KEY, LOCKS AND ALARM

* Option/accessory.

245

Ordering more remote control keys

The car is supplied with two remote control
keys. A button-less key is supplied if the car
is equipped with keyless locking and unlock-
ing

. Additional keys can be ordered.

A total of twelve keys can be programmed and
used for one single car. If additional keys are
ordered, additional driver profiles are added -
one per new remote control key. This also
applies for the key tag.

Loss of a remote control key

If you lose a remote control key then a new
one can be ordered at a workshop - an author-
ised Volvo workshop is recommended. The
remaining remote control keys must be taken
to the workshop. The code of the missing key
must be erased from the system as a theft
prevention measure.

The current number of keys registered to the
car can be checked via driver profiles in the
centre display's top view, select

Settings

System

Driver Profiles

Related information

•

Remote control key (p. 237)

Red Key - restricted remote

control key

A Red Key makes it possible for the car's
owner to set limitations for certain of the
car's properties. The limitations are intended
to encourage the car to be driven in a safe
manner, e.g. when being loaned out.

For a Red Key, it is possible to define the car's
maximum speed, set speed reminders and
determine the loudspeaker system's maxi-
mum volume. In addition, some of the car's
driver support systems will always be active.
Other functions of the key are the same as
those of a normal remote control key.

The restrictions are intended to act as meas-
ures to reduce the risk of accidents, thereby
making it feel safer to hand over the car to e.g.
young drivers, valet parking or a workshop.

Driver profile for Red Key

A Red Key is connected to a special Red Key
driver profile, and when it is active, the key's
settings cannot be changed. It is not possible
to change to another driver profile either; this
requires a normal remote control key.

The Red Key driver profile is activated when
the car is unlocked with a Red Key without a
normal remote control key in the vicinity.

NOTE

In the event of a change of driver, the car
must be locked and unlocked in order to
activate a new driver profile.

Ordering Red Key

One or more Red Key can be ordered from a
Volvo dealer. A total of eleven keys with
restrictions can be programmed and used for
a single car - at least one must be a normal
remote control key.

Related information

•

Settings for Red Key

(p. 246)

•

Remote control key (p. 237)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

246

Settings for Red Key

The holder of a regular remote control key
can change settings for a Red Key. However,
certain driver support functions are always
active.

To change setting:

1. Unlock the car with the normal remote

control key.

2. Tap on

Settings

in the centre display's

top view.

3. Press

System

Driver Profiles

Red

Key

> The following settings can be defined:

•

Set Time Gap For Adaptive Cruise
Control

•

Reduced Maximum Volume

•

Max Speed Limit

•

Speed Limit Warning

Details and settings on first use

Set Time Gap For Adaptive Cruise Control

Set the time gap (1 is the shortest and 5 is
the longest gap)

On first use, the setting is

5.0

Reduced Maximum Volume

Lower maximum volume for media
sources

On first use, the function is "On".

Max Speed Limit

Set a maximum speed for this key

On first use, the function is "On" and the
speed is 120 km/h (75 mph).

•

Setting interval: 50-250 km/h
(30-160 mph)

•

Increments: 1 km/h (1 mph)

Speed restriction symbol.

Speed Limit Warning

Warns when car moves above set values

On first use, the function is "On" and the val-
ues are 50, 70 and 90 km/h (30, 45 and
55 mph).

•

Setting interval: 0-250 km/h (0-160 mph)

•

Increments: 1 km/h (1 mph)

•

Max. number of simultaneous reminders:
6

Driver support functions

The following driver support functions will
always be active for the user of a Red Key:

•

Blind Spot Information (BLIS)

•

Lane assistance (LKA)

•

Distance Warning

•

City Safety

•

Driver Alert Control (DAC)

•

Road Sign Information

Related information

•

Red Key - restricted remote control key

(p. 245)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

* Option/accessory.

247

Detachable key blade

The remote control key contains a detachable
key blade of metal with which a number of
functions can be activated and some opera-
tions carried out.

The key blade's unique code is provided by
authorised Volvo workshops, which are rec-
ommended when ordering new key blades.

The key blade's application areas

Using the remote control key's detachable key
blade

•

the left-hand

front door can be opened

manually if central locking cannot be acti-
vated with the remote control key

•

all doors are emergency-locked

•

the rear doors' mechanical child safety
locks can be activated and deactivated.

The button-less key

does not have a detacha-

ble key blade. If necessary, use the detachable
key blade from the normal remote control key.

Detaching the key blade

Hold the remote control key with the

front visible and the Volvo logo facing the
right way - slide the button at bottom
edge by the key ring to the right. Guide
the front side's shell a few millimetres
upwards.

The shell will then come free and can

be lifted off the key.

Detach the key blade by angling it up.

Return the key blade to its intended posi-
tion in the remote control key after use.

Refit the shell by pressing it downward

until a clicking sound is heard.

Then slide the shell back.

> A further click will indicate that the

shell is securely attached.

This applies whether the car is left-hand drive or right-hand drive.

Supplied with cars equipped with keyless locking/unlocking

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

248

Related information

•

Locking and unlocking with the detacha-
ble key blade (p. 248)

•

Remote control key (p. 237)

Locking and unlocking with the

detachable key blade

Amongst other things, the detachable key
blade can be used to unlock the car from the
outside - e.g. if the remote control key's bat-
tery has become discharged.

Unlocking

Pull out the front door handle on the left-
hand side

to its end position so that the

lock cylinder become visible.

Insert the key in the lock cylinder.

Turn clockwise 45 degrees so that the key
blade is pointing straight back.

Turn the key back 45 degrees to its star-
ting position. Remove the key from the
lock cylinder and release the handle so
that the rear section of the handle is rest-
ing against the car again.

5. Pull out the handle.

> The door opens.

Locking will be performed in the same way,
but with an anticlockwise turn 45 degrees
instead of clockwise in step (3).

This applies whether the car is right-hand drive or left-hand drive.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

249

Switch off the alarm and start the car

NOTE

When the door is unlocked using the key
blade and is then opened, the alarm is trig-
gered.

The backup reader's location in the cup holder.

Deactivate the alarm as follows:

1. Place the remote control key on the key

symbol in the backup reader in the bottom
of the cup holder in the tunnel console.

2. Then turn the start knob clockwise and

release it.
> The alarm signal stops sounding and

the alarm is switched off.

Locking

It is also possible to lock the car with the
remote control key's detachable key blade e.g.

in the event of a loss of power or if the key's
battery has become discharged.

The left-hand front door can be locked with its
lock cylinder and the detachable key blade.

Other doors have no lock cylinders and
instead have a lock switch on the end of each
door which must be depressed using the key
blade - they are then mechanically locked/
blocked to prevent them being opened from
outside.

The doors can still be opened from the inside.

Manual locking of the door. Not to be mixed up with

the child safety locks.

–

Remove the detachable key blade from
the remote control key. Insert the key
blade in the hole for lock reset and press
the key in until it bottoms, approx. 12 mm
(0.5 inches).

The door can be opened from both the
outside and the inside.
The door is blocked against opening from
the outside. To return to position A, the
inner door handle must be opened.

The doors can also be unlocked with the
unlock button on the remote control key or
with the central locking button on the driver's
door.

NOTE

•

A door's lock reset only locks that par-
ticular door - not all doors simultane-
ously.

•

A manually locked rear door with acti-
vated manual or electric child safety
locks cannot be opened from either the
outside or the inside. A rear door that is
locked in this way can only be
unlocked with the remote control key
or central locking button.

Related information

•

Starting the car (p. 432)

•

Detachable key blade (p. 247)

•

Activating and deactivating alarms

(p. 271)

•

Replacing the battery in the remote con-
trol key (p. 241)

•

Remote control key (p. 237)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

250

Immobiliser

The electronic immobiliser is a theft protec-
tion system that prevents an unauthorised
person from starting the car.

The car can only be started with the correct
remote control key.

The following error message in the driver dis-
play is related to the electronic immobiliser:

Symbol Message

Specification

Car key not
found

See
Owner's
manual

Error reading the
remote control
key during star-
ting - place the
key on the key
symbol in the cup
holder and try
again.

Related information

•

Remote control key (p. 237)

•

Ordering more remote control keys
(p. 245)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

* Option/accessory.

251

Type approval for the remote

control key system

Type approval for the car's remote key sys-
tem can be seen in the following tables.

Lock system keyless start (Passive
Start) and keyless locking/unlocking
(Passive Entry

)

CEM marking for the remote control key system. For

supplementary type approval numbers, see following

tables.

Country/Area

Type approval

Europe

Delphi Deutschland GmbH, 42367 Wuppertal hereby declares that
this VO3-134TRX conforms to the essential property requirements
and other relevant provisions contained in directive 2014/53/EU
(RED).

The full text of the EU declaration of conformity can be found at
support.volvocars.com.

Jordan

TRC/LPD/2014/250

Serbia

P1614120100

Argentina

CNC ID: C-14771

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

253

Country/Area

Type approval

Namibia

TA-2016-02

South Africa

TA-2014-1868

Remote control key

Country/Area

Type approval

Europe

Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio
equipment HUF8423 conforms to directive 2014/53/EU.

The full text of the EU declaration of conformity can be found at
support.volvocars.com.

Wavelength: 433.92 MHz

Maximum radiated transmission power: 10 mW

Manufacturer: Huf Hülsbeck & Fürst GmbH & Co. KG, Steeger Str. 17, 42551
Velbert, Germany

Jordan

TRC/LPD/2015/104

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

254

Country/Area

Type approval

Morocco

AGREE PAR L'ANRT MAROC

Numéro d’agrément: MR 10668 ANRT 2015

Date d’agrément: 24/07/2015

Mexico

IFETEL

Marca: HUF

Modelo (s): HUF8423

NOM-121-SCT1-2009

La operación de este equipo está sujeta a las siguientes dos condiciones: (1)
es posible que este equipo o dispositivo no cause interferencia perjudicial y (2)
este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la
que pueda causar su operación no deseada.

Namibia

TA-2015-102

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

256

Country/Area

Type approval

South Africa

TA-2015-432

The United Arab
Emirates

Key Tag

Country/Area

Type approval

Europe

Huf Hülsbeck & Fürst GmbH & Co. KG hereby declares that this type of radio
equipment HUF8432 conforms to directive 2014/53/EU.

The full text of the EU declaration of conformity can be found at
support.volvocars.com.

Wavelength: 433.92 MHz

Maximum radiated transmission power: 10 mW

Manufacturer: Huf Hülsbeck & Fürst GmbH & Co. KG, Steeger Str. 17, 42551
Velbert, Germany

Jordan

TRC/LPD/2015/107

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

257

Country/Area

Type approval

Morocco

AGREE PAR L'ANRT MAROC

Numéro d’agrément: MR 10667 ANRT 2015

Date d’agrément: 24/07/2015

Mexico

IFETEL

Marca: HUF

Modelo (s): HUF8432

NOM-121-SCT1-2009

Namibia

TA-2015-103

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

260

Keyless and touch-sensitive

surfaces

With the keyless locking and unlocking func-
tion, carrying the remote control key in a
pocket or bag will suffice. The car is locked or
unlocked via a touch-sensitive surface on the
door handle.

Touch-sensitive surfaces

Door handle

The outside of the door handles contains a
recess for locking, while the inside contains a
touch-sensitive surface for unlocking.

Touch-sensitive recess for locking

Touch-sensitive surface for unlocking

NOTE

It is important that only one touch-sensi-
tive surface is activated at a time. Gripping
the handle while touching the lock surface
risks giving double commands. This means
that the requested activity (locking/unlock-
ing) will not be executed, or will be execu-
ted with a delay.

Boot lid handle

The boot lid handle has a rubberised pressure
plate that is only used for unlocking.

NOTE

Be aware that the system may be activated
in connection with car washing if the
remote control key is in range.

Related information

•

Keyless locking and unlocking

(p. 261)

•

Keyless unlocking of the boot lid

(p. 262)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Volvo S60 Twin Engine (2020 year). Manual in english - page 15
