Volkswagen Fox (2004 year). Manual - part 39

Kyrgyzstan

Peru

Uruguay

Mainland China

Colombia

Philippines

Uzbekistan

Costa Rica

Croatia

Poland

United Arab Emirates

Dominican Republic

Kuwait

Russia (Eastern & West‐

ern)

Vietnam

El Salvador

Malaysia

Saudi Arabia

Zimbabwe

Ecuador

Morocco

Singapore



Guatemala

Moldavia

South Africa



India

Myanmar

Suriname



10) Yugoslavia = Serbia, Montenegro, Vojvodina, Kosovo

3.8

Engine oils

3.8.1

Approved standards for automotive engine oils

Petrol engines with identification letters AQZ, BAH, BLH, BKR,

BMD, and CFZA

vehicles with PR number (QG0)

Petrol engines

VW standards

3 and 4 cylinders

502 00

Diesel engines with identification letters ASY

vehicles with PR number (QG0)

Diesel engines

VW standards

SDI

505 00 or 505 01

Diesel engines with identification letters BNM

vehicles with PR number (QG0)

Diesel engines

VW standards

TDI

505 01

3.8.2

Oil properties

Multipurpose oils according to VW 505 00 standard:
♦ It can be used throughout the year in mild climate zones.
♦ Excellent cleaning capability.
♦ Lubricating power ensured in every temperature range and

engine load.

♦ High resistance to aging.
Multipurpose oils according to VW 502 00 standard:
♦ It is particularly suitable for use in severe operating conditions,

for instance, in poorly maintained roads under maximum load

conditions and towing, constant traveling in mountain areas

and hot climate zones.

FOX 2004 ➤

3. General remarks

29

01
♦ Engine protection between long maintenance intervals.
♦ Protection against residue build-up.
♦ High viscosity for constant fuel saving in all conditions of use.
♦ Everlasting stability for constant use in high rotation rates and

loads through long distances.

♦ Reduced emission of pollutants because of lower fuel con‐

sumption.

WARNING

♦ Follow the rules for disposal!

3.9

Identification letters and engine number

3.9.1

ASY engine

The engine identification letters and engine number are engraved

on the engine block -arrow- in the engine/gearbox separation

area. Additionally, the upper mechanical distribution cover has a

sticker with the engine identification letters and serial number.

The engine identification letters are also indicated on the vehicle

identification tag.

3.9.2

BNM engine

The engine identification letters and engine number -arrow- are

engraved on the engine block. Additionally, the upper mechanical

distribution cover has a sticker with the engine identification let‐

ters and serial number. The engine identification letters are also

indicated on the vehicle identification tag.

FOX 2004 ➤

30

    3. General remarks

BMD engine

The engine identification letters and engine number are engraved

on the engine block in the area between the engine and the gear‐

box. Additionally, there is on the right engine support side

-arrow- a sticker with the engine identification letters and serial

number. The engine identification letters are also indicated on the

vehicle identification tag.

3.9.4

AQZ, BAH, BLH, BKR, and CFZA en‐

gines

The engine identification letters and serial number are engraved

on the engine block, below the thermo valve case. Additionally,

the upper mechanical distribution cover has a sticker with the en‐

gine identification letters and serial number. The engine identifi‐

cation letters are also indicated on the vehicle identification tag.

3.10

Push starting (pushing the vehicle to

start)/towing

Push starting and towing are carried out in different ways de‐

pending on the legislation of each country.
If the vehicle is provided with a towing hook, then a tow cable or

tow bar should be attached to the front or rear hook.

Note

♦

The tow cable should be elastic, so both vehicles are protec‐

ted. Thus, only synthetic cables or made of similar elastic

materials can be used. Yet, the safest procedure is to use a

tow bar!

♦

First, make sure there are no inadequate drive forces and no

impact loads. On towing maneuvers on dirt roads, there is al‐

ways the risk of overloading and, therefore, damaging the

fastening parts.

♦

Before push starting a vehicle (pushing the vehicle), try to push

start by using the battery from another vehicle.

If the vehicle is push started or towed, please note the following:
Whenever possible, it is recommended that the vehicle is not

pushed for a push start. Instead, use the auxiliary starting cables.
♦ The legal requirements for towing vehicles must be complied

with.

FOX 2004 ➤

3. General remarks

31

ienced people should not try push starting or towing a vehicle.

♦ When using a tow cable, the driver of the towed vehicle must

carefully release the clutch when starting to move and when

shifting gears.

♦ The driver of the towed vehicle must ensure the cable is al‐

ways taut.

♦ The warning lights of both vehicles must be turned on, and

other legal requirements must also be observed, if necessary.

♦ The ignition must be switched on so that the steering wheel is

free and the warning lights, horn, Windscreen wipers and

washer are ready for use.

♦ Once the servo brake only operates with the engine on, it is

necessary to step much harder on the brake pedal when the

engine is turned off.

♦ Since the power steering does not work with the engine off,

are much harder to execute when the engine is off.

♦ If there is no lubricant in the automatic transmission, the ve‐

hicle can only be towed with the drive wheels lifted.

3.10.1

If the jump starting has to be carried out

against our recommendation, please

note the following points for vehicles

with a mechanical transmission:

– Before jump starting, press the clutch pedal and engage the

2nd or 3rd gear.

– Turn the ignition on.
– Release the clutch pedal only when both vehicles are moving.
– As soon as the engine starts, press the clutch pedal and shift

to dead center to avoid a collision with the vehicle ahead (trac‐

tor).

Note

In vehicles equipped with catalytic converter, the engine should

not be started by pushing the vehicle for more than 50 meters if

the catalytic converter is hot. The unused fuel may get into the

catalytic converter and damage it.

Over greater distances, the front vehicle section must be lifted.
With a tow car, the vehicle may only be towed with the front

wheels lifted.
Reason: With the vehicle suspended by the rear wheels, the drive

shafts turn backwards. This causes the planetary gears to turn at

rotation rates so high that the transmission is severely damaged

in a short period of time.

FOX 2004 ➤

32

    3. General remarks
