be cut back to approx. 1 mm.

Note

For bonding reasons, the adhesive bead on the new part should

be cut back only just before it is to be fitted.

15.3.2

Bonding in

Note

For damaged paintwork or new body parts, apply corrosion pro‐

tection measures according to guidelines in ⇒  Paint workshop

manual: Corrosion and corrosion protection, attached and welded

parts, materials .

Prepare bonding surface on body for spare wheel well

-shaded area-.
Areas with new paint work structure:
– Clean respective areas with cleaning solution -D 009 401 04-

and then dry with a lint-free cloth.

– Then apply glass/paint primer -D 009 200 02- evenly using

primer applicator -D 009 500 25- .

♦ Drying time approx. 10 minutes
Areas with residual adhesive:
– If bonding is not performed immediately after cutting back, the

remaining residual material must be activated with activator -

D 181 801 A1- .

WARNING

Activator must not come into contact with the paintwork, oth‐

erwise paint surface will be damaged.
