KEY, LOCKS AND ALARM

}}

* Option/accessory.

245

Care Key limitations

The key is linked to a specific Care Key driver
profile, and when it is active the key's settings
cannot be changed. It is also not possible to
switch to another driver profile, as this
requires a regular remote key.

The driver profile is activated when the vehicle
is unlocked using a Care Key without a regular
remote key nearby.

NOTE

If the vehicle changes owners, the vehicle
must be locked and then unlocked for a
new driver profile to be activated.

Setting options

The following limitations are available:

•

speed range: 50-180 km/h (30-112 mph)

•

Increments: 1 km/h (1 mph)

Symbol

Meaning

Speed limitation is active.

Related information

•

Care Key settings (p. 245)

•

Remote key (p. 234)

Care Key settings

Change maximum speed for a Care Key via
the center display.

1. Unlock the vehicle using a regular remote

key.

2. Tap

Settings

 in the center display's Top

view.

3. Tap

System

Driver Profiles

Care

Key

.

4. Adjust desired settings.

Related information

•

Care Key – restricted remote key (p. 244)

Detachable key blade

The remote key contains a detachable metal
key blade that can be used to activate a num-
ber of functions and preform certain actions.

A Volvo workshop can provide you with the
key blade's unique code, which is recom-
mended in case you need to order a new key
blade.

Using the detachable key blade

The detachable key blade can be used to

•

manually open the left-side front door if
central locking cannot be activated with
the remote key

•

emergency lock all doors

•

activate/deactivate the rear door mechani-
cal child locks.

The button-less key

8

 does not have a detacha-

ble key blade. If needed, use the standard
remote key's detachable key blade.

8

Included in vehicles equipped with keyless locking/unlocking

*

.

||

KEY, LOCKS AND ALARM

246

Detaching the key blade

 Hold the remote key with the front side

(with the Volvo logo) facing up and move
the button on the key ring section to the
right. Slide the front cover slightly upward.

 The cover will loosen and can be

removed from the key.

 Remove the key blade by pulling it up.

Put the key blade back into its designated
spot in the remote key after use.

 Replace the cover by pressing it down

until it clicks into place.

 Slide the cover back.

> An additional click indicates that the

cover is correctly in place.

Related information

•

Locking and unlocking with detachable
key blade (p. 246)

•

Remote key (p. 234)

Locking and unlocking with

detachable key blade

The detachable key blade can be used to
unlock the vehicle from the outside, e.g. if the
battery in the remote key is discharged.

Unlocking

Pull the front left-hand door handle to its
end position to access the lock cylinder.

Put the key in the lock cylinder.

Turn the key clockwise 45 degrees so that
the key blade is pointing straight rear-
ward.

Turn the key blade back 45 degrees to its
original position. Remove the key from the
lock cylinder and release the handle so
that it returns to its original position
against the vehicle.

5. Pull the door handle.

> The door will open.

KEY, LOCKS AND ALARM

* Option/accessory.

247

NOTE

When the door is unlocked using the
detachable key blade and then opened, the
alarm will be triggered. The alarm must be
deactivated manually; see separate sec-
tion.

Locking

The left-hand front door can be locked by
inserting the detachable key into the door's
lock cylinder.

The other doors have lock mechanisms in the
side of the door that must be pushed in using
the key blade. The door will then be locked
mechanically and cannot be opened from the
outside.

The doors can still be opened from inside.

Manual door lock. This is not the child lock.

1. Remove the detachable key blade from

the remote key.

2. Insert the key blade into the opening for

the lock mechanism.

3. Push in the key until it stops, about 12 mm

(0.5 inch).

The door can be opened from both the
outside and the inside.
The door cannot be opened from the out-
side. To return to position A, open the door
using the inside door handle.

NOTE

•

The door's lock controls only lock that
specific door, not all doors simultane-
ously.

•

A manually locked rear door with acti-
vated child lock cannot be opened
from either the outside or the inside.
The door can only be unlocked using
the buttons on the key, the central
locking button, the keyless locking sys-
tem

*

 or Volvo On Call.

Related information

•

Detachable key blade (p. 245)

•

Arming and disarming the alarm (p. 262)

•

Starting the vehicle (p. 408)

•

Replacing the remote key's battery
(p. 240)

•

Remote key (p. 234)

KEY, LOCKS AND ALARM

* Option/accessory.

248

Electronic immobilizer

The electronic immobilizer is a start inhibitor
that helps prevent the vehicle from being
started by an unauthorized person.

The vehicle can only be started with the right
remote key.

The following instrument panel error mes-
sages are related to the electronic immobil-
izer:

Symbol Message

Meaning

Vehicle key
not found

See
Owner's
manual

Remote key not
recognized dur-
ing start. Place
the remote key
on the key sym-
bol in the cup
holder and try to
start the vehicle
again.

Remote immobilizer with tracking
system

9

The vehicle is equipped with a system that
makes it possible to track and locate the vehi-
cle and to remotely activate the immobilizer to
prevent the vehicle from being started. Con-
tact your nearest Volvo retailer for more infor-
mation and assistance activating the system.

The following instrument panel error mes-
sages are related to the remote immobilizer
with tracking system:

Symbol Message

Meaning

Remotely
immobilised

Vehicle not
possible to
start

The remote
immobilizer with
tracking system
is activated. The
vehicle cannot
be started. Con-
tact Volvo On
Call Service
Center.

Related information

•

Remote key (p. 234)

•

Ordering additional remote keys (p. 244)

Start and lock system type

designations

The following information contains type des-
ignations for the start and lock system.

Alarm system

USA FCC ID: MAYDA 5823(3)

This device complies with part 15 of the FCC
rules. Operation is subject to the following
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired opera-
tion.

Canada IC: 4405A-DA 5823(3)

This device is subject to the following condi-
tions: (1) This device may not cause interfer-
ence, and (2) this device must accept any
interference, including interference that may
cause undesired operation of the device.

Remote keys (Passive Entry

*

/Passive

Start)

USA

Volvo Standard Key FCC ID: YGO-
HUF8423MS

Volvo Tag ID FCC ID: YGOHUF8432MS

9

Only certain markets and in combination with Volvo On Call.

KEY, LOCKS AND ALARM

* Option/accessory.

249

This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:

(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

CAUTION: Changes or modifications not
expressly approved by the party responsible
for compliance could void the user’s authority
to operate the equipment.

Canada

Volvo Standard Key IC: 4008C-HUF8423MS

Volvo Tag ID IC: 4008C-HUF8432MS

This device complies with part 15 of the FCC
Rules and Industry Canada license-exempt
RSS standard(s). Operation is subject to the
following two conditions:

(1) This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :

(1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre
le fonctionnement.

Immobilizer and Passive Entry

*

/

Passive Start systems

USA-FCC ID: LTQVO3134

This device complies with part 15 of the FCC
rules. Operation is subject to the following
two conditions:

(1) This device may not cause harmful interfer-
ence, and

(2) this device must accept any interference
received, including interference that may
cause undesired operation.

Any changes or modification not expressly
approved by the party responsible for compli-
ance could void the user's authority to operate
this equipment.

Canada-IC:3659A-VO3134

This device complies with Industry Canada
license-exempt RSS standards. Operation is
subject to the following two conditions:

(1) This device may not cause harmful interfer-
ence, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.

Related information

•

Remote key (p. 234)

KEY, LOCKS AND ALARM

* Option/accessory.

250

Keyless and touch-sensitive

surfaces

*

With the keyless locking and unlocking func-
tion, the remote key only needs to be within
range, e.g. in a pocket or bag. The vehicle can
then be locked or unlocked by touching the
pressure-sensitive surface on the door han-
dle.

Pressure-sensitive surfaces

Door handle

There are indentations on the outside of the
outer door handles for locking, and pressure-
sensitive surfaces on the inside of the handles
for unlocking.

Pressure-sensitive indentation for locking

Pressure-sensitive surface for unlocking

NOTE

It is important that only one pressure-sen-
sitive surface is activated at a time. If the
handle is grasped at the same time as the
lock area is pressed, there is a risk that
double commands may be sent. This may
cause the requested action (locking/
unlocking) to be delayed or not performed
at all.

Trunk lid handle

The trunk lid handle has a rubberized pressure
plate that can only be used for unlocking.

NOTE

Please be aware that the system could be
activated in a car wash if the remote key is
within range.

Related information

•

Keyless locking and unlocking

*

 (p. 251)

•

Keyless unlocking of the trunk lid

*

(p. 252)

KEY, LOCKS AND ALARM

}}

* Option/accessory.

251

Keyless locking and unlocking

*

With keyless locking and unlocking, touching
the pressure-sensitive indentation on the
door handle will lock or unlock the vehicle.

NOTE

One of the vehicle's remote keys must be
within range for locking and unlocking to
be possible.

Pressure-sensitive indentation for locking

Pressure-sensitive surface for unlocking

NOTE

Please be aware that the system could be
activated in a car wash if the remote key is
within range.

Keyless locking

All of the doors have to be closed before the
vehicle can be locked. However, the trunk lid
can be open when a door handle is used for
locking.

–

Touch the marked area on the outside of
one of the door handles after the door is
closed.
> The lock indicator light on the dash-

board will flash to confirm that the vehi-
cle is locked.

To close all door windows at the same time -
place your finger on the pressure-sensitive
indentation on the outside of the door handle
and hold it there until the side windows have
closed.

Locking when the trunk lid is open

If the vehicle is locked and the trunk lid is still
open, make sure that the remote key is not left
in the trunk when the trunk lid is closed.

NOTE

If the key is detected in the vehicle, the
trunk lid will not lock when it is closed.

Keyless unlocking

–

To unlock, grasp a door handle or lightly
press the rubberized button on the under-
side of the trunk lid handle.
> The lock indicator light on the dash-

board will stop flashing to confirm that
the vehicle is unlocked.

The rubberized button on the trunk lid can only be

used for unlocking.

Automatic relocking

If none of the doors or trunk lid are opened
within two minutes after being unlocked, they
will automatically relock. This function reduces
the risk of inadvertently leaving the vehicle
unlocked.

||

KEY, LOCKS AND ALARM

* Option/accessory.

252

Related information

•

Keyless unlock settings

*

 (p. 252)

•

Keyless unlocking of the trunk lid

*

 (p. 252)

•

Keyless and touch-sensitive surfaces

*

(p. 250)

Keyless unlock settings

*

Several different sequences are available for
keyless unlocking.

To change this setting:

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Locking

Keyless

Unlock

.

3. Select alternative:

•

All Doors

 – unlocks all doors at the

same time.

•

Single Door

 – unlocks the selected

door.

Related information

•

Keyless locking and unlocking

*

 (p. 251)

•

Keyless and touch-sensitive surfaces

*

(p. 250)

Keyless unlocking of the trunk lid

*

With keyless locking and unlocking, the trunk
can be unlocked by lightly touching the rub-
berized button on the trunk lid handle.

NOTE

One of the vehicle's remote keys must be
within range behind the vehicle for unlock-
ing to be possible.

The trunk lid is held closed by an electronic
locking mechanism.

To open:

1. Lightly press the rubberized pressure plate

on the underside of the trunk lid handle.
> The lock will disengage.

KEY, LOCKS AND ALARM

* Option/accessory.

253

2. Lift the outer handle to open the trunk lid.

CAUTION

•

Only light pressure on the rubberized
pressure plate is necessary to release
the trunk lid's locking mechanism.

•

Use the handle to lift the trunk lid and
do not apply force to the rubberized
pressure plate. Too much force can
damage the pressure plate's electrical
connections.

Hands-free opening of the trunk lid is also
possible by making a kicking motion under the
rear bumper; see the separate section.

WARNING

Do not drive with the trunk lid open. Toxic

exhaust fumes can be sucked into the vehi-

cle through the trunk.

Related information

•

Operating the trunk lid with a foot move-
ment

*

 (p. 258)

•

Keyless and touch-sensitive surfaces

*

(p. 250)

•

Remote key range (p. 239)

Antenna locations for the start and

lock system

The antennas for the keyless start system and
keyless locking system

*

 are integrated in the

vehicle.

Location of the antennas:

Under the cup holder in the front section
of the tunnel console
In the upper front section of the left-side
rear door

10

In the upper front section of the right-side
rear door

10

In the trunk

10

WARNING

Individuals with an implanted pacemaker

should not allow the pacemaker to come

closer than 22 cm (9 in.) to the Keyless

system antennas. The aim of this is to pre-

vent disturbances between the pacemaker

and the Keyless system.

Related information

•

Keyless and touch-sensitive surfaces

*

(p. 250)

•

Remote key range (p. 239)

10

Only in vehicles equipped with keyless locking and unlocking

*

.

KEY, LOCKS AND ALARM

* Option/accessory.

254

Locking and unlocking from inside

the vehicle

The doors and trunk lid can be locked and
unlocked from inside the vehicle using the
central lock buttons in the front doors.

Central locking

Button with indicator light for locking and unlocking

in front door.

Unlocking using the front door buttons

–

Press the

 button to unlock all side

doors and the trunk lid.

Alternative unlocking method

Alternative unlocking method using side door open-
ing handle

11

.

–

Pull either of the side door inside opening
handles and release.
> Depending on the remote key settings,

either all doors will be unlocked or just
the selected door will be unlocked and
opened.

To change this setting, tap

Settings

My Car

Locking

Remote and

Interior Unlock

 in the Top view of the

center display.

Locking using the front door buttons

–

Press the

 button (both front doors

must be closed).
> All doors and the trunk lid will lock.

Locking using the rear door button

*

Button with indicator light for locking/unlocking in

rear door.

The lock buttons in the rear doors lock/unlock
that particular door.

Unlocking the rear door

1. Pull the opening handle to unlock the rear

door.

2. Pull the opening handle again to open the

rear door

12

.

11

The illustration is generic - details may vary according to vehicle model.

12

If the child lock is not activated.

KEY, LOCKS AND ALARM

}}

255

Related information

•

Settings for remote and inside door unlock
(p. 238)

•

Unlocking the trunk lid from inside the
vehicle (p. 255)

•

Activating and deactivating child locks
(p. 256)

•

Opening the trunk lid from inside the trunk
(p. 255)

Unlocking the trunk lid from inside

the vehicle

The trunk lid can be unlocked from the inside
using the button on the dashboard.

–

Press the

 button on the dashboard.

> The trunk lid will unlock and can be

opened from the outside by pressing
the rubberized pressure plate on the
handle.

Related information

•

Locking and unlocking from inside the
vehicle (p. 254)

Opening the trunk lid from inside

the trunk

13

The vehicle is equipped with a fluorescent
handle on the inside of the trunk lid that can
be used in an emergency to open the trunk lid
from the inside.

13

US market only.

||

KEY, LOCKS AND ALARM

* Option/accessory.

256

1. Pull the handle downward to release the

trunk lid.
> The trunk lid will open.

2. After use, the handle must be pushed

back to its original position before the
trunk lid can be closed.

NOTE

The handle is not intended to be used to
secure the trunk lid, e.g. when transporting
long objects.

WARNING

•

Lock the doors and trunk lid when the
vehicle is parked and keep the remote
keys out of reach of children. Unsuper-
vised children could lock themselves in
the trunk and be injured.

•

On hot days, the temperature in the
trunk and inside the vehicle could rise
very quickly. Exposure to these high
temperatures, even for a short time,
could lead to heat-related injury or
fatality. Small children are particularly
at risk.

Related information

•

Locking and unlocking from inside the
vehicle (p. 254)

•

Unlocking the trunk lid from inside the
vehicle (p. 255)

Activating and deactivating child

locks

The child locks help prevent the rear doors
from being able to be opened from the inside.

The child lock can be either manual or elec-
tric

*

.

Manual child lock

Manual child lock. This is not the manual door lock.

–

Use the detachable key blade in the
remote key to turn the control.

The door cannot be opened from the
inside.
The door can be opened from both the
outside and the inside.

KEY, LOCKS AND ALARM

* Option/accessory.

257

NOTE

•

The door's knob control only locks that
specific door, not both rear doors
simultaneously.

•

There are no manual child locks on
models equipped with electronic child
locks.

Electric child lock

*

The electric child lock can be activated and
deactivated in any ignition mode higher than

0

. The lock can be activated and deactivated

up to 2 minutes after the ignition is turned off
if no door has been opened.

Button for activation and deactivation.

•

Light on – lock is activated.

•

Light off – lock is deactivated.

When the child lock is activated, the rear:

•

windows can only be opened using the
buttons in the driver's door.

•

the rear doors cannot be opened from the
inside.

If the child lock is activated when the vehicle
is switched off, it will remain activated the
next time the vehicle is started.

Symbols and messages

Symbol Message

Meaning

Rear child
lock



Acti-

vated

The child lock is
activated.

Rear child
lock



Deacti-

vated

The child lock is
deactivated.

Related information

•

Locking and unlocking from inside the
vehicle (p. 254)

•

Detachable key blade (p. 245)

Automatic locking when driving

The doors and trunk lid will automatically lock
when the vehicle begins to move.

Related information

•

Locking and unlocking from inside the
vehicle (p. 254)

KEY, LOCKS AND ALARM

* Option/accessory.

258

Locking the trunk lid using the

button

*

The button on the underside of the trunk lid
locks

14

 the vehicle after it is closed manually.

Location of button on underside of trunk lid.

1. Press the

 button on the underside of

the trunk lid.

2. Close the trunk lid manually.

> The trunk lid and doors will lock

15

.

NOTE

•

One of the vehicle's remote keys must
be within range for locking to be possi-
ble.

•

When the keyless locking

*

 function is

used, three audible signals will sound if
the key is not detected close enough to
the tailgate.

Related information

•

Keyless and touch-sensitive surfaces

*

(p. 250)

Operating the trunk lid with a foot

movement

*

To make it easier to operate the trunk lid
when your hands are full, it can be opened by
moving your foot in a forward kicking motion
under the rear bumper.

Opening the trunk lid with a foot
movement

Kicking motion within the sensor's activation area.

–

Make

one

 forward kicking motion with

your foot under the left section of the rear
bumper. Take a step back. Do not touch
the bumper.
> A brief audible signal will sound when

opening is activated – the trunk lid will
open/close.

14

Vehicles equipped with keyless locking/unlocking.

15

All doors must be closed for the vehicle to lock.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

259

If several opening attempts have been made
without the remote key in range behind the
vehicle, foot movement operation will not be
available for a short period of time.

Do not keep your foot under the vehicle in a
kicking motion. This may prevent activation.

The trunk lid is closed by pressing it down
manually.

NOTE

Please note that the system could be inad-
vertently activated in a car wash or similar
if the remote key is within range.

Related information

•

Keyless and touch-sensitive surfaces

*

(p. 250)

•

Remote key range (p. 239)

Private Locking

The trunk lid and rear seat backrests can be
locked using the private locking function, e.g.
when the vehicle is left at a workshop or with
a valet. This function prevents the trunk lid
from being opened and locks the rear seat
backrests in the upright position.

The function button for pri-
vate locking is located in the
center display's Function
view. Depending on the cur-
rent status of the lock,

Private Locking Unlocked

or

Private Locking Locked

will be displayed.

Related information

•

Activating and deactivating private locking
(p. 259)

Activating and deactivating private

locking

Private locking is activated using the function
button in the center display and a PIN code.

NOTE

For the valet lock function to be activated
the car must be in at least ignition mode

I

.

Two codes are used for private locking:

•

A security code, which is created the first
time the function is used.

•

A PIN code, which is changed each time
the function is activated.

Entering security code before initial
use

The first time the function is used, a security
code must be selected. This code can then be
used to deactivate private locking if the
selected PIN code has been forgotten or lost.
The security code functions as a PUK (secur-
ity) code for all PIN codes used for private
locking.

Save the security code in a safe place.

||

KEY, LOCKS AND ALARM

260

To create a security code:

1. Tap the button for private locking in Func-

tion view.

> A pop-up window will appear.

2. Enter the desired security code and press

Confirm

.

> The security code is saved. The private

locking function is now ready for activa-
tion.

Activating private locking

NOTE

The rear seat must be in the upright posi-
tion when private locking is activated in
order for the seats to lock.

1. Tap the button for private locking in Func-

tion view.

> A pop-up window will appear.

2. Enter the code you would like to use to

unlock the trunk lid and rear seats and tap

Confirm

.

> The trunk lid and rear seats will lock. A

green indicator light will illuminate next
to the button in Function view to con-
firm locked status.

Deactivating private locking

1. Tap the button for private locking in Func-

tion view.

> A pop-up window will appear.

2. Enter the code used for locking and tap

Confirm

.

> The trunk lid and rear seats will unlock.

The green indicator light next to the
button in Function view will go out to
confirm unlocked status.

Forgotten PIN code

If you have forgotten your PIN code or entered
it incorrectly more than three times, the secur-
ity code can be used to deactivate private
locking.

If the vehicle is unlocked using Volvo On Call
or the Volvo On Call app, private locking will
be automatically deactivated.

Forgotten security code

If you have forgotten your security code, con-
tact an authorized Volvo retailer for assistance
deactivating private locking.

Related information

•

Private Locking (p. 259)
