MAINTENANCE AND SERVICE

Car wash

WARNING

NOTE

The car should be washed as soon as it

Always have the engine cleaned by a work-

The car must only be washed by hand over

becomes dirty. Wash the car in a car wash with

shop. There is a risk of fire if the engine is hot.

the first few months. This is because the paint

oil separator. Use car shampoo.

is more delicate when it is new.

Handwashing

IMPORTANT

•

Remove bird droppings from the paintwork

Dirty headlamps have impaired functionality.

IMPORTANT

as soon as possible. Bird droppings contain

Clean them regularly, when refuelling for

chemicals that affect and discolour paintwork

If the car is painted with a matte clear coat,

example.

never use a washing program that finishes

very quickly. An authorised Volvo workshop is

recommended for the removal of any discol-

Do not use any corrosive cleaning agents or

with hot wax treatment.

oration.

cleaning agents with a pH value lower than

•

Hose down the underbody.

3.5 or higher than 11.5. Use water and a non-

High-pressure washing

scratching sponge.

When using high-pressure washing, use sweep-

•

Rinse the entire car until the dissolved dirt

has been removed so as to reduce the risk of

ing movements and make sure that the nozzle

does not come closer than 30 cm to the surface

scratches from washing. Do not spray directly

NOTE

of the car (the distance applies to all exterior

onto the locks.

Outside lighting such as headlamps and rear

parts). Do not spray directly onto the locks.

•

If necessary, use cold degreasing agent on

lamps may temporarily have condensation on

very dirty surfaces. Note that in this case, the

the inside of the lens. This is normal, all exte-

Testing the brakes

surfaces must not be hot from the sun!

rior lighting is designed to withstand this.

•

Wash using a sponge, car shampoo and

Condensation is normally vented out of the

WARNING

plenty of lukewarm water.

lamp housing when the lamp has been

Always test the brakes after washing the car,

switched on for a time.

•

Clean the wiper blades with a lukewarm soap

including the parking brake, to ensure that

solution or car shampoo.

moisture and corrosion do not attack the

Automatic car washes

brake linings and reduce braking perform-

•

Dry the car using a clean, soft chamois or a

ance.

water scraper. If you avoid allowing drops of

An automatic car wash is a simple and quick way

of washing the car, but it cannot reach every-

water to dry in strong sunlight, you reduce

where. Handwashing the car is recommended for

Lightly depress the brake pedal now and then

the risk of water drying stains which may

achieving optimum results.

when driving long distances in rain or slush. The

need to be polished out.

heat from the friction causes the brake linings to

warm up and dry. Do the same thing after starting

in very damp or cold weather.

376

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MAINTENANCE AND SERVICE

Wiper blades

IMPORTANT

Asphalt, dust and salt residue on wiper blades, as

Avoid washing the car with cleaning agent

well as insects, ice etc. on the windscreen, impair

with a pH value lower than 3.5 or higher than

the service life of wiper blades.

11.5. This may result in discolouration of ano-

For cleaning:

dised aluminium parts such as roof rack and

around the side windows.

- Set the wiper blades to the service position;

see Wiper blades (p. 359).

Never use metal polishing agent on anodised

aluminium parts, this can result in discoloura-

NOTE

tion and destroy the surface treatment.

Wash the wiper blades and windscreen regu-

larly with lukewarm soap solution or car

Rims

Parts that should be washed using a cleaning agent with

shampoo.

Only use rim cleaning agent recommended by

a pH value between 3.5 and 11.5.

Volvo.

Do not use any strong solvents.

IMPORTANT

After washing, discolouration at the base of the

spokes may remain due to metal dust from the

Exterior plastic, rubber and trim

Avoid waxing and polishing on plastic, rubber

brake discs attaching in the wheel rim's paint.

components

and on parts painted in matte or semi-matte

Paint cleaner works in many cases, with very fine

A special cleaning agent available from Volvo

version.

polishing using a soft cloth.

dealers is recommended for the cleaning and

When using degreasant on plastic and rubber,

care of coloured plastic parts, rubber and trim

Strong rim cleaning agents can damage the sur-

only rub with light pressure if it is necessary.

components, such as glossy trim mouldings.

face and cause stains on chrome-plated alumi-

Use a soft washing sponge.

When using such a cleaning agent the instruc-

nium rims.

tions must be followed carefully.

Polishing glossy trim mouldings could wear

away or damage the glossy surface layer.

Related information

The frames around the side windows, the car's

• Polishing and waxing (p. 378)

roof rails and the door frames at the windows*

Polishing agent that contains abrasive must

• Cleaning the interior (p. 380)

are produced in anodised aluminium. This means

not be used.

that they should only be washed using a cleaning

• Water and dirt-repellent coating (p. 379)

agent with a pH value between 3.5 and 11.5.

This is in order to avoid discolouration.

* Option/accessory.
