tween lock reinforcement and wheel housing liner.

– Check fit with side panel.
– Weld in lock reinforcing, RP spot weld seam.
– Install side panel

⇒ page 345

 .

Passat 2011 ➤ , Passat Variant 2011 ➤

14. Renewing outer wheel housing liner (Variant)

369

15

Renewing spare wheel well

WARNING

Observe safety notes!

Safety notes ⇒ General Information; Body Repairs, General Body

Repairs ; Safety notes

1 - Spare wheel well (bonded)
2 - Rear longitudinal member
3 - Floor panel

15.1

Tools

Special tools and workshop equipment required

Passat 2011 ➤ , Passat Variant 2011 ➤

370

♦ Double-cartridge gun -VAS 5237-

♦ Electric cutter -V.A.G 1561/A-

Passat 2011 ➤ , Passat Variant 2011 ➤

15. Renewing spare wheel well

371

Removing

– Roughly cut out spare wheel well at edge -parting line- using

pneumatic sabre saw -V.A.G 1523/A- .

– Leave bonding flange -1-.

Passat 2011 ➤ , Passat Variant 2011 ➤

372
