Toyota Prius (2023 year). Manual in english - page 12

191

3-2. Opening, closing and locking the doors

3

O

p

er

ati

on
of e
a

ch

 c

o

m

pon
ent

■

Note for the entry function

●

Even when the electronic key is within the effective range (detection areas),
the system may not operate properly in the following cases:
• The electronic key is too close to the window or outside door handle, near

the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is on the instrument panel, floor, or in the door pockets

or glove box when the hybrid system is started or power switch modes
are changed.

●

Do not leave the electronic key on top of the instrument panel or near the
door pockets when exiting the vehicle. Depending on the radio wave recep-
tion conditions, it may be detected by the antenna outside the cabin and the
door will become lockable from the outside, possibly trapping the electronic
key inside the vehicle.

●

As long as the electronic key is within the effective range, the doors may be
unlocked or locked by anyone.

●

Even if the electronic key is not inside the vehicle, it may be possible to start
the hybrid system if the electronic key is near the window.

●

The doors may unlock if a large amount of water splashes on the door han-
dle, such as in the rain or in a car wash when the electronic key is within the
effective range. (The door will automatically be locked after approximately
30 seconds if the doors are not opened and closed.)

●

If the wireless remote control is used to lock the doors when the electronic
key is near the vehicle, there is a possibility that the door may not be
unlocked by the entry function. (Use the wireless remote control to unlock
the doors.)

●

Touching the door lock sensor while wearing gloves may delay or prevent
lock operation. Remove the gloves and touch the lock sensor again.

●

On some models: When the lock operation is performed using the lock sen-
sor, recognition signals will be shown up to two consecutive times. After this,
no recognition signals will be given.

●

If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. In this case, follow the
following correction procedures to wash the vehicle.
• Place the electronic key in a location 2 m (6 ft.) or more away from the

vehicle. (Take care to ensure that the key is not stolen.)

• Set electronic key to battery-saving mode to disable the smart entry &

start system. (



P. 189)

192

3-2. Opening, closing and locking the doors

●

If the electronic key is inside the vehicle and a door handle becomes wet
during a car wash, a message may be shown on the multi-information dis-
play and a buzzer will sound outside the vehicle. To turn off the alarm, lock
all the doors.

●

The lock sensor may not work properly if it comes into contact with ice,
snow, mud, etc. Clean the lock sensor and attempt to operate it again.

●

A sudden approach to the effective range or door handle may prevent the
doors from being unlocked. In this case, return the door handle to the origi-
nal position and check that the doors unlock before pulling the door handle
again.

●

If there is another electronic key in the detection area, it may take slightly
longer to unlock the doors after the door handle is gripped.

■

When the vehicle is not driven for extended periods

●

To prevent theft of the vehicle, do not leave the electronic key within 2 m
(6 ft.) of the vehicle.

●

The smart entry & start system can be deactivated in advance. (



P. 670)

■

To operate the system properly

Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from the
outside of the vehicle.
Depending on the position and holding condition of the electronic key, the key
may not be detected correctly and the system may not operate properly. (The
alarm may go off accidentally, or the door lock prevention may not operate.)

■

If the smart entry & start system does not operate properly

●

Locking and unlocking the doors: Use the mechanical key. (



P. 636)

●

Starting the hybrid system:



P. 637

■

Customization

Settings (e.g. smart entry & start system) can be changed.
(Customizable features:



P. 670)

■

If the smart entry & start system has been deactivated in a customized
setting

●

Unlocking and locking the doors:
Use the wireless remote control or mechanical key. (



P. 177, 636)

●

Starting the hybrid system and changing power switch modes:



P. 637

●

Stopping the hybrid system:



P. 245

193

3-2. Opening, closing and locking the doors

3

O

p

er

ati

on
of e
a

ch

 c

o

m

pon
ent

WARNING

■

Caution regarding interference with electronic devices

●

People with implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should keep
away from the smart entry & start system antennas. (



P. 187)

The radio waves may affect the operation of such devices. If necessary,
the entry function can be disabled. Ask any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer for details, such as the
frequency of radio waves and timing of the emitted radio waves. Then,
consult your doctor to see if you should disable the entry function.

●

Users of any electrical medical device other than implantable cardiac
pacemakers, cardiac resynchronization therapy-pacemakers or implanta-
ble cardioverter defibrillators should consult the manufacturer of the
device for information about its operation under the influence of radio
waves.
Radio waves could have unexpected effects on the operation of such
medical devices.

Ask any authorized Toyota retailer or Toyota authorized repairer, or any reli-
able repairer for details on disabling the entry function.

194

3-3. Adjusting the seats

Front seats

Seat position adjustment lever
Seatback angle adjustment
lever
Vertical height adjustment lever
(for driver’s side)
Lumbar support adjustment
switch (for driver’s side)

■

When adjusting the seat

Take care when adjusting the seat so that the head restraint does not touch
the ceiling.

Adjustment procedure

1
2

3

4

195

3-3. Adjusting the seats

3

O

p

er

ati

on
of e
a

ch

 c

o

m

pon
ent

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

■

Seat adjustment

●

To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

●

After adjusting the seat, make sure that the seat is locked in position.

196

3-3. Adjusting the seats

Rear seats

Park the vehicle in a safe place.

Apply the parking brake firmly (



P. 260) and shift the shift position to P.

(



P. 254)

Adjust the position of the front seat and the angle of the seatback.
(



P. 194)

Depending on the position of the front seat, if the seatback is folded back-
ward, it may interfere with the operation of the rear seat.

Lower the head restraint of the rear seat. (



P. 199)

Stow the armrest of the rear seat if it is pulled out. (



P. 493)

This step is not necessary when operating the left side seat only.

The seatbacks can be folded down.

Before folding down the seatbacks

1

2

3

4

197

3-3. Adjusting the seats

3

O

p

er

ati

on
of e
a

ch

 c

o

m

pon
ent

Pull the seatback lock release
lever and fold the seatback down.

To avoid trapping the seat belt
between the seat and the inside of
the vehicle, pass the seat belt
inside the seat belt guide and then
return the seatback securely to
the locked position.

Folding down the seatbacks

Returning the rear seatbacks

Seat belt guide

WARNING

■

When folding the seatbacks down

Observe the following precautions. Failure to do so may result in death or
serious injury.

●

Do not fold the seatbacks down while driving.

●

Stop the vehicle on level ground, apply the parking brake firmly and shift
the shift position to P.

●

Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.

●

Do not allow children to enter the luggage compartment.

●

Do not operate the rear seat if it is occupied.

●

Be careful not to get feet or hands caught in the moving parts or joints of
the seats during operation.

●

Do not allow children to operate the seat.

198

3-3. Adjusting the seats

WARNING

■

After returning the seatback to the upright position

Observe the following precautions. Failure to do so may result in death or
serious injury.

●

Check that the seat belts are not twisted or caught in the seatback.

●

Make sure that the seatback is securely
locked in position by lightly pushing it
back and forth.
If the seatback is not securely locked,
the red marking will be visible on the
seatback lock release lever. Make sure
that the red marking is not visible.

199

3

3-3. Adjusting the seats

O

p

er

ati

on
of e
a

ch

 c

o

m

pon
ent

Head restraints

Up

Pull the head restraints up.

Down

Push the head restraint down while
pressing the lock release button.

■

Rear outboard seats

Up

Pull the head restraints up.

Down

Push the head restraint down
while pressing the lock release
button.

■

Rear center seat

Up

Pull the head restraints up.

Down

Push the head restraint down
while pressing the lock release
button.

Head restraints are provided for all seats.

Front seats

Lock release button

1

2

Rear seats

Lock release button

1

2

Lock release button

1

2

200

3-3. Adjusting the seats

■

Removing the head restraints



Front and rear center seats



Rear outboard seats

Pull the head restraint up while pressing
the lock release button.

Pull the seatback lock release lever and
fold down the seatback until it reaches
the position where the head restraints
can be removed.

Pull the head restraint up while pressing
the lock release button.

Lock release button

1

2

Lock release
button

201

3-3. Adjusting the seats

3

O

p

er

ati

on
of e
a

ch

 c

o

m

pon
ent

■

Installing the head restraints



Front and rear center seats



Rear outboard seats

■

Adjusting the height of the head restraints (front seats)

■

Adjusting the rear seat head restraint

Always raise the head restraint one level from the stowed position when
using.

Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.

Pull the seatback lock release lever and
fold down the seatback until it reaches
the position where the head restraints
can be installed.

Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.

Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

Lock release button

1

2

Lock release
button

202

3-3. Adjusting the seats

WARNING

■

Head restraint precautions

Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After adjusting the head restraints, push down on them and make sure
they are locked in position.

●

Do not drive with the head restraints removed.

203

3

3-4. Adjusting the steering wheel and mirrors

O

p

er

ati

on
of e
a

ch

 c

o

m

pon
ent

Steering wheel

Hold the steering wheel and
push the lever down.

Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.

After adjustment, pull the lever up
to secure the steering wheel.

To sound the horn, press on or
close to the

 mark.

Adjustment procedure

1

2

Horn

204

3-4. Adjusting the steering wheel and mirrors

WARNING

■

Caution while driving

Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.

■

After adjusting the steering wheel

Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident, and resulting in death or serious injury. Also, the horn may not
sound if the steering wheel is not securely locked.

205

3

3-4. Adjusting the steering wheel and mirrors

O

p

er

ati

on
of e
a

ch

 c

o

m

pon
ent

Inside rear view mirror

The height of the rear view mirror can be adjusted to suit your driving
posture.

Adjust the height of the rear view
mirror by moving it up and down.



Manual anti-glare inside rear view mirror

Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.

Normal position
Anti-glare position

The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

1
2

206

3-4. Adjusting the steering wheel and mirrors



Auto anti-glare inside rear view mirror

Responding to the level of brightness of the headlights of vehicles
behind, the reflected light is automatically reduced.

Changing automatic anti-glare
function mode
On/off

When the automatic anti-glare
function is in ON mode, the indica-
tor illuminates.
The function will set to ON mode
each time the power switch is
turned to ON mode.
Pressing the button turns the func-
tion to OFF mode. (The indicator
also turns off.)

■

To prevent sensor error (vehicles with auto anti-glare inside rear view
mirror)

Indicator

To ensure that the sensors operate prop-
erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.
