Toyota Corolla (2024 year). Manual in english

Please note that this manual
applies to all models and
explains all equipment, including
options. Therefore, you may find
explanations for equipment not
installed on your vehicle and the
illustrations used may differ from
your vehicle.

All specifications provided in this
manual are current at the time of
printing. Over time, your vehicle
may receive updates that modify
the vehicle and make material in
this manual incomplete and/or
inaccurate. Because of Toyota's
interest in continual product
improvement, Toyota reserves
the right to make changes to this
manual at any time without
notice.

If Toyota chooses to update the
manual, updated versions can
be viewed by selecting your
vehicle by model and year at the
following URL or on your mobile
device if you have access to the
Toyota app.

www.toyota.com/owners

Approximately five hours after
the engine is turned off, you
may hear sound coming from

under the vehicle for several
minutes. This is the sound of a
fuel evaporation leakage check
and, it does not indicate a mal-
function.

A wide variety of non-genuine
spare parts and accessories for
Toyota vehicles are currently
available in the market. You
should know that Toyota does
not warrant these products and
is not responsible for their per-
formance, repair, or replace-
ment, or for any damage they
may cause to, or adverse effect
they may have on, your Toyota
vehicle.

This vehicle should not be modi-
fied with non-genuine Toyota
products. Modification with
non-genuine Toyota products
could affect its performance,
safety or durability, and may
even violate governmental regu-
lations. In addition, damage or
performance problems resulting
from the modification may not
be covered under warranty.

Also, remodeling like this will
have an effect on advanced
safety equipment such as Toy-
ota Safety Sense 3.0 and there
is a danger that it will not work
properly or the danger that it

For your information

Main Owner’s Manual

Noise from under vehicle
after turning off the engine

Accessories, spare parts
and modification of your
Toyota

may work in situations where it
should not be working.

Installing electronic devices and
radios increases the risk of
cyber attacks through the
installed parts, which may lead
to unexpected accidents and
leakage of personal informa-
tion. Toyota does not make any
guarantees for problems caused
by installing non-genuine Toyota
products.

The installation of a mobile
two-way radio system in your
vehicle could affect electronic
systems such as:



Multiport fuel injection sys-
tem/sequential multiport fuel
injection system



Toyota Safety Sense 3.0



Anti-lock brake system



SRS airbag system



Seat belt pretensioner system

Be sure to check with your Toy-
ota dealer for precautionary
measures or special instructions
regarding installation of a mobile
two-way radio system.

This vehicle is equipped with
sophisticated computers that
record certain data regarding
vehicle controls and operations.



Data recorded by the comput-

ers

Certain data, such as the following,
is recorded depending on the oper-
ation timing and status of each
function.

• Basic vehicle behavior related

data (engine speed, accelera-
tor/brake pedal operation, vehi-
cle speed, etc.)

• Operating state of the driving

support systems (recorded during
system operation, includes basic
vehicle behavior related data)

• Driving support system sensor

data

• Image data (images from the

front, rear and side cameras)

• Location information

These computers do not record
conversations, sounds, or
images of the inside of the vehi-
cle.

Also, personal information which
may be used to identify the
owner of the vehicle (name,
gender, age, etc.) is not
recorded.

: The recorded data varies accord-

ing to the vehicle grade level and
options with which it is equipped.

: The vehicle has multiple cam-

eras. For details on from which

Cyber Attack Risk

Installation of a mobile
two-way radio system

Vehicle data recording

cameras images are recorded,
contact your Toyota dealer.



Usage of recorded data and
personal information by the
Toyota Safety Sense 3.0

The operating state of each sys-
tem, data from each sensor, image
data (images from the front/rear
cameras), and position information
is recorded by the Toyota Safety
Sense 3.0 in the following situa-
tions. Toyota obtains this informa-
tion when the vehicle is brought to
the dealership or when sent to the
Toyota servers.

• In certain collisions or colli-

sion-like situations

• When driving on roads with cer-

tain traffic situations, such as
congestion, poor road surfaces,
poor weather, etc.

• When driving on certain roads,

such as roads which were
recently opened or extended

• After the engine is started, for a

certain amount of time

To learn more about the vehicle
data collected, used and shared by
Toyota, please visit www.toy-
ota.com/privacyvts/.



Data provision and use pur-
pose by third parties

Data recorded by the computers
may be used for collision analysis,
malfunction diagnosis, automated
driving, advanced safety and map
related technologies (technology,
product development, product
improvement, etc.) and products
and services which use data (maps
used for automated driving and

advanced safety technologies, driv-
ing condition analysis, analysis of
the driving environment, such as
road infrastructure, traffic condition
communication, etc. Herein
referred to as “individual ser-
vices”.) Also, this data may be used
for customer support related to a
collision, collision analysis or reso-
lution.

In situations such as the following,
Toyota may disclose the recorded
data to a third party:

• When the consent of the vehicle

owner (or the lessee if the vehicle
is leased) has been given

• When officially requested by the

police, a court of law or a govern-
ment agency

• When it is to be used by Toyota in

a lawsuit

• When data is to be used research

purposes after processing so that
the data is not tied to a specific
vehicle or vehicle owner

In addition to the above, Toyota
may disclose the data recorded by
the Toyota Safety Sense 3.0 to a
third party in the following situa-
tions:

• When separate consent of the

vehicle owner (or the lessee if the
vehicle is leased) has been given.
This includes situations when the
user subscribes to an individual
service which is provided by a
second party and uses vehicle
recorded data, where the provider
has obtained the user’s consent
for providing data to a third-party

• When providing data to a com-

pany involved in autonomous

driving software, etc. for the pur-
pose of research and develop-
ment (technology, product
development, product improve-
ment, etc.) of automated driving,
advanced safety and map related
technologies

• When providing image data and

position information to a company
involved in map creation, etc. for
the purpose of research and
development map related tech-
nologies

• When providing image data and

position information to a local
government for the purpose of
road maintenance, etc.

• When providing processed image

data and position information to
traffic condition communication
individual services

• When providing image data from

near a fire, or other area that
emergency services are dis-
patched, to the fire department of
a local government which has
entered a separate contract with
Toyota

Image information recorded by the
vehicle can be erased by your Toy-
ota dealer.

The image recording function can
be disabled. However, if the function
is disabled, data from when systems
operate will not be available.

If you wish to stop the collection of
Toyota Safety Sense 3.0 data by the
Toyota servers for the purpose of
research and development and pro-
vision to individual services, contact
your Toyota dealer.

If your Toyota has Safety Con-
nect and if you have subscribed
to those services, please refer to
the Safety Connect Telematics
Subscription Service Agreement
for information on data collected
and its usage.



To learn more about the vehi-
cle data collected, used and
shared by Toyota, please visit
www.toyota.com/privacyvts/.

The Magnuson-Moss Warranty
Act, 15 U.S.C. s.2301 et seq.,
makes it illegal for motor vehicle
manufacturers to void a motor
vehicle warranty or deny war-
ranty coverage solely because
an aftermarket or recycled part
has been used to repair the
vehicle or someone other than
the authorized service provider
performed service on the vehi-
cle. This provision does not
apply to a new motor vehicle
purchased solely for commercial
or industrial use.
Under federal law, a manufac-
turer may deny warranty cover-
age and charge for repairs to a

Usage of data collected
through Safety Connect
(U.S. mainland only)

Statement on Warranty
Coverage for Aftermarket
and Recycled Parts (For
U.S. Owners)

vehicle if it is discovered that an
aftermarket or recycled part
installed on the vehicle is defec-
tive or was installed incorrectly
and caused damage to another
part of the vehicle otherwise
covered under warranty. The
Federal Trade Commission
requires that a manufacturer
demonstrate that an aftermar-
ket or recycled part or service
performed by a person other
than an authorized service pro-
vider caused damage to another
part of the vehicle otherwise
covered under warranty before
denying warranty coverage.
Additionally, federal law allows a
manufacturer to void a motor
vehicle warranty or deny war-
ranty coverage if the manufac-
turer provides the article or
service to consumers free of
charge under the warranty or
the manufacturer has secured a
waiver from the Federal Trade
Commission.

This vehicle is equipped with an
event data recorder (EDR). The
main purpose of an EDR is to
record, in certain crash or near
crash-like situations, such as an
air bag deployment or hitting a
road obstacle, data that will
assist in understanding how a
vehicle’s systems performed.
The EDR is designed to record

data related to vehicle dynamics
and safety systems for a short
period of time, typically 30 sec-
onds or less.

The EDR in this vehicle is
designed to record such data
as:
• How various systems in your

vehicle were operating;

• Whether or not the driver and

passenger safety belts were
buckled/fastened;

• How far (if at all) the driver

was depressing the accelera-
tor and/or brake pedal; and,

• How fast the vehicle was trav-

eling.

These data can help provide a
better understanding of the cir-
cumstances in which crashes
and injuries occur.

NOTE: EDR data are recorded
by your vehicle only if a non-triv-
ial crash situation occurs; no
data are recorded by the EDR
under normal driving conditions
and no personal data (e.g.,
name, gender, age, and crash
location) are recorded. How-
ever, other parties, such as law
enforcement, could combine the
EDR data with the type of per-
sonally identifying data rou-
tinely acquired during a crash
investigation.
To read data recorded by an
EDR, special equipment is
required, and access to the
vehicle or the EDR is needed. In

Event data recorder

addition to the vehicle manufac-
turer, other parties, such as law
enforcement, that have the spe-
cial equipment, can read the
information if they have access
to the vehicle or the EDR.



Disclosure of the EDR data

Toyota will not disclose the data
recorded in an EDR to a third party
except when:

• An agreement from the vehicle’s

owner (or the lessee for a leased
vehicle) is obtained

• In response to an official request

by the police, a court of law or a
government agency

• For use by Toyota in a lawsuit

However, if necessary, Toyota may:

• Use the data for research on

vehicle safety performance

• Disclose the data to a third party

for research purposes without
disclosing information about the
specific vehicle or vehicle owner

The SRS airbag and seat belt
pretensioner devices in your
Toyota contain explosive chemi-
cals. If the vehicle is scrapped
with the airbags and seat belt
pretensioners left as they are,
this may cause an accident such
as fire. Be sure to have the sys-
tems of the SRS airbag and seat
belt pretensioner removed and
disposed of by a qualified ser-
vice shop or by your Toyota
dealer before you scrap your

vehicle.

Special handling may apply, See
www.dtsc.ca.gov/
hazardouswaste/perchlorate.

Your vehicle has components
that may contain perchlorate.
These components may include
the airbags, seat belt preten-
sioners, wireless remote control
batteries, and the batteries in
the tire pressure warning valve
and transmitters.

The word “QR Code” is regis-
tered trademark of DENSO
WAVE INCORPORATED in
Japan and other countries.

Scrapping of your Toyota

Perchlorate Material

“QR Code”

WARNING

■

General precautions while

driving

Driving under the influence: Never

drive your vehicle when under the

influence of alcohol or drugs that

have impaired your ability to oper-

ate your vehicle. Alcohol and cer-

tain drugs delay reaction time,

impair judgment and reduce coor-

dination, which could lead to an

accident that could result in death

or serious injury.
Defensive driving: Always drive

defensively. Anticipate mistakes

that other drivers or pedestrians

might make and be ready to avoid

accidents.
Driver distraction: Always give

your full attention to driving. Any-

thing that distracts the driver, such

as adjusting controls, talking on a

cellular phone or reading can

result in a collision with resulting

death or serious injury to you,

your occupants or others.

■

General precaution regarding

children’s safety

Never leave children unattended

in the vehicle, and never allow

children to have or use the key.
Children may be able to start the

vehicle or shift the vehicle into

neutral. There is also a danger

that children may injure them-

selves by playing with the win-

dows, the moon roof, or other

features of the vehicle. In addi-

tion, heat build-up or extremely

cold temperatures inside the vehi-

cle can be fatal to children.

Reading this manual

Explains symbols used in
this manual.

Symbols in this manual

Symbols

Meanings

WARNING:

Explains something
that, if not obeyed,
could cause death or
serious injury to peo-
ple.

NOTICE:

Explains something
that, if not obeyed,
could cause dam-
age to or a malfunc-
tion in the vehicle or
its equipment.

Indicates operating
or working proce-
dures. Follow the
steps in numerical
order.

Symbols in illustrations

Symbols

Meanings

Indicates the action
(pushing, turning,
etc.) used to operate
switches and other
devices.

Indicates the out-
come of an operation
(e.g. a lid opens).

Symbols

Meanings

Indicates the compo-
nent or position
being explained.

Means

Do not

not do this

, or

not let this happen

Pictorial index

■

Exterior

Doors................................................................................... P.105

Locking/unlocking ................................................................ P.105

Opening/closing the side windows ....................................... P.128

Locking/unlocking by using the mechanical key

................ P.376

Warning messages .............................................................. P.109

Trunk ................................................................................... P.111

Opening from inside ............................................................. P.112

Opening from outside........................................................... P.112

Warning messages .............................................................. P.113

Outside rear view mirrors ................................................. P.126

Adjusting the mirror angle .................................................... P.126

Folding the mirrors ............................................................... P.127

Defogging the mirrors

................................................ P.254, 259

Windshield wipers.............................................................. P.172

Precautions for winter season.............................................. P.247

To prevent freezing (windshield wiper de-icer)

.................. P.261

Pictorial index

Fuel filler door .................................................................... P.174

Refueling method ................................................................. P.175

Fuel type/fuel tank capacity ................................................. P.387

Tires..................................................................................... P.305

Tire size/inflation pressure ................................................... P.391

Winter tires/tire chains ......................................................... P.247

Checking/rotation/tire pressure warning system

............... P.305

Coping with flat tires............................................................. P.364

Hood .................................................................................... P.296

Opening ............................................................................... P.296

Engine oil ............................................................................. P.388

Coping with overheating ...................................................... P.381

Headlights/daytime running lights ................................... P.167

Turn signal lights/parking lights....................................... P.167

Front side marker lights .................................................... P.167

LED accent lights

............................................................ P.167

Stop lights/tail lights/rear side marker lights/turn signal lights
P.167

License plate lights............................................................ P.167

Tail lights

.......................................................................... P.167

Back-up lights

Shifting the shift position to R ...................................... P.154, 156

Side turn signal lights

..................................................... P.161

: Vehicles with a smart key system

: If equipped

Light bulbs of the exterior lights for driving

(Replacing method: P.334, Watts: P.392)

Pictorial index

■

Instrument panel

Engine switch ............................................................. P.148, 149

Starting the engine/changing the positions

....................... P.148

Starting the engine/changing the modes

........................... P.149

Emergency stop of the engine ............................................. P.342

When the engine will not start .............................................. P.373

Warning messages .............................................................. P.360

Shift lever.................................................................... P.154, 156

Changing the shift position........................................... P.154, 156

Precautions for towing ......................................................... P.345

When the shift lever does not move..................................... P.155

Meters ............................................................................. P.80, 83

Reading the meters/adjusting the instrument panel light . P.80, 83

Warning lights/indicator lights ................................................ P.76

When a warning light turns on ............................................. P.350

Multi-information display .............................................. P.85, 91

Display ............................................................................. P.85, 91

Pictorial index

When a warning message is displayed................................ P.360

Turn signal lever................................................................. P.161
Headlight switch ................................................................ P.167

Headlights/parking lights/tail lights/side marker lights/daytime run-

ning lights/LED accent lights

............................................. P.167

Windshield wiper and washer switch............................... P.172

Usage................................................................................... P.172

Adding washer fluid.............................................................. P.304

Emergency flasher switch................................................. P.342

Hood lock release lever ..................................................... P.296

Tilt and telescopic steering lock release lever................ P.124

Air conditioning system ............................................ P.252, 257

Usage........................................................................... P.252, 257

Rear window defogger ................................................. P.254, 259

Audio system

: Vehicles without a smart key system

: Vehicles with a smart key system

: If equipped

: Refer to “MULTIMEDIA OWNER’S MANUAL”.

For safety and secu

rity

For safety and security

1-1. For safe use

Before driving .................

For safe driving ..............

Seat belts .......................

SRS airbags ...................

Front passenger occupant

classification system ....

Exhaust gas precautions

.....................................

1-2. Child safety

Riding with children ........

Child restraint systems...

1-3. Emergency assistance

Safety Connect ..............

1-4. Theft deterrent system

Engine immobilizer system

.....................................

Alarm..............................

1-1. For safe use

1-1.For safe use

Use only floor mats designed

specifically for vehicles of the

same model and model year as

your vehicle. Fix them securely

in place onto the carpet.

Insert the retaining hooks

(clips) into the floor mat eye-

lets.

Turn the upper knob of each

retaining hook (clip) to secure

the floor mats in place.

Always align the

marks .

The shape of the retaining hooks

(clips) may differ from that shown in

the illustration.

Before driving

Observe the following

before starting off in the

vehicle to ensure safety of

driving.

Floor mat

WARNING

Observe the following precau-

tions.

Failure to do so may cause the

driver’s floor mat to slip, possibly

interfering with the pedals while

driving. An unexpectedly high

speed may result or it may

become difficult to stop the vehi-

cle. This could lead to an acci-

dent, resulting in death or serious

injury.

■

When installing the driver’s

floor mat

●

Do not use floor mats designed

for other models or different

model year vehicles, even if

they are Toyota Genuine floor

mats.

●

Only use floor mats designed

for the driver’s seat.

●

Always install the floor mat

securely using the retaining

hooks (clips) provided.

●

Do not use two or more floor

mats on top of each other.

●

Do not place the floor mat bot-

tom-side up or upside-down.

1-1. For safe use

For safety and secu

rity

Adjust the angle of the seat-

back so that you are sitting

straight up and so that you do

not have to lean forward to

steer. (



P.119)

Adjust the seat so that you

can depress the pedals fully

and so that your arms bend

slightly at the elbow when

gripping the steering wheel.

(



P.119)

Lock the head restraint in

place with the center of the

head restraint closest to the

top of your ears. (



P.122)

Wear the seat belt correctly.

(



P.27)

WARNING

■

Before driving

●

Check that the floor mat is

securely fixed in the correct

place with all the provided

retaining hooks (clips). Be espe-

cially careful to perform this

check after cleaning the floor.

●

With the engine stopped and

the shift lever in P, fully depress

each pedal to the floor to make

sure it does not interfere with

the floor mat.

For safe driving

For safe driving, adjust the

seat and mirror to an appro-

priate position before driv-

ing.

Correct driving posture

1-1. For safe use

Make sure that all occupants are

wearing their seat belts before

driving the vehicle. (



P.27)

Use a child restraint system

appropriate for the child until the

child becomes large enough to

properly wear the vehicle’s seat

belt. (



P.48)

Make sure that you can see

backward clearly by adjusting

the inside and outside rear view

mirrors properly. (



P.125, 126)

WARNING

■

For safe driving

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

●

Do not adjust the position of the

driver’s seat while driving.

Doing so could cause the driver

to lose control of the vehicle.

●

Do not place a cushion between

the driver or passenger and the

seatback.

A cushion may prevent correct

posture from being achieved,

and reduce the effectiveness of

the seat belt and head restraint.

●

Do not place anything under the

front seats.

Objects placed under the front

seats may become jammed in

the seat tracks and stop the

seat from locking in place. This

may lead to an accident and the

adjustment mechanism may

also be damaged.

●

Always observe the legal speed

limit when driving on public

roads.

●

When driving over long dis-

tances, take regular breaks

before you start to feel tired.

Also, if you feel tired or sleepy

while driving, do not force your-

self to continue driving and take

a break immediately.

●

Take care when adjusting the

seat position to ensure that

other passengers are not

injured by the moving seat.

●

When adjusting the seat posi-

tion, do not put your hands

under the seat or near the mov-

ing parts to avoid injury. Fingers

or hands may become jammed

in the seat mechanism.

Correct use of the seat

belts

Adjusting the mirrors

1-1. For safe use

For safety and secu

rity

Seat belts

Make sure that all occu-

pants are wearing their seat

belts before driving the

vehicle.

WARNING

Observe the following precautions

to reduce the risk of injury in the

event of sudden braking, sudden

swerving or an accident.

Failure to do so may cause death

or serious injury.

■

Wearing a seat belt

●

Ensure that all passengers wear

a seat belt.

●

Always wear a seat belt prop-

erly.

●

Each seat belt should be used

by one person only. Do not use

a seat belt for more than one

person at once, including chil-

dren.

●

Toyota recommends that chil-

dren be seated in the rear seat

and always use a seat belt

and/or an appropriate child

restraint system.

●

To achieve a proper seating

position, do not recline the seat

more than necessary. The seat

belt is most effective when the

occupants are sitting up straight

and well back in the seats.

●

Do not wear the shoulder belt

under your arm.

●

Always wear your seat belt low

and snug across your hips.

■

Pregnant women

Obtain medical advice and wear

the seat belt in the proper way.

(



P.28)

Women who are pregnant should

position the lap belt as low as

possible over the hips in the same

manner as other occupants,

extending the shoulder belt com-

pletely over the shoulder and

avoiding belt contact with the

rounding of the abdominal area.
If the seat belt is not worn prop-

erly, not only the pregnant

woman, but also the fetus could

suffer death or serious injury as a

result of sudden braking or a colli-

sion.

■

People suffering illness

Obtain medical advice and wear

the seat belt in the proper way.

(



P.28)

■

When children are in the vehi-

cle



P.58

■

Seat belt damage and wear

●

Do not damage the seat belts

by allowing the belt, plate, or

buckle to be jammed in the

door.

1-1. For safe use



Extend the shoulder belt so

that it comes fully over the

shoulder, but does not come

into contact with the neck or

slide off the shoulder.



Position the lap belt as low as

possible over the hips.



Adjust the position of the

seatback. Sit up straight and

well back in the seat.



Do not twist the seat belt.

■

Child seat belt usage

The seat belts of your vehicle were

principally designed for persons of

adult size.

●

Use a child restraint system

appropriate for the child, until the

child becomes large enough to

properly wear the vehicle’s seat

belt. (



P.48)

●

When the child becomes large

enough to properly wear the vehi-

cle’s seat belt, follow the instruc-

tions regarding seat belt usage.

(



P.27)

■

Seat belt extender

If your seat belts cannot be fastened

securely because they are not long

enough, a personalized seat belt

extender is available from your Toy-

ota dealer free of charge.

WARNING

●

Inspect the seat belt system

periodically. Check for cuts,

fraying, and loose parts. Do not

use a damaged seat belt until it

is replaced. Damaged seat belts

cannot protect an occupant

from death or serious injury.

●

Ensure that the belt and plate

are locked and the belt is not

twisted.

If the seat belt does not function

correctly, immediately contact

your Toyota dealer.

●

Replace the seat assembly,

including the belts, if your vehi-

cle has been involved in a seri-

ous accident, even if there is no

obvious damage.

●

Do not attempt to install,

remove, modify, disassemble or

dispose of the seat belts. Have

any necessary repairs carried

out by your Toyota dealer. Inap-

propriate handling may lead to

incorrect operation.

Correct use of the seat

belts

WARNING

■

Using a seat belt extender

●

Do not wear the seat belt

extender if you can fasten the

seat belt without the extender.

1-1. For safe use

For safety and secu

rity

To fasten the seat belt, push

the plate into the buckle until

a click sound is heard.

To release the seat belt,
press the release button .

■

Emergency locking retractor

(ELR)

The retractor will lock the belt during

a sudden stop or on impact. It may

also lock if you lean forward too

quickly. A slow, easy motion will

allow the belt to extend so that you

can move around fully.

■

Automatic locking retractor

(ALR)

When a passenger’s shoulder belt is

completely extended and then

retracted even slightly, the belt is

locked in that position and cannot

be extended. This feature is used to

hold the child restraint system

(CRS) firmly. To free the belt again,

fully retract the belt and then pull the

belt out once more. (



P.48)

■

Rear seat belt

Use the seat belt after passing it

through the guide if the seat belt

comes free from the guide.

Push the seat belt shoulder

WARNING

●

Do not use the seat belt

extender when installing a child

restraint system because the

belt will not securely hold the

child restraint system, increas-

ing the risk of death or serious

injury in the event of an acci-

dent.

●

The personalized extender may

not be safe on another vehicle,

when used by another person,

or at a different seating position

other than the one originally

intended.

NOTICE

■

When using a seat belt

extender

When releasing the seat belt,

press on the buckle release but-

ton on the extender, not on the

seat belt.

This helps prevent damage to the

vehicle interior and the extender

itself.

Fastening and releasing

the seat belt

Adjusting the seat belt

shoulder anchor height

(front seats)

1-1. For safe use

anchor down while pressing
the release button .

Push the seat belt shoulder

anchor up while pressing the
release button .

Move the height adjuster up and

down as needed until you hear a

click.

The pretensioners help the seat

belts to quickly restrain the

occupants by retracting the seat

belts when the vehicle is sub-

jected to certain types of severe

frontal or side collision or a vehi-

cle rollover.

The pretensioners do not activate

in the event of a minor frontal

impact, a minor side impact or a

rear impact.

■

Replacing the belt after the pre-

tensioner has been activated

If the vehicle is involved in multiple

collisions, the pretensioner will acti-

vate for the first collision, but will not

activate for the second or subse-

quent collisions.

■

PCS-linked seat belt preten-

sioner control

If the PCS (Pre-Collision System)

determines that the possibility of a

collision with a vehicle is high, the

seat belt pretensioners will be pre-

pared to operate.

WARNING

■

Adjustable shoulder anchor

Always make sure the shoulder

belt is positioned across the cen-

ter of your shoulder. The belt

should be kept away from your

neck, but not falling off your shoul-

der. Failure to do so could reduce

the amount of protection in an

accident and cause death or seri-

ous injuries in the event of a sud-

den stop, sudden swerve or

accident.

Seat belt pretensioners

(front seats and outboard-

rear seats)

WARNING

■

Seat belt pretensioners

Observe the following precautions

to reduce the risk of injury in the

event of sudden braking, sudden

swerving or an accident.

Failure to do so may result in

death or serious injury.

●

Do not place anything, such as

a cushion, on the front passen-

ger’s seat. Doing so will

disperse the passenger’s

weight, which prevents the sen-

sor from detecting the passen-

ger’s weight properly. As a

result, the seat belt pretensioner

for the front passenger’s seat

may not operate in the event of

a collision.

●

If a pretensioner has operated,

the SRS warning light will illumi-

nate. In this situation, the seat

belt cannot be used and must

be replaced by your Toyota

dealer.

1-1. For safe use

SRS rear side airbags

Can help protect the torso of occupants in the rear outer seats

SRS curtain shield airbags

• Can help protect primarily the head of occupants in the outer seats
• Can help prevent the occupants from being thrown from the vehicle in the

event of vehicle rollover

■

SRS airbag system components

Seat cushion airbag

Front passenger's seat belt buckle switch

Front passenger airbag

Curtain shield airbags

Side impact sensors (front doors)

Front side airbags

“AIR BAG ON” and “AIR BAG OFF” indicator lights

Seat belt pretensioners and force limiters

Rear side airbags

Side impact sensors (front)

Driver airbag

Driver’s seat belt buckle switch

Driver’s seat position sensor

Driver’s knee airbag

SRS warning light

Toyota Corolla (2024 year). Manual in english - page 1
