Approach light duration (p. 150)

INSTRUMENTS AND CONTROLS

* Option/accessory.

150

Home safe light duration

Some of the exterior lighting can be kept
switched on to work as home safe lighting after
the car has been locked.

To activate the function:

1. Switch off the car.

2. Move the left-hand stalk switch forward

toward the instrument panel and release.

3. Get out of the car and lock the door.

When the function is activated, dipped beam,
position lamps, lighting in the outside handles

and number plate lighting are switched on.

The length of time that home safe lighting
remains on can be set via the centre display.

Related information

•

•

Home safe light duration (p. 150)

Approach light duration

Approach lighting is switched on when the car is
unlocked and is used to switch on the car's
lighting at a distance.

When the function is activated with the remote
control key during unlocking, the position lamps,
lighting in outer handles

*, number plate lighting,

interior roof lighting and floor lighting will switch
on. If a door is opened within the activation time,
the time for the lighting in the outside handles

and the interior lighting will be extended.

The function can be deactivated/activated via the
centre display.

Related information

•

•

Remote control key (p. 236)

•

Using windscreen wipers

The windscreen wiper cleans the windscreen.
Different settings for the windscreen wiper are
made with the right-hand steering wheel stalk
switch.

Right-hand stalk switch.

Thumbwheel, used to set rain sensor

* sensi-

tivity and wiper swipe frequency.

Single sweep

Lower the stalk switch and release to
make one sweep.

Windscreen wipers off

Move the stalk switch to position 0 to
switch off the windscreen wipers.

INSTRUMENTS AND CONTROLS

}}

151

Intermittent wiping

Set the number of sweeps per time unit
with the thumbwheel when intermittent

wiping is selected.

Continuous wiping

Raise the stalk switch for the wipers to
sweep at normal speed.

Raise the stalk switch further for the wip-
ers to sweep at high speed.

Before activating the wipers - ensure that the
wiper blades are not frozen in, and that any
snow or ice on the windscreen and rear win-
dow is scraped away.

Activating/deactivating the rain sensor
(p. 151)

Use plenty of washer fluid when the wipers
are cleaning the windscreen. The windscreen
must be wet when the windscreen wipers are
operating.

Related information

•

•

Windscreen and headlamp washers (p. 152)

•

Rear window wiper and washer (p. 153)

•

Wiper blades in service position (p. 560)

Activating/deactivating the rain

sensor

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen. Rain sensor sensitiv-
ity can be adjusted with the thumbwheel on the
right-hand stalk switch.

Right-hand stalk switch.

Rain sensor button

Thumbwheel sensitivity/frequency

When the rain sensor is activated, the rain sensor
symbol

is shown in the driver display.

Activating the rain sensor

When activating the rain sensor, the car must be
running or the electrical system in ignition posi-
tion I or II while the windscreen wiper stalk

switch must be in position 0 or in the position for
a single sweep.

Activate the rain sensor by pressing the rain sen-
sor button

Press the stalk switch down for the wipers to
make an extra sweep.

Turn the thumbwheel upward for higher sensitiv-
ity and downward for lower sensitivity. An extra
sweep is made when the thumbwheel is turned
upward.

Deactivating the rain sensor

Deactivate the rain sensor by pressing the rain
sensor button

or moving the stalk switch

up to another wiper program.

The rain sensor is deactivated automatically in
ignition position 0 or when the engine is
switched off.

The rain sensor is deactivated automatically when
wiper blades are set in service position. The rain
sensor is reactivated when service position has
been deactivated.

Using windscreen wipers (p. 150)

The windscreen wipers could start and be
damaged in an automatic car wash. Deacti-
vate the rain sensor while the car is running
or when the car's electrical system is in igni-
tion position I or II. The symbol in the driver
display extinguishes.

INSTRUMENTS AND CONTROLS

* Option/accessory.

152

Activating/deactivating the memory
function

The memory function for the rain sensor can be
activated in such a way that the rain sensor but-
ton does not need to be depressed each time the
car is started:

1. Press

Settings

in the top view in the centre

display.

2. Press

My Car

Wipers

3. Select

Rain Sensor Memory

to activate/

deactivate the memory function.

Related information

•

•

Wiper blades in service position (p. 560)

•

Rear window wiper and washer (p. 153)

Windscreen and headlamp washers

Windscreen and headlamp washers clean the
windscreen and headlamps. Washing/wiping is
started by means of the right-hand stalk switch.

Starting windscreen and headlamp
washers

Washing function, right-hand stalk switch.

–

Move the right-hand stalk switch toward the
steering wheel to start the windscreen and
headlamp washers.
> The windscreen wipers will make several

more sweeps once the stalk switch has
been released.

Using windscreen wipers (p. 150)

Avoid activating the washer system when it is
frozen or the washer reservoir is empty, other-
wise there is a risk of damaging the pump.

Heated washer nozzles

The washer nozzles are heated automatically in
cold weather to prevent the washer fluid from
freezing.

Headlamp washing

To save fluid, the headlamps are washed auto-
matically at a defined interval when the head-
lamps are switched on.

Reduced washing

If only approx. 1 litre of washer fluid remains in
the reservoir and the message

Washer fluid

Level low, refill

, together with the

symbol,

is shown in the driver display, then the supply of
washer fluid to the headlamps is switched off.
This is in order to prioritise cleaning the wind-
screen and the visibility through it.

Related information

•

•

Rear window wiper and washer (p. 153)

•

Filling washer fluid (p. 563)

INSTRUMENTS AND CONTROLS

* Option/accessory.

153

Rear window wiper and washer

Rear window wiper and washer clean the rear
window. Washing/wiping is started and settings
are changed by means of the right-hand steering
wheel stalk switch.

Using windscreen wipers (p. 150)

The rear window wiper is equipped with over-
heating protection which means that the
motor is switched off if it overheats. The rear
window wiper works again after a cooling-
down period.

Using the rear window wiper and
washer

Select

for intermittent wiping with the

rear window wiper.

Select

for continuous speed with the

rear window wiper.

–

Move the right-hand steering wheel stalk
switch forward to start rear window washing
and wiping.

Activating/deactivating wiping when
reversing

1. Press

Settings

in the top view in the centre

display.

2. Press

My Car

Wipers

3. Select

Auto Rear Wiper

to activate/deacti-

vate wiping when reversing.

Engaging reverse gear while the windscreen wip-
ers are on initiates rear window wiping. The func-
tion stops when reverse gear is disengaged.

If the rear window wiper is already on at continu-
ous speed, no change is made.

Related information

•

•

Windscreen and headlamp washers (p. 152)

•

Activating/deactivating the rain sensor
(p. 151)

•

Filling washer fluid (p. 563)

Power windows

Using the driver's door control panel, all power
windows can be operated - using the control
panels in the other doors operates the power
window in the individual door.

Driver's door control panel.

Electric child safety locks

* that prevent chil-

dren from being able to open the rear doors
from inside and open/close the rear win-
dows.
Controls for rear windows.

Controls for front windows.

Related information

•

Operating power windows (p. 154)

•

Child safety locks (p. 262)

INSTRUMENTS AND CONTROLS

154

Operating power windows

Using the driver's door control panel, all power
windows can be operated - using the control
panels in the other doors operates the power
window in the individual door.

WARNING

Check that no children or other passengers

are trapped when the windows are closed

from the driver's door.

WARNING

Check that no children or other passengers

are trapped if/when the windows are closed

using the remote control key.

WARNING

If there are children in the car - remember to

always switch off the power supply to the

power windows by setting the car's electrical

system in ignition position 0 and then take

the remote control key with you when leaving

the car.

WARNING

Never leave children alone in the car.

Operating

Operating the power windows.

Operating without auto

Operating with auto

Using the driver's door control panel, all power
windows can be operated - using the control
panels in the other doors can only operate the
power window in the individual door. Only one
control panel can be operated at a time.

In order for the power windows to be used, the
ignition position must be at least I. The power
windows can be operated for a few minutes after
the car has been switched off and after the igni-
tion has been switched off - although not after a
door has been opened.

One way to reduce the pulsating wind noise
when the rear windows are open is to also
open the front windows slightly.

Child safety locks (p. 262)

The windows cannot be opened at speeds
above approx. 180 km/h (approx. 112 mph),
but they can be closed.

Operating without auto

Move one of the controls up/down gently. The
power windows move up/down as long as the
control is held in position.

Operating with auto

Move one of the controls up/down to the end
position and release it. The window runs auto-
matically to its end position.

Operating with the remote control key, door
handle or central locking button

To operate the power windows with the remote
control key, door handles on the outside, or from
the inside with the central locking button, see the
section "Remote control key", "Locking/unlock-
ing from the outside" or "Locking/unlocking from
the inside".

Pinch protection

Closing of the windows is stopped and the win-
dow is opened if anything prevents its movement.

INSTRUMENTS AND CONTROLS

* Option/accessory.

155

It is possible to override the pinch protection
when closing has been interrupted, e.g. if ice has
formed on the window. After two successive clos-
ing interruptions the pinch protection will be over-
ridden and the automatic function deactivated for
a short while, now it is possible to close by hold-
ing the button in its raised position.

Resetting

If the starter battery is disconnected then the
function for automatic opening must be reset so
that it can work correctly.

1. Gently raise the front section of the button to

raise the window to its end position and hold
it there for one second.

2. Release the button briefly.

3. Raise the front section of the button again

for one second.

WARNING

A reset must take place for pinch protection

to work.

Related information

•

Power windows (p. 153)

•

•

Using the sun blind

* (p. 155)

•

Remote control key (p. 236)

•

•

Locking/unlocking from the outside (p. 241)

•

Locking/unlocking from the inside (p. 245)

Using the sun blind

Sun blinds can be installed, built into each rear
door.

In the rear door - manually operated

Hook with associated catch

–

Pull up the sun blind and attach it to the
hook in the upper door frame.

The window can still be opened and closed with
the sun blind up.

Related information

•

Operating power windows (p. 154)

INSTRUMENTS AND CONTROLS

* Option/accessory.

156

Adjusting the door mirrors

The door mirror positions are adjusted with the
joystick in the driver's door control panel.

Controls for door mirrors.

Adjusting

1. Press the L button for the left-hand door mir-

ror or the R button for the right-hand door
mirror. The light in the button illuminates.

2. Adjust the position with the joystick in the

centre.

3. Press the L or R button again. The light

should no longer be illuminated.

WARNING

Both mirrors are bent to provide optimal

vision. Objects may appear further away than

they actually are.

Memory function in power front seat

Door mirror positions can be saved in the mem-
ory function of the power front seat.

Retractable power door mirrors

The mirrors can be retracted for parking/driving
in narrow spaces:

1. Depress the L and R buttons simultaneously

(ignition position must be at least I).

2. Release them after approximately 1 second.

The mirrors automatically stop in the fully
retracted position.

Fold out the mirrors by pressing down the L and
R buttons simultaneously. The mirrors automati-
cally stop in the fully extended position.

Angling the door mirror when parking

The door mirror can be angled down for the
driver to view the side of the road when parking
for example.

–

Engage reverse gear and press the L or R
button.

When reverse gear is disengaged the mirror
automatically returns to its original position after

approx. 10 seconds, or earlier by pressing the
button labelled L or R respectively.

Automatic angling of the door mirror
when parking

When reverse gear is engaged the door mirror is
automatically angled down so that the driver can
see the side of the road when parking for exam-
ple. When reverse gear is disengaged the mirror
automatically returns to its original position after
a short time.

Settings for this function are set via the centre
display:

1. Press

Settings

in the top view.

2. Press

My Car

Mirrors and Easy Entry

3. Under

Exterior Mirror Tilt at Reverse

select

Off

Driver

Passenger

Both

activate/deactivate and to select which
review mirror should be angled.

Automatic retraction when locking

When the car is locked/unlocked with the remote
control key the door mirrors are automatically
retracted/extended.

The function can be activated/deactivated via the
centre display:

1. Press

Settings

in the top view.

2. Press

My Car

Mirrors and Easy Entry

Only in combination with power seat with memory.

INSTRUMENTS AND CONTROLS

}}

* Option/accessory.

157

3. Select

Fold Mirror When Locked

to acti-

vate/deactivate.

Resetting to neutral

Mirrors that have been moved out of position by
an external force must be reset electrically to the
neutral position for electric retracting/extending
to work correctly:

1. Retract the mirrors with the L and R buttons.

2. Fold them out again with the L and R but-

tons.

3. Repeat the above procedure as necessary.

The mirrors are now reset in neutral position.

Automatic dimming

Bright light from behind is automatically dimmed
by the interior rearview and door mirrors.

For the door mirrors to be fitted with this function
requires that the interior rearview mirror also has
automatic dimming, see the section "Interior rear-
view mirror".

Automatic dimming is always active while driving,
apart from when gearbox reverse position is
selected. Dimming sensitivity can be adjusted in
three levels and will affect the interior rearview
and the door mirrors.

Interior rearview mirror (p. 157)

When sensitivity is changed there is no imme-
diately noticeable change in dimming, but the
change will be complete after a while.

Settings for this function are set via the centre
display:

1. Press

Settings

in the top view.

2. Press

My Car

Mirrors and Easy Entry

3. Under

Rearview Mirror Auto Dimming

select

Normal

Dark

Light

Related information

•

•

Using the memory function in the power
front seat

•

* (p. 128)

Interior rearview mirror

The interior rearview mirror can be dimmed with
a control in the mirror's lower edge. Alternatively,
the rearview mirror dims automatically.

Control for dimming

Manual dimming

Bright light from behind could be reflected in the
rearview mirror and dazzle the driver. Use dim-
ming with the dimming control when lights from
behind are distracting:

1. Use dimming by moving the control in

towards the passenger compartment.

2. Return to normal mode by moving the control

towards the windscreen.

INSTRUMENTS AND CONTROLS

* Option/accessory.

158

Automatic dimming

Bright light from behind is automatically dimmed
by the rearview mirror. The control for manual
dimming is not available on mirrors with auto-
matic dimming.

The rearview mirror contains two sensors - one
forward facing and one rearward facing - that
work together to identify and eliminate dazzling
light. The forward facing sensor detects ambient
light, while the rearward facing sensor detects
the light from vehicle headlights behind.

If the sensors are obscured by e.g. parking
permits, transponders, sun visors or objects in
the seats or in the cargo area in such a way
that light is prevented from reaching the sen-
sors, then the dimming function of the interior
rearview and door mirrors is reduced.

Adjusting the door mirrors (p. 156)

When sensitivity is changed there is no imme-
diately noticeable change in dimming, but the
change will be complete after a while.

Settings for this function are set via the centre
display:

1. Press

Settings

in the top view.

2. Press

My Car

Mirrors and Easy Entry

3. Under

Rearview Mirror Auto Dimming

select

Normal

Dark

Light

Related information

•

•

Compass

The upper right-hand corner of the rearview mir-
ror has an integrated display that shows the
compass direction in which the front of the car is
pointing.

Rearview mirror with compass.

Eight different compass directions are shown by
their English abbreviations:

(north),

(north

east),

(east),

(south east),

(south),

(south west),

(west) and

(north west).

Activating/deactivating the compass

The compass is activated automatically when the
car is started.

To deactivate/activate the compass:

–

Depress the button on the underside of the
rearview mirror using e.g. a paper clip.

INSTRUMENTS AND CONTROLS

}}

* Option/accessory.

159

Related information

•

Calibrating the compass

* (p. 159)

•

Activating/deactivating defrost of windows
and door mirrors (p. 194)

•

Calibrating the compass

The earth is divided into 15 magnetic zones. The
compass should be calibrated if the car is
moved between several magnetic zones.

Proceed as follows to perform calibration:

1. Stop the car in a large open area free from

steel structures and high-voltage power lines.

2. Start the car and switch off all electrical

equipment (air conditioning, wipers, etc.) and
ensure that all doors are closed.

Calibration may fail or not start at all if electri-
cal equipment is not switched off.

3. Hold the button on the underside of the rear-

view mirror depressed (use a paper clip or
similar) for approx. 3 seconds. The number of
the current magnetic zone is shown.

Magnetic zones.

4. Press the button repeatedly until the

required magnetic zone (

1–15

) is shown.

See the map of magnetic zones for the com-
pass.

5. Wait until the display returns to showing the

character

, or hold the button on the under-

side of the rearview mirror depressed for
approx. 6 seconds until the character

shown.

6. Drive slowly in a circle at a speed of no more

than 10 km/h (6 mph) until a compass direc-
tion is shown in the display, indicating that
calibration is complete. Then drive a further 2
circles to fine-tune calibration.

INSTRUMENTS AND CONTROLS

* Option/accessory.

160

7. Cars with heated windscreen

*: If the char-

acter

is shown in the display when the

heated windscreen is activated, perform the
calibration in accordance with point 6 above
with the heated windscreen activated.

8. Repeat the above procedure as necessary.

Related information

•

Compass

* (p. 158)

Panorama roof

The panorama roof is divided into two glass sec-
tions. The front section can be opened vertically
at the rear edge (ventilation position) or horizon-
tally (open position). The rear section is fixed
roof glass.

The panoramic roof has a wind deflector.

The panorama roof has a sun blind made of per-
forated fabric and located under the glass roof to
provide extra protection from factors such as
strong sunlight.

The panoramic roof and sun blind are operated
with a control located in the roof.

The control is activated when the car's electrical
system is in ignition position I or II.

WARNING

Children, other passengers or objects may be

trapped by the panoramic roof's moving parts.

•

Always operate the panoramic roof with
caution.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the power
supply to the panoramic roof by setting
the car's electrical system in ignition posi-
tion 0, and then take the remote control
key with you when leaving the car.

•

Never put an object or part of the body
through the panoramic roof, even if the
car's electrical system is fully discon-
nected.

•

Do not open the panoramic roof when
load carriers are fitted.

•

Do not place any heavy objects on the
panoramic roof.

INSTRUMENTS AND CONTROLS

}}

* Option/accessory.

161

Operating the panorama roof

•

Remove ice and snow before opening the
panoramic roof.

•

Do not operate the panoramic roof if it
has frozen closed.

Wind deflector

The panorama roof has a wind deflector that is
raised when the panorama roof is in the open
position.

Related information

•

* (p. 161)

•

Operating the panorama roof

When operating with the control in the roof, the
panoramic roof is first opened horizontally to a
comfort position.

In ventilation position, the front glass cover in the
roof is raised at the rear.

WARNING

Children, other passengers or objects may be

trapped by the panoramic roof's moving parts.

•

Always operate the panoramic roof with
caution.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Never put an object or part of the body
through the panoramic roof, even if the
car's electrical system is fully discon-
nected.

•

Do not open the panoramic roof when
load carriers are fitted.

•

Do not place any heavy objects on the
panoramic roof.

•

Remove ice and snow before opening the
panoramic roof.

•

Do not operate the panoramic roof if it
has frozen closed.

In order that the panoramic roof and sun blind
can be operated, the car's electrical system must
be in at least ignition position I. Turn the start
knob clockwise and then release it. The panor-
amic roof and sun blind are operated using the
control in the ceiling.

INSTRUMENTS AND CONTROLS

162

Ventilation position

Ventilation position, vertically at the rear edge.

Open by pressing the control upward.

Close by pressing the control forward/down-
ward.

When the ventilation position is selected the front
glass cover is raised at its rear edge. If the sun
blind is fully closed when ventilation position is
selected, then it opens automatically approx.
50 mm (approx. 2 inches).

The sun blind follows automatically if the panor-
amic roof is closed from ventilation position.

Operating with the control in the roof

Opening, manual

Opening, automatic

Closing, manual

Closing, automatic

Manual operation

1. To open the sun blind - press the control

backwards to the position for manual open-
ing. The sun blind moves towards maximum
opening position for as long as the control is
held depressed rearward.

2. Open the panorama roof - press the control

backwards a second time to the position for
manual opening. The panoramic roof first
reaches comfort position

. In order to open

to maximum opening position - press the
control backwards a third time.

Close the roof/blind by repeating the preceding
procedure in reverse order - press the control
forward/downward to the manual closing position
instead.

The movement of the roof is stopped if the con-
trol is released or when the glass reaches the
comfort position or the maximum opening or
closing position. The movement is also stopped if
the control is operated again in the opposite
direction to the direction of movement in pro-
gress.
