Toyota Camry (2024 year). Manual in english

544

7-2. Steps to take in an emergency

CAMRY_U



2WD models



AWD models

Location of the spare tire, jack and tools

Luggage floor cover

Wheel nut wrench

Jack

Spare tire

Jack handle

Wheel lock key (if equipped)

545

7-2. Steps to take in an emergency

CAMRY_U

Wh
en
tro

uble
a

ris

WARNING

■

Using the tire jack

Observe the following precautions.

Improper use of the tire jack may cause the vehicle to suddenly fall off

the jack, leading to death or serious injury.

●

Do not use the tire jack for any purpose other than replacing tires or

installing and removing tire chains.

●

Only use the tire jack that comes with this vehicle for replacing a flat

tire.

Do not use it on other vehicles, and do not use other tire jacks for

replacing tires on this vehicle.

●

Put the jack properly in its jack point.

●

Do not put any part of your body under the vehicle while it is supported

by the jack.

●

Do not start the engine or drive the vehicle while the vehicle is sup-

ported by the jack.

●

Do not raise the vehicle while someone is inside.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to

replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.

●

When lowering the vehicle, make sure that there is no-one near the

vehicle. If there are people nearby, warn them vocally before lowering.

NOTICE

■

To prevent damage to the vehicle when using a jack

When jacking up the rear of the vehi-

cle, make sure not to position the jack

under the bracket shown in the illustra-

tion near the rear jack point, as the

vehicle body may be damaged.

546

7-2. Steps to take in an emergency

CAMRY_U

When replacing tires on a vehicle with wheel lock nuts, use the follow-

ing procedures to remove and install the wheel lock nuts. The wheel

lock key is stored in the tray inside the luggage compartment. Always

return the wheel lock key to its original position after use, so that it

does not get lost. (



P. 544)

■

Removal

For ease of removal, the wheel lock nut should always be the first

one loosened.

Place the wheel lock key on top of the wheel lock nut, turning

until the wheel lock key and wheel lock nut patterns engage.
Place the wheel nut wrench on the wheel lock key, and while

applying pressure on the wheel lock key, loosen the wheel lock

nut.

■

Installation

For ease of installation, the wheel lock nut should always be the

last one tightened.

By hand, install a wheel lock nut on the wheel to be installed.
Place the wheel lock key on top of the wheel lock nut, turning

until the wheel lock key and wheel lock nut patterns engage.
Place the wheel nut wrench on the wheel lock key, and while

applying pressure on the wheel lock key, tighten the wheel lock

nut to the recommended torque.

Wheel lock nut (if equipped)

NOTICE

■

When using a wheel lock key

Do not use an impact wrench. Using an impact wrench may cause perma-

nent damage to wheel lock nut and wheel lock key. If in doubt about wheel

lock application, contact your Toyota dealer.

547

7-2. Steps to take in an emergency

CAMRY_U

en tro

uble

ris

Lift up the hook of the luggage
floor cover on the trunk floor.

Secure the luggage floor cover
using the hook provided.

Remove the jack.

Taking out the jack



2WD models



AWD models

549

7-2. Steps to take in an emergency

CAMRY_U

Wh
en
tro

uble
a

ris

Loosen the center fastener that

secures the spare tire.

When taking out or stowing the

spare tire, make sure to firmly

hold opposite end of the tire.

WARNING

■

When storing the spare tire

Be careful not to catch fingers or other body parts between the spare

tire and the body of the vehicle.

550

7-2. Steps to take in an emergency

CAMRY_U

Chock the tires.

For vehicles with steel wheels,
remove the wheel ornament
using the wrench.

To protect the wheel ornament,
place a rag between the wrench
and the wheel ornament, as
shown in the illustration.

Slightly loosen the wheel nuts
(one turn).

Vehicles with wheel locks: Use
the wheel lock key to loosen the
wheel lock.

Replacing a flat tire

Flat tire

Wheel chock positions

Front

Left-hand side

Behind the rear right-hand side tire

Right-hand side

Behind the rear left-hand side tire

Rear

Left-hand side

In front of the front right-hand side tire

Right-hand side

In front of the front left-hand side tire

551

7-2. Steps to take in an emergency

CAMRY_U

en tro

uble

ris

Turn the tire jack portion “A” by
hand until the notch of the jack
is in contact with the jack point.

To prevent damage to the vehicle
when using the jack, position the
jack in the correct location.
(



P. 545)

The jack point guides are located
under the rocker panel. They
indicate the jack point positions.

Assemble the jack handle.

Raise the vehicle until the tire is
slightly raised off the ground.

Remove all the wheel nuts and
the tire.

When resting the tire on the
ground, place the tire so that the
wheel design faces up to avoid
scratching the wheel surface.

552

7-2. Steps to take in an emergency

CAMRY_U

WARNING

■

Replacing a flat tire

●

Do not touch the disc wheels or the area around the brakes immedi-

ately after the vehicle has been driven.

After the vehicle has been driven the disc wheels and the area around

the brakes will be extremely hot. Touching these areas with hands, feet

or other body parts while changing a tire, etc. may result in burns.

●

Failure to follow these precautions could cause the wheel nuts to

loosen and the tire to fall off, resulting in death or serious injury.
• Never use oil or grease on the wheel bolts or wheel nuts.

Oil and grease may cause the wheel nuts to be excessively tight-

ened, leading to bolt or disc wheel damage. Remove any oil or

grease that has adhered when installing the wheel nuts.

• After replacing a tire, check the tightening torque as soon as possi-

ble.

Wheel nut torque: 76 ft•lbf (103 N•m, 10.5 kgf•m)

• Do not attach a heavily damaged wheel ornament, as it may fly off

the wheel while the vehicle is moving.

• When installing a tire, only use wheel nuts that have been specifi-

cally designed for that wheel.

• If there are any cracks or deformations in the bolt screws, nut

threads or bolt holes of the wheel, have the vehicle inspected by

your Toyota dealer.

• When installing the wheel nuts, be sure to install them with the

tapered ends facing inward.

553

7-2. Steps to take in an emergency

CAMRY_U

Wh
en
tro

uble
a

ris

Remove any dirt or foreign mat-

ter from the wheel contact sur-

face.

If foreign matter is on the wheel

contact surface, the wheel nuts

may loosen while the vehicle is in

motion, causing the tire to come

off.

Install the tire and loosely tighten each wheel nut by hand by

approximately the same amount.
When replacing a steel wheel

with a steel wheel, tighten the

wheel nuts until the tapered

portion comes into loose con-

tact with the disc wheel seat.

When replacing an aluminum

wheel with a steel wheel,

tighten the wheel nuts until the

tapered portion comes into

loose contact with the disc

wheel seat.

Lower the vehicle.

Installing the spare tire

Tapered portion

Disc wheel

seat

Tapered portion

Disc wheel

seat

554

7-2. Steps to take in an emergency

CAMRY_U

Securely tighten the wheel nuts
two or three times in the order
shown in the illustration using a
wheel nut wrench.

Vehicles with wheel locks:
Tighten the wheel lock using the
wheel lock key after tightening
the other wheel nuts.

Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)

Stow the flat tire, tire jack and all tools.

■

The compact spare tire

●

The compact spare tire is identified by the label “TEMPORARY USE
ONLY” on the tire sidewall.
Use the compact spare tire temporarily, and only in an emergency.

●

Make sure to check the tire inflation pressure of the compact spare tire.
(



P. 584)

■

When using the compact spare tire

As the compact spare tire is not equipped with a tire pressure warning
valve and transmitter, low inflation pressure of the spare tire will not be
indicated by the tire pressure warning system. Also, if you replace the
compact spare tire after the tire pressure warning light comes on, the light
remains on.

■

When the compact spare tire is equipped

When driving with the compact spare tire installed, the vehicle height will
be different than when driving with standard tires.

■

If you have a flat front tire on a road covered with snow or ice (vehi-
cles with 16 or 17-inch wheels)

Install the compact spare tire on one of the rear wheels of the vehicle.
Perform the following steps and fit tire chains to the front tires:

Replace a rear tire with the compact spare tire.

Replace the flat front tire with the tire removed from the rear of the vehi-
cle.

Fit tire chains to the front tires.

555

7-2. Steps to take in an emergency

CAMRY_U

Wh
en
tro

uble
a

ris

WARNING

■

When using the compact spare tire

●

Remember that the compact spare tire provided is specifically

designed for use with your vehicle. Do not use your compact spare tire

on another vehicle.

●

Do not use more than one compact spare tires simultaneously.

●

Replace the compact spare tire with a standard tire as soon as possi-

ble.

●

Avoid sudden acceleration, abrupt steering, sudden braking and shift-

ing operations that cause sudden engine braking.

■

When the compact spare tire is attached

The vehicle speed may not be correctly detected, and the following sys-

tems may not operate correctly:

Also, not only can the following systems not be utilized fully, but they may

actually negatively affect the drive-train components:
• Dynamic Torque Control AWD system

If equipped

■

Speed limit when using the compact spare tire

Do not drive at speeds in excess of 50 mph (80 km/h) when a compact

spare tire is installed on the vehicle.
The compact spare tire is not designed for driving at high speeds. Fail-

ure to observe this precaution may lead to an accident causing death or

serious injury.

■

After using the tools and jack

Before driving, make sure all the tools and jack are securely in place in

their storage location to reduce the possibility of personal injury during a

collision or sudden braking.

• ABS & Brake assist

• VSC

• TRAC

• EPS

• AHB (Automatic High Beam)

• Dynamic radar cruise control

with full-speed range

• LTA (Lane Tracing Assist)

• PCS (Pre-Collision System)

• Tire pressure warning system

• BSM (Blind Spot Monitor)

• Intuitive parking assist

• PKSB (Parking Support

Brake)

• Rear view monitor system

• Toyota parking assist monitor

• Panoramic view monitor

• Navigation system

556

7-2. Steps to take in an emergency

CAMRY_U

NOTICE

■

Be careful when driving over bumps with the compact spare tire

installed on the vehicle.

The vehicle becomes lower when driving with the compact spare tire

compared to when driving with standard tires. Be careful when driving

over uneven road surfaces.

■

Driving with tire chains and the compact spare tire

Do not fit tire chains to the compact spare tire.

Tire chains may damage the vehicle body and adversely affect driving

performance.

■

When replacing the tires

When removing or fitting the wheels, tires or the tire pressure warning

valve and transmitter, contact your Toyota dealer as the tire pressure

warning valve and transmitter may be damaged if not handled correctly.

■

To avoid damage to the tire pressure warning valve and transmit-

ters

When a tire is repaired with liquid sealants, the tire pressure warning

valve and transmitter may not operate properly. If a liquid sealant is

used, contact your Toyota dealer or other qualified service shop as soon

as possible. Make sure to replace the tire pressure warning valve and

transmitter when replacing the tire. (



P. 475)

557

7-2. Steps to take in an emergency

CAMRY_U

en tro

uble

ris

One of the following may be the cause of the problem:

●

There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.

●

The engine may be flooded.
Try to restart the engine again following correct starting procedures.
(



P. 209, 211)

●

There may be a malfunction in the engine immobilizer system.
(



P. 80)

One of the following may be the cause of the problem:

●

The battery may be discharged. (



P. 562)

●

The battery terminal connections may be loose or corroded.

The engine starting system may be malfunctioning due to an electrical
problem such as electronic key battery depletion or a blown fuse.
However, an interim measure is available to start the engine.
(



P. 558)

If the engine will not start

If the engine will not start even though correct starting proce-
dures are being followed (



P. 209, 211), consider each of the fol-

lowing points:

The engine will not start even though the starter motor operates
normally.

The starter motor turns over slowly, the interior lights and head-
lights are dim, or the horn does not sound or sounds at a low
volume.

The starter motor does not turn over (vehicles with a smart key
system)

558

7-2. Steps to take in an emergency

CAMRY_U

One of the following may be the cause of the problem:

●

One or both of the battery terminals may be disconnected.

●

The battery may be discharged. (



P. 562)

Contact your Toyota dealer if the problem cannot be repaired, or if repair
procedures are unknown.

When the engine does not start, the following steps can be used as an
interim measure to start the engine if the engine switch is functioning
normally:

Set the parking brake.

Shift the shift lever to P.

Turn the engine switch to ACCESSORY mode.

Press and hold the engine switch for about 15 seconds while
depressing the brake pedal firmly.

Even if the engine can be started using the above steps, the system
may be malfunctioning. Have the vehicle inspected by your Toyota
dealer.

The starter motor does not turn over, the interior lights and head-
lights do not turn on, or the horn does not sound.

Emergency start function (vehicles with a smart key system)

559

7-2. Steps to take in an emergency

CAMRY_U

en tro

uble

ris

■

Doors

Using the mechanical key (



142) in order to perform the fol-
lowing operations (driver’s door
only):

Locks all doors

Closes the windows and the
moon roof

or panoramic

moon roof

(turn and hold)

Unlocks the door

Turning the key rearward unlocks the driver's door. Turning the key once
again unlocks the other doors.

Opens the windows and the moon roof

or panoramic moon

roof

(turn and hold)

: If equipped

: This setting must be customized at your Toyota dealer.

If the electronic key does not operate properly

(vehicles with a smart key system)

If communication between the electronic key and vehicle is
interrupted (



P. 163) or the electronic key cannot be used

because the battery is depleted, the smart key system and wire-
less remote control cannot be used. In such cases, the doors
and trunk can be opened and the engine can be started by fol-
lowing the procedure below.

Locking and unlocking the doors, unlocking the trunk and key
linked functions

560

7-2. Steps to take in an emergency

CAMRY_U

■

Trunk

Turn the mechanical key clock-
wise to open.

Ensure that the shift lever is in P and firmly depress the brake
pedal.

Touch the Toyota emblem side
of the electronic key to the
engine switch.

When the electronic key is
detected, a buzzer sounds and the
engine switch will turn to IGNITION
ON mode.

When the smart key system is
deactivated in customization set-
ting, the engine switch will turn to
ACCESSORY mode.

Firmly depress the brake pedal and check that

is displayed

on the multi-information display.

Press the engine switch shortly and firmly.

In the event that the engine still cannot be started, contact your Toyota
dealer.

Starting the engine

561

7-2. Steps to take in an emergency

CAMRY_U

Wh
en
tro

uble
a

ris

■

Stopping the engine

Shift the shift lever to P and press the engine switch as you normally do when

stopping the engine.

■

Replacing the key battery

As the above procedure is a temporary measure, it is recommended that the

electronic key battery be replaced immediately when the battery is depleted.

(



P. 494)

■

Alarm (for Canada only)

Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set,

the alarm may be triggered.

■

Changing engine switch modes

Release the brake pedal and press the engine switch in step above.

The engine does not start and modes will be changed each time the switch is

pressed. (



P. 213)

■

When the electronic key does not work properly

●

Make sure that the smart key system has not been deactivated in the cus-

tomization setting. If it is off, turn the function on.

(Customizable features:



P. 606)

●

Check if battery-saving mode is set. If it is set, cancel the function.

(



P. 163)

WARNING

■

When using the mechanical key and operating the power windows or

the moon roof or panoramic moon roof

Operate the power window or the moon roof or panoramic moon roof after

checking to make sure that there is no possibility of any passenger having

any of their body parts caught in the window or the moon roof or panoramic

moon roof. Also, do not allow children to operate the mechanical key. It is

possible for children and other passengers to get caught in the power win-

dow or the moon roof or panoramic moon roof.

562

7-2. Steps to take in an emergency

CAMRY_U

If you have a set of jumper (or booster) cables and a second vehicle
with a 12-volt battery, you can jump start your vehicle by following the
steps below.

Confirm that the electronic key
(vehicles with a smart key sys-
tem) or key (vehicles without a
smart key system) is being car-
ried.

When connecting the jumper (or
booster) cables, depending on the
situation, the alarm may activate
and doors locked. (



P. 84)

Open the hood. (



P. 457)

Vehicles with 3.5 L V6 (2GR-
FKS) engine: Remove the
engine cover.

Make sure to pull the engine cover
straight up when removing it.

If the vehicle battery is discharged

The following procedures may be used to start the engine if the
vehicle’s battery is discharged.
You can also call your Toyota dealer or a qualified repair shop.

563

7-2. Steps to take in an emergency

CAMRY_U

en tro

uble

ris

Connect the jumper cables according to the following procedure:



2.5 L 4-cylinder (A25A-FKS) engine



3.5 L V6 (2GR-FKS) engine

Connect a positive jumper cable clamp to the positive (+) battery
terminal on your vehicle.

Connect the clamp on the other end of the positive cable to the
positive (+) battery terminal on the second vehicle.

Connect a negative cable clamp to the negative (-) battery termi-
nal on the second vehicle.

Connect the clamp at the other end of the negative cable to a
metallic point shown in the illustration.

Use jumper cables that can reach the specified terminals and connect-
ing point.

564

7-2. Steps to take in an emergency

CAMRY_U

Start the engine of the second vehicle. Increase the engine speed
slightly and maintain at that level for approximately 5 minutes to
recharge the battery of your vehicle.

Vehicles with a smart key system: Open and close any of the doors
of your vehicle with the engine switch off.

Vehicles without a smart key system:
Maintain the engine speed of the second vehicle and turn the
engine switch to the “ON” position, then start the vehicle's engine.

Vehicles with a smart key system:
Maintain the engine speed of the second vehicle and turn the
engine switch to IGNITION ON mode, then start the vehicle's
engine.

Once the vehicle’s engine has started, remove the jumper cables in
the exact reverse order from which they were connected.

Once the engine starts, have the vehicle inspected at your Toyota
dealer as soon as possible.

■

Starting the engine when the battery is discharged

The engine cannot be started by push-starting.

■

To prevent battery discharge

●

Turn off the headlights and the audio system while the engine is off.

●

Turn off any unnecessary electrical components when the vehicle is running
at a low speed for an extended period, such as in heavy traffic.

■

When the battery is removed or discharged

●

Information stored in the ECU is cleared. When the battery is depleted, have
the vehicle inspected at your Toyota dealer.

●

Some systems may require initialization. (

→

P. 614)

■

When removing the battery terminals

When the battery terminals are removed, the information stored in the ECU is
cleared. Before removing the battery terminals, contact your Toyota dealer.

■

Charging the battery

The electricity stored in the battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the battery may
discharge, and the engine may be unable to start. (The battery recharges
automatically during driving.)

565

7-2. Steps to take in an emergency

CAMRY_U

Wh
en
tro

uble
a

ris

■

When recharging or replacing the battery (vehicles with a smart key sys-

tem)

●

In some cases, it may not be possible to unlock the doors using the smart

key system when the battery is discharged. Use the wireless remote control

or the mechanical key to lock or unlock the doors.

●

The engine may not start on the first attempt after the battery has recharged

but will start normally after the second attempt. This is not a malfunction.

●

The engine switch mode is memorized by the vehicle. When the battery is

reconnected, the system will return to the mode it was in before the battery

was discharged. Before disconnecting the battery, turn the engine switch off.

If you are unsure what mode the engine switch was in before the battery dis-

charged, be especially careful when reconnecting the battery.

■

When replacing the battery

●

Use a battery that conforms to European regulations.

●

Use a battery with the same case size, equivalent or greater 20 hour rate

capacity (20HR), and equivalent or greater performance rating (CCA) as the

battery which is being replaced.

The case size, 20 hour rate capacity (20HR) and performance rating

(CCA) are specified on the label attached to the battery.

• If the sizes differ, the battery cannot be properly secured.

• If the 20 hour rate capacity is low, even if the time period where the vehi-

cle is not used is a short time, the battery may discharge and the engine

may not be able to start.

●

For details, consult your Toyota dealer.

Case size

20 hour rate

capacity (20HR)

Performance rating

(CCA)

Type A

LN2

60Ah

563A

Type B

LN3

70Ah

603A

WARNING

■

When removing the battery terminals

Always remove the negative (-) terminal first. If the positive (+) terminal con-

tacts any metal in the surrounding area when the positive (+) terminal is

removed, a spark may occur, leading to a fire in addition to electrical shocks

and death or serious injury.

566

7-2. Steps to take in an emergency

CAMRY_U

WARNING

■

Avoiding battery fires or explosions

Observe the following precautions to prevent accidentally igniting the flam-

mable gas that may be emitted from the battery:

●

Make sure each jumper cable is connected to the correct terminal and that

it is not unintentionally in contact with any other than the intended terminal.

●

Do not allow the other end of the jumper cable connected to the “+” termi-

nal to come into contact with any other parts or metal surfaces in the area,

such as brackets or unpainted metal.

●

Do not allow the + and - clamps of the jumper cables to come into contact

with each other.

●

Do not smoke, use matches, cigarette lighters or allow open flame near

the battery.

■

Battery precautions

The battery contains poisonous and corrosive acidic electrolyte, while

related parts contain lead and lead compounds. Observe the following pre-

cautions when handling the battery:

●

When working with the battery, always wear safety glasses and take care

not to allow any battery fluids (acid) to come into contact with skin, clothing

or the vehicle body.

●

Do not lean over the battery.

●

In the event that battery fluid comes into contact with the skin or eyes,

immediately wash the affected area with water and seek medical attention.

Place a wet sponge or cloth over the affected area until medical attention

can be received.

●

Always wash your hands after handling the battery support, terminals, and

other battery-related parts.

●

Do not allow children near the battery.

NOTICE

■

When handling jumper cables

When connecting the jumper cables, ensure that they do not become entan-

gled in the cooling fan or engine drive belt.

■

When connecting jumper cables

Make sure to connect jumper cables to the specified terminals and connect-

ing point. Failure to do so may adversely affect the electronic devices or

damage to them.

567

7-2. Steps to take in an emergency

CAMRY_U

en tro

uble

ris

Stop the vehicle in a safe place and turn off the air conditioning sys-
tem, and then stop the engine.

If you see steam:
Carefully lift the hood after the steam subsides.

If you do not see steam:
Carefully lift the hood.

After the engine has cooled
down sufficiently, inspect the
hoses and radiator core (radia-
tor) for any leaks.

Radiator

Cooling fan

If a large amount of coolant leaks,
immediately contact your Toyota
dealer.

If your vehicle overheats

The following may indicate that your vehicle is overheating.

●

The needle of the engine coolant temperature gauge (



P. 94)

enters the red zone or a loss of engine power is experienced. (For
example, the vehicle speed does not increase.)

●

“Engine Coolant Temp High Stop in a Safe Place See Owner’s
Manual” is shown on the multi-information display.

●

Steam comes out from under the hood.

Correction procedures

568

7-2. Steps to take in an emergency

CAMRY_U

The coolant level is satisfactory if it is between the “F” and “L” lines
on the reservoir.

Reservoir

“F” line

“L” line

Radiator cap

Add coolant if necessary.

Water can be used in an emergency if coolant is unavailable.



2.5 L 4-cylinder (A25A-FKS)
engine



3.5 L V6 (2GR-FKS) engine



2.5 L 4-cylinder (A25A-FKS)
engine



3.5 L V6 (2GR-FKS) engine

569

7-2. Steps to take in an emergency

CAMRY_U

Wh
en
tro

uble
a

ris

Start the engine and turn the air conditioning system on to check

that the radiator cooling fan operates and to check for coolant leaks

from the radiator or hoses.

The fan operates when the air conditioning system is turned on immedi-

ately after a cold start. Confirm that the fan is operating by checking the fan

sound and air flow. If it is difficult to check these, turn the air conditioning

system on and off repeatedly. (The fan may not operate in freezing tem-

peratures.)

If the fan is not operating:

Stop the engine immediately and contact your Toyota dealer.
If the fan is operating:

Have the vehicle inspected at the nearest Toyota dealer.

WARNING

■

To prevent an accident or injury when inspecting under the hood of

your vehicle

Observe the following precautions.

Failure to do so may result in serious injury such as burns.

●

If steam is seen coming from under the hood, do not open the hood until

the steam has subsided. The engine compartment may be very hot.

●

Keep hands and clothing (especially a tie, a scarf or a muffler) away from

the fan and belts. Failure to do so may cause the hands or clothing to be

caught, resulting in serious injury.

●

Do not loosen the radiator cap and the coolant reservoir cap while the

engine and radiator are hot.

High temperature steam or coolant could spray out.

NOTICE

■

When adding engine coolant

Wait until the engine has cooled down before adding engine coolant.

When adding coolant, do so slowly. Adding cool coolant to a hot engine too

quickly can cause damage to the engine.

■

To prevent damage to the cooling system

Observe the following precautions:

●

Avoid contaminating the coolant with foreign matter (such as sand or dust

etc.).

●

Do not use any coolant additives.

570

7-2. Steps to take in an emergency

CAMRY_U

Stop the engine. Set the parking brake and shift the shift lever to P.

Remove the mud, snow or sand from around the front wheels.

Place wood, stones or some other material under the front wheels
to help provide traction.

Restart the engine.

Shift the shift lever to D or R and release the parking brake. Then,
while exercising caution, depress the accelerator pedal.

If the vehicle becomes stuck

Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:

571

7-2. Steps to take in an emergency

CAMRY_U

Wh
en
tro

uble
a

ris

■

When it is difficult to free the vehicle

Press

to turn off TRAC.

WARNING

■

When attempting to free a stuck vehicle

If you choose to push the vehicle back and forth to free it, make sure the

surrounding area is clear to avoid striking other vehicles, objects or people.

The vehicle may also lunge forward or lunge back suddenly as it becomes

free. Use extreme caution.

■

When shifting the shift lever

Be careful not to shift the shift lever with the accelerator pedal depressed.

This may lead to unexpected rapid acceleration of the vehicle that may

cause an accident resulting in death or serious injury.

NOTICE

■

To avoid damaging the transmission and other components

●

Avoid spinning the front wheels and depressing the accelerator pedal

more than necessary.

●

If the vehicle remains stuck even after these procedures are performed,

the vehicle may require towing to be freed.

574

CAMRY_U

8-1. Specifications

: Unladen vehicles

: For LE or XLE grade models

: For SE or XSE grade models

: 205/65R16 tires

: 215/55R17 tires and TRD models with 235/40R19 tires

: 235/45R18, and SE or XSE grade models with 235/40R19 tires

: For TRD models

Maintenance data (fuel, oil level, etc.)

Dimensions and weights (2WD models)

Overall length

192.1 in. (4880 mm)

192.7 in. (4895 mm)

194.6 in. (4944 mm)

Overall width

72.4 in. (1840 mm)

2, 3

73.1 in. (1856 mm)

Overall height

56.9 in. (1445 mm)

2, 3

56.3 in. (1430 mm)

Wheelbase

111.2 in. (2825 mm)

Tread

Front

63.0 in. (1600 mm)

62.6 in. (1590 mm)

62.2 in. (1580 mm)

Rear

63.2 in. (1605 mm)

62.8 in. (1595 mm)

62.6 in. (1590 mm)

Vehicle capacity weight
(occupants + luggage)

925 lb. (420 kg)

575

8-1. Specifications

Vehi

e specificatio

CAMRY_U

: Unladen vehicles

: For LE or XLE grade models

: For SE or XSE grade models

: 215/55R17 tires

: 235/45R18 and 235/40R19 tires

Dimensions and weights (AWD models)

Overall length

192.1 in. (4880 mm)

192.7 in. (4895 mm)

Overall width

72.4 in. (1840 mm)

Overall height

57.1 in. (1450 mm)

Wheelbase

111.2 in. (2825 mm)

Tread

Front

62.6 in. (1590 mm)

62.2 in. (1580 mm)

Rear

63.0 in. (1600 mm)

62.8 in. (1595 mm)

Vehicle capacity weight
(occupants + luggage)

925 lb. (420 kg)

Seating capacity

Seating capacity

5 (Front 2, Rear 3)

Toyota Camry (2024 year). Manual in english - page 18
