WINDOWS, GLASS AND MIRRORS

180

Intermittent wiping

Move the lever up to switch the wipers
to intermittent wiping. Set the number

of sweeps per time unit with the thumbwheel
when intermittent wiping is selected.

Continuous wiping

Raise the stalk switch for the wipers to
sweep at normal speed.

Raise the stalk switch further for the
wipers to sweep at high speed.

IMPORTANT

Before activating the wipers - ensure that
the wiper blades are not frozen in, and that
any snow or ice on the windscreen is scra-
ped away.

IMPORTANT

Use plenty of washer fluid when the wipers
are cleaning the windscreen. The wind-
screen must be wet when the windscreen
wipers are operating.

Related information

•

Using the rain sensor (p. 180)

•

Using windscreen and headlamp washers
(p. 182)

•

Wiper blades and washer fluid (p. 179)

•

Activating and deactivating the rain sen-
sor's memory function (p. 181)

•

Filling washer fluid (p. 661)

•

Set the wiper blades in service position
(p. 660)

•

Replacing windscreen wiper blades
(p. 659)

Using the rain sensor

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen. Rain sensor sen-
sitivity can be adjusted with the thumbwheel
on the right-hand stalk switch.

Right-hand stalk switch.

Rain sensor button

Thumbwheel sensitivity/frequency

When the rain sensor is activated, the rain
sensor symbol

 is shown in the driver

display.

Activating the rain sensor

When activating the rain sensor, the car must
be running or in ignition position

I

 or

II

 while

the windscreen wiper stalk switch is in posi-
tion

0

 or in the position for a single sweep.

WINDOWS, GLASS AND MIRRORS

181

Activate the rain sensor by pressing the rain
sensor button

.

Move the lever down to make the wipers
move.

Turn the thumbwheel upward for higher sensi-
tivity and downward for lower sensitivity. An
extra sweep is made when the thumbwheel is
turned upward.

Deactivating the rain sensor

Deactivate the rain sensor by pressing the rain
sensor button

 or moving the stalk

switch up to another wiper program.

The rain sensor is deactivated automatically in
ignition position

0

 or when the engine is

switched off.

The rain sensor is deactivated automatically
when wiper blades are set in service position.
The rain sensor is reactivated when service
mode has been deactivated.

IMPORTANT

The windscreen wipers could start and be
damaged in an automatic car wash. Deac-
tivate the rain sensor while the car is run-
ning or when the car's electrical system is
in ignition position

I

 or

II

. The symbol in the

driver display extinguishes.

Related information

•

Using windscreen and headlamp washers
(p. 182)

•

Wiper blades and washer fluid (p. 179)

•

Activating and deactivating the rain sen-
sor's memory function (p. 181)

•

Filling washer fluid (p. 661)

•

Set the wiper blades in service position
(p. 660)

•

Replacing windscreen wiper blades
(p. 659)

•

Using windscreen wipers (p. 179)

Activating and deactivating the

rain sensor's memory function

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen.

When the memory function is activated, the
rain sensor button does not need to be
pressed every time the vehicle is started:

1. Tap on

Settings

 in the centre display's

top view.

2. Press

My Car

Wipers

.

3. Select

Rain Sensor Memory

 to activate/

deactivate the memory function.

Related information

•

Using the rain sensor (p. 180)

•

Using windscreen and headlamp washers
(p. 182)

•

Wiper blades and washer fluid (p. 179)

•

Filling washer fluid (p. 661)

•

Set the wiper blades in service position
(p. 660)

•

Replacing windscreen wiper blades
(p. 659)

•

Using windscreen wipers (p. 179)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

182

Using windscreen and headlamp

washers

Windscreen and headlamp washers are
designed to clean the windscreen and head-
lamps. Windscreen and headlamp washers
are started using the right-hand stalk switch.

Starting windscreen and headlamp
washers

Washing function, right-hand stalk switch.

–

Move the right-hand stalk switch toward
the steering wheel to start the windscreen
and headlamp washers.
> The windscreen wipers will make sev-

eral more sweeps once the stalk switch
has been released.

IMPORTANT

Avoid activating the washer system when
it is frozen or the washer reservoir is
empty, otherwise there is a risk of damag-
ing the pump.

Headlamp washing

*

To save fluid, the headlamps are washed auto-
matically at a defined interval when the head-
lamps are switched on.

Reduced washing

If only approx. 1 litre (1 qt) of washer fluid
remains in the reservoir and the message

Washer fluid



Level low, refill

, together with

the

 symbol, is shown in the driver dis-

play, then the supply of washer fluid to the
headlamps is switched off. This is to prioritise
cleaning the windscreen and the visibility
through it. The headlamps are only washed if
main or dipped beam is switched on.

Related information

•

Using the rain sensor (p. 180)

•

Wiper blades and washer fluid (p. 179)

•

Activating and deactivating the rain sen-
sor's memory function (p. 181)

•

Filling washer fluid (p. 661)

•

Set the wiper blades in service position
(p. 660)

•

Replacing windscreen wiper blades
(p. 659)

•

Using windscreen wipers (p. 179)

SEATS AND STEERING WHEEL

* Option/accessory.

184

Manual front seat

The car's front seats have a range of setting
options in order to enhance comfort.

Raise/lower the front edge of the seat
cushion

*

 by pumping up/down.

1

Change the length

*

 of the seat cushion by

pulling the lever up and moving the seat
cushion forward/backward by hand.
Adjust the seat forward/backward by lift-
ing the handle and adjusting the distance
to the steering wheel and pedals. Check
that the seat is locked after the position
has been adjusted.
Change the lumbar support

*

 by pressing

the button upward/downward/forward/
back.

2

Raise/lower the seat by means of adjust-
ing the control up/down.
Change the backrest inclination by turning
the control knob.

WARNING

Adjust the position of the driver's seat

before setting off, never while driving.

Make sure that the seat is in locked posi-

tion in order to avoid personal injury in the

event of heavy braking or an accident.

Related information

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

1

Only applies to the driver's seat.

2

Applicable to four-way lumbar support

*

. Two-way lumbar support

*

 is adjusted forwards/backwards.

SEATS AND STEERING WHEEL

}}

* Option/accessory.

185

Power

*

 front seat

The car's front seats have a range of setting
options in order to enhance comfort. The
power seat can be moved forwards/back-
wards and upwards/downwards. The front
edge of the seat cushion can be raised/
lowered as well as adjusted in length

*

 and the

backrest inclination can be changed. The
lumbar support

*

 can be adjusted upward/

downward/forward/backward.

3

Seat setup can take place when the engine is
running and within a certain time after unlock-
ing the door without the engine running.
Adjustment can also be performed within a
certain time after the engine has been
switched off.

IMPORTANT

The power seats have overload protection
that is triggered if any seat is blocked by an
object. If this happens, remove the object
and then move the seat again.

Related information

•

Manual front seat (p. 184)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

Adjusting the power

*

 front seat

Set the preferred seat position using the con-
trol on the front seat's seating section. To set
the various comfort functions, turn the multi-
function control

4

 up/down.

The illustration shows the controls from a car with
four-way lumbar support

*

. Cars with two-way lumbar

support

*

 do not have the rotatable multifunction con-

trol.

In cars with four-way lumbar support

*

,

turn the multifunction control

4

 up/down to

set the different comfort functions. In cars
with two-way lumbar support

*

, use the

round button to adjust the lumbar support
forward/backward.
Raise/lower the seat cushion front edge
by adjusting the control up/down.

3

Applicable to four-way lumbar support

*

. Two-way lumbar support

*

 is adjusted forwards/backwards.

4

Not available in cars with two-way lumbar support

*

.

||

SEATS AND STEERING WHEEL

* Option/accessory.

186

Raise/lower the seat by means of adjust-
ing the control up/down.
Move the seat forward/backward by
adjusting the control forward/backward.
Change the backrest inclination by adjust-
ing the control forward/backward.

Only one movement (forward/back/up/down)
can be made at a time.

The backrests of the front seats cannot be
lowered fully forward.

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

Storing position for seat, door

mirrors and head-up display

*

You can store the position for power

*

 seat,

door mirrors and head-up display

*

 in the

memory buttons.

Store two different positions for the power

*

seat, the door mirrors and the head-up dis-
play

*

 using the memory buttons. The buttons

are located on the inside of one of the front
doors or both

*

.

Button

M

 for storing settings.

Memory button.

Memory button.

Storing a position

1. Adjust seat, door mirrors and head-up dis-

play to the desired position.

SEATS AND STEERING WHEEL

}}

* Option/accessory.

187

2. Press and hold the

M

 button depressed.

The light indicator in the button illumi-
nates.

3. Within three seconds, press and hold the

1

or

2

 button.

> When the position has been stored in

the selected memory button, an acous-
tic signal can be heard and the light
indicator in the

M

 button extinguishes.

If none of the memory buttons is depressed
within three seconds then the

M

 button extin-

guishes and no storing takes place.

The seat, the door mirrors or the head-up-dis-
play must be readjusted before a new memory
can be set.

NOTE

All driver profiles need to be set in

Protect

Profile

 mode in order for the stored posi-

tions to work.

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

•

Angling adjustment of the door mirrors
(p. 174)

•

Settings for head-up display

*

 (p. 141)

•

Protect driver profile (p. 135)

Using a stored position for seat,

door mirrors and head-up display

*

If the positions for the power

*

 seat, the door

mirrors and the head-up display

*

 have been

stored, they can be activated by using the
memory buttons.

Using a stored setting

A stored setting can be used with the front
door either open or closed:

Open front door

–

Depress one of the memory buttons

1

 (

)

or

2

 (

) with a short press. Power seat,

door mirrors and head-up display move
and then stop at the positions stored in
the selected memory button.

||

SEATS AND STEERING WHEEL

* Option/accessory.

188

Closed front door

–

Hold one of the memory buttons

1

 (

) or

2

 (

) depressed until seat, door mirrors

and head-up display stop in the positions
that are stored in the selected memory
button.

If the memory button is released, the move-
ment of the seat, door mirrors and head-up
display will be stopped.

WARNING

•

Because the driver's seat can be
adjusted with the ignition off, children
should never be left unattended in the
vehicle.

•

Movement of the seat can be STOP-
PED at any time by pressing any but-
ton on the power seat control panel.

•

Do not adjust the seat while driving.

•

Make sure there is nothing under the
seats when they are being adjusted.

NOTE

All driver profiles need to be set in

Protect

Profile

 mode in order for the stored posi-

tions to work.

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

•

Angling adjustment of the door mirrors
(p. 174)

•

Settings for head-up display

*

 (p. 141)

Massage settings

*

 in the front seat

Both the multi-function control on the side of
the seat and the centre display can be used in
order to change the settings. The range of
settings is shown in the centre display.

Multi-function control, located on the side of the

seat's seating section.

Settings for massage

The following setting options are available for
massage:

•

On

/

Off

: Select

On

/

Off

 in order to switch

on/off the massage function.

•

Programs 1-5

: There are 5 preset mas-

sage programs. Select between

Swell

,

Tread

,

Advanced

,

Lumbar

 and

Shoulder

.

SEATS AND STEERING WHEEL

}}

* Option/accessory.

189

•

Intensity

: Select between

Low

,

Normal

and

High

.

•

Speed

: Select between

Slow

,

Normal

and

Fast

.

Restarting massage

The massage function is deactivated automat-
ically after 20 minutes. Reactivation of the
function is performed manually.

–

Tap on

Restart

, which is shown in the

centre display, to restart the selected mas-
sage program.
> The massage program restarts. If no

action is taken, the message remains
shown in the top view.

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

Adjusting massage settings

*

 in the

front seat

Both the multi-function control on the seat
and the centre display can be used in order to
change the settings. The range of settings is
shown in the centre display.

Adjusting massage settings in the
front seat

The front seat has massage in the backrest.
The massage is performed by air cushions that
can massage with different settings.

The massage function can only be activated
when the car's engine is running.

1. Activate the multi-function control by turn-

ing the control

 upwards/downwards.

The seat settings view will be shown in
the centre display.

||

SEATS AND STEERING WHEEL

* Option/accessory.

190

2. Select

Massage

 in the seat settings view.

3. To choose between the different massage

functions, select either directly in the cen-
tre display or by moving the cursor up/
down using the multi-function control's
upper

 /lower

 button. Change the

setting in the selected function directly in
the centre display, by pressing the arrows,
or by using the multi-function control's
front

/rear

 button.

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

Adjusting

*

 the length of the seat

cushion in the front seat

Depending on equipment level selected, seat
cushion length is adjusted either using the
multifunction control

*

 on the side of the

seat's seat cushion, or manually using a con-
trol on the front of the seat cushion.

Adjusting the length of the seat
cushion using the multifunction
control

Multifunction control, located on the side of the seat

cushion.

1. Activate the multi-function control by turn-

ing the control

 upwards/downwards.

The seat settings view will be shown in
the centre display.

2. Select

Cushion extension

 in the seat set-

tings view.

•

Press the front section of the four-way
button

 to extend the seat cushion.

•

Press the rear section of the four-way
button

 to retract the seat cushion.

Adjusting the length of the seat
cushion manually

Control for seat cushion adjustment.

1. Grip the handle

 on the front of the seat

and pull upwards.

2. Adjust the length of the seat cushion.

3. Release the handle and make sure that the

seat cushion has reached the correct posi-
tion.

SEATS AND STEERING WHEEL

* Option/accessory.

191

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

Adjusting the side support

*

 in the

front seat

Increase comfort in the front seat by adjust-
ing the sides of the backrest.

Multi-function button, located on the side of the seat

base section.

The sides of the backrest can be adjusted to
provide side support. Both the multi-function
control on the seat and the centre display can
be used in order to change the settings. The
range of settings is shown in the centre dis-
play.

To adjust the side support:

1. Activate the multi-function control by turn-

ing the it up/down

. The seat settings

view will be shown in the centre display.

2. Select

Side bolsters

 in the seat settings

view.

•

Press the front section of the four-way
button to increase side support

.

•

Press the rear section of the four-way
button to decrease side support

.

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

SEATS AND STEERING WHEEL

* Option/accessory.

192

Adjusting the lumbar support

*

 in

the front seat

The lumbar support is adjusted using a con-
trol on the side of the seat cushion.

Multifunction control in cars with four-way lumbar
support

*

.

Control in cars with two-way lumbar support

*

.

The lumbar support is adjusted using the mul-
tifunction control in cars with four-way lumbar
support

*

, or using the round button in cars

with two-way lumbar support

*

. The control is

located on the side of the seat's seating sec-
tion. Depending on the equipment level
selected, the lumbar support can be adjusted
forward/back and up/down (four-way lumbar
support) or forward/back (two-way lumbar
support).

Adjust the lumbar support in the car
using the four-way lumbar support

1. Activate the multi-function control by turn-

ing the control

 upwards/downwards.

The seat settings view will be shown in
the centre display.

2. Select

Lumbar

 in the seat settings view.

•

Press the round button up

/down

to move the lumbar support upwards/
downwards.

•

Press the front section

 of the button

to increase lumbar support.

•

Press the rear section

 of the button

to decrease lumbar support.

Adjust the lumbar support in the car
using the two-way lumbar support

1. Press the front section

 of the round

button to increase lumbar support.

2. Press the rear section

 of the round but-

ton to decrease lumbar support.

SEATS AND STEERING WHEEL

}}

* Option/accessory.

193

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 193)

Adjusting the passenger seat from

the driver's seat

*

The front passenger seat can be adjusted
from the driver's seat.

Activating the function

The function is activated via the function view
in the centre display:

Press the

Adjust Passenger

Seat

 button to activate.

Adjust passenger seat

From activation of the function, the driver
must adjust the passenger seat within 10 sec-
onds. If no adjustment is made within this
time the function is deactivated.

The driver adjusts the passenger seat using
the controls on the driver's seat:

Move the passenger seat forward/back-
ward by adjusting the control forward/
backward.
Change the passenger seat's backrest
inclination by adjusting the control for-
ward/backward.

Related information

•

Manual front seat (p. 184)

•

Power

*

 front seat (p. 185)

•

Adjusting the power

*

 front seat (p. 185)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 186)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 187)

•

Adjusting massage settings

*

 in the front

seat (p. 189)

SEATS AND STEERING WHEEL

* Option/accessory.

194

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 190)

•

Massage settings

*

 in the front seat

(p. 188)

•

Adjusting the side support

*

 in the front

seat (p. 191)

•

Adjusting the lumbar support

*

 in the front

seat (p. 192)

Lowering the backrests in the rear

seat

*

The rear seat's backrest is divided into two
parts. The two parts can be folded forward
individually.

WARNING

•

Adjust the seat and fix it before driving
away. Take care when adjusting the
seat. Uncontrolled or careless adjust-
ment can lead to trapping injuries.

•

When loading long objects, they must
always be strapped in securely to avoid
injury and damage during sudden brak-
ing.

•

Always switch off the engine and apply
the parking brake when loading and
unloading the car.

•

For cars with automatic gearbox, set
the gear selector in

P

 to prevent it from

being moved by mistake.

IMPORTANT

There must be no objects on the rear seat
when the backrest is to be folded down.
The seat belts must not be connected
either. Otherwise there is a risk of damag-
ing the rear seat upholstery.

IMPORTANT

The seat cushion on the integrated child
seat

*

 must be in the lowered position

before lowering the rear seat backrest.

The armrest

*

 for the centre seat must be

raised before lowering the seat.

Through-load hatch

*

 in the rear seat must

be closed before lowering.

NOTE

When private locking is activated, the rear
seat must be in upright position for locking
to work. With the rear seat in lowered
position, locking will not work.

NOTE

The front seats may need to be pushed for-
wards, and/or the backrests adjusted
upwards, in order that the rear backrests
can be fully folded forward.

Lowering the backrest

To facilitate folding of the rear seat, the car
must be stationary and at least one rear door
open.

SEATS AND STEERING WHEEL

}}

* Option/accessory.

195

Buttons for seat folding, located on the upper section

of the rear seat.

1. Ensure that there are no occupants or

objects in the rear seat.

2. Lower the centre seat's head restraint

manually.

3. Press and hold one of the buttons located

in the parcel shelf on the left-hand side of
the car.

4. The seat is released from the lock but

remains in the same position. The head
restraints are lowered automatically.

5. Lower the backrest manually to the hori-

zontal position.

Raising the backrest

Raising the backrest to upright position is car-
ried out manually:

1. Move the backrest up/back.

2. Press the backrest until the lock engages.

3. Raise the head restraints manually.

4. If necessary, raise the centre seat's head

restraint.

WARNING

Check that the backrests and head

restraints in the rear seat are locked prop-

erly after being folded up.
The head restraints of the outer seats must

always be raised when there are passen-

gers on any of the rear seats.

Related information

•

Adjusting the head restraints in the rear
seat (p. 195)

•

Private locking (p. 283)

•

Activating and deactivating private locking
(p. 283)

Adjusting the head restraints in the

rear seat

Adjust the centre seat head restraint accord-
ing to the height of the passenger. Fold down
the outer seat head restraints

*

 to improve

rearward visibility.

Adjust the head restraint for the
centre seat

The centre seat's head restraint must be
adjusted according to the passenger's height
so that, if possible, the whole of the back of
the head is covered. Slide it up manually as
required.

||

SEATS AND STEERING WHEEL

* Option/accessory.

196

To lower the head restraint, the button (see
illustration) must be depressed while the
restraint is carefully moved down.

WARNING

The centre seat head restraint must be in

its lowest position when the centre seat is

not used. When the centre seat is used, the

head restraint must be correctly adjusted

to the height of the passenger so that it

covers the whole of the back of the head if

possible.

Fold down the rear seat's outer head
restraints via the centre display

*

The outer head restraints can be retracted via
the centre display's function view. You can
lower the head restraints in ignition position

0

.

Press the

Headrest Fold

button to activate/deactivate
lowering.

Move the head restraint back manually until a
click is heard.

WARNING

Do not lower the outer head restraints if

there are passengers in any of the outer

rear seats.

WARNING

The head restraint must be in locked posi-

tion after being folded up.

Related information

•

Lowering the backrests in the rear seat

*

(p. 194)
