Using windscreen and headlamp

washers

Windscreen and headlamp washers are
designed to clean the windscreen and head-
lamps. Windscreen and headlamp washers
are started using the right-hand stalk switch.

Starting windscreen and headlamp
washers

Washing function, right-hand stalk switch.

–

Move the right-hand stalk switch toward
the steering wheel to start the windscreen
and headlamp washers.
> The windscreen wipers will make sev-

eral more sweeps once the stalk switch
has been released.

Using the rain sensor (p. 178)

Avoid activating the washer system when
it is frozen or the washer reservoir is
empty, otherwise there is a risk of damag-
ing the pump.

Headlamp washing

To save fluid, the headlamps are washed auto-
matically at a defined interval when the head-
lamps are switched on.

Reduced washing

If only approx. 1 litre (1 qt) of washer fluid
remains in the reservoir and the message

Washer fluid

Level low, refill

, together with

the

symbol, is shown in the driver dis-

play, then the supply of washer fluid to the
headlamps is switched off. This is to prioritise
cleaning the windscreen and the visibility
through it. The headlamps are only washed if
main or dipped beam is switched on.

Related information

•

•

Using automatic rear windscreen wiping
when reversing (p. 182)

•

Wiper blades and washer fluid (p. 177)

•

Using the rain sensor's memory function
(p. 179)

•

Using the rear window wiper and washer
(p. 181)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

181

•

Filling washer fluid (p. 661)

•

•

•

•

Using the rain sensor (p. 178)

Using the rear window wiper and

washer

The rear windscreen washer and wiper are
designed to clean the rear window. Washing/
wiping is started and settings are changed by
means of the right-hand steering wheel stalk
switch.

Activating the rear window wiper and
washer

NOTE

The rear window wiper motor is equipped
with overheating protection which means
that it is switched off if it overheats. The
rear window wiper works again after a
cooling-down period.

Select

for intermittent wiping with

the rear window wiper.

Select

for continuous speed with the

rear window wiper.

–

Move the right-hand steering wheel stalk
switch forward to start rear window
washing and wiping.

Related information

•

•

Using windscreen and headlamp washers
(p. 180)

•

Using automatic rear windscreen wiping
when reversing (p. 182)

•

Using the rain sensor's memory function
(p. 179)

•

Wiper blades and washer fluid (p. 177)

•

Filling washer fluid (p. 661)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

182

•

•

•

•

Using the rain sensor (p. 178)

Using automatic rear windscreen

wiping when reversing

Engaging reverse gear while the windscreen
wipers are switched on initiates rear window
wiping. The function stops when reverse gear
is disengaged.

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

My Car

Wipers

3. Select

Auto Rear Wiper

to activate/deac-

tivate wiping when reversing.

If the rear windscreen wiper is already operat-
ing at a constant speed then no change takes
place when reverse gear is engaged.

Related information

•

•

Using windscreen and headlamp washers
(p. 180)

•

Wiper blades and washer fluid (p. 177)

•

Using the rain sensor's memory function
(p. 179)

•

Using the rear window wiper and washer
(p. 181)

•

Filling washer fluid (p. 661)

•

•

•

•

Storing position for seat, door mirrors and
head-up display

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

184

Manual front seat

The car's front seats have a range of setting
options in order to enhance comfort.

Raise/lower the front edge of the seat
cushion

by pumping up/down.

Change the length

of the seat cushion by

pulling the lever up and moving the seat
cushion forward/backward by hand.
Adjust the seat forward/backward by lift-
ing the handle and adjusting the distance
to the steering wheel and pedals. Check
that the seat is locked after the position
has been adjusted.
Change the lumbar support

by pressing

the button upward/downward/forward/
back

Raise/lower the seat by means of adjust-
ing the control up/down.
Change the backrest inclination by turning
the control knob.

WARNING

Adjust the position of the driver's seat

before setting off, never while driving.

Make sure that the seat is in locked posi-

tion in order to avoid personal injury in the

event of heavy braking or an accident.

Related information

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Only applies to the driver's seat.

Applicable to four-way lumbar support

. Two-way lumbar support

is adjusted forwards/backwards.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

185

Power

front seat

The car's front seats have a range of setting
options in order to enhance comfort. The
power seat can be moved forwards/back-
wards and upwards/downwards. The front
edge of the seat cushion can be raised/
lowered as well as adjusted in length

and the

backrest inclination can be changed. The
lumbar support

can be adjusted upward/

downward/forward/backward.

Seat setup can take place when the engine is
running and within a certain time after unlock-
ing the door without the engine running.
Adjustment can also be performed within a
certain time after the engine has been
switched off.

The power seats have overload protection
that is triggered if any seat is blocked by an
object. If this happens, remove the object
and then move the seat again.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

Adjusting the power

front seat (p. 185)

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting the power

front seat

Set the preferred seat position using the con-
trol on the front seat's seating section. To set
the various comfort functions, turn the multi-
function control

up/down.

The illustration shows the controls from a car with
four-way lumbar support

. Cars with two-way lumbar

support

do not have the rotatable multifunction con-

trol.

In cars with four-way lumbar support

turn the multifunction control

up/down to

set the different comfort functions. In cars
with two-way lumbar support

, use the

round button to adjust the lumbar support
forward/backward.
Raise/lower the seat cushion front edge
by adjusting the control up/down.

Applicable to four-way lumbar support

. Two-way lumbar support

is adjusted forwards/backwards.

Not available in cars with two-way lumbar support

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

186

Raise/lower the seat by means of adjust-
ing the control up/down.
Move the seat forward/backward by
adjusting the control forward/backward.
Change the backrest inclination by adjust-
ing the control forward/backward.

Only one movement (forward/back/up/down)
can be made at a time.

The backrests of the front seats cannot be
lowered fully forward.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

Power

front seat (p. 185)

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Storing position for seat, door

mirrors and head-up display

You can store the position for power

seat,

door mirrors and head-up display

in the

memory buttons.

Store two different positions for the power

seat, the door mirrors and the head-up dis-
play

using the memory buttons. The buttons

are located on the inside of one of the front
doors or both

Button

for storing settings.

Memory button.

Storing a position

1. Adjust seat, door mirrors and head-up dis-

play to the desired position.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

187

2. Press and hold the

button depressed.

The light indicator in the button illumi-
nates.

3. Within three seconds, press and hold the

button.

> When the position has been stored in

the selected memory button, an acous-
tic signal can be heard and the light
indicator in the

button extinguishes.

If none of the memory buttons is depressed
within three seconds then the

button extin-

guishes and no storing takes place.

The seat, the door mirrors or the head-up-dis-
play must be readjusted before a new memory
can be set.

Related information

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Angling the door mirrors (p. 171)

•

•

Settings for head-up display

(p. 142)

Using a stored position for seat,

door mirrors and head-up display

If the positions for the power

seat, the door

mirrors and the head-up display

have been

stored, they can be activated by using the
memory buttons.

Using a stored setting

A stored setting can be used with the front
door either open or closed:

Open front door

–

Depress one of the memory buttons

(

)

(

) with a short press. Power seat,

door mirrors and head-up display move
and then stop at the positions stored in
the selected memory button.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

188

Closed front door

–

Hold one of the memory buttons

(

) or

(

) depressed until seat, door mirrors

and head-up display stop in the positions
that are stored in the selected memory
button.

If the memory button is released, the move-
ment of the seat, door mirrors and head-up
display will be stopped.

WARNING

•

Because the driver's seat can be
adjusted with the ignition off, children
should never be left unattended in the
vehicle.

•

Movement of the seat can be STOP-
PED at any time by pressing any but-
ton on the power seat control panel.

•

Do not adjust the seat while driving.

•

Make sure there is nothing under the
seats when they are being adjusted.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Angling the door mirrors (p. 171)

•

•

Settings for head-up display

(p. 142)

Massage settings

in the front seat

Both the multi-function control on the side of
the seat and the centre display can be used in
order to change the settings. The range of
settings is shown in the centre display.

Multi-function control, located on the side of the

seat's seating section.

Settings for massage

The following setting options are available for
massage:

•

Off

: Select

Off

in order to switch

on/off the massage function.

•

Programs 1-5

: There are 5 preset mas-

sage programs. Select between

Swell

Tread

Advanced

Lumbar

and

Shoulder

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

189

•

Intensity

: Select between

Low

Normal

and

High

•

Speed

: Select between

Slow

Normal

and

Fast

Restarting massage

The massage function is deactivated automat-
ically after 20 minutes. Reactivation of the
function is performed manually.

–

Tap on

Restart

, which is shown in the

centre display, to restart the selected mas-
sage program.
> The massage program restarts. If no

action is taken, the message remains
shown in the top view.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting massage settings

in the

front seat

Both the multi-function control on the seat
and the centre display can be used in order to
change the settings. The range of settings is
shown in the centre display.

Adjusting massage settings in the
front seat

The front seat has massage in the backrest.
The massage is performed by air cushions that
can massage with different settings.

The massage function can only be activated
when the car's engine is running.

1. Activate the multi-function control by turn-

ing the control

upwards/downwards.

The seat settings view will be shown in
the centre display.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

190

2. Select

Massage

in the seat settings view.

3. To choose between the different massage

functions, select either directly in the cen-
tre display or by moving the cursor up/
down using the multi-function control's
upper

/lower

button. Change the

setting in the selected function directly in
the centre display, by pressing the arrows,
or by using the multi-function control's
front

/rear

button.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting

the length of the seat

cushion in the front seat

Depending on equipment level selected, seat
cushion length is adjusted either using the
multifunction control

on the side of the

seat's seat cushion, or manually using a con-
trol on the front of the seat cushion.

Adjusting the length of the seat
cushion using the multifunction
control

Multifunction control, located on the side of the seat

cushion.

1. Activate the multi-function control by turn-

ing the control

upwards/downwards.

The seat settings view will be shown in
the centre display.

2. Select

Cushion extension

in the seat set-

tings view.

•

Press the front section of the four-way
button

to extend the seat cushion.

•

Press the rear section of the four-way
button

to retract the seat cushion.

Adjusting the length of the seat
cushion manually

Control for seat cushion adjustment.

1. Grip the handle

on the front of the seat

and pull upwards.

2. Adjust the length of the seat cushion.

3. Release the handle and make sure that the

seat cushion has reached the correct posi-
tion.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

191

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting the side support

in the

front seat

Increase comfort in the front seat by adjust-
ing the sides of the backrest.

Multi-function control, located on the side of the

seat's seating section.

The sides of the backrest can be adjusted to
provide side support. Both the multi-function
control on the seat and the centre display can
be used in order to change the settings. The
range of settings is shown in the centre dis-
play.

To adjust the side support:

1. Activate the multi-function control by turn-

ing the it up/down

. The seat settings

view will be shown in the centre display.

2. Select

Side bolsters

in the seat settings

view.

•

Press the front section of the four-way
button to increase side support

•

Press the rear section of the four-way
button to decrease side support

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

192

Adjusting the lumbar support

the front seat

The lumbar support is adjusted using a con-
trol on the side of the seat cushion.

Multifunction control in cars with four-way lumbar
support

Control in cars with two-way lumbar support

The lumbar support is adjusted using the mul-
tifunction control in cars with four-way lumbar
support

, or using the round button in cars

with two-way lumbar support

. The control is

located on the side of the seat's seating sec-
tion. Depending on the equipment level
selected, the lumbar support can be adjusted
forward/back and up/down (four-way lumbar
support) or forward/back (two-way lumbar
support).

Adjust the lumbar support in the car
using the four-way lumbar support

1. Activate the multi-function control by turn-

ing the control

upwards/downwards.

The seat settings view will be shown in
the centre display.

2. Select

Lumbar

in the seat settings view.

•

Press the round button up

/down

to move the lumbar support upwards/
downwards.

•

Press the front section

of the button

to increase lumbar support.

•

Press the rear section

of the button

to decrease lumbar support.

Adjust the lumbar support in the car
using the two-way lumbar support

1. Press the front section

of the round

button to increase lumbar support.

2. Press the rear section

of the round but-

ton to decrease lumbar support.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

193

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting the passenger seat from

the driver's seat

The front passenger seat can be adjusted
from the driver's seat.

Activating the function

The function is activated via the function view
in the centre display:

Press the

Adjust Passenger

Seat

button to activate.

Adjust passenger seat

From activation of the function, the driver
must adjust the passenger seat within 10 sec-
onds. If no adjustment is made within this
time the function is deactivated.

The driver adjusts the passenger seat using
the controls on the driver's seat:

Move the passenger seat forward/back-
ward by adjusting the control forward/
backward.
Change the passenger seat's backrest
inclination by adjusting the control for-
ward/backward.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

194

•

•

•

•

Lowering the backrests in the rear

seat

The rear seat's backrest is divided into two
parts. The two parts can be folded forward
individually.

WARNING

•

Adjust the seat and fix it before driving
away. Take care when adjusting the
seat. Uncontrolled or careless adjust-
ment can lead to trapping injuries.

•

When loading long objects, they must
always be strapped in securely to avoid
injury and damage during sudden brak-
ing.

•

Always switch off the engine and apply
the parking brake when loading and
unloading the car.

•

For cars with automatic gearbox, set
the gear selector in

to prevent it from

being moved by mistake.

There must be no objects on the rear seat
when the backrest is to be folded down.
The seat belts must not be connected
either. Otherwise there is a risk of damag-
ing the rear seat upholstery.
