Climate control - sensors (p. 201)

If necessary, the climate control can be
used to cool the media system in the cen-
tre display. In these cases, the message

Climate system

Cooling the

infotainment system

is shown in the

driver display.

Related information

•

Climate zones (p. 200)

•

•

Perceived temperature (p. 202)

•

Controlling the climate control system
using voice control (p. 202)

•

•

•

•

Climate controls (p. 212)

•

Climate zones

The number of climate zones that the car is
divided into governs the options for setting
different temperatures for different parts of
the passenger compartment.

2-zone climate

Climate zones with 2-zone climate.

With 2-zone climate, the temperature in the
passenger compartment can be set separately
for the left and right-hand sides.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

201

4-zone climate

Climate zones with 4-zone climate.

With 4-zone climate the temperature in the
passenger compartment can be set separately
for the left and right-hand sides in both the
front and rear seat.

Related information

•

Climate control - sensors

The climate control system has a number of
sensors to help control the climate in the car.
Do not cover or block the sensors with cloth-
ing or other objects.

Sensor location

Sun sensor - on the upper side of the
instrument panel.
Moisture sensor - in the casing by the
interior rearview mirror.
Temperature sensor for the passenger
compartment - by the physical buttons in
the centre console.
Airborne particulate matter sensor

– on

the underside of the glovebox.
Outside temperature sensor - in the right-
hand door mirror.

With the Interior Air Quality System

there is

also an air quality sensor that is fitted into the
climate control system air intake.

Related information

•

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

202

Perceived temperature

The climate control system regulates the cli-
mate in the passenger compartment based
on the perceived temperature, not on actual
temperature.

The temperature you select in the passenger
compartment corresponds to the physically
perceived temperature as affected by factors
such as the ambient temperature, air speed,
humidity, solar radiation, etc. in and around
the car at the time.

The system includes a sun sensor which
detects on which side the sun is shining into
the passenger compartment. This means that
the temperature can differ between the right
and left-hand side's air vents despite the con-
trols being set for the same temperature on
both sides.

Related information

•

Controlling the climate control

system using voice control

Commands for voice control of the climate
control system in order to e.g. change tem-
perature, activate a heated seat

or change

fan level.

Tap on

and say one of the following com-

mands:

•

Climate

" - starts a dialogue for climate

control and shows examples of com-
mands.

•

Set temperature to X degrees

" - sets

the desired temperature.

•

Raise temperature

"/"

Lower

temperature

" - raise/lower the tempera-

ture setting one step.

•

Sync temperature

" - synchronises the

temperature for all climate zones in the car
with the temperature set for the driver's
side.

•

Air on feet

"/"

Air on body

" - opens the

desired air flow.

•

Air on feet off

"/"

Air on body off

" -

closes the desired air flow.

•

Set fan to max

"/"

Turn off fan

" -

changes the air flow to

Max

Off

•

Raise fan speed

"/"

Lower fan speed

" -

raises/lowers the fan level one step.

•

Turn on auto

" - activates automatic cli-

mate regulation.

•

Air condition on

"/"

Air condition off

" -

activates/deactivates the air conditioning.

•

Recirculation on

"/"

Recirculation off

" -

activates/deactivates the air circulation.

•

Turn on defroster

"/"

Turn off

defroster

" - activates/deactivates defrost-

ing of windows and door mirrors.

•

Turn on max defroster

"/"

Turn max

defroster off

" - activates/deactivates the

max defroster.

•

Turn on electric defroster

"/"

Turn off

electric defroster

" - activates/deacti-

vates the heated windscreen

•

Turn on rear defroster

"/"

Turn off rear

defroster

" - activates/deactivates the

heated rear window and door mirrors.

•

Turn steering wheel heat on

"/"

Turn

steering wheel heat off

" - activates/

deactivates the heated steering wheel

•

Raise steering wheel heat

"/"

Lower

steering wheel heat

" - raises/lowers the

setting for the heated steering wheel

one

step.

•

Turn on seat heat

"/"

Turn off seat heat

- activates/deactivates the heated seat

Applies to certain markets.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

203

•

Raise seat heat

"/"

Lower seat heat

" -

raises/lowers the setting for the heated
seat

one step.

•

Turn on seat ventilation

"/"

Turn off

seat ventilation

" - activates/deactivates

the seat ventilation

•

Raise seat ventilation

"/"

Lower seat

ventilation

" - raises/lowers the setting for

the ventilated seat

one step.

Not all system languages support voice
recognition. The ones that do are high-
lighted with the

symbol in the list of

available system languages. Read more
about where the information can be found
in the section on settings for voice recogni-
tion.

Related information

•

Voice recognition (p. 142)

•

•

Using voice recognition (p. 143)

•

Settings for voice recognition (p. 147)

Air quality

The materials selected for the passenger
compartment and the air cleaning system
ensure that the air quality in the passenger
compartment is high.

Materials in the passenger
compartment

The interior of the passenger compartment is
designed to be pleasant and comfortable,
even for people with contact allergies and for
asthma sufferers.

Tested materials have been developed in order
to reduce the quantity of dust in the passenger
compartment and to contribute to making the
passenger compartment easier to keep clean.

The carpets in both the passenger compart-
ment and the cargo area are removable and
easy to remove and clean.

Use cleaning agents and car care products
recommended by Volvo to clean the interior.

Air cleaning system

In addition to the passenger compartment fil-
ter, the car is equipped with an air cleaning
system that helps to maintain high air quality
in the passenger compartment.

Related information

•

•

•

•

•

Advanced Air Cleaner

(p. 206)

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

204

CleanZone

The CleanZone function checks and indicates
whether or not all conditions have been met
for good air quality in the passenger compart-
ment.

The indicator is visible in the climate view
in the centre display.
The indicator is visible in the climate row
when the climate view is not open.

If the conditions have not been met then the

Clean Zone

text is white. When all conditions

have been met, this is indicated by the text
changing colour to blue.

Conditions that need to be met:

•

That all doors and the boot lid are closed.

•

That all side windows and the sunroof

are

closed.

•

That the air quality system Interior Air
Quality System

is activated.

•

That the ventilation fan is activated.

•

That the air recirculation is deactivated.

CleanZone does not indicate that the air
quality is good. It only indicates that the
conditions for good air quality have been
met.

Related information

•

•

•

•

Clean Zone Interior Package

Clean Zone Interior Package (CZIP) compri-
ses a series of modifications that keep the
passenger compartment even clearer from
allergy and asthma-inducing substances,
among other things.

The following is included:

•

An enhanced fan function that means that
the fan starts when the car is unlocked
with the remote control key. The fan fills
the passenger compartment with fresh air.
The function starts when required and is
disengaged automatically after a time or
when one of the passenger compartment
doors is opened. The amount of time the
fan runs is reduced gradually due to
reduced need up until the car is 4 years
old.

•

The fully automatic air quality system
Interior Air Quality System (IAQS).

Related information

•

•

•

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

205

Interior Air Quality System

Interior Air Quality System (IAQS) is a fully
automatic air quality system that separates
gases and particles to reduce the levels of
odours and contaminants in the passenger
compartment.

IAQS is a part of the Clean Zone Interior
Package (CZIP) and cleans the air in the pas-
senger compartment from contaminants such
as particles, hydrocarbons, nitrous oxides and
ground-level ozone.

If the air quality sensor senses that the outside
air is contaminated, the air intake is closed
and air recirculation is activated.

Activating and deactivating the air quality
sensor

The air quality sensor must always be ena-
bled to ensure the best air in the passenger
compartment.

In a cold climate recirculation is limited so
as to prevent misting.

In the event of misting, the defrost func-
tions for windscreen, side windows and
rear window should be used.

Related information

•

•

•

•

•

Activating and deactivating the air

quality sensor

The air quality sensor is part of the fully auto-
matic air quality system Interior Air Quality
System (IAQS).

It is possible to set whether the air quality sen-
sor should be activated/deactivated.

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

Climate

3. Select

Air Quality Sensor

to activate/

deactivate the air quality sensor.

Related information

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

206

Passenger compartment filter

All air entering the car's passenger compart-
ment is cleaned with a filter.

Replacing the passenger
compartment filter

To maintain high climate system performance,
the filter must be changed at regular intervals.
Follow the Volvo Service Programme for the
recommended replacement intervals. If the car
is used in a severely contaminated environ-
ment, it may be necessary to replace the filter
more often.

There are different types of passenger
compartment filter. Make sure that the cor-
rect filter is fitted.

Related information

•

•

•

•

Advanced Air Cleaner

Advanced Air Cleaner is a fully-automatic air
purifier that collects contaminants in the form
of small airborne particulate matter and
exhaust gases in the passenger compartment
filter, which improves the climate in the pas-
senger compartment.

The function is started automatically when the
fan is started.

Small airborne particulate matter is some-
times called PM

2.5

(particles smaller than 2.5

µm), the content of such particles in the car is
measured by one of the car's climate sensors.
The content in the car is presented in the
downloadable Air Quality app.

Related information

•

•

•

•

•

Climate control - sensors (p. 201)

•

Air distribution

The climate control system distributes the
incoming air via a number of different vents in
the passenger compartment.

Automatic and manual air distribution

With auto-regulated climate running the air
distribution takes place automatically. If nec-
essary, the air distribution can be controlled
manually.

Adjustable air vents

Some of the air vents in the car are adjustable,
which means that you can open/close the vent
to aim the air flow.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

207

Location of adjustable air vents in the passenger

compartment.

With 2-zone climate - four on the instru-
ment panel and one on each of the door
pillars between the front and rear doors.
Addition with 4-zone climate

- two at the

rear of the tunnel console.

Related information

•

Changing air distribution (p. 207)

•

•

Opening, closing and aiming the air vents
(p. 208)

•

Table of air distribution options (p. 209)

Changing air distribution

The air distribution can be changed manually
if required.

1. Open climate view in the centre display by

pressing the symbol in the middle of the
climate row.

The air distribution buttons in the climate view.

Air distribution - windscreen defroster
vents
Air distribution - air vents in instrument
panel and centre console
Air distribution - air vents in the floor

2. Press one or more of the air distribution

buttons in order to open/close the corres-
ponding air flow.
> The air distribution is changed and the

buttons illuminate/extinguish.

Related information

•

Opening, closing and aiming the air vents
(p. 208)

•

•

Table of air distribution options (p. 209)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

208

Opening, closing and aiming the

air vents

Some air vents in the passenger compart-
ment can be opened, closed and aimed indi-
vidually.

If the car's outer vents are aimed at the side
windows then misting can be eliminated.

If the car's outer vents are aimed inwards
then, in a hot climate, a comfortable environ-
ment is obtained in the passenger compart-
ment.

Opening and closing the air vents

Air vents on the instrument panel:

–

Turn the rotary knob in the middle of the
air vent to open/close the air flow from the
vent.

The air flow is at maximum when the
marking on the knob is in vertical position.

Air vents on the door pillars and at the rear of
the tunnel console

–

Roll the thumbwheel under the air vent in
order to open/close the air flow from the
vent.

The longer the white lines on the thumb-
wheel that are visible, the higher the air
flow.

Aiming the air vents

–

Move the lever in the middle of the air vent
horizontally/vertically to direct the air flow
from the vent.

Related information

•

Changing air distribution (p. 207)

•

•

Table of air distribution options (p. 209)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

}}

209

Table of air distribution options

The air distribution can be changed manually
if required. The following options are available
for setting.

Air distribution

Purpose

If all air distribution buttons are deselected in manual mode, the climate control system returns to automatically regulated climate
control.

Main air flow from the defroster vents. Some air flows from other air
vents.

Counteracts misting and icing in a cold and humid cli-
mate (to achieve this, fan level must not be low).

Main air flow from the air vents in the instrument panel. Some air flows
from other air vents.

Provides efficient cooling in a hot climate.

Main air flow from the air vents at the floor. Some air flows from other
air vents.

Provides heat or cooling to the floor.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

210

Air distribution

Purpose

Main air from the defroster vents and air vents in the instrument panel.
Some air flows from other air vents.

Provides good comfort in hot and dry climates.

Main air flow from the defroster vents and air vents at the floor. Some
air flows from other air vents.

Provides good comfort and good demisting in a cold or
humid climate.

Main air flow from the air vents in the instrument panel and air vents at
the floor. Some air flows from other air vents.

Provides good comfort in sunny weather with cool out-
door temperatures.

Main air flow from the defroster vents, from the air vents in the instru-
ment panel and air vents at the floor.

Gives balanced comfort in the passenger compart-
ment.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

211

Related information

•
