WINDOWS, GLASS AND MIRRORS

* Option/accessory.

180

3. Press the

L

 or

R

 button again. The light

should no longer be illuminated.

Folding in rearview mirrors
electrically

*

The mirrors can be retracted for parking/driv-
ing in narrow spaces.

1. Depress the

L

 and

R

 buttons simultane-

ously.

2. Release them after approximately 1 sec-

ond. The mirrors automatically stop in the
fully retracted position.

Fold out the mirrors by pressing down the

L

and

R

 buttons simultaneously. The mirrors

automatically stop in the fully extended posi-
tion.

Resetting to neutral

Mirrors that have been moved out of position
by an external force must be reset electrically
to the neutral position for electric retracting/
extending

*

 to work correctly.

1. Fold in the door mirrors by pressing down

the

L

 and

R

 buttons simultaneously.

2. Fold them out again by pressing the

L

and

R

 buttons simultaneously.

3. Repeat the above procedure as necessary.

The mirrors are now reset in neutral position.

Angling during parking

3

A door mirror can be angled down for the
driver to view the side of the road when park-
ing, for example.

–

Engage reverse gear and press the

L

 or

R

button.

Note that the button may need to be pressed
twice, depending on whether it was already
preselected. The button flashes when the door
mirror is angled down. When reverse gear is
disengaged, the door mirror automatically
starts to return after approx. 3 seconds and
then reaches its original position after approx.
8 seconds.

Automatic angling during parking

3

With this setting, the door mirror is automati-
cally angled down when reverse gear is
selected. The folded position is preset and
cannot be adjusted.

1. Tap on

Settings

 in the centre display's

top view.

2. Press

My Car

Mirrors and

Convenience

.

3. Under

Exterior Mirror Tilt at Reverse

,

select

Off

,

Driver

,

Passenger

 or

Both

 to

activate/deactivate and to select which
review mirror should be angled.

You can make the door mirror return to its
original position by pressing the

L

 or

R

 button

twice.

Automatic retraction when locking

*

When the car is locked/unlocked with the
remote control key, the door mirrors can be
automatically retracted/extended. However, if
the mirrors have been folded in manually then
they have to be folded out manually as well.

1. Tap on

Settings

 in the centre display's

top view.

2. Press

My Car

Mirrors and

Convenience

.

3. Select

Fold Mirror When Locked

 to acti-

vate/deactivate.

Related information

•

Rearview and door mirrors (p. 178)

•

Adjusting rearview mirror dimming
(p. 178)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 194)

•

Activating and deactivating the heated
rear window and door mirrors (p. 232)

3

Only in combination with power seat with memory buttons

*

.

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

181

Panorama roof

*

The panorama roof is divided into two glass
sections. The front section can be opened
vertically at the rear edge (ventilation posi-
tion) or horizontally (open position). The rear
section is fixed roof glass.

The panoramic roof has a wind deflector and
a sun blind made of perforated fabric and
located under the glass roof to provide extra
protection from factors such as strong sun-
light.

The panoramic roof and sun blind are operated
with a control located in the roof.

In order that the panoramic roof and the sun
blind can be operated, the car's electrical sys-
tem must be in ignition position

I

 or

II

.

WARNING

Children, other passengers or objects may

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the
power supply to the power windows
by setting the car's electrical system in
ignition position

0

, and then take the

remote control key with you when leav-
ing the car.

•

Never put an object or part of the body
through the windows, even if the car's
electrical system is fully disconnected.

IMPORTANT

•

Do not open the panoramic roof when
load carriers are fitted.

•

Do not place any heavy objects on the
panoramic roof.

IMPORTANT

•

Remove ice and snow before opening
the panoramic roof. Take care not to
scratch surfaces or damage strips.

•

Do not operate the panoramic roof if it
has frozen closed.

Wind deflector

The panorama roof has a wind deflector that is
raised when the panorama roof is in the open
position.

Related information

•

Operating the panorama roof

*

 (p. 182)

•

Automatic closing of the panoramic roof's

*

sun blind (p. 184)

•

Pinch protection for windows and sun
blinds (p. 174)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

182

•

Keyless locking and unlocking

*

 (p. 279)

•

Locking and unlocking with the remote
control key (p. 257)

Operating the panorama roof

*

The panoramic roof and sun blind are oper-
ated with a control in the roof panel and both
are equipped with pinch protection.

WARNING

Children, other passengers or objects may

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the
power supply to the power windows
by setting the car's electrical system in
ignition position

0

, and then take the

remote control key with you when leav-
ing the car.

•

Never put an object or part of the body
through the windows, even if the car's
electrical system is fully disconnected.

IMPORTANT

•

Do not open the panoramic roof when
load carriers are fitted.

•

Do not place any heavy objects on the
panoramic roof.

IMPORTANT

•

Remove ice and snow before opening
the panoramic roof. Take care not to
scratch surfaces or damage strips.

•

Do not operate the panoramic roof if it
has frozen closed.

In order that the panoramic roof and the sun
blind can be operated, the car's electrical sys-
tem must be in ignition position

I

 or

II

.

It can also be operated using a remote control
key or keyless opening

*

 with the door handle.

WARNING

Check that children or other passengers

are not at risk of crushing when all the win-

dows are closed with a remote control key

or keyless opening

*

 with a door handle.

WINDOWS, GLASS AND MIRRORS

}}

183

IMPORTANT

Check that the panoramic roof is properly
closed when closing.

The movement of the roof is stopped if the
control is released during manual operation, or
when the glass reaches the comfort position

4

or the maximum opening or closing position.
The movement of both panoramic roof and
sun blind are also stopped if the roof control is
operated again in the opposite direction to the
current direction of movement.

The panoramic roof and the sun blind are also
equipped with pinch protection. If any fault
arises with the pinch protection, a reset
sequence can be tested.

NOTE

For manual opening, the sun blind must be
fully open before the panoramic roof can
be opened. When the procedure is
reversed, the panoramic roof must be fully
closed before the sun blind can be fully
closed.

NOTE

It may not be possible to operate windows
at low temperatures.

Open and close ventilation position

Ventilation position, vertically at the rear edge.

Open by pressing the control upward
once.
Close by pressing the control downward
once.

When the ventilation position is selected the
front glass cover is raised at its rear edge. If
the sun blind is fully closed when ventilation
position is selected, then it opens automati-
cally approx. 50 mm (approx. 2 inches).

The sun blind follows automatically if the pan-
oramic roof is closed from ventilation position.

Fully open and close the panoramic
roof using the roof control

Operation, manual mode

Operation, automatic mode

4

Comfort position is a position where wind noise and resonance noise are at a comfortably low level while driving.

||

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

184

Manual operation

1. To open the sun blind - press the control

backwards to the position for manual
opening.

2. Open the panoramic roof to comfort posi-

tion - press the control backwards a sec-
ond time to the position for manual open-
ing.

3. Open the panoramic roof to maximum

position - press the control backwards a
third time to the position for manual open-
ing.

Close by repeating the preceding procedure in
reverse order - press the control forward/
downward to the manual closing position
instead.

Automatic operation

1. Open the sun blind to maximum position -

press the control backward to the position
for automatic opening and release.

2. Open the panoramic roof to comfort posi-

tion - press the control backwards a sec-
ond time to the position for automatic
opening and release.

3. Open the panoramic roof to maximum

position - press the control backwards a
third time to the position for automatic
opening and release.

Close by repeating the preceding procedure in
reverse order - press the control forward/

downward to the automatic closing position
instead.

Automatic operation - rapid opening or
closing

The panoramic roof and sun blind can be
opened or closed simultaneously:

–

To open - press the control rearward to
the automatic operation position twice
and release.

–

To close - press the control forward/
downward to the automatic operation
position twice and release.

Related information

•

Panorama roof

*

 (p. 181)

•

Automatic closing of the panoramic roof's

*

sun blind (p. 184)

•

Pinch protection for windows and sun
blinds (p. 174)

•

Keyless locking and unlocking

*

 (p. 279)

•

Locking and unlocking with the remote
control key (p. 257)

Automatic closing of the

panoramic roof's

*

 sun blind

With this function, the sun blind is closed
automatically 15 minutes after the car has
been locked if it is parked in hot weather. This
is in order to lower the passenger compart-
ment temperature and protect the car's
upholstery from sun-fading.

The function is deactivated when the car is
supplied from the factory and can be activated
or deactivated in the centre display.

1. Press

Settings

 in the top view in the cen-

tre display.

2. Press

My Car

Locking

.

Select

Auto Close Sunroof Curtain

 to

activate/deactivate.

NOTE

The sun blind is also closed when all win-
dows are closed using the remote control
key or keyless opening

*

 with a door handle.

Related information

•

Panorama roof

*

 (p. 181)

•

Operating the panorama roof

*

 (p. 182)

•

Pinch protection for windows and sun
blinds (p. 174)

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

185

•

Keyless locking and unlocking

*

 (p. 279)

•

Locking and unlocking with the remote
control key (p. 257)

Wiper blades and washer fluid

Together with the washer fluid, the wipers
aim to improve visibility as well as headlamp
pattern.

The washer nozzles are heated

*

 automatically

in cold weather to prevent the washer fluid
from freezing.

Information indicating that the washer fluid
needs topping up appears in the driver display
when there is approx. 1 litre (1 qt) of washer
fluid remaining.

Related information

•

Using the rain sensor (p. 186)

•

Using windscreen and headlamp washers
(p. 188)

•

Using automatic rear windscreen wiping
when reversing (p. 190)

•

Using the rain sensor's memory function
(p. 187)

•

Using the rear window wiper and washer
(p. 189)

•

Filling washer fluid (p. 687)

•

Set the wiper blades in service position
(p. 686)

•

Replacing windscreen wiper blades
(p. 685)

•

Replacing the wiper blade, rear window
(p. 684)

•

Using windscreen wipers (p. 185)

Using windscreen wipers

The windscreen wipers are designed to clean
the windscreen. Different settings for the
windscreen wipers are set using the right-
hand stalk switch.

Right-hand stalk switch.

The thumbwheel is used to set rain sensor
sensitivity and wiper swipe frequency.

Single sweep

Lower the stalk switch and release to
make one sweep.

Windscreen wipers off

Move the stalk switch to position

0

 to

switch off the windscreen wipers.

||

WINDOWS, GLASS AND MIRRORS

186

Intermittent wiping

Move the lever up to switch the wipers
to intermittent wiping. Set the number

of sweeps per time unit with the thumbwheel
when intermittent wiping is selected.

Continuous wiping

Raise the stalk switch for the wipers to
sweep at normal speed.

Raise the stalk switch further for the
wipers to sweep at high speed.

IMPORTANT

Before activating the wipers - ensure that
the wiper blades are not frozen in, and that
any snow or ice on the windscreen and
rear window is scraped away.

IMPORTANT

Use plenty of washer fluid when the wipers
are cleaning the windscreen. The wind-
screen must be wet when the windscreen
wipers are operating.

Related information

•

Using the rain sensor (p. 186)

•

Using windscreen and headlamp washers
(p. 188)

•

Using automatic rear windscreen wiping
when reversing (p. 190)

•

Wiper blades and washer fluid (p. 185)

•

Using the rain sensor's memory function
(p. 187)

•

Using the rear window wiper and washer
(p. 189)

•

Filling washer fluid (p. 687)

•

Set the wiper blades in service position
(p. 686)

•

Replacing windscreen wiper blades
(p. 685)

•

Replacing the wiper blade, rear window
(p. 684)

Using the rain sensor

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen. Rain sensor sen-
sitivity can be adjusted with the thumbwheel
on the right-hand stalk switch.

Right-hand stalk switch.

Rain sensor button

Thumbwheel sensitivity/frequency

When the rain sensor is activated, the rain
sensor symbol

 is shown in the driver

display.

Activating the rain sensor

When activating the rain sensor, the car must
be running or in ignition position

I

 or

II

 while

the windscreen wiper stalk switch is in posi-
tion

0

 or in the position for a single sweep.

WINDOWS, GLASS AND MIRRORS

}}

187

Activate the rain sensor by pressing the rain
sensor button

.

Move the lever down to make the wipers
move.

Turn the thumbwheel upward for higher sensi-
tivity and downward for lower sensitivity. An
extra sweep is made when the thumbwheel is
turned upward.

Deactivating the rain sensor

Deactivate the rain sensor by pressing the rain
sensor button

 or moving the stalk

switch up to another wiper program.

The rain sensor is deactivated automatically in
ignition position

0

 or when the engine is

switched off.

The rain sensor is deactivated automatically
when wiper blades are set in service position.
The rain sensor is reactivated when service
mode has been deactivated.

IMPORTANT

The windscreen wipers could start and be
damaged in an automatic car wash. Deac-
tivate the rain sensor while the car is run-
ning or when the car's electrical system is
in ignition position

I

 or

II

. The symbol in the

driver display extinguishes.

Related information

•

Using windscreen and headlamp washers
(p. 188)

•

Using automatic rear windscreen wiping
when reversing (p. 190)

•

Wiper blades and washer fluid (p. 185)

•

Using the rain sensor's memory function
(p. 187)

•

Using the rear window wiper and washer
(p. 189)

•

Filling washer fluid (p. 687)

•

Set the wiper blades in service position
(p. 686)

•

Replacing windscreen wiper blades
(p. 685)

•

Replacing the wiper blade, rear window
(p. 684)

•

Using windscreen wipers (p. 185)

Using the rain sensor's memory

function

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen.

Activating/deactivating the memory
function

The memory function for the rain sensor can
be activated in such a way that the rain sensor
button does not need to be depressed each
time the car is started:

1. Press

Settings

 in the top view in the cen-

tre display.

2. Press

My Car

Wipers

.

3. Select

Rain Sensor Memory

 to activate/

deactivate the memory function.

Related information

•

Using the rain sensor (p. 186)

•

Using windscreen and headlamp washers
(p. 188)

•

Using automatic rear windscreen wiping
when reversing (p. 190)

•

Wiper blades and washer fluid (p. 185)

•

Using the rear window wiper and washer
(p. 189)

•

Filling washer fluid (p. 687)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

188

•

Set the wiper blades in service position
(p. 686)

•

Replacing windscreen wiper blades
(p. 685)

•

Replacing the wiper blade, rear window
(p. 684)

•

Using windscreen wipers (p. 185)

Using windscreen and headlamp

washers

Windscreen and headlamp washers are
designed to clean the windscreen and head-
lamps. Windscreen and headlamp washers
are started using the right-hand stalk switch.

Starting windscreen and headlamp
washers

Washing function, right-hand stalk switch.

–

Move the right-hand stalk switch toward
the steering wheel to start the windscreen
and headlamp washers.
> The windscreen wipers will make sev-

eral more sweeps once the stalk switch
has been released.

IMPORTANT

Avoid activating the washer system when
it is frozen or the washer reservoir is
empty, otherwise there is a risk of damag-
ing the pump.

Headlamp washing

*

To save fluid, the headlamps are washed auto-
matically at a defined interval when the head-
lamps are switched on.

Reduced washing

If only approx. 1 litre (1 qt) of washer fluid
remains in the reservoir and the message

Washer fluid



Level low, refill

, together with

the

 symbol, is shown in the driver dis-

play, then the supply of washer fluid to the
headlamps is switched off. This is to prioritise
cleaning the windscreen and the visibility
through it. The headlamps are only washed if
main or dipped beam is switched on.

Related information

•

Using the rain sensor (p. 186)

•

Using automatic rear windscreen wiping
when reversing (p. 190)

•

Wiper blades and washer fluid (p. 185)

•

Using the rain sensor's memory function
(p. 187)

•

Using the rear window wiper and washer
(p. 189)

WINDOWS, GLASS AND MIRRORS

}}

189

•

Filling washer fluid (p. 687)

•

Set the wiper blades in service position
(p. 686)

•

Replacing windscreen wiper blades
(p. 685)

•

Replacing the wiper blade, rear window
(p. 684)

•

Using windscreen wipers (p. 185)

Using the rear window wiper and

washer

The rear windscreen washer and wiper are
designed to clean the rear window. Washing/
wiping is started and settings are changed by
means of the right-hand steering wheel stalk
switch.

Activating the rear window wiper and
washer

NOTE

The rear window wiper motor is equipped
with overheating protection which means
that it is switched off if it overheats. The
rear window wiper works again after a
cooling-down period.

Select

for intermittent wiping with

the rear window wiper.

Select

for continuous speed with the

rear window wiper.

–

Move the right-hand steering wheel stalk
switch forward to start rear window
washing and wiping.

Related information

•

Using the rain sensor (p. 186)

•

Using windscreen and headlamp washers
(p. 188)

•

Using automatic rear windscreen wiping
when reversing (p. 190)

•

Using the rain sensor's memory function
(p. 187)

•

Wiper blades and washer fluid (p. 185)

•

Filling washer fluid (p. 687)

WINDOWS, GLASS AND MIRRORS

190

•

Set the wiper blades in service position
(p. 686)

•

Replacing windscreen wiper blades
(p. 685)

•

Replacing the wiper blade, rear window
(p. 684)

•

Using windscreen wipers (p. 185)

Using automatic rear windscreen

wiping when reversing

Engaging reverse gear while the windscreen
wipers are switched on initiates rear window
wiping. The function stops when reverse gear
is disengaged.

1. Press

Settings

 in the top view in the cen-

tre display.

2. Press

My Car

Wipers

.

3. Select

Auto Rear Wiper

 to activate/deac-

tivate wiping when reversing.

If the rear windscreen wiper is already operat-
ing at a constant speed then no change takes
place when reverse gear is engaged.

Related information

•

Using the rain sensor (p. 186)

•

Using windscreen and headlamp washers
(p. 188)

•

Wiper blades and washer fluid (p. 185)

•

Using the rain sensor's memory function
(p. 187)

•

Using the rear window wiper and washer
(p. 189)

•

Filling washer fluid (p. 687)

•

Set the wiper blades in service position
(p. 686)

•

Replacing windscreen wiper blades
(p. 685)

•

Replacing the wiper blade, rear window
(p. 684)

•

Using windscreen wipers (p. 185)

SEATS AND STEERING WHEEL

* Option/accessory.

192

Manual front seat

The car's front seats have a range of setting
options in order to enhance comfort.

Raise/lower the front edge of the seat
cushion

*

 by pumping up/down.

1

Change the length

*

 of the seat cushion by

pulling the lever up and moving the seat
cushion forward/backward by hand.
Adjust the seat forward/backward by lift-
ing the handle and adjusting the distance
to the steering wheel and pedals. Check
that the seat is locked after the position
has been adjusted.
Change the lumbar support

*

 by pressing

the button upward/downward/forward/
back

2

.

Raise/lower the seat by means of adjust-
ing the control up/down.
Change the backrest inclination by turning
the control knob.

WARNING

Adjust the position of the driver's seat

before setting off, never while driving.

Make sure that the seat is in locked posi-

tion in order to avoid personal injury in the

event of heavy braking or an accident.

Related information

•

Power

*

 front seat (p. 193)

•

Adjusting the power

*

 front seat (p. 193)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 194)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 195)

•

Adjusting massage settings

*

 in the front

seat (p. 197)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 198)

•

Massage settings

*

 in the front seat

(p. 196)

•

Adjusting the side support

*

 in the front

seat (p. 199)

•

Adjusting the lumbar support

*

 in the front

seat (p. 200)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 201)

1

Only applies to the driver's seat.

2

Applicable to four-way lumbar support

*

. Two-way lumbar support

*

 is adjusted forwards/backwards.

SEATS AND STEERING WHEEL

}}

* Option/accessory.

193

Power

*

 front seat

The car's front seats have a range of setting
options in order to enhance comfort. The
power seat can be moved forwards/back-
wards and upwards/downwards. The front
edge of the seat cushion can be raised/
lowered as well as adjusted in length

*

 and the

backrest inclination can be changed. The
lumbar support

*

 can be adjusted upward/

downward/forward/backward.

3

Seat setup can take place when the engine is
running and within a certain time after unlock-
ing the door without the engine running.
Adjustment can also be performed within a
certain time after the engine has been
switched off.

IMPORTANT

The power seats have overload protection
that is triggered if any seat is blocked by an
object. If this happens, remove the object
and then move the seat again.

Related information

•

Manual front seat (p. 192)

•

Adjusting the power

*

 front seat (p. 193)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 194)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 195)

•

Adjusting massage settings

*

 in the front

seat (p. 197)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 198)

•

Massage settings

*

 in the front seat

(p. 196)

•

Adjusting the side support

*

 in the front

seat (p. 199)

•

Adjusting the lumbar support

*

 in the front

seat (p. 200)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 201)

Adjusting the power

*

 front seat

Set the preferred seat position using the con-
trol on the front seat's seating section. To set
the various comfort functions, turn the multi-
function control

4

 up/down.

The illustration shows the controls from a car with
four-way lumbar support

*

. Cars with two-way lumbar

support

*

 do not have the rotatable multifunction con-

trol.

In cars with four-way lumbar support

*

,

turn the multifunction control

4

 up/down to

set the different comfort functions. In cars
with two-way lumbar support

*

, use the

round button to adjust the lumbar support
forward/backward.
Raise/lower the seat cushion front edge
by adjusting the control up/down.

3

Applicable to four-way lumbar support

*

. Two-way lumbar support

*

 is adjusted forwards/backwards.

4

Not available in cars with two-way lumbar support

*

.

||

SEATS AND STEERING WHEEL

* Option/accessory.

194

Raise/lower the seat by means of adjust-
ing the control up/down.
Move the seat forward/backward by
adjusting the control forward/backward.
Change the backrest inclination by adjust-
ing the control forward/backward.

Only one movement (forward/back/up/down)
can be made at a time.

The backrests of the front seats cannot be
lowered fully forward.

Related information

•

Manual front seat (p. 192)

•

Power

*

 front seat (p. 193)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 194)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 195)

•

Adjusting massage settings

*

 in the front

seat (p. 197)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 198)

•

Massage settings

*

 in the front seat

(p. 196)

•

Adjusting the side support

*

 in the front

seat (p. 199)

•

Adjusting the lumbar support

*

 in the front

seat (p. 200)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 201)

Storing position for seat, door

mirrors and head-up display

*

You can store the position for power

*

 seat,

door mirrors and head-up display

*

 in the

memory buttons.

Store three different positions for the power

*

seat, the door mirrors and the head-up dis-
play

*

 using the memory buttons. The buttons

are located on the inside of one of the front
doors or both

*

.

Memory button.

Memory button.

Memory button.

Button

M

 for storing settings.

SEATS AND STEERING WHEEL

}}

* Option/accessory.

195

Storing a position

1. Adjust seat, door mirrors and head-up dis-

play to the desired position.

2. Press and hold the

M

 button depressed.

The light indicator in the button illumi-
nates.

3. Within three seconds, press and hold the

1

,

2

 or

3

 button.

> When the position has been stored in

the selected memory button, an acous-
tic signal can be heard and the light
indicator in the

M

 button extinguishes.

If none of the memory buttons is depressed
within three seconds then the

M

 button extin-

guishes and no storing takes place.

The seat, the door mirrors or the head-up-dis-
play must be readjusted before a new memory
can be set.

Related information

•

Manual front seat (p. 192)

•

Power

*

 front seat (p. 193)

•

Adjusting the power

*

 front seat (p. 193)

•

Using a stored position for seat, door mir-
rors and head-up display

*

 (p. 195)

•

Adjusting massage settings

*

 in the front

seat (p. 197)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 198)

•

Massage settings

*

 in the front seat

(p. 196)

•

Adjusting the side support

*

 in the front

seat (p. 199)

•

Adjusting the lumbar support

*

 in the front

seat (p. 200)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 201)

•

Angling the door mirrors (p. 179)

•

Settings for head-up display

*

 (p. 150)

Using a stored position for seat,

door mirrors and head-up display

*

If the positions for the power

*

 seat, the door

mirrors and the head-up display

*

 have been

stored, they can be activated by using the
memory buttons.

Using a stored setting

A stored setting can be used with the front
door either open or closed:

Open front door

–

Press one of the memory buttons

1

 -

3

with a brief touch. Power seat, door mir-
rors and head-up display move and then
stop at the positions stored in the selected
memory button.

||

SEATS AND STEERING WHEEL

* Option/accessory.

196

Closed front door

–

Hold one of the memory buttons

1

 -

3

depressed until seat, door mirrors and
head-up display stop in the positions that
are stored in the selected memory button.

If the memory button is released, the move-
ment of the seat, door mirrors and head-up
display will be stopped.

WARNING

•

Because the driver's seat can be
adjusted with the ignition off, children
should never be left unattended in the
vehicle.

•

Movement of the seat can be STOP-
PED at any time by pressing any but-
ton on the power seat control panel.

•

Do not adjust the seat while driving.

•

Make sure there is nothing under the
seats when they are being adjusted.

Related information

•

Manual front seat (p. 192)

•

Power

*

 front seat (p. 193)

•

Adjusting the power

*

 front seat (p. 193)

•

Storing position for seat, door mirrors and
head-up display

*

 (p. 194)

•

Adjusting massage settings

*

 in the front

seat (p. 197)

•

Adjusting

*

 the length of the seat cushion

in the front seat (p. 198)

•

Massage settings

*

 in the front seat

(p. 196)

•

Adjusting the side support

*

 in the front

seat (p. 199)

•

Adjusting the lumbar support

*

 in the front

seat (p. 200)

•

Adjusting the passenger seat from the
driver's seat

*

 (p. 201)

•

Angling the door mirrors (p. 179)

•

Settings for head-up display

*

 (p. 150)

Massage settings

*

 in the front seat

Both the multi-function control on the side of
the seat and the centre display can be used in
order to change the settings. The range of
settings is shown in the centre display.

Multi-function control, located on the side of the

seat's seating section.

Settings for massage

The following setting options are available for
massage:

•

On

/

Off

: Select

On

/

Off

 in order to switch

on/off the massage function.

•

Programs 1-5

: There are 5 preset mas-

sage programs. Select between

Swell

,

Tread

,

Advanced

,

Lumbar

 and

Shoulder

.
