CLIMATE

229

Symbol Message

Specification

Parking climate

Unavailable, not connected to the
mains

C

The parking climate control cannot be activated if the charging cable is not connected. Con-
nect the charging cable.

Parking climate

Limited Charge level too low

The running time for parking climate control is limited when the state of charge in the hybrid
battery is low. Start the car.

A

An authorised Volvo workshop is recommended.

B

Applies to fuel-driven heater.

C

Applies to electric heater.

Related information

•

Parking climate (p. 221)

CLIMATE

230

Heater

The heater has two subfunctions that help to
heat the passenger compartment or engine in
different situations.

The heater has two subfunctions:

•

Parking heater - heats the passenger com-
partment, if necessary, when the parking
climate control's preconditioning is acti-
vated.

•

Additional heater - heats the passenger
compartment and engine, if necessary,
during driving.

Either a fuel-driven heater or an electric heater
is used, depending on the market

12

.

The heater is fitted in the front right-hand
wheel housing.

NOTE

When the heater is running

13

, smoke may

be emitted from the right-hand front wheel
housing and a low hum may be heard. A
ticking sound from the fuel pump may also
be heard from the rear section of the car.
This is perfectly normal.

Battery and charging

The heater is powered by the car's hybrid bat-
tery. If the charge level of the hybrid battery is
too low, then the heater is switched off auto-
matically and the driver display shows a mes-
sage.

NOTE

Make sure that there is enough charge in
the battery if the heater needs to be used.

Fuel and refuelling

14

Warning label on fuel filler flap.

The heater uses fuel from the car's normal fuel
tank.

If the car is parked on a steep hill, the front of
the car should point downhill to ensure that
there is a supply of fuel to the heater.

If the level in the fuel tank is too low then the
heater is switched off automatically and the
driver display shows a message.

NOTE

Make sure there is enough fuel in the car's
fuel tank if the heater needs to be used.

WARNING

Fuel which spills out could be ignited.

Switch off the fuel-driven heater before

starting to refuel.

Check in the driver display that

the heater is switched off. This

symbol is lit when it is working as

a parking heater.

Related information

•

Climate (p. 198)

•

Parking heater (p. 231)

•

Additional heater (p. 232)

12

An authorised Volvo dealer has information regarding which markets use which type of heater.

13

Applicable to fuel-driven auxiliary heater.

14

Applies to fuel-driven heater.

CLIMATE

}}

231

Parking heater

The parking heater heats the passenger com-
partment as necessary before driving if the
car's preconditioning is activated.

The parking heater is one of two subfunctions
of the car's heater. The heater is fitted in the
front right-hand wheel housing.

When this symbol illuminates in the
driver display, the parking heater
may be active

15

.

NOTE

When the heater is running

16

, smoke may

be emitted from the right-hand front wheel
housing and a low hum may be heard. A
ticking sound from the fuel pump may also
be heard from the rear section of the car.
This is perfectly normal.

The parking heater starts automatically if the
parking climate's preconditioning is activated
and the passenger compartment needs to be
heated up.

Depending on factors such as battery level,
passenger compartment temperature and
ambient temperature, the heater has different
running times, but never longer than 40
minutes.

NOTE

Make sure there is enough fuel in the car's
fuel tank if the parking heater needs to be
used

17

.

Make sure that there is enough charge in
the hybrid battery if the parking heater
needs to be used.

WARNING

Do not use preconditioning

18

:

•

In unventilated spaces indoors.
Exhaust gases are emitted if the heater
starts.

•

In locations with combustible or flam-
mable material nearby. Fuel, gas, long
grass, sawdust, etc. may ignite.

•

When there is a risk that the heater’s
exhaust line may be blocked. For
example, deep snow inside the front
right-hand wheel housing can obstruct
the heater’s ventilation.

Remember that the preconditioning can be

started by a timer that has been set for a

long time in advance.

WARNING

If there is a smell of fuel, unusual amounts

of smoke, black smoke, or unusual sounds
coming from the parking heater

19

, switch

off the heater and, if possible, pull out its

fuse. Volvo recommends that an authorised

Volvo workshop should be contacted for

repair.

15

Applies to fuel-driven heater.

16

Applicable to fuel-driven auxiliary heater.

17

Applicable to fuel-driven auxiliary heater.

18

Applicable to fuel-driven auxiliary heater.

19

Applicable to fuel-driven auxiliary heater.

||

CLIMATE

232

Related information

•

Heater (p. 230)

•

Additional heater (p. 232)

Additional heater

The auxiliary heater helps to heat the passen-
ger compartment and engine while driving.

The additional heater is one of two subfunc-
tions of the car's heater. The heater is fitted in
the front right-hand wheel housing.

NOTE

When the heater is running

20

, smoke may

be emitted from the right-hand front wheel
housing and a low hum may be heard. A
ticking sound from the fuel pump may also
be heard from the rear section of the car.
This is perfectly normal.

The additional heater starts and is controlled
automatically when heating is required while
the car is being driven.

It switches off automatically when the car is
switched off.

NOTE

Make sure there is enough fuel in the car's
fuel tank if the auxiliary heater needs to be
used

21

.

Related information

•

Heater (p. 230)

•

Parking heater (p. 231)

•

Activating and deactivating automatic
start of auxiliary heater (p. 233)

20

Applicable to fuel-driven auxiliary heater.

21

Applicable to fuel-driven auxiliary heater.

CLIMATE

233

Activating and deactivating

automatic start of auxiliary heater

The auxiliary heater helps to heat the passen-
ger compartment and engine while driving.

It is possible to set whether automatic start
for the additional heater should be activated/
deactivated.

1. Press

Settings

 in the top view in the cen-

tre display.

2. Press

Climate

.

3. Select

Additional Heater

 to activate/

deactivate automatic start of the addi-
tional heater.

NOTE

Volvo recommends that the automatic
start for the additional heater should be
switched off for short driving distances

22

.

NOTE

If the auxiliary heater's automatic starting
is deactivated, this may impede comfort in
the passenger compartment as the climate
control system will then have no heat
source during electrical operation.

Related information

•

Additional heater (p. 232)

22

Applicable to fuel-driven auxiliary heater.

KEY, LOCKS AND ALARM

KEY, LOCKS AND ALARM

* Option/accessory.

236

Lock confirmation

The car indicates with hazard warning flash-
ers when the car is locked or unlocked.

Exterior indication

Locking

•

The car's hazard warning flashers indicate
locking by flashing and retracting the door
mirrors

1

.

Unlocking

•

The car's hazard warning flashers indicate
unlocking by two flashes and extending
the door mirrors

1

.

All doors, the boot lid and the bonnet must be
closed for the car to indicate that it is locked.
If locking takes place with just the driver door
closed

2

, locking will take place but the lock

indication with hazard warning flashers will
only take place when all doors, the boot lid
and the bonnet have been closed.

Lock and alarm indicator on the
instrument panel

The lock and alarm indicator shows the status
of the locking system:

•

A long flash indicates locking.

•

Short flashes indicate that the car is
locked.

•

Rapid flashes after disarming the alarm

*

indicate that the alarm has been triggered.

Indication in lock buttons

Front door

Lock buttons with indicator lamp in the front door.

An illuminated indicator lamp in the lock but-
ton of either front door indicates that all doors
are locked. If any door is opened, the lamp will
extinguish in both doors.

1

Only for cars with retractable power door mirrors.

2

Not applicable to with cars equipped with keyless locking/unlocking

*

.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

237

Rear door

*

Lock button with indicator lamp in the rear door.

An illuminated indicator lamp in the lock but-
ton for one of the doors indicates that the door
in question is locked. If any door is unlocked,
its lamp will extinguish while the others will
continue to illuminate.

Other indication

The home safe lighting and approach light
functions can also be activated when locking
and unlocking.

Related information

•

Lock indication setting (p. 237)

•

Approach light duration (p. 161)

•

Using home safe lighting (p. 161)

Lock indication setting

It is possible to select various options for how
the car confirms locking and unlocking in the
settings menu in the centre display.

To change the locking response setting:

1. Tap on

Settings

 in the centre display's

top view.

2. Press

My Car

Locking

.

3. Press

Visible Locking Feedback

 to

select when the car is to give a visible
response:

•

Lock

•

Unlock

•

Both

Or switch off the function by selecting

Off

.

To change the setting for retractable rearview
mirrors

*

 when locking:

1. Tap on

Settings

 in the centre display's

top view.

2. Press

My Car

Mirrors and

Convenience

.

3. Select

Fold Mirror When Locked

 to acti-

vate or deactivate the function.

Related information

•

Lock confirmation (p. 236)

Remote control key

The remote control key locks and unlocks the
doors and boot lid. The remote control key
needs to be inside the car for it to be started.

Remote control key

3

 or key tag (Key Tag)

*

.

The remote control key is not physically used
when starting since the car is equipped with
support for keyless starting (Passive Start) as
standard. You simply need to have the key in
the front part of the passenger compartment.

For cars equipped with keyless locking and
unlocking (Passive Entry)

*

 the key can be any-

where in the car to start the car. In this case, a
slightly smaller, lighter key tag (Key Tag) is
also supplied.

The remote control keys can be linked to dif-
ferent driver profiles to save personal preferen-
ces in the car.

||

KEY, LOCKS AND ALARM

* Option/accessory.

238

Remote control key buttons

The remote control key has four buttons - one on the

left-hand side and three on the right-hand side.



Locking

 – Pressing the button locks the

doors, boot lid and fuel filler flap and also
arms the alarm

*

.

Press and hold to close all of the windows
and the panorama roof

*

 simultaneously.



Unlocking

 – Pressing the button unlocks

the doors and boot lid and also deacti-
vates the alarm.
A longer press opens all windows simulta-
neously. This total airing function can be
used, for example, to quickly air the car in
hot weather.


Boot lid

 – Unlocks and disarms the

alarm for the boot lid only. The boot lid is

opened mechanically, by spring pressure,
using a long press.


Panic function

 – Used to attract atten-

tion in an emergency. Press and hold the
button for at least 3 seconds or press it
twice within 3 seconds to activate the
direction indicators and the horn. The
function can be turned off with the same
button once it has been active for at least
5 seconds. Otherwise the function
switches off automatically after 3 minutes.

WARNING

If anyone is left in the car, make sure the

power windows and panoramic roof

*

 are

de-energised by always taking the remote

control key with you when you leave the

car.

NOTE

Be aware of the risk of locking the remote
control key in the car.

•

A remote control key or key tag left in
the car will be deactivated when the
car is locked and the alarm is armed
using another valid key. The "Double
lock" function is also deactivated. The
key left behind is reactivated when the
car is unlocked.

•

A Red Key left in the car will be deacti-
vated even when the car is locked
using Volvo On Call, and reactivated
when the car is unlocked using Volvo
On Call or with another valid key.

Button-less key (Key Tag)

*

The key tag provided with the keyless locking
and unlocking function works in the same way
as the standard remote control key as regards
keyless starting and locking and unlocking.
The key is waterproof to a depth of approx. 10
metres (30 feet) for up to 60 minutes. It has
no detachable key blade and the battery can-
not be replaced.

3

The figure is schematic - parts may vary depending on car model.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

239

Red Key - restricted remote control
key

*

A Red Key is a key that makes it possible to
set restrictions for some of the car's proper-
ties, e.g. the car's maximum speed and the
loudspeaker system's maximum volume. A key
for any car owner who wants their car to be
driven responsibly even when someone else is
driving it.

Interference

Remote control key functions for keyless star-
ting and keyless locking and unlocking

*

 can be

disrupted by electromagnetic fields and
screening.

NOTE

Avoid storing the remote control key close
to metal objects or electronic apparatus,
e.g. mobile phones, tablets, laptops or
chargers - preferably no closer than
10-15 cm (4-6 inches).

If there is still interference - use the remote
control key's detachable key blade to unlock
and then place the key in the backup reader in
the cup holder to disarm the car and allow the
car to be started.

NOTE

When the remote control key is placed in
the cup holder, make sure that no other car
keys, metal objects or electronic apparatus
(e.g. mobile phones, tablets, laptops or
chargers) are in the cup holder. Several car
keys close to each other in the cup holder
can cause interference with each other.

Related information

•

Starting the car (p. 432)

•

Locking and unlocking with the remote
control key (p. 239)

•

Remote control key range (p. 241)

•

Replacing the battery in the remote con-
trol key (p. 241)

•

Detachable key blade (p. 247)

•

Immobiliser (p. 250)

•

Linking remote control key to driver profile
(p. 136)

Locking and unlocking with the

remote control key

The buttons on the remote control key can be
used to lock and unlock all doors and the
boot lid simultaneously.

Locking with the remote control key

The figure is schematic - parts may vary depending

on car model.

–

Press the remote control key

 button to

lock the car.

For the lock sequence to be activated, the
driver door must be closed

4

. If any of the other

doors or the boot lid are open, these are
locked and alarmed

*

 only when they are

closed. The alarm's movement detectors

*

 are

activated when all the doors and the boot lid
are closed and locked.

4

If the car is equipped with keyless locking/unlocking

*

 then all side doors must be closed.

||

KEY, LOCKS AND ALARM

* Option/accessory.

240

NOTE

Be aware of the risk of locking the remote
control key in the car.

•

A remote control key or key tag left in
the car will be deactivated when the
car is locked and the alarm is armed
using another valid key. The "Double
lock" function is also deactivated. The
key left behind is reactivated when the
car is unlocked.

•

A Red Key left in the car will be deacti-
vated even when the car is locked
using Volvo On Call, and reactivated
when the car is unlocked using Volvo
On Call or with another valid key.

Locking when the boot lid is open

NOTE

If the car has been locked while the boot
lid is open, be careful not to leave the
remote control key in the cargo area when
the boot lid is closed and the car is com-
pletely locked

5

.

Unlocking with the remote control key

–

Press the remote control key

 button to

unlock the car.

Automatic relocking

If none of the doors or the boot lid is opened
within 2 minutes of unlocking, they are locked
automatically. This function prevents the car
from being left unlocked unintentionally.

When the remote control key does not
work

NOTE

Always try moving closer to the car and
making another unlock attempt.

If it is not possible to lock or unlock with the
remote control key, the battery may be dis-
charged - in which case, lock or unlock the
driver's door with the detachable key blade.

Related information

•

Settings for remotely controlled and inside
unlocking (p. 240)

•

Remote control key (p. 237)

•

Replacing the battery in the remote con-
trol key (p. 241)

•

Locking and unlocking with the detacha-
ble key blade (p. 248)

Settings for remotely controlled

and inside unlocking

It is possible to select different sequences for
remotely controlled unlocking.

To change setting:

1. Tap on

Settings

 in the centre display's

top view.

2. Press

My Car

Locking

Remote and

Interior Unlock

.

3. Select option:

•

All Doors

 - unlocks all doors simultane-

ously.

•

Single Door

 - unlocks the driver's

door. Unlocking all of the doors
requires two presses on the remote
control key's unlock button.

The settings made here also affect central
unlocking via opening handles from the inside.

Related information

•

Locking and unlocking with the remote
control key (p. 239)

•

Locking and unlocking from inside the car
(p. 264)

5

If the car is equipped with keyless locking/unlocking and the key is detected inside the car, the boot lid will not lock when it is closed.

*

KEY, LOCKS AND ALARM

}}

* Option/accessory.

241

Remote control key range

In order for the remote control key to work
properly it needs to be within a certain dis-
tance from the car.

For manual use

The remote control key's functions for e.g.
locking/unlocking that are activated by press-
ing on

 or

 have a range that extends

approx. 20 metres (65 feet) from the car.

If the car does not verify a button being
pressed - move closer and try again.

For keyless

*

 use

The marked area in the illustration shows areas cov-

ered by the system's antennas.

For keyless use, a remote control key or the
button-less key (Key Tag) must be within a
semicircular area with a radius of approx.

1.5 metres (5 feet) on both long sides and
approx. 1 metre (3 feet) from the boot lid.

NOTE

The remote control key functions may be
disrupted by surrounding radio waves,
buildings, topographical conditions, etc.
The car can always be locked/unlocked
with the key blade.

If the remote control key is removed
from the car

If the remote control key is removed
from the car when the engine is run-
ning, the warning message

Car key

not found



Removed from car

 is

shown in the driver display and an acoustic
reminder sounds when the last door is closed.

The message extinguishes when the key is
returned to the car, followed by a press of the
right-hand keypad's

O

 button, or when the last

door is closed.

Related information

•

Remote control key (p. 237)

•

Antenna locations for the start and lock
systems (p. 263)

•

Keyless and touch-sensitive surfaces

*

(p. 260)

Replacing the battery in the

remote control key

The battery in the remote control key needs
to be replaced when it has become dis-
charged.

NOTE

All batteries have a limited service life and
must eventually be replaced (does not
apply to Key Tag). The service life of the
battery varies depending on how often the
vehicle/key is used.

The battery for the remote control key should
be replaced if

•

the information symbol illuminates and the
message

Car key battery low

 is shown in

the driver display

•

the locks repeatedly do not react to sig-
nals from the remote control key within
20 metres (65 feet) of the car.

NOTE

Always try moving closer to the car and
making another unlock attempt.

||

KEY, LOCKS AND ALARM

* Option/accessory.

242

The battery in the button-less key

6

 (Key Tag)

cannot be replaced - a new key can be
ordered from an authorised Volvo workshop.

IMPORTANT

A discharged Key Tag must be handed
over to an authorised Volvo workshop. The
key must be deleted from the car since it is
still possible to use it to start the car via
back-up start.

Opening the key and changing the
battery

 Hold the remote control key with the

front visible and the Volvo logo facing the
right way - slide the button at bottom
edge by the key ring to the right. Slide the
front side's shell a few millimetres
upwards.

 The shell will then come free and can

be lifted off the key.

 Turn the key, move the button to the

side and slide the back shell a few milli-
metres upwards.

 The shell will then come free and can

be lifted off the key.

6

Supplied with cars equipped with keyless locking/unlocking

*

.

KEY, LOCKS AND ALARM

}}

243

Use a screwdriver or similar to turn the
battery cover anticlockwise until the mark-
ings meet at the

OPEN

 text.

Carefully lift away the battery cover by
pressing e.g. a fingernail into the recess.

Then prize the battery cover upwards.

The battery (

+

) side is facing upwards.

Then carefully prize loose the battery as
illustrated.

IMPORTANT

Avoid touching new batteries and their
contact surfaces with your fingers as this
may impair their function.

Install a new battery with the (

+

) side up.

Avoid touching the remote control key's
battery contacts with your fingers.

 Place the battery in the holder with the

edge down. Then slide the battery for-
wards so that it fastens under the two
plastic catches.

 Press the battery down so that it fas-

tens under the upper black plastic catch.

NOTE

Use batteries with the designation
CR2032, 3 V.

||

KEY, LOCKS AND ALARM

244

NOTE

Volvo recommends that the batteries to be
used in the remote control key fulfil UN
Manual of Test and Criteria, Part III, sub-
section 38.3. Batteries fitted in the factory
or replaced by an authorised Volvo work-
shop fulfil the above criteria.

Refit the battery cover and turn it clock-
wise until the marking aligns with the

CLOSE

 text.

 Reposition the rear side's shell and

press it down until a clicking sound can be
heard.

 Then slide the shell back.

> A further click will indicate that the

shell is properly positioned and securely
attached.

 Turn the remote control key over and

refit the front side's shell by pressing it
down until a clicking sound can be heard.

 Then slide the shell back.

> A further click will indicate that the

shell is securely attached.

IMPORTANT

Make sure that exhausted batteries are dis-
posed of in a manner which is kind to the
environment.

Related information

•

Locking and unlocking with the detacha-
ble key blade (p. 248)

•

Starting the car (p. 432)

•

Remote control key (p. 237)
