Service

– Timing belt for camshaft drive: replace. Additional work with separate pay‐

ment!

♦ Diesel engine: identification letters BNM
♦ every 90,000 km.
♦ for Europe on vehicles model ▸2007
♦ at every 93,205.68 mi
♦ for Europe on vehicles model 2008▸.

⇒ page 85

– Timing belt for camshaft drive: check state.

♦ 4-cylinder petrol engines.
♦ Identification letters AQZ, BAH, BLH, BKR, and CFZA
♦ at 90,000 km and at every 30,000 km

⇒ page 85

– Air cleaner: replace the filtering element and clean the filter case.

♦ identification letters BAH and BLH.
♦ at every 60,000 km or every 4 years, whichever occurs first.

⇒ page 86

– Air cleaner: replace the filtering element and clean the filter case.

♦ Identification letters CFZA.
♦ at every 30,000 km or every 2 years, whichever occurs first

⇒ page 87

– Air cleaner: replace the filtering element and clean the filter case.

♦ identification letters AQZ and BKR.
♦ at every 30,000 km or every 2 years, whichever occurs first

⇒ page 86

– Air cleaner: replace the filtering element and clean the filter case.

♦ Engine identification letters ASY, BKR, BNM, and BMD.
♦ at every 37,282.27 mi or every 4 years, whichever occurs first.

⇒ page 87

– Fuel filter: replace.

♦ Only for diesel engine vehicles according to DIN EN 590.
♦ at every 37,282.27 mi

⇒ page 88

– Fuel filter: replace.

♦ Only for bio diesel vehicles in compliance with DIN E 51606 and for diesel

vehicles not covered by standard DIN EN 590.

♦ at every 30.000 km

⇒ page 88

– Fuel filter: drain the water

♦ Only for diesel engine vehicles according to DIN EN 590 (only for ASY en‐

gines).

♦ at 30,000 km and, then, every 60,000 km.

⇒ page 89

– Brake fluid: replace every 2 years (additional work with separate payment!)

♦ at every 2 years.
♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008).

♦ at 3 years and after every 2 years for Europe on vehicles model 2008▸ and

except Europe on vehicles model 2009▸.

⇒ page 90

– Brake fluid: replenish to the level (depending on pad wearing).

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008.

⇒ page 93

– Battery: fill the electrolyte level (except for maintenance-free batteries).



FOX 2004 ➤

2. Service plans

17

Service

– Power steering: check the oil level.

♦ at every 60,000 km (except for maintenance-free).

⇒ page 82

– Carry out an exhaust gas inspection/additional work with separate payment!

♦ 3 years after initial licensing, and then every two years.

⇒ page 99

Concluding tasks
– Headlight adjustment: check.

♦ every 18,641.14 mi.
♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model

▸2008

♦ at every 60,000 km or 3 years and, then, every 2 years
♦ for Europe on vehicles model 2008▸ and except Europe on vehicles model

2009▸.

⇒ page 94

– Maintenance interval indicator (if available) : reset.

⇒ page 34

– Maintenance and Warranty book: record the date and kilometers traveled

for the next service.



– Service tag: write the date of the next service (including brake fluid change)

and attach the tag to the left side of the command panel or to the left door

pillar (B).

⇒ page 23

– Perform a test run.

⇒ page 98

2.7

Supplementary services based on time

elapsed and/or kilometers traveled

Besides the oil change or inspection service — which depends

on the conditions of usage and optional equipments in the vehicle

— performing supplementary maintenance works is necessary.
Also, it is possible to perform additional works, by considering the

records in the service plan (or on the adhesive tag: Your next

service), out of the regular maintenance intervals.
At every 30,000 km

Supplementary services

Page

– Dust and pollen filter: clean case and change filter element

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model ▸2008
♦ for vehicles with kilometers traveled over 30,000 km, within a 2-year period
♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

⇒ page 84

– Headlights: adjust the beams

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model ▸2008

⇒ page 94

– Sunroof: check operation, clean the guide rails and lubricate them with Special

grease -G 000 450 02-

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model ▸2008

⇒ page 46

– Mechanical transmission: check oil level.

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model ▸2008

⇒ page 66

– Fuel filter: replace (vehicles with engine AQZ, BAH, BLH, and CFZA only)

⇒ page 87

– Air cleaner: replace the filtering element and clean the filter case.

♦ identification letters AQZ and BKR.
♦ for vehicles with kilometers traveled over 30,000 km, within a 2-year period

⇒ page 86

FOX 2004 ➤

18

    2. Service plans

Page

– Air cleaner: replace the filtering element and clean the filter case.

♦ Identification letters CFZA.
♦ for vehicles with kilometers traveled over 30,000 km, within a 2-year period

⇒ page 87

– Fuel filter: drain the water

♦ Only for diesel engine vehicles according to DIN EN 590 (only for ASY engines).
♦ at 30,000 km and after every 60,000 km

⇒ page 89

– Fuel filter: replace

♦ Only for biodiesel vehicles in compliance with DIN E 51606 and for diesel vehicles

not covered by standard DIN EN 590.

⇒ page 88

At every 37,282.27 mi

Supplementary services

Page

– Headlights: adjust the beams

♦ for vehicles with kilometers traveled over 60,000 km, within a 3-year period and, then,

every 2 years.

♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

⇒ page 94

– Mechanical transmission: check oil level.

♦ for vehicles with kilometers traveled over 60,000 km, within a 3-year period and, then,

every 2 years.

♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

⇒ page 66

– Air cleaner: replace the filtering element and clean the filter case.

♦ identification letters BAH and BLH.
♦ for vehicles with kilometers traveled over 37,282.27 mi, within a 4-year period

⇒ page 86

– Air cleaner: replace the filtering element and clean the filter case.

♦ Engine identification letters ASY, BKR, BNM, and BMD.
♦ for vehicles with kilometers traveled over 60,000 km, within a 4-year period.

⇒ page 87

– Spark plugs: replace

♦ for vehicles with kilometers traveled over 37,282.27 mi, within a 4-year period
♦ Checking data, spark plugs ⇒  Ignition system; Rep. Gr.  28 ; Ignition system

⇒ page 79

– Fuel filter: replace

♦ (only for diesel engine vehicles according to DIN EN 590).

⇒ page 88

– Fuel filter: drain the water

♦ Only for diesel engine vehicles according to DIN EN 590 (only for ASY engines).

⇒ page 89

– Poly-V belt: check condition: In vehicles without automatic tensioning element, adjust

tension.

♦ for Europe on vehicles model ▸2007 and except Europe on vehicles model ▸2008
♦ for vehicles with kilometers traveled over 60,000 km, within a 3-year period and, then,

every 2 years.

♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

⇒ page 65

– Power steering: check the oil level.

⇒ page 82

FOX 2004 ➤

2. Service plans

19

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.

Supplementary services

Page

– Sunroof: check operation, clean the guide rails and lubricate them with Special

grease -G 000 450 02-

♦ for vehicles with kilometers traveled over 60,000 km, within a 3-year period and, then,

every 2 years.

♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

⇒ page 46

– Body and paintwork: check for damage.

♦ for vehicles with kilometers traveled over 60,000 km, within a 3-year period and, then,

every 2 years.

♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere



At every 55,923.41 mi

Supplementary services

Page

– Timing belt for camshaft drive: check state

♦ Diesel engine: identification letters BNM
♦ for Europe on vehicles model ▸2007

⇒ page 85

At 90,000 km and, then, at every 30,000 km)

Supplementary services

Page

– Timing belt for camshaft drive: check state

♦ 4-cylinder petrol engines: Identification letters AQZ, BAH, BLH, BKR, and CFZA

⇒ page 85

At every 93,205.68 mi

Supplementary services

Page

– Timing belt and tensioning roll for camshaft drive: replace

♦ Diesel engine: Identification letters ASY
♦ extra work to be billed separately!

⇒ page 85

– Timing belt for camshaft drive: check state

♦ Diesel engine: identification letters BNM
♦ for Europe on vehicles model 2008▸

⇒ page 85

At every 2 years

Supplementary services

Page

– Dust and pollen filter: clean case and change filter element

♦ for Europe in model 2008▸ vehicle and in model 2009▸ vehicles elsewhere

⇒ page 84

– Air cleaner: replace the filtering element and clean the filter case.

♦ identification letters AQZ and BKR.
♦ for vehicles with kilometers traveled over 30,000 km, within a 2-year period

⇒ page 86

– Air cleaner: replace the filtering element and clean the filter case.

♦ Identification letters CFZA.
♦ for vehicles with kilometers traveled over 30,000 km, within a 2-year period

⇒ page 87
