Volvo S60 Cross Country (2018 year). Instruction

INSTRUMENTS AND CONTROLS

}}

* Option/accessory.

•

In heavy rain or dense fog

•

In freezing rain

•

In snow flurries or slush

•

In moonlight

•

When driving in poorly lit built-up areas

•

When the traffic ahead has weak lighting

•

If there are pedestrians on or beside the
road

•

If there are highly reflective objects such
as signs in the vicinity of the road

•

When the lighting from oncoming traffic
is obscured by e.g. a crash barrier

•

When there is traffic on connecting roads

•

On the brow of a hill or in a hollow

•

In sharp bends.

For more information on the limitations of the
camera sensor, see Collision warning system

* -

camera sensor limitations (p. 229).

Related information

•

Main/dipped beam (p. 88)

•

Light switches (p. 85)

Active Xenon headlamps*

Active xenon headlamps/active bending lights
are designed to provide maximum illumination in
bends and junctions and so provide increased
safety.

Active xenon headlamps/active
bending lights - ABL

Headlamp pattern with function deactivated (left) and

activated (right) respectively.

If the car is equipped with active xenon head-
lamps/active bending lights (Active Bending
Lights, ABL) the light from the headlamps follows
the steering wheel movement in order to provide
maximum lighting in bends and junctions and so
provide increased safety.

The function is activated automatically when the
car is started (provided that it has not been deac-

tivated in the menu system MY CAR, see MY
CAR (p. 109)). In the event of a fault in the func-
tion the

symbol illuminates in the com-

bined instrument panel at the same time as the
information display shows an explanatory text and
a further illuminated symbol.

Symbol

Message

Specification

Headlamp
system
malfunction
Service
required

The system is dis-
engaged. Visit a
workshop if the
message remains.
Volvo recommends
that you contact an
authorised Volvo
workshop.

The function is only active in twilight or darkness
and only when the car is moving.

The function

can be deactivated/activated in

the menu system MY CAR, see MY CAR
(p. 109).

Activated on delivery from the factory.

INSTRUMENTS AND CONTROLS

* Option/accessory.

Cornering lights*

Active xenon headlamps/active bending lights
with Automatic main beam function with adaptive
functionality are equipped with cornering lights.
The cornering lights temporarily illuminate the
area diagonally in front of the car in the direction
the steering wheel is turned on a sharp bend, or
in the direction shown by the direction indicators.

The function is activated when main beam or
dipped beam is used and the car's speed is lower
than approx. 30 km/h (20 mph).

In addition, both cornering lights are switched on
as a supplement to the reversing lamp during
reversing.

Related information

•

Main/dipped beam (p. 88)

•

Active main beam

* (p. 89)

•

Light switches (p. 85)

Headlamps - adjusting headlamp

pattern

If the car is equipped with active Xenon head-
lamps and has the Active main beam function
then the headlamp pattern must be reset when
changing from right to left-hand traffic, and vice
versa.

Active Xenon headlamps

No adjustment of the headlamp pattern is neces-
sary for cars without the Active main beam

* func-

tion. The headlamp pattern is designed in such a
way that oncoming traffic is not dazzled.

Adjustment of the headlamp pattern is required
for cars with Active main beam. The car must be
stationary with the engine running when the
headlamp pattern is shifted between right and
left-hand traffic.

The headlamp pattern is changed in the menu
system MY CAR, see MY CAR (p. 109).

Halogen headlamps

No adjustment of the headlamp pattern is neces-
sary. The headlamp pattern is designed in such a
way that oncoming traffic is not dazzled.

Rear fog lamp

When visibility is reduced by fog the rear fog
lamp can be used so that other road users can
detect the vehicle in front at an early stage.

Button for rear fog lamp.

The rear fog lamp can only be switched on when
key position II is active or the engine is running
and the headlamp control's knob is in position

Press the button for On/Off. The indicator sym-
bol

in the combined instrument panel and

the light in the button both illuminate when the
rear fog lamp is switched on.

The rear fog lamp is switched off automatically
when the START/STOP ENGINE button is
depressed or when the headlamp control's knob
is turned to position

INSTRUMENTS AND CONTROLS

}}

NOTE

Regulations on the use of rear fog lamps vary
from country to country.

Related information

•

Light switches (p. 85)

Brake lights

The brake light automatically comes on during
braking.

The brake light is switched on when the brake
pedal is depressed. In addition, it is switched on
when one of driving support systems Adaptive
cruise control (p. 196), City Safety (p. 215) or
Collision warning system (p. 222) brakes the car.

Related information

•

Foot brake - emergency brake lights and
automatic hazard warning flashers (p. 295)

Hazard warning flashers

The hazard warning flashers warn other road
users by means of all of the car's direction indi-
cator lamps flashing simultaneously when this
function is activated.

Button for hazard warning flashers.

Press the button to activate the hazard warning
flashers. Both direction indicator symbols in the
combined instrument panel flash when the haz-
ard warning flashers are used.

The hazard warning flashers are activated auto-
matically when the car has been braked so sud-
denly that the emergency brake lights have been
activated and speed is below approx. 10 km/h
(6 mph). The hazard warning flashers remain
active when the car has stopped and are deacti-
vated automatically when you start driving again;
they can also be deactivated by pressing the but-
ton.

INSTRUMENTS AND CONTROLS

Related information

•

direction indicators (p. 94)

•

Foot brake - emergency brake lights and
automatic hazard warning flashers (p. 295)

direction indicators

The car's direction indicators are operated with
the left-hand stalk switch. The direction indicator
lamps flash three times or continuously, depend-
ing on how far up or down the stalk switch is
moved.

Direction indicators.

Short flash sequence

Move the stalk switch up or down to the first
position and release. The direction indicator
lamps flash three times. The function can be
activated/deactivated in the menu system
MY CAR, see MY CAR (p. 109).

Continuous flash sequence

Move the stalk switch up or down to its end
position.

The stalk switch remains in its position and is
moved back manually, or automatically by the
steering wheel movement.

Direction indicator symbols

For direction indicator symbols, see Combined
instrument panel - meaning of indicator symbols
(p. 67).

Related information

•

Hazard warning flashers (p. 93)

INSTRUMENTS AND CONTROLS

}}

Interior lighting

The passenger compartment lighting is acti-
vated/deactivated with the buttons in the con-
trols above the front seats and the rear seat.

G021149

Controls in roof console for the front reading lamps and

passenger compartment lighting.

Reading lamp, left-hand side

Reading lamp, right-hand side

Interior lighting

All lighting in the passenger compartment can be
switched on and off manually within 30 minutes
from when:

•

the engine has been switched off and the
car's electrical system is in key position 0

•

the car has been unlocked but the engine
has not been started.

Front roof lighting

The front reading lamps are switched on or off by
pressing the relevant button in the roof console.

Rear roof lighting

G021150

Rear roof lighting.

The lamps are switched on or off by pressing
each respective button.

Courtesy lighting

Courtesy lighting (and passenger compartment
lighting) is switched on and off respectively when
a side door is opened or closed.

Glovebox lighting

Glovebox lighting is switched on and off respec-
tively when the lid is opened or closed.

Vanity mirror lighting

The lighting for the vanity mirror (p. 147) is
switched on and off respectively when the cover
is opened or closed.

Lighting in cargo area

The lighting in the cargo area is switched on and
off respectively when the boot lid is opened or
closed.

Automatic lighting

The switch for passenger compartment lighting
has three positions for the lighting in the passen-
ger compartment:

•

Off – right-hand side pressed in, automatic
lighting deactivated.

•

Neutral position – automatic lighting acti-
vated.

•

On – left-hand side pressed in, passenger
compartment lighting switched on.

Neutral position

When the button is in neutral position the pas-
senger compartment lighting is switched on and
off automatically in accordance with the following.

The passenger compartment lighting is switched
on and remains on for 30 seconds if:

•

the car is unlocked with the remote control
key or key blade, see Remote control key -

INSTRUMENTS AND CONTROLS

* Option/accessory.

functions (p. 158) or Detachable key blade -
unlocking doors (p. 162)

•

the engine has been switched off and the
car's electrical system is in key position 0.

Passenger compartment lighting is switched off
when:

•

the engine is started

•

the car is locked.

The passenger compartment lighting comes on
and remains on for two minutes if one of the
doors is open.

If any lighting is switched on manually and the
car is locked then it will be switched off automati-
cally after two minutes.

Ambience lights

When the normal passenger compartment light-
ing is switched off and the engine is running, a
number of LEDs illuminate, including one in the
ceiling lighting, in order to provide a low-light and
enhance the mood while driving. The light also
makes it easier to see objects in storage com-
partments etc. during the darker hours of the day.
This lighting goes out for a little while after the
normal passenger compartment lighting when
the car is locked. The brightness is controlled
using the thumbwheel on the headlamp control
(p. 85).

Home safe lighting

Home safe lighting consists of dipped beam,
position lamps, lamps in the door mirrors, num-
ber plate lighting.

Some of the exterior lighting can be kept
switched on to work as home safe lighting after
the car has been locked.

1. Remove the remote control key from the

ignition switch.

2. Move the left-hand stalk switch toward the

steering wheel to the end position and
release it. The function can be activated in
the same way as with main beam flash; see
Main/dipped beam (p. 88).

3. Get out of the car and lock the door.

When the function is activated, dipped beam,
position lamps, lamps in the door mirrors and
number plate lighting are switched on.

The length of time for which the home safe light-
ing should be kept on can be set in the menu
system MY CAR, see MY CAR (p. 109).

Related information

•

Approach lighting (p. 96)

Approach lighting

Approach lighting consists of position lamps,
lamps in the door mirrors, number plate lighting,
interior roof lighting as well as courtesy lighting.

Approach lighting is switched on with the remote
control key, see Remote control key - functions
(p. 158), and is used to switch on the car's light-
ing at a distance.

When the function is activated with the remote
control key, position lamps, lamps in the door mir-
rors, number plate lighting, interior roof lamps
and courtesy lighting are switched on.

The length of time for which the approach light-
ing should be kept on can be set in the menu
system MY CAR, see MY CAR (p. 109).

Related information

•

Home safe lighting (p. 96)

INSTRUMENTS AND CONTROLS

}}

* Option/accessory.

Wipers and washers

Wipers and washers clean the windscreen and
rear window. The headlamps are cleaned with
high-pressure washing.

Windscreen wipers

Windscreen wipers and windscreen washers.

Rain sensor, On/Off

Thumbwheel sensitivity/frequency

Windscreen wipers off

Move the stalk switch to position 0 to
switch off the windscreen wipers.

Single sweep

Raise the stalk switch and release to
make one sweep.

Intermittent wiping

Set the number of sweeps per time
unit with the thumbwheel when inter-
mittent wiping is selected.

Continuous wiping

The wipers sweep at normal speed.

The wipers sweep at high speed.

IMPORTANT

Before activating the wipers - ensure that the
wiper blades are not frozen in, and that any
snow or ice on the windscreen (and rear win-
dow) is scraped away.

IMPORTANT

Use plenty of washer fluid when the wipers
are cleaning the windscreen. The windscreen
must be wet when the windscreen wipers are
operating.

Service position wiper blade

For cleaning the windscreen/wiper blades and
replacement of wiper blades, see Car wash
(p. 391) and Wiper blades (p. 368).

Rain sensor

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen. The sensitivity of the
rain sensor can be adjusted using the thumb-
wheel.

When the rain sensor is activated a lamp in the
button is illuminated and the rain sensor symbol

is shown in the combined instrument

panel.

Activating and setting the sensitivity

When activating the rain sensor, the car must be
running or the remote control key in position I or
II while the windscreen wiper stalk switch must
be in position 0 or in the position for a single
sweep.

Activate the rain sensor by pressing the rain sen-
sor button

. The windscreen wipers make

one sweep.

Press the stalk switch up for the wipers to make
an extra sweep.

Turn the thumbwheel upward for higher sensitiv-
ity and downward for lower sensitivity. (An extra
sweep is made when the thumbwheel is turned
upward.)

For replacing the wiper blades and service position wiper blades, see Wiper blades (p. 368). For filling washer fluid, see Washer fluid - filling (p. 369).

INSTRUMENTS AND CONTROLS

* Option/accessory.

Deactivate

Deactivate the rain sensor by pressing the rain
sensor button

or move the stalk switch

down to another wiper program.

The rain sensor is automatically deactivated when
the remote control key is removed from the igni-
tion switch or five minutes after the engine has
been switched off.

IMPORTANT

The windscreen wipers could start and be
damaged in an automatic car wash. Switch off
the rain sensor while the car is in motion or
when the remote control key is in position I or
II. The symbol in the combined instrument
panel and the lamp in the button go out.

Washing the headlamps and windows

Washing function.

Washing the windscreen

Move the stalk switch toward the steering wheel
to start the windscreen and headlamp washers.

The windscreen wipers will make several more
sweeps and the headlamps are washed once the
stalk switch has been released.

Heated washer nozzles

The washer nozzles are heated automatically in
cold weather to prevent the washer fluid freezing
solid.

High-pressure headlamp washing

High-pressure headlamp washing consumes a
large quantity of washer fluid. To save fluid, the
headlamps are washed automatically at every
fifth windscreen wash cycle.

Reduced washing

If only approx. 1 litre of washer fluid remains in
the reservoir and the message that you should fill
the washer fluid is shown in the combined instru-
ment panel, then the supply of washer fluid to the
headlamps is switched off. This is in order to pri-
oritise cleaning the windscreen and the visibility
through it.

Related information

•

Washer fluid - filling (p. 369)

Power windows

All power windows can be operated using the
control panel for the driver's door - the control
panels for the other doors operate their respec-
tive power window.

Driver's door control panel.

Electric child safety locks that prevent chil-
dren from being able to open the rear doors
from inside

* and open/close the rear win-

dows, see Child safety locks - electrical acti-
vation

* (p. 177).

Controls for rear windows

Controls for front windows

INSTRUMENTS AND CONTROLS

}}

WARNING

Check that children or other passengers are

not trapped when the windows are closed

from the driver's door.

WARNING

Check that no children or other passengers

are trapped if/when the windows are closed

using the remote control key.

WARNING

If there are children in the car - remember to

always switch off the power supply to the

power windows by selecting key position 0

and then take the remote control key with you

when leaving the car. For information on key

positions - see Key positions - functions at

different levels (p. 77).

Operating

Operating the power windows.

Operating without auto

Operating with auto

All power windows can be operated using the
control panel for the driver's door - the control
panels for the other doors can only operate their
respective power window. Only one control panel
can be operated at a time.

In order for the power windows to be used, the
key position must be at least I - see Key posi-
tions - functions at different levels (p. 77). The
power windows can be operated for a few
minutes after the engine has been switched off
and after the remote control key has been
removed - although not after a door has been
opened.

Closing of the windows is stopped and the win-
dow is opened if anything prevents its movement.
It is possible to override the pinch protection
when closing has been interrupted, e.g. if there is
ice forming. After two successive closing inter-
ruptions the pinch protection will be forced and
the automatic function deactivated for a short
while, now it is possible to close by continually
holding the button pulled up.

NOTE

One way to reduce the pulsating wind noise
when the rear windows are open is to also
open the front windows slightly.

Operating without auto

Move one of the controls up/down gently. The
power windows move up/down as long as the
control is held in position.

Operating with auto

Move one of the controls up/down to the end
position and release it. The window runs auto-
matically to its end position.

Operating with the remote control key or
central locking button

To operate the power windows from the outside
with the remote control key, or from inside with
the central locking button, see Remote control
key - functions (p. 158) or Locking/unlocking -
from the inside (p. 171).

INSTRUMENTS AND CONTROLS

* Option/accessory.

100

Resetting

If the battery is disconnected then the function
for automatic opening must be reset so that it
can work correctly.

1. Gently raise the front section of the button to

raise the window to its end position and hold
it there for one second.

2. Release the button briefly.

3. Raise the front section of the button again

for one second.

WARNING

A reset must take place for pinch protection

to work.

Sun blind*

There is a sun blind built into the rear parcel
shelf.

–

Pull up the sun blind and hook it into the roof
clip using the two hooks for the blind.
> The spring force in the blind keeps the

hooks in position.

When the sun blind is not in use - unhook it, hold
onto the handle and allow the blind to roll up
slowly.

Door mirrors

The door mirror positions are adjusted with the
joystick in the driver's door controls.

Controls for door mirrors.

Adjusting

1. Press the L button for the left-hand door mir-

ror or the R button for the right-hand door
mirror. The light in the button illuminates.

2. Adjust the position with the joystick in the

centre.

3. Press the L or R button again. The light

should no longer be illuminated.

INSTRUMENTS AND CONTROLS

* Option/accessory.

101

WARNING

Both mirrors are bent to provide optimal

vision. Objects may appear further away than

they actually are.

Storing settings

The settings for the door mirrors and the posi-
tions of the driver's seat can be stored for each
remote control key in the car key memory

*, see

Remote control key - personalisation

* (p. 155).

Angling the door mirror when parking

The door mirror can be angled down for the
driver to view the side of the road when parking
for example.

–

Engage reverse gear and press the L or R
button.

When reverse gear is disengaged the mirror
automatically returns to its original position after
approx. 10 seconds, or earlier by pressing the
button labelled L or R respectively.

Automatic angling of the door mirror
when parking

When reverse gear is engaged the door mirror is
automatically angled down so that the driver can
see the side of the road when parking for exam-
ple. When reverse gear is disengaged the mirror

automatically returns to its original position after
a short time.

The function can be activated/deactivated in the
menu system MY CAR, see MY CAR (p. 109).

Automatic retraction when locking

When the car is locked/unlocked with the remote
control key the door mirrors are automatically
retracted/extended.

The function can be activated/deactivated in the
menu system MY CAR, see MY CAR (p. 109).

Resetting to neutral

Mirrors that have been moved out of position by
an external force must be reset electrically to the
neutral position for electric retracting/extending
to work correctly:

1. Retract the mirrors with the L and R buttons.

2. Fold them out again with the L and R but-

tons.

3. Repeat the above procedure as necessary.

The mirrors are now reset in neutral position.

Automatic dimming

For the door mirrors to be fitted with this function
requires that the interior rearview mirror also has
automatic dimming, see Rearview mirror - interior
(p. 102).

Retractable power door mirrors

The mirrors can be retracted for parking/driving
in narrow spaces:

1. Depress the L and R buttons simultaneously

(key position must be at least I).

2. Release them after approximately 1 second.

The mirrors automatically stop in the fully
retracted position.

Fold out the mirrors by pressing down the L and
R buttons simultaneously. The mirrors automati-
cally stop in the fully extended position.

Home safe and approach lighting

The lamp on the door mirrors illuminates when
approach lighting (p. 96) or home safe lighting
(p. 96) is selected.

Related information

•

Rearview mirror - interior (p. 102)

•

Windows and rearview and door mirrors -
heating (p. 102)

Only in combination with power seat with memory, see Seats, front - electrically operated

* (p. 80).

INSTRUMENTS AND CONTROLS

* Option/accessory.

102

Windows and rearview and door

mirrors - heating

The defroster is used to quickly remove misting
and ice from the windscreen, rear window and
door mirrors.

Heated windscreen

*, rear window and

door mirrors

Heating, windscreen

Heating, rear window and door mirrors

The function is used to remove ice and misting
from the windscreen, rear window and door mir-
rors.

One press of the respective button starts the
heating. The light in the button indicates that the
function is active. Switch off the heating as soon
as the ice/misting is cleared in order not to load
the battery unnecessarily. However, the function

is switched off automatically after a certain time.
Following which, rear window heating is switched
on and off automatically as long as the outside
temperature is lower than +7 °C.

NOTE

Rear window heating is not switched on and
off automatically if the Eco function is acti-
vated, but then remains switched off, even in
outside temperatures below +7 °C. For infor-
mation about the Eco function, see Drive
mode ECO

* (p. 292).

The door mirrors and rear window are demisted/
defrosted automatically if the car is started in an
outside temperature lower than +7 °C. Automatic
defrosting can be selected in the menu system
MY CAR, see MY CAR (p. 109).

Using the Engine Remote Start (ERS)

* function,

the heated windscreen is demisted/defrosted
automatically if the ambient temperature is lower
than +5 °C and automatic defrosting has been
selected in the menu system MY CAR.

Rearview mirror - interior

The interior rearview mirror can be dimmed with
a control in the mirror's lower edge. Alternatively,
the rearview mirror dims automatically.

Control for dimming

Manual dimming

Bright light from behind could be reflected in the
rearview mirror and dazzle the driver. Use dim-
ming with the dimming control when lights from
behind are distracting:

1. Use dimming by moving the control in

towards the passenger compartment.

2. Return to normal position by moving the con-

trol towards the windscreen.

INSTRUMENTS AND CONTROLS

}}

* Option/accessory.

103

Automatic dimming

Bright light from behind is automatically dimmed
by the rearview mirror. The control for manual
dimming is not available on mirrors with auto-
matic dimming.

The rearview mirror contains two sensors - one
forward facing and one rearward facing - that
work together to identify and eliminate dazzling
light. The forward facing sensor detects ambient
light, while the rearward facing sensor detects
the light from vehicle headlights behind.

NOTE

If the sensors are obscured by e.g. parking
permits, transponders, sun visors or objects in
the seats or on the parcel shelf in such a way
that light is prevented from reaching the sen-
sors, then the dimming function of the interior
rearview and door mirrors is reduced.

Only rearview mirror with automatic dimming can
be equipped with compass (p. 103).

Related information

•

Door mirrors (p. 100)

Compass*

The upper right-hand corner of the rearview mir-
ror contains a display that shows the compass
direction in which the front of the car is pointing.

Operation

Rearview mirror with compass.

Eight different directions are shown with English
abbreviations:

(north),

(north east),

(east),

(south east),

(south),

(south west),

(west) and

(north west).

The compass is activated automatically when the
car is started or when key position II is active, see
Key positions - functions at different levels
(p. 77). To deactivate/activate the compass -
press in the button on the underside of the mirror
using a paper clip for example.

Calibration

The compass may need calibrating to show the
correct compass direction.

The earth is divided into 15 magnetic zones. The
compass should be calibrated if the car is moved
across several magnetic zones.

Proceed as follows to perform calibration:

1. Stop the car in a large open area free from

steel structures and high-voltage power lines.

2. Start the car and switch off all electrical

equipment (air conditioning, wipers, etc.) and
ensure that all doors are closed.

NOTE

Calibration may fail or not start at all if electri-
cal equipment is not switched off.

3. Hold the button on the underside of the rear-

view mirror depressed (use a paper clip or
similar) for approx. 3 seconds. The number of
the current magnetic zone is shown.

INSTRUMENTS AND CONTROLS

* Option/accessory.

104

Magnetic zones.

4. Press the button repeatedly until the

required magnetic zone (

1–15

) is shown.

See the map of magnetic zones for the com-
pass.

5. Wait until the display returns to showing the

character

, or hold the button on the under-

side of the rearview mirror depressed for
approx. 6 seconds until the character

shown.

6. Drive slowly in a circle at a speed of no more

than 10 km/h (6 mph) until a compass direc-
tion is shown in the display, indicating that
calibration is complete. Then drive a further
2 circles to fine-tune calibration.

7. Cars with heated windscreen

*: If the

character is shown in the display when the
heated windscreen is activated, perform a
calibration as described in point 6 above with
the heated windscreen activated; see
Demisting and defrosting the windscreen
(p. 130).

8. Repeat the above procedure as necessary.

Sunroof*

The sunroof is operated with the control in the
roof.

The sunroof's inner sunscreen is closed man-
ually.

The sunroof has a wind deflector.

The sunroof controls are located in the roof
panel. The sunroof can be opened vertically at
the rear edge and horizontally. Key position I or II
is required for the sunroof to be opened.

Horizontal opening

G021343

Horizontal opening, backward/forward.

Opening, automatic

Opening, manual

Closing, manual

Closing, automatic

INSTRUMENTS AND CONTROLS

}}

105

Opening

To open the sunroof to comfort position

, press

the control back to the position for automatic
opening and release. To fully open the sunroof,
press the control back to the position for auto-
matic opening again and release.

Open manually by pressing the control back-
wards to the point of resistance for manual open-
ing. The sunroof moves to comfort position

while the control is being pressed backwards. To
fully open the sunroof, press the control back-
wards again.

Closing

Close manually by pushing the control forwards
to the point of resistance for manual closing. The
sunroof moves to the closed position while the
control is being pressed forwards.

WARNING

Risk of crushing when the sunroof is closed.

The sunroof's pinch-protection function only

operates during automatic closing, not man-

ual.

Close automatically by pressing the control to the
position for automatic closing and then release it.

The power supply to the sunroof is switched off
by selecting key position 0 and removing the
remote control key from the ignition switch.

WARNING

If there are children in the car:
Remember to always switch off the power

supply to the sunroof by selecting key posi-

tion 0 and then take the remote control key

with you when leaving the car. For information

on key positions - see Key positions - func-

tions at different levels (p. 77).

Vertical opening

G028899

Vertical opening, raised at the rear edge.

Open by pressing the rear edge of the con-
trol upward.
Close by pulling the rear edge of the control
down.

Closing using the remote control key or
central locking button

G021345

Remote control key
–

Give one long press on the remote control
key's lock button

until the sunroof and

all the windows are closed and the doors and
the boot lid are locked.

To interrupt closing, press the remote control
key's lock button again.

Comfort position is an open position for the sunroof, where wind noise and resonance noise are at a comfortably low level while driving.

INSTRUMENTS AND CONTROLS

* Option/accessory.

106

Central locking button

The central locking button in the driver's door or
passenger door

* can be used to close the sun-

roof.

–

Give one long press on the central locking
button

until the sunroof and all the win-

dows are closed and the doors and the boot
lid are locked.

To interrupt closing, press the central locking
button again.

WARNING

If the sunroof is closed with the remote con-

trol key or the central locking button, check

that no one risks being trapped.

Sunscreen

The sunroof features a manual, sliding interior
sunscreen. The sunscreen slides back automati-
cally when the sunroof is opened. Grip the handle
and slide the sunscreen forward to close it.

Pinch protection

The sunroof has a pinch protection function
which is triggered if it is blocked by an object
during automatic closing. If blocked, the sunroof
will stop and automatically open to the previous
position.

Wind deflector

The sunroof has a wind deflector that is folded
up when the sunroof is in the open position.

Related information

•

Remote control key - functions (p. 158)

•

Locking/unlocking - from the inside (p. 171)

Menu navigation - combined

instrument panel

The left-hand stalk controls the menus (p. 107)
shown on the information display in the com-
bined instrument panel (p. 62). Which menus
are shown depends on the key position (p. 77).

Display (analogue combined instrument panel) and con-

trols for menu navigation.

Volvo S60 Cross Country (2018 year). Instruction - part 5
