❑ Remove and install with spark plug socket and extension 3122 B.
❑ Type and electrode gap
11 - Knock sensor 2 -G66-
❑ Line to knock sensor secured to bracket
.
12 - Bracket
13 - 10 Nm
14 - Hall sender -G40-
❑ For inlet camshaft bank 1.
❑ Gold-plated contacts on sensor and connector.
1.2
Safety precautions
To prevent injuries to persons and/or damage to the injection and
ignition system, the following must be observed:
♦ Switch off ignition before connecting or disconnecting injection
and ignition system wiring as well as test instrument cables.
♦ If the engine is to be turned at starter speed without starting:
– Pull connectors off ignition coils with output stage (cylinders
1…8).
Note the following if testers and measuring instruments have to
be used during a road test:
♦ Test and measuring instruments must always be secured to
rear seat and operated by a second person from this location.
If test and measuring instruments are operated from front pas‐
senger seat and the vehicle is involved in an accident, there is a
possibility that the person sitting in this seat may receive serious
injuries when the airbag is triggered.
1.3
Removing and installing ignition coils
with output stage
Special tools and workshop equipment required
♦ Puller -T40039-
Touareg 2003 ➤
158
