaining.

Related information

•

•

Activating and deactivating the rain sen-
sor's memory function (p. 179)

•

•

•

•

•

Using windscreen wipers

The windscreen wipers are designed to clean
the windscreen. Different settings for the
windscreen wipers are set using the right-
hand stalk switch.

Right-hand stalk switch.

The thumbwheel is used to set rain sensor
sensitivity and wiper swipe frequency.

Single sweep

Lower the stalk switch and release to
make one sweep.

Windscreen wipers off

Move the stalk switch to position

switch off the windscreen wipers.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

178

Intermittent wiping

Move the lever up to switch the wipers
to intermittent wiping. Set the number

of sweeps per time unit with the thumbwheel
when intermittent wiping is selected.

Continuous wiping

Raise the stalk switch for the wipers to
sweep at normal speed.

Raise the stalk switch further for the
wipers to sweep at high speed.

Before activating the wipers - ensure that
the wiper blades are not frozen in, and that
any snow or ice on the windscreen is scra-
ped away.

Use plenty of washer fluid when the wipers
are cleaning the windscreen. The wind-
screen must be wet when the windscreen
wipers are operating.

Related information

•

•

•

Activating and deactivating the rain sen-
sor's memory function (p. 179)

•

•

•

•

Using the rain sensor

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen. Rain sensor sen-
sitivity can be adjusted with the thumbwheel
on the right-hand stalk switch.

Right-hand stalk switch.

Rain sensor button

Thumbwheel sensitivity/frequency

When the rain sensor is activated, the rain
sensor symbol

is shown in the driver

display.

Activating the rain sensor

When activating the rain sensor, the car must
be running or in ignition position

while

the windscreen wiper stalk switch is in posi-
tion

or in the position for a single sweep.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

179

Activate the rain sensor by pressing the rain
sensor button

Move the lever down to make the wipers
move.

Turn the thumbwheel upward for higher sensi-
tivity and downward for lower sensitivity. An
extra sweep is made when the thumbwheel is
turned upward.

Deactivating the rain sensor

Deactivate the rain sensor by pressing the rain
sensor button

or moving the stalk

switch up to another wiper program.

The rain sensor is deactivated automatically in
ignition position

or when the engine is

switched off.

The rain sensor is deactivated automatically
when wiper blades are set in service position.
The rain sensor is reactivated when service
mode has been deactivated.

The windscreen wipers could start and be
damaged in an automatic car wash. Deac-
tivate the rain sensor while the car is run-
ning or when the car's electrical system is
in ignition position

. The symbol in the

driver display extinguishes.

Related information

•

•

Activating and deactivating the rain sen-
sor's memory function (p. 179)

•

•

•

•

•

Activating and deactivating the

rain sensor's memory function

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen.

When the memory function is activated, the
rain sensor button does not need to be
pressed every time the vehicle is started:

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Wipers

3. Select

Rain Sensor Memory

to activate/

deactivate the memory function.

Related information

•

•

•

•

•

•

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

180

Using windscreen and headlamp

washers

Windscreen and headlamp washers are
designed to clean the windscreen and head-
lamps. Windscreen and headlamp washers
are started using the right-hand stalk switch.

Starting windscreen and headlamp
washers

Washing function, right-hand stalk switch.

–

Move the right-hand stalk switch toward
the steering wheel to start the windscreen
and headlamp washers.
> The windscreen wipers will make sev-

eral more sweeps once the stalk switch
has been released.

Avoid activating the washer system when
it is frozen or the washer reservoir is
empty, otherwise there is a risk of damag-
ing the pump.

Headlamp washing

To save fluid, the headlamps are washed auto-
matically at a defined interval when the head-
lamps are switched on.

Reduced washing

If only approx. 1 litre (1 qt) of washer fluid
remains in the reservoir and the message

Washer fluid

Level low, refill

, together with

the

symbol, is shown in the driver dis-

play, then the supply of washer fluid to the
headlamps is switched off. This is to prioritise
cleaning the windscreen and the visibility
through it. The headlamps are only washed if
main or dipped beam is switched on.

Related information

•

•

Activating and deactivating the rain sen-
sor's memory function (p. 179)

•

•

•

•

•
