Toyota Camry (2024 year). Manual in english

480

6-3. Do-it-yourself maintenance

CAMRY_U

■

Tire types

●

Summer tires

Summer tires are high-speed performance tires best suited to highway
driving under dry conditions. Since summer tires do not have the same
traction performance as snow tires, summer tires are inadequate for
driving on snow-covered or icy roads. For driving on snow-covered
roads or icy roads, the use of snow tires is recommended. When install-
ing snow tires, be sure to replace all four tires.

●

All season tires

All season tires are designed to provide better traction in snow and to
be adequate for driving in most winter conditions as well as for use
year-round. All season tires, however, do not have adequate traction
performance compared with snow tires in heavy or loose snow. Also, all
season tires fall short in acceleration and handling performance com-
pared with summer tires in highway driving.

●

Snow tires

For driving on snow-covered roads or icy roads, we recommend using
snow tires. If you need snow tires, select tires of the same size, con-
struction and load capacity as the originally installed tires. Since your
vehicle has radial tires as original equipment, make sure your snow
tires also have radial construction. Do not install studded tires without
first checking local regulations for possible restrictions. Snow tires
should be installed on all wheels. (



P. 377)

■

If the tread on snow tires wears down below 0.16 in. (4 mm)

The effectiveness of the tires as snow tires is lost.

■

Situations in which the tire pressure warning system may not oper-
ate properly

●

In the following situations, the tire pressure warning system may not
operate properly.

• If non-genuine Toyota wheels are used.
• If a tire has been replaced with a tire that is not an OE (Original

Equipment) tire.

• If a tire has been replaced with a tire that is not of the specified size.
• If tire chains, etc. are installed.
• If a window tint that affects radio wave signals is installed.
• If there is a lot of snow or ice on the vehicle, particularly around the

wheels or wheel housings.

• If the tire inflation pressure is much higher than the specified level.
• If wheels not equipped with tire pressure warning valve and transmit-

ter are used.

• If the ID codes of the tire pressure warning valve and transmitters are

not registered in the tire pressure warning computer.

481

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

●

Performance may be affected in the following situations.

• When driving near a TV tower, electric power plant, gas station, radio

station, large display, airport or other facility that generates strong
radio waves or electrical noise

• When carrying a portable radio, cellular phone, cordless phone or

other wireless communication device

Vehicles with a tire inflation pressure display function: If tire position
information is not correctly displayed due to the radio wave conditions,
the display may be corrected by changing the location of the vehicle as
the radio wave conditions may change.

●

When the vehicle is stopped, the time taken for the warning to start or
turn off may be longer.

●

When the inflation pressure of a tire drops rapidly, for example when a
tire has burst, the warning may not operate.

■

Initialization procedure

●

Make sure to perform the initialization procedure after adjusting the tire
inflation pressure.
Also, make sure the tires are cold before performing the initialization
procedure or adjusting the tire inflation pressure.

●

If the engine switch is turned to the “LOCK” position (vehicles without a
smart key system) or off (vehicles with a smart key system) during ini-
tialization, it is not necessary to restart the initialization procedure from
the beginning as it will begin automatically when the engine switch is
turned back to the “ON” position (vehicles without a smart key system)
or IGNITION ON mode (vehicles with a smart key system).

●

If initialization has accidentally been started when it is not necessary,
adjust the tire inflation pressure to the specified level when the tires are
cold and then perform the initialization procedure again.

●

Vehicles with a tire inflation pressure display function: While the position
of each tire is being determined and the inflation pressures are not being
displayed on the multi-information display, if the inflation pressure of a
tire drops, the tire pressure warning light will come on.

■

Warning performance of the tire pressure warning system

The warning of the tire pressure warning system will change in accor-
dance with the conditions under which it was initialized. For this reason,
the system may give a warning even if the tire pressure does not reach a
low enough level, or if the pressure is higher than the pressure that was
adjusted to when the system was initialized.

482

6-3. Do-it-yourself maintenance

CAMRY_U

■

If the tire pressure warning system is not initialized properly



Vehicles without a tire inflation pressure display function

Initialization can be completed in a few minutes. However, in the following
cases, the settings have not been recorded and the system will not oper-
ate properly. If repeated attempts to record tire inflation pressure settings
are unsuccessful, have the vehicle inspected by your Toyota dealer.

●

If initialization is attempted and the tire pressure warning light does not
blink 3 times.

●

If, when the vehicle has been driven for about 20 minutes after perform-
ing initialization, the tire pressure warning light blinks for approximately
1 minute and then illuminates.



Vehicles with a tire inflation pressure display function

●

In the following situations, initialization may take longer than usual to be
completed or may not be possible. (Usually, the vehicle will need to be
driven for approximately 10 to 30 minutes to complete initialization.)
If initialization is not complete after driving approximately 30 minutes,
continue driving for a while.

• If the vehicle is driven on an unpaved road, it may take longer to com-

plete initialization.

• If the vehicle is backed up while performing initialization, data col-

lected during initialization will be cleared and it will take longer than
normal to complete.

• If the vehicle is driven in heavy traffic or another situation where other

vehicles are driven close by, it may take time for the system to recog-
nize the tire pressure warning valve and transmitters of your vehicle
over those of other vehicles.

If initialization is not complete after driving for approximately 1 hour,
park the vehicle in a safe place for approximately 20 minutes and then
drive the vehicle again.

●

In the following situations, initialization will not be started or was not
completed properly and the system will not operate properly. Perform
the initialization procedure again.

• If, when attempting to start initialization, the tire pressure warning light

does not blink 3 times.

• If, when the vehicle has been driven for about 20 minutes after per-

forming initialization, the tire pressure warning light blinks for approxi-
mately 1 minute and then illuminates.

●

If initialization cannot be completed after performing the above proce-
dure, contact your Toyota dealer.

483

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

■

When registering ID codes (vehicles with a tire inflation pressure dis-
play function)

●

Before performing ID code registration, make sure that no wheels with
tire pressure warning valve and transmitters installed are near the vehi-
cle.

●

Make sure to initialize the tire pressure warning system after registering
the ID codes. If the system is initialized before registering the ID codes,
the initialized values will be invalid.

●

As the tires will be warm when registration is completed, make sure to
allow the tires to cool before performing initialization.

■

Canceling ID code registration (vehicles with a tire inflation pressure
display function)

●

To cancel ID code registration after it has been started, turn the engine
switch off before driving the vehicle.
If the vehicle is driven after ID code registration is started, to cancel reg-
istration, perform the ID code registration start procedure again and turn
the engine switch off before driving.

●

If ID code registration has been canceled, the tire pressure warning light
will blink for approximately 1 minute when the engine switch is turned to
the “ON” position (vehicles without a smart key system) or IGNITION
ON mode (vehicles with a smart key system) and then illuminate. The
tire pressure warning system will be operational when the tire pressure
warning light turns off.

●

If the warning light does not turn off even after several minutes have
elapsed, ID code registration may not have been cancelled correctly. To
cancel registration, perform the ID code registration start procedure
again and then turn the engine switch off before driving.

484

6-3. Do-it-yourself maintenance

CAMRY_U

■

If ID codes are not registered properly (vehicles with a tire inflation
pressure display function)

●

In the following situations, ID code registration may take longer than
usual to be completed or may not be possible. (Usually, the vehicle will
need to be driven for approximately 10 to 30 minutes to complete ID
code registration.)
If ID code registration is not complete after driving for approximately 30
minutes, continue driving for a while.

• If the vehicle is driven on an unpaved road, it may take longer than

normal to complete registration.

• If the vehicle is backed up while performing registration, data col-

lected during registration will be cleared, and it will take longer than
normal to complete.

• If the vehicle is driven in heavy traffic or another situation where other

vehicles are driven close by, it may take time for the system to recog-
nize the tire pressure warning valve and transmitters of your vehicle
over those of other vehicles.

• If a wheel with a tire pressure warning valve and transmitter installed

is inside or near the vehicle, registration of the ID codes for the
installed wheels may not be possible.

If ID registration is not complete after driving for approximately 1 hour,
park the vehicle in a safe place for approximately 20 minutes and then
perform the ID code registration procedure again.

●

In the following situations, ID code registration will not be started or was
not completed properly and the system will not operate properly. Per-
form the ID code registration procedure again.

• If, when attempting to start ID code registration, the tire pressure

warning light does not blink slowly 3 times.

• If, when the vehicle has been driven for about 20 minutes after per-

forming ID code registration, the tire pressure warning light blinks for
approximately 1 minute and then illuminates.

●

If ID code registration cannot be completed after performing the above
procedure, contact your Toyota dealer.

485

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca
re

WARNING

■

When inspecting or replacing tires

Observe the following precautions to prevent accidents.

Failure to do so may cause damage to parts of the drive train as well as

dangerous handling characteristics, which may lead to an accident

resulting in death or serious injury.

●

Do not mix tires of different makes, models or tread patterns.

Also, do not mix tires of remarkably different treadwear.

●

Do not use tire sizes other than those recommended by Toyota.

●

Do not mix differently constructed tires (radial, bias-belted or bias-ply

tires).

●

Do not mix summer, all season and snow tires.

●

Do not use tires that have been used on another vehicle.

Do not use tires if you do not know how they were used previously.

■

When initializing the tire pressure warning system

Do not initialize the tire pressure warning system without first adjusting

the tire inflation pressure to the specified level. Otherwise, the tire pres-

sure warning light may not come on even if the tire inflation pressure is

low, or it may come on when the tire inflation pressure is actually nor-

mal.

486

6-3. Do-it-yourself maintenance

CAMRY_U

NOTICE

■

Repairing or replacing tires, wheels, tire pressure warning valve

and transmitters and tire valve caps

●

When removing or fitting the wheels, tires or the tire pressure warning

valve and transmitters, contact your Toyota dealer as the tire pressure

warning valve and transmitters may be damaged if not handled cor-

rectly.

●

Make sure to install the tire valve caps. If the tire valve caps are not

installed, water may enter the valves of the tire pressure warning valve

and transmitters and the valves may become stuck.

●

When replacing tire valve caps, do not replace them with metal caps or

any tire valve caps other than specified, as they may become stuck.

■

To avoid damage to the tire pressure warning valve and transmit-

ters

When a tire is repaired with liquid sealants, the tire pressure warning

valve and transmitter may not operate properly. If a liquid sealant is

used, contact your Toyota dealer or other qualified service shop as soon

as possible. Make sure to replace the tire pressure warning valve and

transmitter when replacing the tire. (



P. 475)

■

Driving on rough roads

Take particular care when driving on roads with loose surfaces or pot-

holes.

These conditions may cause losses in tire inflation pressure, reducing

the cushioning ability of the tires. In addition, driving on rough roads

may cause damage to the tires themselves, as well as the vehicle’s

wheels and body.

■

Low profile tires (vehicles with 18 or 19-inch wheels)

Low profile tires may cause greater damage than usual to the tire wheel

when sustaining impact from the road surface. Therefore, pay attention

to the following:

●

Be sure to use proper tire inflation pressure. If tires are under-inflated,

they may be damaged more severely.

●

Avoid potholes, uneven pavement, curbs and other road hazards. Fail-

ure to do so may lead to severe tire and wheel damage.

■

If tire inflation pressure of each tire becomes low while driving

Do not continue driving, or your tires and/or wheels may be ruined.

487

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

The recommended cold tire inflation pressure and tire size are dis-
played on the tire and loading information label. (



P. 584)

Tire inflation pressure



Type A



Type B

488

6-3. Do-it-yourself maintenance

CAMRY_U

Tire valve

Tire pressure gauge

Remove the tire valve cap.

Press the tip of the tire pressure gauge onto the tire valve.

Read the pressure using the gauge gradations.

If the tire inflation pressure is not at the recommended level, adjust
the pressure.
If you add too much air, press the center of the valve to deflate.

After completing the tire inflation pressure measurement and
adjustment, apply soapy water to the valve and check for leakage.

Put the tire valve cap back on.

■

Tire inflation pressure check interval

You should check tire inflation pressure every two weeks, or at least once
a month.
Do not forget to check the spare.

■

Effects of incorrect tire inflation pressure

Driving with incorrect tire inflation pressure may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor handling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drivetrain

If a tire needs frequent inflating, have it checked by your Toyota dealer.

Inspection and adjustment procedure

489

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca
re

■

Instructions for checking tire inflation pressure

When checking tire inflation pressure, observe the following:

●

Check only when the tires are cold.

If your vehicle has been parked for at least 3 hours or has not been

driven for more than 1 mile or 1.5 km, you will get an accurate cold tire

inflation pressure reading.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is properly inflated based only on its appear-

ance.

●

It is normal for the tire inflation pressure to be higher after driving as

heat is generated in the tire. Do not reduce tire inflation pressure after

driving.

●

Never exceed the vehicle capacity weight.

Passengers and luggage weight should be placed so that the vehicle is

balanced.

WARNING

■

Proper inflation is critical to save tire performance

Keep your tires properly inflated.

If the tires are not properly inflated, the following conditions may occur

which could lead to an accident resulting in death or serious injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting from overheated tires

●

Air leaking from between tire and wheel

●

Wheel deformation and/or tire damage

●

Greater possibility of tire damage while driving (due to road hazards,

expansion joints, sharp edges on the road, etc.)

NOTICE

■

When inspecting and adjusting tire inflation pressure

Be sure to put the tire valve caps back on.

If a valve cap is not installed, dirt or moisture may get into the valve and

cause an air leak, resulting in decreased tire inflation pressure.

490

6-3. Do-it-yourself maintenance

CAMRY_U

When replacing wheels, care should be taken to ensure that they are
equivalent to those removed in load capacity, diameter, rim width and
inset

Replacement wheels are available at your Toyota dealer.

: Conventionally referred to as “offset”.

Toyota does not recommend using the following:

●

Wheels of different sizes or types

●

Used wheels

●

Bent wheels that have been straightened

●

Use only Toyota wheel nuts and wrenches designed for use with
your aluminum wheels.

●

When rotating, repairing or changing your tires, check that the
wheel nuts are still tight after driving 1000 miles (1600 km).

●

Be careful not to damage the aluminum wheels when using tire
chains.

●

Use only Toyota genuine balance weights or equivalent and a plas-
tic or rubber hammer when balancing your wheels.

■

When replacing wheels

The wheels of your vehicle are equipped with tire pressure warning valve
and transmitters that allow the tire pressure warning system to provide
advance warning in the event of a loss in tire inflation pressure. When-
ever wheels are replaced, tire pressure warning valve and transmitters
must be installed. (



P. 475)

Wheels

If a wheel is bent, cracked or heavily corroded, it should be
replaced. Otherwise, the tire may separate from the wheel or
cause a loss of handling control.

Wheel selection

Aluminum wheel precautions (if equipped)

491

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca
re

WARNING

■

When replacing wheels

●

Do not use wheels that are a different size from those recommended in

the Owner’s Manual, as this may result in a loss of handling control.

●

Never use an inner tube in a leaking wheel which is designed for a

tubeless tire. Doing so may result in an accident, causing death or seri-

ous injury.

■

When installing the wheel nuts

●

Be sure to install the wheel nuts with the tapered ends facing inward.

(



P. 553) Installing the nuts with the tapered ends facing outward can

cause the wheel to break and eventually cause the wheel to come off

while driving, which could lead to an accident resulting in death or seri-

ous injury.

●

Never use oil or grease on the wheel bolts or wheel nuts.

Oil and grease may cause the wheel nuts to be excessively tightened,

leading to bolt or disc wheel damage. In addition, the oil or grease can

cause the wheel nuts to loosen and the wheel may fall off, causing an

accident and resulting in death or serious injury. Remove any oil or

grease from the wheel bolts or wheel nuts.

NOTICE

■

Replacing tire pressure warning valve and transmitters

●

Because tire repair or replacement may affect the tire pressure warn-

ing valve and transmitters, make sure to have tires serviced by your

Toyota dealer or other qualified service shop. In addition, make sure to

purchase your tire pressure warning valve and transmitters at your

Toyota dealer.

●

Ensure that only genuine Toyota wheels are used on your vehicle.

Tire pressure warning valve and transmitters may not work properly

with non-genuine wheels.

492

6-3. Do-it-yourself maintenance

CAMRY_U

Turn the engine switch off.

Open the glove box and
remove the glove box cover
inside the glove box.

Remove the filter cover.

Unlock the filter cover.

Move the filter cover in the
direction of the arrow, and
then pull it out of the claws.

Remove the filter case.

There may be foreign objects on
top of the air conditioning filter.

Air conditioning filter

The air conditioning filter must be changed regularly to maintain
air conditioning efficiency.

Removal method

493

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca
re

Remove the air conditioning fil-

ter from the filter case and

replace it with a new one.

The “



UP” marks shown on the fil-

ter and the filter case should be

pointing up.

■

Checking interval

Inspect and replace the air conditioning filter according to the maintenance

schedule. In dusty areas or areas with heavy traffic flow, early replacement

may be required. (For scheduled maintenance information, please refer to the

“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.)

■

If air flow from the vents decreases dramatically

The filter may be clogged. Check the filter and replace if necessary.

■

Air conditioning filter with deodorizing function

When fragrances are placed in your vehicle, the deodorizing effect may

become significantly weakened in a short period.
When an air conditioning odor comes out continuously, replace the air condi-

tioning filter.

NOTICE

■

When using the air conditioning system

Make sure that a filter is always installed.

Using the air conditioning system without a filter may cause damage to the

system.

■

To prevent damage to the filter cover

When moving the filter cover in the direc-

tion of arrow to release the fitting, pay

attention not to apply excessive force to

the claws. Otherwise, the claws may be

damaged.

494

6-3. Do-it-yourself maintenance

CAMRY_U

●

Flathead screwdriver

●

Small flathead screwdriver

●

Lithium battery CR2032



Vehicles without a smart key system

Remove the key cover.

To prevent damage to the key,
cover the tip of the flathead screw-
driver with a rag.

Remove the battery cover.

If the battery cover is difficult to
remove, lift the edge to remove it.

Remove the depleted battery
using a small flathead screw-
driver.

Insert a new battery with the “+”
terminal facing up.

Wireless remote control/electronic key

battery

Replace the battery with a new one if it is depleted.

You will need the following items:

Replacing the battery

495

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

Install the battery cover with the
tab facing up.

Push the entire edge of the battery
cover into the key.

Install the key cover.

Align the key cover with the key
and then press it straight into the
key.

Make sure that the key cover is
securely installed without any gaps
between it and the key.

Operate the

switch and check that the doors can

be locked/unlocked.

496

6-3. Do-it-yourself maintenance

CAMRY_U



Vehicles with a smart key system

Release the lock and remove
the mechanical key.

Remove the key cover.

To prevent damage to the key,
cover the tip of the flathead screw-
driver with a rag.

Remove the depleted battery
using a small flathead screw-
driver.

When removing the cover, the
electronic key module may stick to
the cover and the battery may not
be visible. In this case, remove the
electronic key module in order to
remove the battery.

Insert a new battery with the “+” terminal facing up.

When installing the key cover and mechanical key, install by con-
ducting

and

with

the directions reversed.

Operate the

switch and check that the doors can

be locked/unlocked.

497

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca
re

■

When replacing the key battery

Be careful not to lose the battery or any other small parts.

■

Use a CR2032 lithium battery

●

Batteries can be purchased at your Toyota dealer, local electrical appliance

shops or camera stores.

●

Replace only with the same or equivalent type recommended by the manu-

facturer.

●

Dispose of used batteries according to local laws.

■

If the key battery is depleted

The following symptoms may occur:

●

The smart key system (if equipped) and wireless remote control will not

function properly.

●

The operational range will be reduced.

WARNING

■

Battery precautions

Observe the following precautions. Failure to do so may result in death or

serious injury.

●

Do not swallow the battery. Doing so may cause chemical burns.

●

Vehicles without a smart key system: A coin battery or button battery is

used in the key. If a battery is swallowed, it may cause severe chemical

burns in as little as 2 hours and may result in death or serious injury.

●

Vehicles with a smart key system: A coin battery or button battery is used

in the electronic key. If a battery is swallowed, it may cause severe chemi-

cal burns in as little as 2 hours and may result in death or serious injury.

●

Keep away new and removed batteries from children.

●

Vehicles without a smart key system: If the cover cannot be firmly closed,

stop using the key and stow the key in the place where children cannot

reach, and then contact your Toyota dealer.

●

Vehicles with a smart key system: If the cover cannot be firmly closed,

stop using the electronic key and stow the key in the place where children

cannot reach, and then contact your Toyota dealer.

●

If you accidentally swallow a battery or put a battery into a part of your

body, get emergency medical attention immediately.

498

6-3. Do-it-yourself maintenance

CAMRY_U

WARNING

■

To prevent battery explosion or leakage of flammable liquid or gas

●

Replace the battery with a new battery of the same type. If a wrong type of

battery is used, it may explode.

●

Do not expose batteries to extremely low pressure due to high altitude or

extremely high temperatures.

●

Do not burn, break or cut a battery.

NOTICE

■

For normal operation after replacing the battery

Observe the following precautions to prevent accidents:

●

Always work with dry hands.

Moisture may cause the battery to rust.

●

Do not touch or move any other component inside the remote control.

●

Do not bend either of the battery terminals.

■

When removing the battery cover (vehicles without a smart key sys-

tem)

Do not forcibly remove the battery cover, otherwise it may be damaged.
If the battery cover is difficult to remove, lift the edge to remove it.

499

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

Turn the engine switch off.

Open the fuse box cover.

Checking and replacing fuses

If any of the electrical components do not operate, a fuse may
have blown. If this happens, check and replace the fuses as nec-
essary.



Engine compartment (type A)



Engine compartment (type B)
(if equipped)

Push the tabs in and lift the lid off.

Push the tabs in and lift the lid
off.



Under the driver’s side instru-
ment panel

Remove the lid.

Make sure to push the claw when
removing/installing the lid.

500

6-3. Do-it-yourself maintenance

CAMRY_U

Remove the fuse with the pull-
out tool.

Only type A fuses can be removed
using the pullout tool.

Check if the fuse is blown.

Normal fuse

Blown fuse

Replace the blown fuse with a new fuse of an appropriate amperage rat-
ing. The amperage rating can be found on the fuse box lid.



Type A



Type B



Type C

501

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca
re

■

After a fuse is replaced

●

If the lights do not turn on even after the fuse has been replaced, a bulb may

need replacement. (



P. 502)

●

If the replaced fuse blows again, have the vehicle inspected by your Toyota

dealer.

■

If there is an overload in a circuit

The fuses are designed to blow, protecting the wiring harness from damage.

WARNING

■

To prevent system breakdowns and vehicle fire

Observe the following precautions.

Failure to do so may cause damage to the vehicle, and possibly a fire or

injury.

●

Never use a fuse of a higher amperage rating than that indicated, or use

any other object in place of a fuse.

●

Always use a genuine Toyota fuse or equivalent.

Never replace a fuse with a wire, even as a temporary fix.

●

Do not modify the fuses or fuse boxes.

NOTICE

■

Before replacing fuses

Have the cause of electrical overload determined and repaired by your

Toyota dealer as soon as possible.

502

6-3. Do-it-yourself maintenance

CAMRY_U

Check the wattage of the light bulb to be replaced. (



P. 589)

Light bulbs

You may replace the following bulbs yourself. The difficulty level
of replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perform, contact your Toyota
dealer.

For more information about replacing other light bulbs, contact
your Toyota dealer.

Preparing for light bulb replacement

Bulb locations



Front



Rear

Front turn signal/parking lights
(bulb type)

Front side marker lights (bulb
type)

Back-up lights (bulb type)

Rear turn signal lights (bulb
type)

Rear side marker lights (bulb
type)

503

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

■

Front turn signal/parking lights (bulb type)

Turn the bulb base counter-
clockwise.

Remove the light bulb.

Install a new light bulb and
then install the bulb base to
the light unit by inserting it
and turning it clockwise.

Replacing light bulbs

504

6-3. Do-it-yourself maintenance

CAMRY_U

■

Front side marker lights (bulb type)

To ensure enough space to
perform work, turn the steer-
ing wheel to move the front
wheel away from the light
bulb to be replaced.

Turn the steering wheel to the
left when replacing the right side
light bulb, and turn the steering
wheel to the right when replac-
ing the left side light bulb.

Remove the fender liner
clips.

To protect the front bumper
from being damaged, apply
protective tape around the
clip as shown in the illustra-
tion.

Use masking tape, etc. Do not
use duct tape, as it may leave
residue or damage the paint
when removed.

505

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

Insert a small flathead screw-
driver between the front
bumper and fender liner at
the position marked with a
“



” and then separate the

front bumper from the fender
liner.

To separate the front bumper
from the fender liner, pry up the
fender liner while pulling the
front bumper outward as shown
in the illustration.

Pull back the fender liner and
turn the bulb base counter-
clockwise.

Remove the light bulb.

Install a new light bulb and
then install the bulb base to
the light unit by inserting it
and turning it clockwise.

507

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

■

Back-up lights (bulb type)

Open the trunk lid and
remove the clips.

Partly remove the trunk lid
cover.

Disconnect the connector
while depressing the lock
release. (When replacing
right side bulb only.)

Turn the bulb base counter-
clockwise.

509

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

■

Rear turn signal lights (bulb type) and rear side marker lights
(bulb type)

Open the trunk and apply
protective tape to the vehicle
body around the light unit.

Use masking tape, etc. Do not
use duct tape, as it may leave
residue or damage the paint
when removed.

Remove the cover.

Insert a flathead screw-
driver between the cover
and the light unit and pry
up the cover in several
positions as shown in the
illustration to disengage
the claws (indicated by a
dotted line).

Pull the cover toward the
rear of the vehicle to dis-
engage the claws (indi-
cated by a dotted line) and
remove the cover.

To prevent scratching the vehi-
cle, wrap the tip of the flathead
screwdriver with a cloth, etc.

Remove the 2 bolts.

510

6-3. Do-it-yourself maintenance

CAMRY_U

Remove the light unit.

Attach a long piece of
packing tape to the light
unit and fold the excess in
half.

Hold the folded portion
and pull it toward the rear
of the vehicle to remove
the light unit.

Turn the bulb base counterclockwise.

Remove the light bulb.



Rear turn signal lights



Rear side marker lights



Rear turn signal lights



Rear side marker lights

511

6-3. Do-it-yourself maintenance

CAMRY_U

Mainten

ance an

d ca

Install a new light bulb and then install the bulb base to the light
unit by inserting it and turning it clockwise.

Install the light unit.

Align the tabs and push the light
unit toward the front of the vehi-
cle to install it.

Install the 2 bolts.



Rear turn signal lights



Rear side marker lights

Toyota Camry (2024 year). Manual in english - page 16
