Optional equipment and accessories - e.g.
display screens, music players and mobile
phones - which are connected to one of the
passenger compartment's 12V electrical
sockets, could be activated by the climate
control system, even when the remote control
key has been removed or when the car is
locked, for example, when the parking heater
is activated at a preset time.

For this reason remove the plugs from the
electrical sockets for optional equipment or
accessories when not in use because the bat-
tery could be drained in the event of such an
occurrence!

LOADING AND STORAGE

* Option/accessory.

154

Max. socket is 10 A (120 W) if one socket is
used at a time. If both sockets in the tunnel
console are used simultaneously, 7.5 A (90
W) per socket is applicable.

If the compressor for emergency puncture
repair is connected to one of the two sockets,
no other current consumer must be con-
nected to the other one.

12 V electrical socket - cargo area

The compressor for emergency puncture
repair (p. 346) has been tested and approved
by Volvo.

Related information

•

* (p. 156)

Payload depends on the car's kerb weight.

The total of the weight of the passengers and all
accessories reduces the car's payload by a cor-
responding weight.

For more detailed information on weights, see
Weights (p. 412).

The tailgate is opened via a button on
the lighting panel or the remote control
key, see Locking/unlocking - tailgate

(p. 181).

WARNING

The car’s driving properties change depend-

ing on the weight and positioning of the load.

To bear in mind when loading

•

Position the load firmly against the rear
seat's backrest.

Note that objects must not prevent the function
of the WHIPS system for the front seats if any of
the rear seat's backrests is folded down, see
WHIPS - seating position (p. 42).

•

Centre the load.

•

Heavy objects should be placed as low as
possible. Avoid placing heavy loads on low-
ered backrests.

•

Cover sharp edges with something soft to
avoid damaging the upholstery.

•

Secure all loads to the load retaining eyelets
with straps or web lashings.

WARNING

A loose object weighing 20 kg (44 pounds)

can, in a frontal collision at a speed of

50 km/h (30 mph) carry the impact of an

item weighing 1000 kg (2200 pounds).

WARNING

The protection provided by the inflatable cur-

tain in the headlining may be compromised or

eliminated by high loads.

•

Never load cargo above the backrest.

WARNING

Always secure the load. During heavy braking

the load may otherwise shift, causing injury to

the car's occupants.
Cover sharp edges and sharp corners with

something soft.
Switch off the engine and apply the parking

brake when loading/unloading long items.

Otherwise you may accidentally knock the

gear lever or gear selector with the load into a

drive position - and the car could then move

off.

LOADING AND STORAGE

* Option/accessory.

155

Related information

•

Load retaining eyelets (p. 156)

•

Safety net

* (p. 157)

•

Loading - long load (p. 155)

•

Roof load (p. 155)

Loading - long load

To simplify loading (p. 154) in the cargo area,
the rear seat backrest can be folded down. The
passenger seat

backrest can also be folded

for an extra long load.

Lowering the rear seat backrest

If the rear seat backrest needs to be lowered, see
Seats, rear (p. 87).

Roof load

The load carriers recommended for roof loads
are the ones developed by Volvo. This is in order
to avoid damage to the car and in order to
achieve the maximum possible safety during a
journey.

Carefully follow the installation instructions sup-
plied with the carriers.

•

Check periodically that the load carriers and
load are properly secured. Lash the load
securely with retaining straps.

•

Distribute the load evenly over the load carri-
ers. Put the heaviest objects at the bottom.

•

The size of the area exposed to the wind, and
therefore fuel consumption, increase with the
size of the load.

•

Drive gently. Avoid quick acceleration, heavy
braking and hard cornering.

WARNING

The car's centre of gravity and driving charac-

teristics are altered by roof loads.
For information about the maximum permitted

load on the roof, including load carriers and

any space box, see Weights (p. 412).

Related information

•

Only applies to comfort seats.

LOADING AND STORAGE

* Option/accessory.

156

Load retaining eyelets

The folding load retaining eyelets are used to
fasten straps in order to anchor items in the
cargo area.

WARNING

Hard, sharp and/or heavy objects which pro-

trude may cause injury under violent braking.
Always secure large and heavy objects with a

seatbelt or cargo retaining straps.

Related information

•

12 V electrical socket - cargo area*

The electrical socket can be used for various
accessories designed for 12 V, e.g. screens,
music players and mobile phones.

Lower the cover to access the electrical socket.

•

The socket also provides voltage when the
remote control key is not in the ignition
switch.

Max. power takeoff is 10 A (120 W).

Remember that using the electrical socket
with the engine switched off involves the risk
of discharging the car's starter battery.

Tunnel console - 12 V-sockets (p. 153)

The compressor for temporary emergency
puncture repair has been tested and
approved by Volvo. For information on the use
of Volvo's recommended temporary emer-
gency puncture repair (TMK), see Emergency
puncture repair (p. 346).

Related information

•

LOADING AND STORAGE

}}

* Option/accessory.

157

Safety net*

A safety net prevents loads from being thrown
forward in the passenger compartment in the
event of sudden braking.

Attaching

For safety reasons, the safety net must always be
correctly fastened and secured.

The net is made of a strong nylon fabric and can
be secured two different locations in the car:

•

Rear fitting - Behind the rear seat backrest

•

Front fitting - Behind the front seat back-
rests.

WARNING

Loads in the luggage compartment must be

anchored well, and also using a correctly fit-

ted safety net.

Rear fitting

1. Fold out the safety net. Make sure that the

safety net's storage pockets are turned
backwards.

2. Hook one of the net's retaining hooks into

the rear roof mounting.

Hook the net's other retaining hook into the
roof mounting on the opposite side.

Take care to press forward the net's retaining
hooks for each respective roof mounting's
front end position.

3. Hook the hook into the load retaining eyelets

on both sides and tension the cam lock by
pressing down the tongue and tensioning
the strap.

Standard in certain markets.

LOADING AND STORAGE

* Option/accessory.

158

Front fitting

1. Fold out the safety net. Make sure that the

safety net's storage pockets are turned
backwards.

2. Place the seats as far forward as possible.

3. Hook one of the net's retaining hooks into

the front roof mounting.

Hook the net's other retaining hook into the
roof mounting on the opposite side.

Take care to press forward the net's retaining
hooks for each respective roof mounting's
front end position.

4. Hook the hook into the eyelet on the seat rail

on both sides and tension the cam lock by
pressing down the tongue and tensioning
the strap.

Related information

•

•

Safety grille

* (p. 158)

Safety grille*

A safety grille prevents loads or pets from being
thrown forward in the passenger compartment in
the event of sudden braking.

Folding up

Take hold of the bottom of the safety grille and
pull back/up.

The protective grille cannot be folded up or
down when a cargo cover is fitted.

Fitting/removal

The safety grille is normally permanently installed
in the car because it can easily be folded up in
the roof and so be out of the way if a longer
cargo area is required. However, if desired, the

LOADING AND STORAGE

* Option/accessory.

159

safety grille can be dismantled and removed from
the car.

For information about the tools required and
methods for fitting/removal, see the installation
instructions that were included with the initial
purchase.

For safety reasons, the safety grille must always
be correctly fastened and secured when being
refitted.

Related information

•

Safety net

* (p. 157)

•

Load retaining eyelets (p. 156)

•

Cargo cover*

Pull the cargo cover over the load and hook it
into the recesses at the cargo area's rear posts.

The protective grille cannot be folded up or
down when the cargo cover is fitted.

Attaching the cargo cover

Move one end piece of the cover into the
recess on the side panel.

Move the other end piece into the corres-
ponding recess.

Press both sides in. A "click" should be audi-
ble and the red marking should disappear.
> Check that both end pieces are locked.

Removing the cargo cover

1. Press in one end piece button and lift it out.

2. Carefully angle the cover up/out and the

other end piece loosens automatically.

Lowering the cargo cover's rear sealing
disc

In its rolled-in position, the cargo cover's rear
sealing disc protrudes horizontally into the cargo
area when it is fitted.

–

Pull the sealing disc back gently, free from
its support shelves, and lower.

Related information

•

Loading - long load (p. 155)

•

Standard in certain markets.

LOCKS AND ALARM

* Option/accessory.

162

Remote control key

Amongst other things, the remote control key is
used for locking/unlocking and starting the
engine.

There are two variants of remote control key -
Remote control key in basic version and Remote
control key with PCC (Personal Car
Communicator)

Functionality

Basic

with

PCC

Locking/unlocking and
detachable key blade

Keyless locking/unlock-
ing

Keyless engine starting

Information button and
indicator lamps

5-button key

6-button key

Remote control key with PCC has extended func-
tionality compared with the remote control key in
the basic version - e.g. support for keyless star-
ting and locking/unlocking (Keyless Drive
(p. 173)) as well as certain unique functions
(p. 167).

All remote control keys have a detachable key
blade (p. 169) made of metal. The visible section
is available in two versions so that it is possible to
distinguish between the remote control keys.

More remote control keys can be ordered - but
not variants other than the one supplied with the
car. Up to six keys can be programmed and used
for one single car.

The car is supplied with two remote control keys.

WARNING

If there are children in the car:
Remember to switch off the supply to the

power windows and sunroof by removing the

remote control key if the driver leaves the car.

Related information

•

Remote control key - functions (p. 166)

Remote control key - losing

If you lose a remote control key then a new one
can be ordered at a workshop - an authorised
Volvo workshop is recommended.

The remaining remote control keys must be
taken to the Volvo workshop. The code of the
missing remote control key must be erased from
the system as a theft prevention measure.

The current number of keys registered to the car
can be checked in the menu system MY CAR.
For a description of the menu system, see MY
CAR (p. 115).

Related information

•

Remote control key - functions (p. 166)

LOCKS AND ALARM

}}

* Option/accessory.

163

Remote control key -

personalisation*

The key memory in the remote control key
(p. 162) means that certain settings in the car
can be individually adapted for different people.

The key memory function is available in combina-
tion with, for example, power

* driver's seat.

Settings for door mirrors (p. 107), driver's seat,
steering force (p. 190) and the combined instru-
ment panel's theme, contrast and colour mode
(p. 69) can be stored in the memory, depending
on the car's equipment level.

The function

can be activated/deactivated in the

menu system MY CAR. For a description of the
menu system, see MY CAR (p. 115).

When the function is activated, the settings are
automatically linked to the key memory. This
means that a change in a setting will automati-
cally be saved to the specific remote control key's
memory.

Storing settings

Proceed as follows in order to store the settings
and use the key memory in the remote control
key:

1. Unlock the car with the remote control key in

whose memory the setting

shall be stored.

2. Make sure that the key memory function is

activated in the menu system MY CAR.

3. Make the desired settings for e.g. the seat

and the door mirrors.

4. The settings are stored in the current remote

control key's memory.

The next time the car is unlocked with the same
remote control key, the positions that are stored
in the key memory will be set automatically - pro-
viding that they have been changed since the last
time the current remote control key was used.

Emergency stop

If the seat accidentally begins to move, press one
of the setting buttons for the seat or memory
buttons in order to stop the seat.

Restarting to reach the seat position stored in
the key memory is performed by pressing the
unlock button on the remote control key. The
driver's door must then be open.

WARNING

Risk of crushing! Make sure that children do

not play with the controls. Check that there

are no objects in front of, behind or under the

seat during adjustment. Make sure that none

of the passengers in the rear seat is in danger

of becoming trapped.

Changing settings

If several people each with a remote control key
approach the car, then the settings for e.g. seat
and door mirrors are implemented for the person
whose remote control key unlocks the driver's
door.

If the driver's door has been opened by person A
with remote control key A, but person B with
remote control key B shall drive, then the settings
can be changed as follows:

•

Standing by the driver's door, or sitting
behind the steering wheel, person B presses
the button for unlocking on his/her remote
control key, see Remote control key - func-
tions (p. 166).

•

Select one of three possible memories for
seat adjustment with seat button 1-3, see
Seats, front - electrically operated

* (p. 85).

•

Adjust seat and door mirrors manually, see
Seats, front - electrically operated

* (p. 85)

and Door mirrors (p. 107).

Called

Car key memory

in MY CAR.

This setting does not affect settings that have been stored in the power seat's memory function.

LOCKS AND ALARM

* Option/accessory.

164

Reactivation of settings

When the car is locked or after 30 minutes if the
car is left unlocked, the key memory will be deac-
tivated and a standard driver profile will be set. To
reactivate the key memory for the current remote
control key, the following is required.

For cars without keyless start and lock
system

The settings that are stored in the key memory
are activated if the car is unlocked by pressing
the remote control key's unlock button.

For cars with keyless start and lock system

The key memory is activated if:

1. The car is unlocked either by pressing the

remote control key's unlock button or via
keyless unlocking.

2. If the car is unlocked, a key scan is made

when the driver's door is opened. If a unique
remote control key is found, its stored set-
tings will be activated. If the car is locked,
see the previous point.

Related information

•

Remote control key with PCC

* - unique func-

tions (p. 167)

Locking/unlocking - indicator

When the car is locked or unlocked using the
remote control key (p. 162) the direction indica-
tors confirm that locking/unlocking was correctly
performed.

•

Locking - one flash and the door mirrors are
folded

in.

•

Unlocking - two flashes and the door mirrors
are folded

out.

After locking the indication is only given if all
locks are activated once the doors have been
closed.

Selecting the function

Different options for indicating locking/unlocking
with light can be set in the car's menu system
MY CAR. For a description of the menu system,
see MY CAR (p. 115).

Related information

•

Keyless drive

* (p. 173)

•

Lock indicator (p. 164)

•

Alarm indicator

* (p. 186)

Lock indicator

A flashing LED by the windscreen verifies that
the car is locked.

Same LED as alarm indicator (p. 186).

Locking/unlocking - indicator (p. 164)

Cars that are not equipped with alarm also
have this indicator.

Related information

•

Only for cars with retractable power door mirrors.

LOCKS AND ALARM

* Option/accessory.

165

Immobiliser

The electronic immobiliser is a theft protection
system that prevents an unauthorised person
from starting the car.

Each remote control key (p. 162) has a unique
code. The car can only be started with the correct
remote control key with the correct code.

The following error messages in the combined
instrument panel's information display are related
to the electronic immobiliser:

Message

Specification

Insert car
key

Error when reading the remote
control key during starting -
Remove the key from the ignition
switch, press it in again and
make a new start attempt.

Car key
not found

Error reading the remote control
key during starting - Try to start
again.

If the error persists: Insert the
remote key into the ignition
switch and try to start again.

Immobi-
liser Try
to start
again

Error in immobiliser system dur-
ing starting. If the error persists:
Contact a workshop - an author-
ised Volvo workshop is recom-
mended.

For starting the car, see Starting the engine
(p. 266).

Related information

•

Remote-controlled immobiliser with tracking
system

* (p. 165)

Remote-controlled immobiliser with

tracking system*

Remote-controlled immobiliser with tracking sys-
tem

makes it possible to track and locate the

car, and to remotely activate the immobiliser.

Contact your nearest Volvo dealer for more infor-
mation and assistance with activating the system.

Related information

•

Remote control key (p. 162)

•

Immobiliser (p. 165)

LOCKS AND ALARM

* Option/accessory.

166

Remote control key - functions

The remote control key in basic version has
functions such as locking and unlocking the
doors.

Functions

Remote control key in basic version.

Locking

Unlocking

Approach light duration

Tailgate

Panic function

Remote control key with PCC

*( Personal Car

Communicator).

Information

Function buttons

Locking – Locks the doors and tailgate

while the alarm is activated.

Press and hold to close all the windows and sun-
roof

* simultaneously. For more information, see

Global opening (p. 180).

WARNING

If the sunroof and windows are closed using

the remote control key, check that nobody's

hands are trapped.

Unlocking – Unlocks the doors and tailgate

while the alarm is deactivated.

Press and hold to open all windows simultane-
ously. For more information, see Global opening
(p. 180).

The function can be changed from unlocking all
doors simultaneously, to unlocking the driver's
door only with one press of the button and, after
a further press of the button - within ten seconds
- unlocking the remaining doors.

The function can be changed in the menu system
MY CAR. For a description of the menu system,
see MY CAR (p. 115).

Approach light duration – Used to switch

on the car's lighting at a distance. For more infor-
mation, see Approach lighting (p. 102).

The button can also be used for activating pre-
conditioning (p. 140).

Tailgate (p. 181) - Unlocks and disarms

the alarm for the tailgate only.

Panic function – Used to attract attention

in an emergency.

Press and hold the button for at least 3 seconds
or press it twice within 3 seconds to activate the
direction indicators and the horn.

The function can be turned off with the same
button once it has been active for at least 5 sec-

Only certain markets and in combination with Volvo On Call

LOCKS AND ALARM

}}

* Option/accessory.

167

onds. Otherwise the function switches off auto-
matically after approx. 3 minutes.

Related information

•

Remote control key (p. 162)

•

Remote control key with PCC

* - unique func-

tions (p. 167)

•

Locking/unlocking - from the outside
(p. 178)

Remote control key - range

Remote control key functions (in its basic ver-
sion) have a range of approx. 20 metres from
the car.

If the car does not verify a button being pressed -
move closer and try again.

Remote control key (p. 162)

The remote control key functions may be dis-
rupted by surrounding radio waves, buildings,
topographical conditions, etc. The car can
always be locked/unlocked with the key blade
(p. 170).

If the remote control key is removed from the car
when the engine is running or key position I or II
(p. 82) is active, and all doors are closed, then a
warning message is shown in the information dis-
play in the combined instrument panel and a
short audio reminder signal sounds at the same
time.

The message extinguishes when the remote con-
trol key is returned to the car, followed by a press
of the OK button, or when all doors are closed.

Related information

•

•

Remote control key - functions (p. 166)

Remote control key with PCC* -

unique functions

A remote control key with PCC (Personal Car
Communicator) has enhanced functionality com-
pared with a remote control key in basic version
(p. 162) in the form of an information button and
indicator lamps.

Remote control key with PCC.

Information button

Indicator lamps

Using the information button enables access to
certain information from the car via the indicator
lamps.

LOCKS AND ALARM

* Option/accessory.

168

Using the information button

–

Press the information button

> All indicator lamps flash for approximately

7 seconds and the light travels around on
the remote control key. This indicates that
information from the car is being scanned.

If any of the other buttons are pressed
during this time then the reading is inter-
rupted.

Remote control key with PCC

If none of the indicator lamps illuminates

with repeated use of the information button
and in different locations (as well as after 7
seconds and after the light has travelled
around on the PCC), contact a workshop - an
authorised Volvo workshop is recommended.

Indicator lamps display information in accordance
with the following illustration:

Green continuous light – the car is locked.

Yellow continuous light – the car is unlocked.

Red continuous light – the alarm has been
triggered since the car was locked.
Red light flashing alternately in both indicator
lamps – The alarm was triggered less than 5
minutes ago.

Related information

•

* - range

(p. 168)

Remote control key with PCC* -

range

The range of a remote control key with PCC
(Personal Car Communicator) for locking,
unlocking the doors and tailgate is approx. 20
metres from the car - the other functions are up
to approx. 100 metres.

If the car does not verify a button being pressed -
move closer and try again.

The information button function may be dis-
rupted by surrounding radio waves, buildings,
topographical conditions, etc.

Outside the remote control key's range

If the remote control key is too far away from the
car for the information to be read then the status
the car was last left in is shown, without the light
in the indicator lamps travelling around on the
remote control key.

If several remote control keys are used for the
car then it is only the one last used for locking/
unlocking that shows the correct status.

LOCKS AND ALARM

}}

* Option/accessory.

169
