CLIMATE CONTROL

* Option/accessory.

227

Parking climate symbols and

messages

A number of symbols and messages related
to parking climate may be displayed in the
instrument panel.

Messages related to parking climate can also
be displayed in a device that has the Volvo On
Call

*

 app.

Symbol Message

Meaning

Parking climate

Service required

Parking climate is not functioning properly. Contact a workshop

A

 to have the system

checked as soon as possible.

Parking climate

Temporarily unavailable

Parking climate is temporarily not functioning properly. If the problem persists, contact a
workshop

A

 to have the system checked.

Parking climate

Unavailable Charge level too low

The parking climate cannot be activated because the hybrid battery's charge level is too low
to start the parking heater. Start the vehicle.

Parking climate

Unavailable, not connected to power
supply

The parking climate cannot be activated if the charging cable is not connected. Connect the
charging cable.

Parking climate

Limited Charge level too low

Parking climate will only run for a limited time when the hybrid battery's charge level is too
low. Start the vehicle.

A

An authorized Volvo workshop is recommended.

Related information

•

Parking climate (p. 219)

CLIMATE CONTROL

228

Heater

The heater has two sub-functions that help
warm the passenger compartment or engine
in various situations.

The heater has two sub-functions:

•

Parking heater - heats the passenger com-
partment as needed when the parking cli-
mate's preconditioning is activated.

•

Auxiliary heater - heats the passenger
compartment and engine while driving.

The heater is a high-voltage coolant heater
and is mounted in the front right-side wheel
housing.

Battery and charging

The heater is powered by the vehicle's hybrid
battery. If the charge level in the hybrid battery
is too low, the heater will switch off automati-
cally and a message will be displayed in the
instrument panel.

NOTE

Make sure that the battery has sufficient
charge if the heater must be used. For the
heater to be used for preconditioning, the
vehicle must be plugged into an electrical
outlet.

Related information

•

Climate (p. 196)

•

Parking heater (p. 228)

•

Additional heater (p. 229)

Parking heater

The parking heater heats the passenger com-
partment as needed before driving if precon-
ditioning is activated.

The parking heater is one of two sub-functions
of the vehicle's heater. The heater is mounted
in the front right-side wheel housing.

The parking heater starts automatically if the
parking climate's preconditioning is activated
and the passenger compartment needs to be
heated.

Heater running time varies depending on fac-
tors such as battery charge level, passenger
compartment temperature and ambient tem-
perature, but it will never run for longer than
30 minutes.

NOTE

Make sure that the hybrid battery has suffi-
cient charge if the parking heater must be
used. For the heater to be used for precon-
ditioning, the vehicle must be plugged into
an electrical outlet.

Related information

•

Heater (p. 228)

•

Additional heater (p. 229)

CLIMATE CONTROL

229

Additional heater

The auxiliary heater helps heat the passenger
compartment and engine while driving.

The auxiliary heater is one of two sub-func-
tions of the vehicle's heater. The heater is
mounted in the front right-side wheel housing.

The auxiliary heater is started and controlled
automatically when extra heat is required
while the vehicle is being driven.

It switches off automatically when the ignition
is switched off.

Related information

•

Heater (p. 228)

•

Parking heater (p. 228)

•

Activating and deactivating the auxiliary
heater (p. 229)

Activating and deactivating the

auxiliary heater

The auxiliary heater helps heat the passenger
compartment and engine while driving.

It is possible to set whether automatic start
for the auxiliary heater should be activated or
deactivated.

1. Tap

Settings

 in the Top view in the center

display.

2. Tap

Climate

.

3. Select

Additional Heater

 to activate/

deactivate automatic start for the auxiliary
heater.

NOTE

If automatic start of the auxiliary heater is
deactivated, this may impair comfort in the
passenger compartment since the climate
system then does not have a heat source
during electrical operation.

Related information

•

Additional heater (p. 229)

KEY, LOCKS AND ALARM

* Option/accessory.

232

Locking and unlocking

The vehicle can be locked and unlocked in
several different ways.

The vehicle can be locked and unlocked

•

using the buttons on the remote key

•

with the detachable key blade (if the bat-
tery in the remote key is discharged)

•

keyless

*

 (Passive Entry), the remote key

must be within range

•

from inside the vehicle using the lock con-
trols in the doors

•

remote door unlocking with Volvo On Call.

There are also several types of remote keys
that can be used.

For vehicles equipped with keyless locking
and unlocking

*

, a smaller, lighter and button-

less key is provided (Key Tag).

A Care Key

*

 (restricted key) makes it possible

to set restrictions for some of the vehicle's
functions e.g. maximum speed and maximum
audio system volume.

Related information

•

Locking and unlocking using the remote
key (p. 237)

•

Keyless locking and unlocking

*

 (p. 251)

•

Locking and unlocking from inside the
vehicle (p. 254)

•

Private Locking (p. 259)

•

Alarm (p. 261)

Lock indication

The turn signals will flash when the vehicle is
locked or unlocked.

Exterior confirmation

Locking

•

The turn signals will flash once and the
door mirrors will fold in

1

 to confirm the

vehicle is locked.

Unlocking

•

The turn signals will flash twice and the
door mirrors will fold out

1

 to confirm the

vehicle is unlocked.

The trunk lid, hood and all doors must be
closed for confirmation to be given. If only the
driver's door is closed when the vehicle is
locked

2

, the vehicle will be locked but the turn

signals will only flash to indicate locking when
all doors and the trunk and hood have been
closed.

KEY, LOCKS AND ALARM

* Option/accessory.

233

Lock and alarm indicators on the
dashboard

The locks and alarm indicator will display the
status of the locking system:

•

One long flash indicates locking.

•

When the vehicle is locked, this will be
indicated by short, pulsating flashes.

•

Rapid flashing after disabling the alarm
indicates that the alarm has been trig-
gered.

Lock button indicators

Front door

Lock buttons with indicator lights in front door.

Illuminated indicator lights in both front door
lock buttons indicate that all doors are locked.
If any door is opened, the lights in both doors
will go out.

Rear door

*

Lock button with indicator light in rear door.

Illuminated indicator lights in each door indi-
cate that that particular door is locked. If any
door is unlocked and opened, the indicator
light in that door will go out. The lights in the
other doors will remain illuminated.

Other indicators

The approach lighting and home safe lighting
functions may be activated when locking and
unlocking.

Related information

•

Lock confirmation settings (p. 234)

•

Locking and unlocking (p. 232)

•

Welcome Light (p. 160)

•

Using home safe lighting (p. 160)

1

Only vehicles with power folding mirrors.

2

Does not apply to vehicles equipped with keyless locking/unlocking

*

.

KEY, LOCKS AND ALARM

* Option/accessory.

234

Lock confirmation settings

Settings for how the vehicle confirms locking
and unlocking can be adjusted in the center
display's Settings menu.

To change the locking response settings:

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Locking

.

3. Tap

Visible Locking Feedback

 to select

when the vehicle should provide a visible
response:

•

Lock

•

Unlock

•

Both

Or turn off the function by marking

Off

.

4. Select to receive an audible response

when locking the vehicle by marking

Audible Locking Feedback

.

To change the settings for folding door mir-
rors

*

 when locking:

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Mirrors and Convenience

.

3. Select

Fold Mirror When Locked

 to acti-

vate or deactivate the function.

Related information

•

Lock indication (p. 232)

Remote key

The remote key is used to lock and unlock
doors and the trunk lid. The remote key must
be in the vehicle in order to start the engine.

Remote key

3

, Care Key and button-less key (Key

Tag)

*

.

The remote key is not physically used to start
the ignition because the vehicle is standard-
equipped with keyless start (Passive Start).
The key only needs to be in the front section of
the passenger compartment.

For vehicles equipped with keyless locking
and unlocking (Passive Entry)

*

, the engine can

be started with the key anywhere in the vehi-
cle. A smaller, lighter and button-less key (Key
Tag) is also provided.

3

The illustration is generic - details may vary according to vehicle model.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

235

The remote keys can be linked to different
driver profiles to store personal settings in the
vehicle.

WARNING

The remote key contains a button cell bat-

tery. Keep new and used batteries out of

the reach of children. If batteries are swal-

lowed, they can cause serious injury.
If any damage is detected, e.g. if the bat-

tery cover cannot be closed properly, do

not use the product. Keep defective prod-

ucts out of the reach of children.

Remote key buttons

The remote key has four buttons, one on the left side

and three on the right.



Locking

 - Press once to lock the doors,

trunk lid and fuel filler door and arm the
alarm.
Press and hold to close all windows.


Unlocking

 - Press once to unlock the

doors and trunk lid and disarm the alarm.
Press and hold to open all windows at the
same time. This total airing function can
be used to e.g. quickly air out the vehicle
in hot weather.


Trunk lid

 - Press to unlock and disarm

the trunk lid only. Pressing and holding

will open the trunk lid mechanically due to
the preloaded springs.


Panic alarm

 - Used to attract attention in

emergency situations. Press and hold the
button for at least 3 seconds or press
twice within 3 seconds to activate the
turn signals and horn. To deactivate, wait
at least 5 seconds and press the button
again. If no action is taken, the panic alarm
will deactivate automatically after 3
minutes.

WARNING

If anyone is left in the vehicle, make sure

that power to the power windows and pan-

oramic roof

*

 is cut off by always taking the

remote key with you when you leave the

vehicle.

||

KEY, LOCKS AND ALARM

* Option/accessory.

236

NOTE

Be aware of the risk of locking the remote
key in the vehicle.

•

If the remote key or key tag is left in
the vehicle, it will be deactivated when
the vehicle is locked and the alarm set
using another valid key. The key will be
reactivated when the vehicle is
unlocked.

•

If the remote key or Care Key is left in
the vehicle, it will be deactivated even
if the vehicle is locked using Volvo On
Call, and will be reactivated when the
vehicle is unlocked using Volvo On Call
or another valid key.

Button-less key (Key Tag)

*

The button-less key

4

 provided with the keyless

locking and unlocking function works in the
same way as the regular remote key for key-
less start, locking and unlocking. The key is
waterproof up to a depth of approx. 10 meters
(30 feet) for up to 60 minutes. It does not
have a detachable key blade and its battery
cannot be replaced.

Care Key - restricted remote key

A Care Key enables the vehicle owner to set a
maximum speed limit for the vehicle. This limit

is intended to promote safe use of the vehicle,
e.g. when it is loaned out.

Interference

Electromagnetic fields or obstructing objects
may interfere with the remote key's functions
for keyless start and keyless locking and
unlocking

*

.

NOTE

Avoid storing the remote key near metal
objects or electronic devices, e.g. cell
phones, tablets, laptops or chargers – pref-
erably no closer than 10-15 cm (4-6 in.).

If you experience interference, use the remote
key's detachable blade to unlock the vehicle
and then place the remote key in the backup
reader in the tunnel console cup holder to dis-
arm the alarm and start the vehicle.

NOTE

When the remote control key is placed in
the cup holder, make sure that no other
vehicle keys, metal objects or electronic
devices (e.g. cell phones, tablets, laptops
or chargers) are found in the cup holder.
Multiple vehicle keys close to each other in
the cup holder can disrupt their functional-
ity.

WARNING

California Proposition 65

Operating, servicing and maintaining a pas-

senger vehicle can expose you to chemi-

cals including engine exhaust, carbon mon-

oxide, phthalates, and lead, which are

known to the State of California to cause

cancer and birth defects or other reproduc-

tive harm. To minimize exposure, avoid

breathing exhaust, do not idle the engine

except as necessary, service your vehicle in

a well ventilated area and wear gloves or

wash your hands frequently when servicing

your vehicle. For more information go to

4

Also called sport key.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

237

Related information

•

Starting the vehicle (p. 408)

•

Locking and unlocking using the remote
key (p. 237)

•

Remote key range (p. 239)

•

Replacing the remote key's battery
(p. 240)

•

Detachable key blade (p. 245)

•

Care Key – restricted remote key (p. 244)

•

Electronic immobilizer (p. 248)

•

Linking a remote key to a driver profile
(p. 136)

Locking and unlocking using the

remote key

All doors and the trunk lid can be locked and
unlocked simultaneously using the buttons
on the remote key.

Locking with remote key

The illustration is generic - details may vary accord-

ing to vehicle model.

–

Press the

 button on the remote key to

lock the vehicle.

To activate the locking sequence, the driver's
door must be closed

5

. If any of the other doors

or the trunk lid are open, they will be locked
and the alarm will be armed once they are
closed.

NOTE

Be aware of the risk of locking the remote
key in the vehicle.

•

If the remote key or key tag is left in
the vehicle, it will be deactivated when
the vehicle is locked and the alarm set
using another valid key. The key will be
reactivated when the vehicle is
unlocked.

•

If the remote key or Care Key is left in
the vehicle, it will be deactivated even
if the vehicle is locked using Volvo On
Call, and will be reactivated when the
vehicle is unlocked using Volvo On Call
or another valid key.

Locking when the trunk lid is open

NOTE

If the vehicle is locked and the trunk lid is
still open, make sure that the remote key is
not left in the trunk when the trunk lid is
closed and the entire vehicle is locked

6

.

Unlocking with remote key

–

Press the

 button on the remote key to

unlock the vehicle.

5

If the vehicle is equipped with keyless locking/unlocking

*

, all side doors must be closed.

6

If the vehicle is equipped with keyless locking/unlocking and the key is detected inside the vehicle, the trunk lid will not lock when it is closed.

*

||

KEY, LOCKS AND ALARM

238

Automatic relocking

If none of the doors or trunk lid are opened
within two minutes after being unlocked, they
will automatically relock. This function reduces
the risk of inadvertently leaving the vehicle
unlocked.

Remote key not working

NOTE

Move closer to the vehicle and try to
unlock it again.

If the remote key is not working to lock or
unlock the vehicle, its battery may be dis-
charged. Use the detachable key blade to
lock/unlock the driver's door instead.

Related information

•

Settings for remote and inside door unlock
(p. 238)

•

Unlocking the trunk lid using the remote
key (p. 238)

•

Remote key (p. 234)

•

Replacing the remote key's battery
(p. 240)

•

Locking and unlocking with detachable
key blade (p. 246)

Settings for remote and inside

door unlock

Several different sequences are available for
remote unlocking.

To change this setting:

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Locking

Remote and

Interior Unlock

.

3. Select alternative:

•

All Doors

 – unlocks all doors at the

same time.

•

Single Door

 – unlocks the driver's

door. Press the remote key unlock but-
ton twice to unlock all doors.

The settings made here also affect central
locking using the inside door handle.

Related information

•

Locking and unlocking using the remote
key (p. 237)

•

Locking and unlocking from inside the
vehicle (p. 254)

Unlocking the trunk lid using the

remote key

The remote key can be used to unlock only
the trunk lid.

–

Press the

 button on the remote key.

> The trunk lid will be unlocked but

remain closed.

The side doors remain locked and
armed. The lock and alarm indicator on
the dashboard will go out to indicate
that the vehicle is no longer fully
locked.

If the trunk lid is not opened within 2 minutes,
it will be relocked and the alarm armed.

KEY, LOCKS AND ALARM

* Option/accessory.

239

Power trunk release

*

–

Press and hold the

 button on the

remote key for about 1,5 seconds.
> The trunk lid will open mechanically

while the doors remain locked and
armed.

Related information

•

Locking and unlocking using the remote
key (p. 237)

Remote key range

In order to function correctly, the remote key
must be within a certain distance from the
vehicle.

Manual use

The remote key's functions for e.g. locking and
unlocking, which are activated by pressing
or

, have a range of approx. 20 meters

(65 feet) from the vehicle.

If the vehicle's locks do not react, move closer
and try again.

Keyless

*

 use

The shaded areas around the vehicle illustrate the

range of the system's antennas.

For keyless use, a remote key or the Key Tag
must be within the shaded areas shown in the
illustration, i.e. a semicircle with a radius of

approx. 1.5 meter (5 feet) along the sides of
the vehicle or approx. 1 meter (3 feet) from the
trunk lid.

NOTE

The functions of the remote control key
can be disrupted by ambient radio waves,
buildings, topographical conditions, etc.
The vehicle can always be locked/unlocked
using the key blade.

If the remote key is removed from the
vehicle

If the remote key is removed from
the vehicle while the engine is run-
ning, the warning message

Vehicle

key not found



Removed from

vehicle

 will be displayed in the instrument

panel and an audible signal will sound when
the last door is closed.

The message will disappear when the key is
returned to the vehicle and the

O

 button on

the right-side steering wheel keypad is
pressed or when the last door is closed again.

Related information

•

Remote key (p. 234)

•

Antenna locations for the start and lock
system (p. 253)

•

Keyless and touch-sensitive surfaces

*

(p. 250)

KEY, LOCKS AND ALARM

* Option/accessory.

240

Replacing the remote key's battery

The battery in the remote key must be
replaced when it is discharged.

NOTE

All batteries have a limited service life and
must eventually be replaced (does not
apply for Key Tag). The battery's service life
varies depending on how often the
vehicle/key is used.

The remote key battery should be replaced if

•

the information symbol illuminates and the
message

Vehicle key bat. low

 is dis-

played in the instrument panel

•

the locks do not react after several
attempts to lock or unlock the vehicle
using the remote key within approx.
20 meter (65 feet) from the vehicle.

NOTE

Move closer to the vehicle and try to
unlock it again.

The battery in the smaller key without but-
tons

7

 (the Key Tag) cannot be replaced. A new

key can be ordered from an authorized Volvo
workshop.

CAUTION

An end-of-life Key Tag must be turned in to
an authorized Volvo workshop. The key
must be deleted from the vehicle because
it can still be used to start the vehicle via
backup start.

Opening the key and replacing the
battery

 Hold the remote key with the front side

(with the Volvo logo) facing up and move
the button on the key ring section to the
right. Slide the front cover slightly upward.

 The cover will loosen and can be

removed from the key.

7

Included in vehicles equipped with keyless locking/unlocking

*

.

KEY, LOCKS AND ALARM

}}

241

 Turn the key over, move the button to

the side and slide the rear cover slightly
upward.

 The cover will loosen and can be

removed from the key.

Use a screwdriver or similar object to turn
the battery cover counterclockwise so the
markers point to

OPEN

.

Remove the cover carefully by pressing
e.g. a fingernail into the indentation.

Pry the cover up.

The battery's positive side (

+

) faces

upward. Carefully pry out the battery as
shown in the illustration.

CAUTION

Avoid touching new batteries and their
contact surfaces with your fingers as this
will impair their function.

||

KEY, LOCKS AND ALARM

242

Insert a new battery with the positive side
(

+

) facing upward. Do not touch the con-

tact surfaces of the remote key battery.

 Place the edge of the battery down-

ward into the holder. Slide the battery for-
ward until it locks into place under the two
plastic catches.

 Press the battery downward until it

locks into place under the upper black
plastic catch.

NOTE

Use batteries with the designation
CR2032, 3 V.

NOTE

Volvo recommends that batteries used in
the remote control key satisfy UN Manual
of Test and Criteria, Part III, sub-section
38.3. The factory installed batteries and
batteries replaced by an authorized Volvo
workshop satisfy the above criterion.

Replace the battery cover and turn it
clockwise until it points to

CLOSE

.

 Put the rear cover back into position

and press it down until it clicks into place.

 Slide the cover back.

> A second click indicates that the cover

is correctly positioned and locked into
place.

KEY, LOCKS AND ALARM

243

 Turn the remote key over and press the

front cover down until it clicks into place.

 Slide the cover back.

> An additional click indicates that the

cover is correctly in place.

WARNING

Make sure the battery is positioned cor-

rectly with the right polarity. If the remote

key will not be used for a prolonged period

of time, remove the battery to avoid battery

leakage and damage. Wear protective

gloves when handling damaged batteries,

as batteries that are damaged or leaking

can cause corrosive damage in contact

with the skin.

•

Keep batteries out of the reach of chil-
dren.

•

Do not leave batteries lying out where
they could be swallowed by children or
pets.

•

Never disassemble, short-circuit or
place a battery into open fire.

•

Do not charge non-rechargeable bat-
teries, as this could cause an explosion.

Check the remote key for damage before

using it. If any damage is detected, e.g. if

the battery cover cannot be closed prop-

erly, do not use the product. Keep defec-

tive products out of the reach of children.

CAUTION

Be sure to dispose of end-of-life batteries
in a way that protects the environment.

WARNING

California Proposition 65

Operating, servicing and maintaining a pas-

senger vehicle can expose you to chemi-

cals including engine exhaust, carbon mon-

oxide, phthalates, and lead, which are

known to the State of California to cause

cancer and birth defects or other reproduc-

tive harm. To minimize exposure, avoid

breathing exhaust, do not idle the engine

except as necessary, service your vehicle in

a well ventilated area and wear gloves or

wash your hands frequently when servicing

your vehicle. For more information go to

Related information

•

Locking and unlocking with detachable
key blade (p. 246)

•

Starting the vehicle (p. 408)

•

Remote key (p. 234)

KEY, LOCKS AND ALARM

* Option/accessory.

244

Ordering additional remote keys

Two remote keys are provided with the vehi-
cle. One Key Tag is also included if the vehi-
cle is equipped with keyless locking/unlock-
ing

*

. Additional keys can be ordered.

A total of 12 keys can be programmed and
used for the same vehicle. An additional driver
profile will be added for each new remote key.
This also applies to the key tag.

Loss of a remote key

If you lose your remote key, you can order a
replacement from a workshop - an authorized
Volvo workshop is recommended. Bring the
other remaining remote keys to the workshop.
As an anti-theft measure, the code of the lost
remote key must be erased from the system.

The current number of keys registered for the
vehicle can be checked via driver profiles in
the center display's Top view. Select

Settings

System

Driver Profiles

.

NOTE

Volvo recommends that you order a new or
duplicate remote key from an authorized
Volvo workshop.

You can also obtain additional or duplicate
remote keys from certain independent
repair facilities and locksmiths that are
qualified to make remote keys. Each key
must be programmed to work with your
vehicle.

A list of independent repair facilities and/or
locksmiths known to Volvo that can cut
and code replacement keys can be found:

•

at volvocars.com

•

by calling Volvo Customer Care
1-800-458-1552.

Related information

•

Remote key (p. 234)

Care Key – restricted remote key

A Care Key enables the vehicle owner to set a
maximum speed limit for the vehicle. This
limit is intended to promote safe use of the
vehicle, e.g. when it is loaned out.

A maximum vehicle speed can be defined for a
Care Key. Otherwise, the Red Key functions in
the same way as a standard remote key.

This restriction is intended to help reduce the
risk of accidents and help the driver feel more
secure when handing over the vehicle to e.g. a
young driver, parking attendant or workshop.

Ordering a Care Key

One or more Care Key can be ordered from a
Volvo retailer. A total of twelve keys can be
programmed and used for the same vehicle.
Up to ten may be restricted keys, but at least
two must be standard remote keys.
