Toyota 4Runner (2024 year). Manual in english

417

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca
re

4RUNNER (U)

The coolant level is satisfactory if it is between the “F” and “L” lines on

the reservoir when the engine is cold.

Reservoir cap
“F” line
“L” line

If the level is on or below the “L”

line, add coolant up to the “F” line.

(



P. 519)

WARNING

■

Used engine oil

●

Used engine oil contains potentially harmful contaminants which may

cause skin disorders such as inflammation and skin cancer, so care

should be taken to avoid prolonged and repeated contact. To remove used

engine oil from your skin, wash thoroughly with soap and water.

●

Dispose of used oil and filters only in a safe and acceptable manner. Do

not dispose of used oil and filters in household trash, in sewers or onto the

ground.

Call your Toyota dealer, service station or auto parts store for information

concerning recycling or disposal.

●

Do not leave used engine oil within the reach of children.

NOTICE

■

To prevent serious engine damage

Check the oil level on a regular basis.

■

When replacing the engine oil

●

Be careful not to spill engine oil on the vehicle components.

●

Avoid overfilling, or the engine could be damaged.

●

Check the oil level on the dipstick every time you refill the vehicle.

●

Be sure the engine oil filler cap is properly tightened.

Engine coolant

418

6-3. Do-it-yourself maintenance

4RUNNER (U)

■

Coolant selection

Only use “Toyota Super Long Life Coolant” or a similar high quality ethylene

glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with

long-life hybrid organic acid technology.
U.S.A.:

“Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deion-

ized water. (Minimum temperature: -31



F [-35



C])

Canada:

“Toyota Super Long Life Coolant” is a mixture of 55% coolant and 45% deion-

ized water. (Minimum temperature: -44



F [-42



C])

For more details about engine coolant, contact your Toyota dealer.

■

If the coolant level drops within a short time of replenishing

Visually check the radiator, hoses, engine coolant reservoir caps, drain cock

and water pump.

If you cannot find a leak, have your Toyota dealer test the cap and check for

leaks in the cooling system.

WARNING

■

When the engine is hot

Do not remove the engine coolant reservoir cap or the radiator cap.

(



P. 520)

The cooling system may be under pressure and may spray hot coolant if the

cap is removed, causing serious injuries, such as burns.

NOTICE

■

When adding coolant

Coolant is neither plain water nor straight antifreeze. The correct mixture of

water and antifreeze must be used to provide proper lubrication, corrosion

protection and cooling. Be sure to read the antifreeze or coolant label.

■

If you spill coolant

Be sure to wash it off with water to prevent it from damaging parts or paint.

419

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca
re

4RUNNER (U)

Check the radiator and condenser and clear away any foreign objects.

If either of the above parts is extremely dirty or you are not sure of

their condition, have your vehicle inspected by your Toyota dealer.

■

Checking fluid level

The brake fluid level should be

between the “MAX” and “MIN”

lines on the tank.

“MAX” line
“MIN” line

■

Adding fluid

Make sure to check the fluid type and prepare the necessary item.

■

Refilling brake fluid

Turn the engine switch off.
Depress the brake pedal more than 40 times.
Remove the reservoir cap by hand. Add brake fluid up to the

“MAX” line.
If you do not follow the procedure above, the reservoir may over-

flow.

Radiator and condenser

WARNING

■

When the engine is hot

Do not touch the radiator or condenser as they may be hot and cause seri-

ous injuries, such as burns.

Brake fluid

Fluid type

FMVSS No.116 DOT 3 or SAE J1703 brake fluid

Items

Clean funnel

420

6-3. Do-it-yourself maintenance

4RUNNER (U)

■

Brake fluid can absorb moisture from the air

Excess moisture in the brake fluid can cause a dangerous loss of braking effi-

ciency. Use only newly opened brake fluid.

WARNING

■

When filling the reservoir

Take care as brake fluid can harm your hands and eyes and damage

painted surfaces.

If fluid gets on your hands or in your eyes, flush the affected area with clean

water immediately.
If you still experience discomfort, see a doctor.

NOTICE

■

If the fluid level is low or high

It is normal for the brake fluid level to go down slightly as the brake pads

wear out or when the fluid level in the accumulator is high.

If the reservoir needs frequent refilling, there may be a serious problem.

421

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

■

Fluid level

The fluid level should be within the appropriate range.

Full (when cold)

Add fluid (when cold)

Full (when hot)

Add fluid (when hot)

Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 min-

utes, or slightly longer in frigid temperatures. (Fluid tempera-
ture, 140°F - 175°F [60°C - 80°C]).

Cold: Engine has not been run for about 5 hours. (Room tempera-

ture, 50°F - 85°F [10°C - 30°C]).

■

Checking the fluid level

Make sure to check the fluid type and prepare the necessary items.

Clean all dirt off the reservoir.

Remove the cap by turning it counterclockwise.

Wipe the dipstick clean.

Reinstall the cap and remove it again.

Check the fluid level.

Power steering fluid

Fluid type

Automatic transmission fluid DEXRON

II or III

Items

Rag or paper, clean funnel (only for adding fluid)

422

6-3. Do-it-yourself maintenance

4RUNNER (U)

Check the battery as follows.

■

Battery exterior

Make sure that the battery terminals are not corroded and that

there are no loose connections, cracks, or loose clamps.

Terminals
Hold-down clamp

■

Before recharging

When recharging, the battery produces hydrogen gas which is flammable and

explosive. Therefore, observe the following before recharging:

●

If recharging with the battery installed on the vehicle, be sure to disconnect

the ground cable.

●

Make sure the power switch on the charger is off when connecting and dis-

connecting the charger cables to the battery.

WARNING

■

When checking the reservoir

Take care as the reservoir may be hot.

NOTICE

■

When adding fluid

Avoid overfilling, or the power steering may be damaged.

■

After replacing the reservoir cap

Check the steering box case, vane pump and hose connections for leaks or

damage.

Battery

423

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca
re

4RUNNER (U)

■

After recharging/reconnecting the battery

The engine may not start. Follow the procedure below to initialize the system.

Shift the shift lever to P.
Open and close any of the doors.
Restart the engine.

●

Unlocking the doors using the smart key system may not be possible imme-

diately after reconnecting the battery. If this happens, use the wireless

remote control or the mechanical key to lock/unlock the doors.

●

Start the engine with the engine switch in ACCESSORY mode. The engine

may not start when the engine switch turned from off. However, the engine

will operate normally from the second attempt.

●

The engine switch mode is recorded by the vehicle. If the battery is recon-

nected, the vehicle will return the engine switch mode to the status it was in

before the battery was disconnected. Make sure to turn off the engine

before disconnect the battery. Take extra care when connecting the battery

if the engine switch mode prior to discharge is unknown.

If the system will not start even after multiple attempts, contact your Toyota

dealer.

WARNING

■

Chemicals in the battery

Batteries contain poisonous and corrosive sulfuric acid and may produce

hydrogen gas which is flammable and explosive. To reduce the risk of death

or serious injury, take the following precautions while working on or near the

battery:

●

Do not cause sparks by touching the battery terminals with tools.

●

Do not smoke or light a match near the battery.

●

Avoid contact with eyes, skin and clothes.

●

Never inhale or swallow electrolyte.

●

Wear protective safety glasses when working near the battery.

●

Keep children away from the battery.

424

6-3. Do-it-yourself maintenance

4RUNNER (U)

WARNING

■

Where to safely charge the battery

Always charge the battery in an open area. Do not charge the battery in a

garage or closed room where there is insufficient ventilation.

■

How to recharge the battery

Only perform a slow charge (5 A or less). The battery may explode if

charged at a quicker rate.

■

Emergency measures regarding electrolyte

●

If electrolyte gets in your eyes

Flush your eyes with clean water for at least 15 minutes and get immedi-

ate medical attention. If possible, continue to apply water with a sponge or

cloth while traveling to the nearest medical facility.

●

If electrolyte gets on your skin

Wash the affected area thoroughly. If you feel pain or burning, get medical

attention immediately.

●

If electrolyte gets on your clothes

It can soak through clothing on to your skin. Immediately take off the cloth-

ing and follow the procedure above if necessary.

●

If you accidentally swallow electrolyte

Drink a large quantity of water or milk. Get emergency medical attention

immediately.

NOTICE

■

When recharging the battery

Never recharge the battery while the engine is running. Also, be sure all

accessories are turned off.

425

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)



Type A

If any washer does not work or the
warning message appears on the
multi-information display, the
washer tank may be empty. Add
washer fluid.



Type B

If the washer fluid level is at
“LOW”, add washer fluid.

■

Using the gauge (Type B only)

Washer fluid

The washer fluid level can be checked by
observing the position of the level on the
liquid-covered holes in the gauge.
If the level falls below the second hole
from the bottom (the “LOW” position), refill
the washer fluid.

Current
fluid
level

426

6-3. Do-it-yourself maintenance

4RUNNER (U)

WARNING

■

When adding washer fluid

Do not add washer fluid when the engine is hot or running as washer fluid

contains alcohol and may catch fire if spilled on the engine etc.

NOTICE

■

Do not use any fluid other than washer fluid

Do not use soapy water or engine antifreeze instead of washer fluid.

Doing so may cause streaking on the vehicle's painted surfaces, as well as

damaging the pump leading to problems of the washer fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as necessary.

Refer to the freezing temperatures listed on the label of the washer fluid bot-

tle.

427

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

Check if the treadwear indicators are showing on the tires. Also check
the tires for uneven wear, such as excessive wear on one side of the
tread.

Check the spare tire condition and pressure if not rotated.

New tread

Worn tread

Treadwear indicator

The location of treadwear indicators is shown by a “TWI” or “



” mark,

etc., molded into the sidewall of each tire.
Replace the tires if the treadwear indicators are showing on a tire.

Tires

Replace or rotate tires in accordance with maintenance sched-
ules and treadwear.

Checking tires

428

6-3. Do-it-yourself maintenance

4RUNNER (U)



Vehicles without P245/60R20 tires

Rotate the tires in the order
shown.

To equalize tire wear and extend
tire life, Toyota recommends that
tire rotation is carried out at the
same interval as tire inspection.



Vehicles with P245/60R20 tires

Rotate the tires in the order
shown.

To equalize tire wear and extend
tire life, Toyota recommends that
tire rotation is carried out at the
same interval as tire inspection.

Tire rotation

Front

429

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

Your vehicle is equipped with a tire pressure warning system that uses
tire pressure warning valve and transmitters to detect low tire inflation
pressure before serious problems arise.

●

The tire pressure detected by
the tire pressure warning sys-
tem can be displayed on the
multi-information display.

If equipped

●

If the tire pressure drops below
a predetermined level, the
driver is warned by a screen
display and a warning light.
(



P. 481)

If equipped

Tire pressure warning system

430

6-3. Do-it-yourself maintenance

4RUNNER (U)

◆

Installing tire pressure warning valve and transmitters

When replacing the tires or wheels, the tire pressure warning valve
and transmitters must be installed to the wheels which will be
installed to the vehicle.

When new tire pressure warning valve and transmitters are
installed, new ID codes must be registered in the tire pressure
warning computer and the tire pressure warning system must be
initialized. (



P. 431)

◆

Initializing the tire pressure warning system

■

The tire pressure warning system must be initialized in the fol-
lowing circumstances:

●

When the tire inflation pressure is changed such as when chang-
ing traveling speed or load weight.

●

When the tire inflation pressure is changed such as when the tire
size is changed.

●

When rotating the tires.

●

After performing the transmitter ID code registration procedure.
(



P. 431)

When the tire pressure warning system is initialized, the current tire
inflation pressure is set as the benchmark pressure.

■

How to initialize the tire pressure warning system

Park the vehicle in a safe place and turn the engine switch off.

The initialization procedure cannot be started while the vehicle is
moving.

Adjust the tire inflation pressure to the specified cold tire inflation
pressure level. (



P. 532)

Make sure to adjust the tire pressure to the specified cold tire infla-
tion pressure level. The tire pressure warning system will operate
based on this pressure level.

Start the engine. (



P. 199)

Select

on the multi-information display using the meter con-

trol switches on the steering wheel. (



P. 96)

Select “Vehicle Settings” and then press and hold

Select “TPWS” and then press

431

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

Select “Set Pressure” then
press and hold

until the

tire pressure warning light
blinks 3 times.

Then a message will be dis-
played on the multi-information
display.

“---” will be displayed on the
multi-information display for
the inflation pressure of each
tire while initialization is being
performed.

Drive straight (with occasional left and right turns) at approxi-
mately 25 mph (40 km/h) or more for approximately 10 to 30 min-
utes.

Initialization is complete when the position of each tire is determined
and the inflation pressure of each tire is displayed on the multi-infor-
mation display.

Initialization may take longer than approximately 1 hour in certain
situations, such as when the vehicle is stopped for a long time at
traffic lights, etc. (



P. 436)

◆

Registering ID codes

Every tire pressure warning valve and transmitter has a unique ID
code. When replacing a tire pressure warning valve and transmitter,
it is necessary to register the ID codes.

The ID codes can be registered on

of the multi-information dis-

play.

432

6-3. Do-it-yourself maintenance

4RUNNER (U)

■

How to register the ID codes

Select

on the multi-information display using the meter con-

trol switches on the steering wheel. (



P. 96)

Select “Vehicle Settings” and then press and hold

Select “TPWS” and then press

Select “Change Wheel Set”
then press and hold

until

the tire pressure warning
light blinks slowly 3 times.

Then a message will be dis-
played on the multi-information
display.

When registration is being per-
formed, the tire pressure warn-
ing light will blink for
approximately 1 minute then
illuminate and “---” will be dis-
played for the inflation pres-
sure of each tire on the multi-
information display.

Drive straight (with occasional left and right turns) at approxi-
mately 25 mph (40 km/h) or more for approximately 10 to 30 min-
utes.

Registration is complete when the tire pressure warning light turns
off and the inflation pressure of each tire is displayed on the multi-
information display.

Registration may take longer than approximately 1 hour in certain
situations, such as when the vehicle is stopped for a long time at
traffic lights, etc. (



P. 437)

After registering the ID codes, make sure to initialize the tire pres-
sure warning system. (



P. 430)

433

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

■

When to replace your vehicle’s tires

Tires should be replaced if:

●

The treadwear indicators are showing on a tire.

●

You have tire damage such as cuts, splits, cracks deep enough to
expose the fabric, and bulges indicating internal damage

●

A tire goes flat repeatedly or cannot be properly repaired due to the size
or location of a cut or other damage

If you are not sure, consult with your Toyota dealer.

■

Replacing tires and wheels

If the ID code of the tire pressure warning valve and transmitter is not reg-
istered, the tire pressure warning system will not work properly. After driv-
ing for about 20 minutes, the tire pressure warning light blinks for 1
minute and stays on to indicate a system malfunction.

■

Tire life

Any tire over 6 years old must be checked by a qualified technician even
if it has seldom or never been used or damage is not obvious.

■

Routine tire inflation pressure checks

The tire pressure warning system does not replace routine tire inflation
pressure checks. Make sure to check tire inflation pressure as part of
your routine of daily vehicle checks.

■

Maximum load of tire

Check that the number given by dividing the maximum load by 1.10 of the
replacement tire is greater than 1/2 of the Gross Axle Weight Ratings
(GAWR) of either the front axle or the rear axle, whichever is greater.

For the GAWR, see the Certification
Label. For the maximum load of the tire,
see the load limit at maximum cold tire
inflation pressure mentioned on the
sidewall of the tire. (



P. 537)

434

6-3. Do-it-yourself maintenance

4RUNNER (U)

■

Tire types

●

Summer tires

Summer tires are high-speed performance tires best suited to highway
driving under dry conditions. Since summer tires do not have the same
traction performance as snow tires, summer tires are inadequate for
driving on snow-covered or icy roads. For driving on snow-covered
roads or icy roads, the use of snow tires is recommended. When install-
ing snow tires, be sure to replace all four tires.

●

All season tires

All season tires are designed to provide better traction in snow and to
be adequate for driving in most winter conditions as well as for use
year-round. All season tires, however, do not have adequate traction
performance compared with snow tires in heavy or loose snow. Also, all
season tires fall short in acceleration and handling performance com-
pared with summer tires in highway driving.

●

Snow tires

For driving on snow-covered roads or icy roads, we recommend using
snow tires. If you need snow tires, select tires of the same size, con-
struction and load capacity as the originally installed tires. Since your
vehicle has radial tires as original equipment, make sure your snow
tires also have radial construction. Do not install studded tires without
first checking local regulations for possible restrictions. Snow tires
should be installed on all wheels. (



P. 331)

■

If the tread on snow tires wears down below 0.16 in. (4 mm)

The effectiveness of the tires as snow tires is lost.

■

Warning performance of the tire pressure warning system

The warning of the tire pressure warning system will change in accor-
dance with the conditions under which it was initialized. For this reason,
the system may give a warning even if the tire pressure does not reach a
low enough level, or if the pressure is higher than the pressure that was
adjusted to when the system was initialized.

435

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

■

Situations in which the tire pressure warning system may not oper-
ate properly

●

In the following cases, the tire pressure warning system may not operate
properly.

• If non-genuine Toyota wheels are used.
• A tire has been replaced with a tire that is not an OE (Original Equip-

ment) tire.

• A tire has been replaced with a tire that is not of the specified size.
• Tire chains etc. are equipped.
• If a window tint that affects the radio wave signals is installed.
• If there is a lot of snow or ice on the vehicle, particularly around the

wheels or wheel housings.

• If the tire inflation pressure is extremely higher than the specified

level.

• If the spare tire is in a location subject to poor radio wave signal

reception.

• If a large metallic object which can interfere with signal reception is

put near the spare tire.

• If tires not equipped with the tire pressure warning valves and trans-

mitters are used.

• If the ID code on the tire pressure warning valves and transmitters is

not registered in the tire pressure warning computer.

●

Performance may be affected in the following situations.

• Near a TV tower, electric power plant, gas station, radio station, large

display, airport or other facility that generates strong radio waves or
electrical noise

• When carrying a portable radio, cellular phone, cordless phone or

other wireless communication device

●

When the vehicle is parked, the time taken for the warning to start or go
off could be extended.

●

When tire inflation pressure declines rapidly for example when a tire has
burst, the warning may not function.

436

6-3. Do-it-yourself maintenance

4RUNNER (U)

■

The initialization operation

●

Make sure to carry out initialization after adjusting the tire inflation pres-
sure.
Also, make sure the tires are cold before carrying out initialization or tire
inflation pressure adjustment.

●

If you have accidentally turned the engine switch off during initialization,
it is not necessary to press the reset switch again as initialization will
restart automatically when the engine switch has been turned to IGNI-
TION ON mode for the next time.

●

If you accidentally press the reset switch when initialization is not neces-
sary, adjust the tire inflation pressure to the specified level when the
tires are cold, and conduct initialization again.

●

While the position of each tire is being determined and the inflation pres-
sures are not being displayed on the multi-information display, if the
inflation pressure of a tire drops, the tire pressure warning light will come
on.

■

When initialization of the tire pressure warning system has failed

●

Do not move the vehicle backward during initialization. Initialization is
started again from the beginning and it may take longer than usual.

●

Initialization may take longer to complete if the vehicle is driven on an
unpaved road.
When performing initialization, drive on a paved road if possible.
Depending on the driving environment and condition of the tires, initial-
ization will be completed in approximately 10 to 30 minutes.

• If initialization is not complete after driving approximately 30 minutes,

continue driving for a while.

• If initialization is not complete after driving approximately 1 hour, park

the vehicle in a safe place for approximately 20 minutes. Then drive
straight (with occasional left and right turns) at approximately 25 mph
(40 km/h) or more

for approximately 10 to 30 minutes.

• If initialization is still not complete, have the vehicle inspected by your

Toyota dealer.

: Except when making a left/right turn

●

In the following situations, the tire inflation pressure will not be recorded
and the system will not operate properly. Perform initialization again.

• When operating the tire pressure warning reset switch, the tire pres-

sure warning light does not blink 3 times.

• After performing initialization, the tire pressure warning light blinks for

1 minute then stays on after driving for about 20 minutes.

437

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

■

When ID code registration has failed

●

Registration may take long time or the ID codes may not be registered in
the following situations.

• When the vehicle is moved backward during registration.

Registration is started again from the beginning and it may take lon-
ger than usual.

• When another vehicle is running the side of the vehicle such as in

heavy traffic.
It may take longer to detect the vehicle’ tire pressure warning valves
and transmitters.

• If tire pressure warning valves and transmitters are in the vehicle.

The ID codes may not be registered.

●

When performing registration, drive on a paved road if possible.
Depending on the driving environment and condition of the tires, regis-
tration will be completed in approximately 10 to 30 minutes.

• If registration is not complete after driving approximately 30 minutes,

continue driving for a while.

• If registration is not complete after driving approximately 1 hour, park

the vehicle in a safe place for approximately 20 minutes. Then drive
straight (with occasional left and right turns) at approximately 40 km/h
(25 mph) or more

for approximately 10 to 30 minutes.

If registration is still not complete, have the vehicle inspected by your
Toyota dealer.

: Except when making a left/right turn

●

When the tire pressure warning light does not blink slowly 3 times, the
ID code will not be registered and the system will not operate properly.
Perform registration again.

■

When registering ID codes

●

Initialize the tire pressure warning system after ID code registration. Ini-
tialization is disabled if the system was initialized before registration.

●

After ID code registration, the tires are hot by driving. Initialize the tire
pressure warning system after the tires become cold.

■

Canceling the change wheel set mode

●

If turning the engine switch off when in the change wheel set mode
before driving, the change wheel set mode is canceled.

●

After driving when in the change wheel set mode, the change wheel set
mode cannot be canceled. To cancel the mode, perform the procedure
for ID code registration again and turn the engine switch off before driv-
ing.

●

If the change wheel set mode is canceled, the ID codes that have
already been registered are communicated. When communication is fin-
ished, the tire pressure warning light will turn off.

438

6-3. Do-it-yourself maintenance

4RUNNER (U)

WARNING

■

When inspecting or replacing tires

Observe the following precautions to prevent accidents.

Failure to do so may cause damage to parts of the drive train as well as

dangerous handling characteristics, which may lead to an accident

resulting in death or serious injury.

●

Do not mix tires of different makes, models or tread patterns.

Also, do not mix tires of remarkably different treadwear.

●

Do not use tire sizes other than those recommended by Toyota.

●

Do not mix differently constructed tires (radial, bias-belted or bias-ply

tires).

●

Do not mix summer, all season and snow tires.

●

Do not use tires that have been used on another vehicle.

Do not use tires if you do not know how they were used previously.

■

When initializing the tire pressure warning system

Do not operate the tire pressure warning reset switch without first

adjusting the tire inflation pressure to the specified level. Otherwise, the

tire pressure warning light may not come on even if the tire inflation

pressure is low, or it may come on when the tire inflation pressure is

actually normal.

439

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca
re

4RUNNER (U)

NOTICE

■

Repairing or replacing tires, wheels, tire pressure warning valves,

transmitters and tire valve caps

●

When removing or fitting the wheels, tires or the tire pressure warning

valves and transmitters, contact your Toyota dealer as the tire pres-

sure warning valves and transmitters may be damaged if not handled

correctly.

●

Make sure to install the tire valve caps. If the tire valve caps are not

installed, water could enter the tire pressure warning valves and the

tire pressure warning valves could be bound.

●

When replacing tire valve caps, do not use tire valve caps other than

those specified. The cap may become stuck.

■

To avoid damage to the tire pressure warning valves and transmit-

ters

When a tire is repaired with liquid sealants, the tire pressure warning

valve and transmitter may not operate properly. If a liquid sealant is

used, contact your Toyota dealer or other qualified service shop as soon

as possible. Make sure to replace the tire pressure warning valve and

transmitter when replacing the tire. (



P. 430)

■

Driving on rough roads

Take particular care when driving on roads with loose surfaces or pot-

holes.

These conditions may cause losses in tire inflation pressure, reducing

the cushioning ability of the tires. In addition, driving on rough roads

may cause damage to the tires themselves, as well as the vehicle’s

wheels and body.

■

If tire inflation pressure of each tire becomes low while driving

Do not continue driving, or your tires and/or wheels may be ruined.

441

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

Tire valve

Tire pressure gauge

Remove the tire valve cap.

Press the tip of the tire pressure gauge onto the tire valve.

Read the pressure using the gauge gradations.

If the tire inflation pressure is not at the recommended level, adjust
the pressure.
If you add too much air, press the center of the valve to deflate.

After completing the tire inflation pressure measurement and
adjustment, apply soapy water to the valve and check for leakage.

Put the tire valve cap back on.

■

Tire inflation pressure check interval

You should check tire inflation pressure every two weeks, or at least once
a month.
Do not forget to check the spare.

■

Effects of incorrect tire inflation pressure

Driving with incorrect tire inflation pressure may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor handling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drive train

If a tire needs frequent inflating, have it checked by your Toyota dealer.

Inspection and adjustment procedure

442

6-3. Do-it-yourself maintenance

4RUNNER (U)

■

Instructions for checking tire inflation pressure

When checking tire inflation pressure, observe the following:

●

Check only when the tires are cold.

If your vehicle has been parked for at least 3 hours or has not been

driven for more than 1 mile or 1.5 km, you will get an accurate cold tire

inflation pressure reading.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is properly inflated based only on its appear-

ance.

●

It is normal for the tire inflation pressure to be higher after driving as

heat is generated in the tire. Do not reduce tire inflation pressure after

driving.

●

Never exceed the vehicle capacity weight.

Passengers and luggage weight should be placed so that the vehicle is

balanced.

WARNING

■

Proper inflation is critical to save tire performance

Keep your tires properly inflated.

If the tires are not properly inflated, the following conditions may occur

which could lead to an accident resulting in death or serious injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting from overheated tires

●

Air leaking from between tire and wheel

●

Wheel deformation and/or tire damage

●

Greater possibility of tire damage while driving (due to road hazards,

expansion joints, sharp edges in the road, etc.)

NOTICE

■

When inspecting and adjusting tire inflation pressure

Be sure to put the tire valve caps back on.

If a valve cap is not installed, dirt or moisture may get into the valve and

cause an air leak, resulting in decreased tire inflation pressure.

443

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

When replacing wheels, care should be taken to ensure that they are
equivalent to those removed in load capacity, diameter, rim width and
inset

Replacement wheels are available at your Toyota dealer.

Conventionally referred to as “offset”.

Toyota does not recommend using the following:

●

Wheels of different sizes or types

●

Used wheels

●

Bent wheels that have been straightened

●

Use only Toyota wheel nuts and wrenches designed for use with
your aluminum wheels.

●

When rotating, repairing or changing your tires, check that the
wheel nuts are still tight after driving 1000 miles (1600 km).

●

Be careful not to damage the aluminum wheels when using tire
chains.

●

Use only Toyota genuine balance weights or equivalent and a plas-
tic or rubber hammer when balancing your wheels.

Wheels

If a wheel is bent, cracked or heavily corroded, it should be
replaced. Otherwise, the tire may separate from the wheel or
cause a loss of handling control.

Wheel selection

Aluminum wheel precautions

444

6-3. Do-it-yourself maintenance

4RUNNER (U)

■

When replacing wheels

The wheels of your vehicle are equipped with tire pressure warning

valves and transmitters that allow the tire pressure warning system to

provide advance warning in the event of a loss in tire inflation pressure.

Whenever wheels are replaced, tire pressure warning valves and trans-

mitters must be installed. (



P. 430)

WARNING

■

When replacing wheels

●

Do not use wheels that are a different size from those recommended in

the Owner’s Manual, as this may result in a loss of handling control.

●

Never use an inner tube in a leaking wheel which is designed for a

tubeless tire. Doing so may result in an accident, causing death or seri-

ous injury.

■

When installing the wheel nuts

Never use oil or grease on the wheel bolts or wheel nuts.

Oil and grease may cause the wheel nuts to be excessively tightened, lead-

ing to bolt or disc wheel damage. In addition, the oil or grease can cause the

wheel nuts to loosen and the wheel may fall off, causing an accident and

resulting in death or serious injury. Remove any oil or grease from the wheel

bolts or wheel nuts.

NOTICE

■

Replacing tire pressure warning valves and transmitters

●

Because tire repair or replacement may affect the tire pressure warn-

ing valves and transmitters, make sure to have tires serviced by your

Toyota dealer or other qualified service shop. In addition, make sure to

purchase your tire pressure warning valves and transmitters at your

Toyota dealer.

●

Ensure that only genuine Toyota wheels are used on your vehicle.

Tire pressure warning valves and transmitters may not work properly

with non-genuine wheels.

445

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

Turn the engine switch off.

Open the glove box and
remove the cover.

Remove the filter cover.

Remove the air conditioning fil-
ter and replace it with a new
one.

The “



UP” marks shown on the fil-

ter should be pointing up.

Air conditioning filter

The air conditioning filter must be changed regularly to maintain
air conditioning efficiency.

Removal method

446

6-3. Do-it-yourself maintenance

4RUNNER (U)

■

Checking interval

Inspect and replace the air conditioning filter according to the maintenance

schedule. In dusty areas or areas with heavy traffic flow, early replacement

may be required. (For scheduled maintenance information, please refer to the

“Schedule maintenance guide” or “Owner’s Manual Supplement”.)

■

If air flow from the vents decreases dramatically

The filter may be clogged. Check the filter and replace if necessary.

NOTICE

■

When using the air conditioning system

Make sure that a filter is always installed.

Using the air conditioning system without a filter may cause damage to the

system.

447

6-3. Do-it-yourself maintenance

Mainten

ance an

d ca

4RUNNER (U)

●

Flathead screwdriver

●

Small flathead screwdriver

●

Lithium battery CR2032

Release the lock and remove
the mechanical key.

Remove the key cover.

To prevent damage to the key,
cover the tip of the flathead screw-
driver with a rag.

Remove the depleted battery
using a small flathead screw-
driver.

When removing the cover, the
electronic key module may stick to
the cover and the battery may not
be visible. In this case, remove the
electronic key module in order to
remove the battery.

Insert a new battery with the “+” terminal facing up.

Electronic key battery

Replace the battery with a new one if it is depleted.

You will need the following items:

Replacing the battery

448

6-3. Do-it-yourself maintenance

4RUNNER (U)

When installing the key cover and mechanical key, install by con-

ducting and with the directions reversed.
Operate the

switch and check that the doors can

be locked/unlocked.

■

When replacing the key battery

Be careful not to lose the battery or any other small parts.

■

Use a CR2032 lithium battery

●

Batteries can be purchased at your Toyota dealer, local electrical appliance

shops or camera stores.

●

Replace only with the same or equivalent type recommended by the manu-

facturer.

●

Dispose of used batteries according to local laws.

■

If the electronic key battery is depleted

The following symptoms may occur:

●

The smart key system and wireless remote control will not function properly.

●

The operational range will be reduced.

WARNING

■

Battery precautions

Observe the following precautions.

Failure to do so may result in death or serious injury.

●

Do not swallow the battery. Doing so may cause chemical burns.

●

A coin battery or button battery is used in the wireless remote control/elec-

tronic key. If a battery is swallowed, it may cause severe chemical burns in

as little as 2 hours and may result in death or serious injury.

●

Keep away new and removed batteries from children.

●

If the cover cannot be firmly closed, stop using the wireless remote con-

trol/electronic key and stow the key in the place where children cannot

reach, and then contact your Toyota dealer.

●

If you accidentally swallow a battery or put a battery into a part of your

body, get emergency medical attention immediately.

■

To prevent battery explosion or leakage of flammable liquid or gas

●

Replace the battery with a new battery of the same type. If a wrong type of

battery is used, it may explode.

●

Do not expose batteries to extremely low pressure due to high altitude or

extremely high temperatures.

●

Do not burn, break or cut a battery.

Toyota 4Runner (2024 year). Manual in english - page 14
