MAINTENANCE AND SERVICE
}}
* Option/accessory.
581
WARNING
•
Apply the parking brake and put the
gear selector in the Park (
P
) position.
•
Block the wheels standing on the
ground, use rigid wooden blocks or
large stones.
•
Check that the jack is not damaged,
the threads are properly lubricated and
it is free from dirt.
•
Be sure the jack is on a firm, level, non-
slippery surface and that it is upright
and not leaning.
•
The jack must correctly engage in the
jack attachment.
•
No objects should be placed between
the base of the jack and the ground, or
between the jack and the attachment
bar on the vehicle.
•
Never let anyone remain in the vehicle
when it is raised on a jack.
•
If a tire must be changed near passing
traffic, make sure all passengers move
to a safe location.
•
Use a jack intended for the vehicle
when changing a tire. For any other
job, use stands to support the vehicle.
•
Never crawl under or allow any part of
your body to be extended under a vehi-
cle supported by a jack.
WARNING
If the vehicle is lifted on a garage jack, the
jack must be placed under one of the four
lifting points. Make sure that the vehicle is
correctly positioned on the jack and that it
cannot slide off. Make sure the jack plate
has a rubber pad to help keep the vehicle
stable and prevent damage. Always use
axle stands or similar.
When not in use, the jack
*
should be kept in
its storage compartment under the cargo
compartment floor.
Read through all instructions before starting.
Before raising the vehicle using a jack or lift,
take out all the tools you will need.
1. Turn on the vehicle's hazard warning
flashers if e.g. a wheel change must be
performed in an area with traffic.
2. Apply the parking brake and put the gear
selector in
P
, or first gear if the vehicle has
a manual transmission.
If the vehicle is equipped with
Leveling
Control
*
, this feature must be turned off
before the vehicle is lifted onto a tow
truck.
3. Place chocks in front of and behind the
wheels that are still on the ground. For
example, use heavy wooden blocks or
large stones.
4. Position the jack or garage lift arms at the
designated points under the vehicle. The
triangle markings on the plastic cover indi-
cate where the jack attachment points/lift-
ing points are located. There are two jack
attachment points on each side of the
vehicle. There is a groove for the jack at
each attachment point.
5. Position the jack under the attachment
point being used, ensuring that the sur-
face is firm, flat and not slippery.
