WHEELS AND TIRES

548

Uniform Tire Quality Grading

ALL PASSENGER VEHICLE TIRES MUST
CONFORM TO FEDERAL SAFETY REQUIRE-
MENTS IN ADDITION TO THESE GRADES.

Quality grades can be found, where applica-
ble, on the tire sidewall between the tread
shoulder and maximum section width. For
example:

Treadwear 200 Traction AA Temperature A

TREADWEAR

The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified gov-
ernment test course. For example, a tire graded
150 would wear one and one half (1 ½) times as
well on the government course as a tire graded
100. The relative performance of tires depends
upon the actual conditions of their use, however,
and many depart significantly from the norm due
to variation in driving habits, maintenance practi-
ces and differences in road characteristics and
climate.

TRACTION

The traction grades, from highest to lowest, are
AA, A, B, and C, as measured under controlled
conditions on specified government test surfaces
of asphalt and concrete. A tire marked C may
have poor traction performance.

WARNING

The traction grade assigned to this tire is

based on braking (straight-ahead) traction

tests and is not a measure of cornering (turn-

ing) traction.

TEMPERATURE

The temperature grades are A (the highest), B,
and C, representing the tire's resistance to the
generation of heat and its ability to dissipate heat
when tested under controlled conditions on a
specified indoor laboratory test wheel. Sustained
high temperature can cause the material of the
tire to degenerate and reduce tire life, and exces-
sive temperature can lead to sudden tire failure.
The grade C corresponds to a minimum level of
performance that all passenger vehicle tires must
meet under the Federal Motor Safety Standard
No. 109. Grades B and A represent higher levels
of performance on the laboratory test wheel than
the minimum required by law.

WARNING

The temperature grade for this tire is estab-

lished for a tire that is properly inflated and

not overloaded. Excessive speed, under-infla-

tion, or excessive loading, either separately or

in combination, can cause heat buildup and

tire failure.

Related information

•

Tires (p. 542)

•

Tire sidewall designations (p. 546)

WHEELS AND TIRES

* Option/accessory.

549

Checking tire pressure

Correct inflation pressure helps improve driving
stability, save fuel and increase the service life of
the tires.

Tire pressure decreases over time, which is nor-
mal. Tire pressure also varies depending on the
ambient temperature. Driving on under-inflated
tires could cause the vehicle to overheat and lead
to damage. Tire pressure affects traveling com-
fort, road noise and driving characteristics.

Check the pressure in the tires every month. Use
the recommended inflation pressure for cold tires
for optimal tire performance and wear. Under-
inflated or over-inflated tires could cause uneven
tread wear.

Use an air pressure gauge and check the infla-
tion pressure on all the tires, including the spare
tire

4

, at least once a month and before long trips.

Volvo strongly recommends buying a reliable air
pressure gauge, as the automatic gauges provi-
ded at service stations may be inaccurate.

WARNING

•

Under-inflation is the most common
cause of tire failure and may result in
severe tire cracking, tread separation, or
"blow-out," with unexpected loss of vehi-
cle control and increased risk of injury.

•

Under-inflated tires reduce the load car-
rying capacity of your vehicle.

Cold tires

Inflation pressure should be checked when the
tires are cold.

The tires are considered to be cold when they
have the same temperature as the surrounding
(ambient) air.

This temperature is normally reached after the
vehicle has been parked for at least 3 hours.

After driving for approximately 1.6 km (1 mile),
the tires are considered to be warm. If you need
to drive longer than that to inflate the tires, check
and record the inflation pressure of the tires first
and inflate accordingly when you arrive at the
pump.

When the ambient temperature changes, so does
the inflation pressure. A 10-degree temperature
drop causes a corresponding drop in inflation
pressure of 1 psi (7 kPa). Check the inflation
pressure of the tires regularly and adjust to the

correct pressure, which can be found on the vehi-
cle's tire information placard or certification label.

If you check inflation pressure when the tires are
warm, you should never release air. The tires
become warm after driving and it is normal for
warm tires to have an inflation pressure above
the recommended pressure for cold tires. A warm
tire with an inflation pressure equal to or under
the recommended pressure for cold tires could
be significantly under-inflated.

Related information

•

Adjusting tire pressure (p. 550)

•

Recommended tire pressure (p. 551)

•

Tire pressure monitoring system* (p. 551)

•

Tires (p. 542)

4

Not available in all models.

WHEELS AND TIRES

550

Adjusting tire pressure

Tire pressure decreases over time, which is nor-
mal. The tire pressure must therefore be
adjusted to maintain the recommended tire pres-
sure.

Use the recommended inflation pressure for cold
tires for optimal tire performance and wear.

NOTE

To help prevent incorrect inflation pressure,
pressure should be checked when the tires
are cold. The tires are considered to be cold
when they have reached the same tempera-
ture as the ambient temperature (about 3
hours after the vehicle was last driven). After
driving for a few kilometers, the tires will warm
up and the pressure will increase.

1. Remove the valve cap from the tire and press

the air pressure gauge firmly onto the valve.

2. Inflate the tire to the correct inflation pres-

sure; see the tire pressure placard on the
driver's side B pillar for recommended pres-
sures for factory-mounted tires.

3. Screw the valve cap back on.

NOTE

•

After inflating a tire, always replace the
valve cap to help prevent valve damage
caused by gravel, dirt, etc.

•

Use plastic valve caps only. Metal caps
could corrode and become difficult to
remove.

4. Visually inspect the tire to make sure there

are no nails or other embedded objects that
could puncture the tire and cause air leak-
age.

5. Check the sidewalls to make sure there are

no gouges, cuts, bulges or other irregulari-
ties.

6. Repeat this procedure for each tire, including

the spare tire

5

.

NOTE

If you have overfilled the tire, release air by
pushing on the metal stem in the center of
the valve. Then recheck the pressure with
your tire gauge.

Some spare tires require higher inflation pres-
sure than the other tires. Consult the tire
inflation pressure table or the inflation pres-
sure placard.

Related information

•

Recommended tire pressure (p. 551)

•

Checking tire pressure (p. 549)

•

Inflate tires with the compressor included in
the tire sealing system (p. 569)

•

Approved tire pressure (p. 649)

5

Not available on all models.

WHEELS AND TIRES

}}

* Option/accessory.

551

Recommended tire pressure

The tire pressure placard on the driver's side B
pillar (between the front and the rear door) indi-
cates tire pressure for different loads and speed
conditions.

The decal specifies the designation for the fac-
tory-mounted tires on the vehicle, as well as load
limits and inflation pressures.

Related information

•

Checking tire pressure (p. 549)

•

Approved tire pressure (p. 649)

Tire pressure monitoring system*

The tire pressure monitoring system

6

 provides a

warning symbol in the instrument panel if pres-
sure is too low in one or more tires.

Symbol

Explanation

This symbol illuminates to indicate
low inflation pressure.

If there is a system malfunction, the
inflation pressure warning symbol
will flash for approximately one
minute and then glow steadily.

System description

The tire pressure monitoring system measures
differences in rotational speed between the
wheels through the ABS system to determine if
the tires are properly inflated. If inflation pressure
in a tire is too low, its diameter (and consequently
its rotational speed) changes. By comparing the
tires with each other, the system can determine if
the pressure in one or more tires is too low.

General information about the tire pressure
monitoring system

In the following description, the tire monitoring
system is generally referred to as TPMS.

Each tire, including the spare (if provided)

7

should be checked monthly when cold and infla-

ted to the inflation pressure recommended by the
vehicle manufacturer on the vehicle placard or
tire inflation pressure label. (If your vehicle has
tires of a different size than the size indicated on
the vehicle placard or tire inflation pressure label,
you should determine the proper tire inflation
pressure for those tires.)

As an added safety feature, your vehicle has
been equipped with a tire pressure monitoring
system (TPMS) that illuminates a low tire pres-
sure telltale when one or more of your tires is
significantly under-inflated. Accordingly, when the
low tire pressure telltale illuminates, you should
stop and check your tires as soon as possible,
and inflate them to the proper pressure.

Driving on a significantly under-inflated tire cau-
ses the tire to overheat and can lead to tire fail-
ure. Under-inflation also reduces fuel efficiency
and tire tread life, and may affect the vehicle's
handling and stopping ability. Please note that
the TPMS is not a substitute for proper tire main-
tenance, and it is the driver's responsibility to
maintain correct tire pressure, even if under-infla-
tion has not reached the level to trigger illumina-
tion of the TPMS low tire pressure telltale.

Your vehicle has also been equipped with a
TPMS malfunction indicator to indicate when the
system is not operating properly. The TPMS mal-
function indicator is combined with the low tire

6

Tire Pressure Monitoring System (TPMS)

7

Not available on all models.

||

WHEELS AND TIRES

* Option/accessory.

552

pressure telltale. When the system detects a mal-
function, the telltale will flash for approximately
one minute and then remain continuously illumi-
nated. This sequence will continue upon subse-
quent vehicle start-ups as long as the malfunc-
tion exists. When the malfunction indicator is illu-
minated, the system may not be able to detect or
signal low tire pressure as intended.

TPMS malfunctions may occur for a variety of
reasons, including the installation of replacement
or alternate tires or wheels on the vehicle that
prevent the TPMS from functioning properly.

Always check the TPMS malfunction telltale after
replacing one or more tires or wheels on your
vehicle to ensure that the replacement or alter-
nate tires and wheels allow the TPMS to con-
tinue to function properly.

Messages in the instrument panel

If tire pressure is too low, the low tire pressure
warning symbol is shown in the instrument panel
along with a message.

•

Tire pressure low



Check tires, calibrate

after fill

•

Tire pressure system



Temporarily

unavailable

•

Tire pressure system



Service required

To keep in mind

•

Always calibrate the system after changing
wheels or adjusting tire pressure. See the tire
pressure placard on the driver's side B pillar
for Volvo-recommended tire pressures.

•

If you switch to a tire of another size than the
factory-mounted tires, the system must be
calibrated for these tires to avoid false warn-
ings.

•

If a spare wheel

8

 is used, it is possible that

the tire pressure monitoring system will not
work correctly due to the differences
between the wheels.

•

The system does not replace the need for
regular tire inspection and maintenance.

•

It is not possible to deactivate the tire pres-
sure monitoring system.

WARNING

•

Incorrect inflation pressure could lead to
tire failure, which could cause the driver
to lose control of the vehicle.

•

The system cannot predict sudden tire
damage.

Related information

•

Recommended tire pressure (p. 551)

•

Viewing tire pressure status in the center
display* (p. 554)

•

Action when warned of low tire pressure
(p. 555)

•

Calibrating the tire pressure monitoring sys-
tem* (p. 553)

8

Not available on all models.

WHEELS AND TIRES

}}

* Option/accessory.

553

Calibrating the tire pressure

monitoring system*

In order for the tire pressure monitoring system

9

to function correctly, tire pressure reference val-
ues must be set correctly. This must be done
each time the tires are changed or the tire pres-
sure is adjusted.

For example, when driving with a heavy load or at
high speeds (over 160 km/h (100 mph)), tire
pressure should be adjusted to the Volvo-recom-
mended tire pressure values. The system should
then be recalibrated.

1. Switch off the ignition.

2. Inflate the tire to the correct inflation pres-

sure; see the tire pressure placard on the
driver's side B pillar for recommended pres-
sures for factory-mounted tires.

3. Start the vehicle.

4. Open the

Car Status

 app in App view.

5. Tap

TPMS

.

NOTE

The car must be stationary when calibration is
started.

6. Tap

Calibrate

.

7. Tap

OK

 to confirm that the tire pressure in

all four tires has been checked and adjusted.

8. Run the car until calibration is complete.

Calibration is done when the vehicle is driv-
ing at a speed above 35 km/h (22 mph).

If the car's ignition is switched off before cal-
ibration is complete, the tires in the center
display change color from gray to green upon
next start-up, even if calibration is not com-
plete. Perform the calibration again and allow
it to complete within the same operating
cycle to ensure that the calibration is carried
out correctly.
> When enough data has been collected for

the system to detect low tire pressure, the
color of the tire symbols in the center dis-
play will change from gray to green. The
system will not provide any other confir-
mation that calibration has been comple-
ted.

If start-up of calibration fails, the following
message appears:

Calibration

unsuccessful. Try again.

.

9

Tire Pressure Monitoring System (TPMS)

||

WHEELS AND TIRES

* Option/accessory.

554

NOTE

Always remember to calibrate the Tire Pres-
sure Monitoring System when the wheels
have been changed or the tire inflation pres-
sure has been corrected according to the tire
pressure decal or tire inflation pressure table.

If correct reference values have not been set,
the system cannot issue low tire pressure
alerts correctly.

The vehicle must be stationary with the
engine running to access the calibration but-
ton and to start the calibration process.

WARNING

The exhaust gases contain carbon monoxide,

which is invisible and odorless but very poi-

sonous. For this reason, always perform the

calibration procedure outdoors or in a work-

shop with exhaust gas evacuation equipment.

Related information

•

Recommended tire pressure (p. 551)

•

Adjusting tire pressure (p. 550)

•

Viewing tire pressure status in the center
display* (p. 554)

•

Action when warned of low tire pressure
(p. 555)

•

Tire pressure monitoring system* (p. 551)

Viewing tire pressure status in the

center display*

With the system for tire pressure monitoring

10

,

tire pressure status can be viewed in the center
display.

Checking status

1. Open the

Car Status

 app in App view.

2. Tap

TPMS

 to display the status of the tires.

Status indicator light

The graphic in the center display shows the sta-
tus of each tire

11

.

Green tire:

•

Inflation pressure is above the warning
threshold.

Yellow tire:

•

The tire's inflation pressure is too low. Stop
and check/inflate the tire as soon as possi-
ble. Recalibrate the system after adjusting
the tire pressure.

All tires yellow:

•

The inflation pressure is too low in one or
more tires. Stop and check/inflate the tires
as soon as possible. Recalibrate the system
after adjusting tire pressure.

10

Tire Pressure Monitoring System (TPMS)

WHEELS AND TIRES

}}

* Option/accessory.

555

All tires gray:

•

Calibration in progress.

•

Status unknown.

The vehicle may need to be driven for a few
minutes at a speed above 35 km/h (22 mph) to
activate the system.

All tires gray and a message:

•

Tire pressure system



Temporarily

unavailable

. The indicator symbol will flash

for about 1 minute and then glow steadily.
The system is temporarily unavailable and will
be activated momentarily.

•

Tire pressure system



Service required

.

The indicator symbol will flash for about 1
minute and then glow steadily. If the system
is not working properly, contact a work-
shop

12

.

Related information

•

Calibrating the tire pressure monitoring sys-
tem* (p. 553)

•

Action when warned of low tire pressure
(p. 555)

•

Tire pressure monitoring system* (p. 551)

•

Vehicle status (p. 588)

Action when warned of low tire

pressure

When the system for monitoring inflation pres-
sure

13

 detects low inflation pressure in a tire,

immediate action is required.

If the system's indicator symbol illumi-
nates and the message

Tire pressure

low

 is displayed, check the tire pres-

sure and inflate if necessary.

1. Switch off the ignition.

2. Check the inflation pressure on all four tires

using a tire pressure gauge.

3. Inflate the tire to the correct inflation pres-

sure; see the tire pressure placard on the
driver's side B pillar for recommended pres-
sures for factory-mounted tires.

4. Through calibration of the system via the

center display after the tire pressure has
been adjusted.

Please be aware that the indicator symbol
will not go out until the low tire pressure has
been corrected and the system has been
recalibrated.

NOTE

To help prevent incorrect inflation pressure,
pressure should be checked when the tires
are cold. The tires are considered to be cold
when they have reached the same tempera-
ture as the ambient temperature (about 3
hours after the vehicle was last driven). After
driving for a few kilometers, the tires will warm
up and the pressure will increase.

NOTE

•

After inflating a tire, always replace the
valve cap to help prevent valve damage
caused by gravel, dirt, etc.

•

Use plastic valve caps only. Metal caps
could corrode and become difficult to
remove.

WARNING

•

Incorrect inflation pressure could lead to
tire failure, which could cause the driver
to lose control of the vehicle.

•

The system cannot predict sudden tire
damage.

11

The illustration is generic. Layout may vary depending on vehicle model or software version.

12

An authorized Volvo workshop is recommended.

13

Tire Pressure Monitoring System (TPMS)

||

WHEELS AND TIRES

* Option/accessory.

556

Related information

•

Recommended tire pressure (p. 551)

•

Adjusting tire pressure (p. 550)

•

Calibrating the tire pressure monitoring sys-
tem* (p. 553)

•

Viewing tire pressure status in the center
display* (p. 554)

•

Tire pressure monitoring system* (p. 551)

•

Inflate tires with the compressor included in
the tire sealing system (p. 569)

When changing wheels

The wheels can be changed, e.g. to switch to
snow tires or spare tires. Follow the applicable
instructions for removing and installing the
wheel.

Changing to tires of another dimension

Make sure that the tire dimension is approved for
use on the vehicle.

If you change to tires of another dimension, con-
tact an authorized Volvo workshop to update the
vehicle's software. A software update may be
necessary when changing to tires of larger/
smaller dimensions or when changing to or from
snow tires.

Related information

•

Removing a wheel (p. 558)

•

Installing a wheel (p. 560)

•

Tool kit (p. 556)

•

Snow tires (p. 563)

•

Spare wheel (p. 561)

•

Wheel bolts (p. 557)

Tool kit

Tools for e.g. towing or changing wheels are
provided in the vehicle's trunk.

The foam block under the cargo compartment
floor contains the towing eyelet, the tire sealing
system, the tool for removing plastic wheel bolt
covers and the tool for removing the locking
wheel bolts.

If the vehicle is equipped with a spare wheel*

14

, a

jack, lug wrench, and a package with
disposable gloves and a bag for the damaged
wheel are also provided.

Related information

•

When changing wheels (p. 556)

•

Jack* (p. 557)

14

Not available on all models.

WHEELS AND TIRES

}}

* Option/accessory.

557

Jack*

The jack can be used to lift the vehicle to e.g.
change a wheel.

The illustration is generic – the design may vary.

CAUTION

•

When not in use, the jack* should be kept
in its storage compartment under the
cargo compartment floor.

•

The jack provided with your vehicle is
intended to be used only in temporary sit-
uations such as changing wheels in the
event of a flat tire. Only the jack that
came with your particular model should
be used to lift the vehicle. If the vehicle
needs to be lifted more frequently or for a
prolonged period, using a garage jack or
hoist is recommended. Always follow this
device's instructions for use.

The jack needs to be cranked together to the
correct position in order to fit.

Models with leveling control*

If the vehicle is equipped with the optional pneu-
matic suspension, it must be turned off before
the vehicle is lifted on a jack.

Related information

•

Tool kit (p. 556)

Wheel bolts

The wheel bolts hold the wheel in place on the
wheel hub.

CAUTION

The wheel bolts should be tightened to
140 Nm (103 ft. lbs.). Over-tightening or
under-tightening could damage the threaded
joints.

Only use rims that have been tested and
approved by Volvo and are included in Volvo's
original product range.

Use a torque wrench to check that the wheel
bolts are tightened correctly.

Do not grease the wheel bolt threads.

WARNING

The wheel bolts may need to be tightened

again several days after a wheel change.

Temperature fluctuations and vibrations can

cause them to loosen slightly.

Locking wheel bolts*

A tool for removing the locking wheel bolts is
located in the foam block under the cargo com-
partment floor.

||

WHEELS AND TIRES

* Option/accessory.

558

Related information

•

Removing a wheel (p. 558)

•

Installing a wheel (p. 560)

Removing a wheel

Instructions for removing a wheel when chang-
ing wheels. Wheel changes must always be car-
ried out correctly.

CAUTION

•

When not in use, the jack* should be kept
in its storage compartment under the
cargo compartment floor.

•

The jack provided with your vehicle is
intended to be used only in temporary sit-
uations such as changing wheels in the
event of a flat tire. Only the jack that
came with your particular model should
be used to lift the vehicle. If the vehicle
needs to be lifted more frequently or for a
prolonged period, using a garage jack or
hoist is recommended. Always follow this
device's instructions for use.

WARNING

•

Apply the parking brake and put the gear
selector in the Park (P) position.

•

Block the wheels standing on the ground,
use rigid wooden blocks or large stones.

•

Check that the jack is not damaged, the
threads are properly lubricated and it is
free from dirt.

•

Be sure the jack is on a firm, level, non-
slippery surface and that it is upright and
not leaning.

•

The jack must correctly engage in the
jack attachment.

•

No objects should be placed between the
base of the jack and the ground, or
between the jack and the attachment bar
on the vehicle.

•

Never let anyone remain in the vehicle
when it is raised on a jack.

•

If a tire must be changed near passing
traffic, make sure all passengers move to
a safe location.

•

Use a jack intended for the vehicle when
changing a tire. For any other job, use
stands to support the vehicle.

•

Never crawl under or allow any part of
your body to be extended under a vehicle
supported by a jack.

WHEELS AND TIRES

}}

* Option/accessory.

559

1. Turn on the vehicle's hazard warning flashers

if a wheel change must be performed in an
area with traffic.

2. Apply the parking brake and put the gear

selector in P.

For vehicles with

Leveling Control

*

: If the

vehicle is equipped with pneumatic suspen-
sion, this must be switched off before the
vehicle is lifted with the jack*.

3. Take out the jack*, lug wrench* and tool for

removing the plastic covers, which are
stowed in the foam block.

Tool for removing the plastic covers on the wheel bolts.

4. Place chocks in front of and behind the

wheels that are still on the ground. For exam-
ple, use heavy wooden blocks or large
stones.

5. Using the lug wrench*, screw the towing eye

into place as far as possible according to the
instructions.

CAUTION

The towing eyelet must be screwed into the
lug wrench* as far as possible.

6. Remove the plastic covers from the wheel

bolts using the designated tool.

7. With the vehicle still on the ground, use the

lug wrench/towing eye to loosen the wheel
bolts ½-1 turn by pressing downward (coun-
terclockwise).

8. When hoisting the vehicle, it is important that

the jack* or garage lift arms are positioned
on the designated points under the vehicle.
The triangle markings on the plastic cover
indicate where the jack attachment points/
lifting points are located. There are two jack
attachment points on each side of the vehi-
cle. There is a groove for the jack at each
attachment point.

9. Position the jack under the attachment point

being used, ensuring that the surface is firm,
flat and not slippery.

||

WHEELS AND TIRES

* Option/accessory.

560

10. Crank it up until it is properly aligned and it is

in contact with the vehicle's jack attachment
point. Make sure the top of the jack (or the
garage lift arms) is correctly positioned in the
attachment point, with the bump on the top
of the jack in the recess in the attachment
point and the base positioned vertically under
the attachment point.

11. Turn the jack so that the crank is as far as

possible from the side of the vehicle, which
will position the jack's arms perpendicular to
the vehicle's direction of movement.

12. Raise the vehicle until the wheel to be

changed can move freely. Unscrew the wheel
bolts and lift off the wheel.

Related information

•

Leveling control settings* (p. 453)

•

When changing wheels (p. 556)

•

Hoisting the vehicle (p. 592)

•

Jack* (p. 557)

•

Tool kit (p. 556)

•

Installing a wheel (p. 560)

Installing a wheel

Instructions for installing a wheel during a wheel
change.

NOTE

The jack provided with your vehicle is
intended to be used only in temporary situa-
tions such as changing wheels in the event of
a flat tire. Only the jack that came with your
particular model should be used to lift the
vehicle. If the vehicle needs to be lifted more
frequently or for a prolonged period, using a
garage jack or hoist is recommended. Always
follow this device's instructions for use.

WARNING

•

Apply the parking brake and put the gear
selector in the Park (P) position.

•

Block the wheels standing on the ground,
use rigid wooden blocks or large stones.

•

Check that the jack is not damaged, the
threads are properly lubricated and it is
free from dirt.

•

Be sure the jack is on a firm, level, non-
slippery surface and that it is upright and
not leaning.

•

The jack must correctly engage in the
jack attachment.

•

No objects should be placed between the
base of the jack and the ground, or
between the jack and the attachment bar
on the vehicle.

•

Never let anyone remain in the vehicle
when it is raised on a jack.

•

If a tire must be changed near passing
traffic, make sure all passengers move to
a safe location.

•

Use a jack intended for the vehicle when
changing a tire. For any other job, use
stands to support the vehicle.

•

Never crawl under or allow any part of
your body to be extended under a vehicle
supported by a jack.

WHEELS AND TIRES

}}

* Option/accessory.

561

1. Clean the contact surfaces between the

wheel and the wheel hub.

2. Lift the wheel into place. Tighten the wheel

bolts securely.

Do not grease the wheel bolt threads.

3. Lower the vehicle so that the wheel cannot

rotate.

4. Tighten the wheel bolts in a crisscross pat-

tern (as shown in illustration). It is important
that the wheel bolts are securely tightened.
Tighten to a torque of 140 Nm (103 ft.lbs.).
Use a torque wrench to check torque.

5. Press the plastic covers onto the wheel bolts.

WARNING

The wheel bolts may need to be tightened

again several days after a wheel change.

Temperature fluctuations and vibrations can

cause them to loosen slightly.

NOTE

•

After inflating a tire, always replace the
valve cap to help prevent valve damage
caused by gravel, dirt, etc.

•

Use plastic valve caps only. Metal caps
could corrode and become difficult to
remove.

Related information

•

Leveling control settings* (p. 453)

•

When changing wheels (p. 556)

•

Hoisting the vehicle (p. 592)

•

Jack* (p. 557)

•

Tool kit (p. 556)

•

Removing a wheel (p. 558)

Spare wheel

15

The spare wheel is a Temporary Spare and can
be used to temporarily replace a punctured tire
on one of the vehicle's regular wheels.

The spare tire is only intended for temporary use.
Replace it with a normal wheel as soon as possi-
ble.

The driving characteristics of the vehicle change
and ground clearance reduces when the spare
wheel is used. Do not wash the vehicle in an
automatic car wash while using the Temporary
Spare.

The recommended tire pressure must be main-
tained regardless of at which position the tempo-
rary spare wheel is used on the vehicle.

If the spare wheel is damaged, a new one can be
purchased from a Volvo retailer.

WARNING

Current legislation prohibits the use of the

"Temporary Spare" tire other than as a tem-

porary replacement for a punctured tire. It

must be replaced as soon as possible by a

standard tire. Road holding and handling may

be affected with the "Temporary Spare" in

use. Do not drive faster than 80 km/h

(50 mph).

15

Not available on all models.

||

WHEELS AND TIRES

562

WARNING

•

The vehicle must never be driven with
more than one "Temporary Spare" tire
mounted.

•

Driving with a spare wheel may alter the
driving characteristics of the vehicle.
Replace the spare wheel with a normal
wheel as soon as possible.

•

The spare wheel is smaller than the nor-
mal wheel, which affects the vehicle's
ground clearance. Watch for high curbs
and do not wash the vehicle in an auto-
matic car wash when a spare wheel is
mounted.

•

Follow the manufacturer's recommended
tire inflation pressure for the spare wheel.

•

On all-wheel drive vehicles, the drive on
the rear axle can be disconnected.

•

If the spare wheel is mounted on the
front axle, snow chains must not be used.

•

The spare wheel must not be repaired.

CAUTION

The vehicle must not be driven with wheels of
different dimensions or with a spare tire other
than the one that came with the vehicle. The
use of different size wheels can seriously
damage your vehicle's transmission.

Related information

•

When changing wheels (p. 556)

•

Recommended tire pressure (p. 551)

Accessing the spare wheel

Follow these instructions regarding handling the
spare wheel.

The spare wheel is stored in a bag and should be
secured with two straps onto the floor of the
trunk/cargo compartment when the vehicle is
being driven. The straps should be strapped
down crosswise over the wheel, attached to the
load anchoring eyelets and pulled taut.

Wheel changing tools are located under the
cargo compartment floor.

Related information

•

Spare wheel (p. 561)

WHEELS AND TIRES

}}

563

Snow tires

Snow tires are designed for winter driving.

Volvo recommends snow tires with specific
dimensions. The tire dimensions vary depending
on engine type. When driving with snow tires, the
correct type of tires must be mounted on all four
wheels.

NOTE

Contact a Volvo dealer for advice on the best
choice of rims and tires.

Tips for changing snow tires

When switching between regular tires and snow
tires, mark the tires according to which side they
were mounted on, e.g. L for left and R for right.

Studded tires

Studded tires should be broken in by driving
500–1000 km (300–600 miles) slowly and gen-
tly to help the studs settle properly in the tires.
This gives the tire, and especially the studs, a
longer service life.

NOTE

Regulations regarding the use of studded
tires vary from country to country.

Tread depth

Road conditions with ice, slush and low tempera-
tures place considerably higher demands on tires
than summer conditions. Volvo therefore recom-
mends not driving on snow tires that have a tread
depth of less than 4 mm (0.15 inch).

Related information

•

When changing wheels (p. 556)

•

Winter driving (p. 458)

•

Tread wear indicator (p. 545)

Snow chains

Using snow chains and/or snow tires can help
improve traction in winter driving conditions.

WARNING

Use Volvo genuine snow chains or equivalent

snow chains that are suitable for the vehicle

model and the tire and wheel sizes. Only one-

sided snow chains are permitted.
If uncertain about snow chains, Volvo recom-

mends contacting an authorized Volvo work-

shop. Use of the wrong snow chains could

cause serious damage to the vehicle and

result in an accident.
