8-2. Steps to take in an emergency

hen
trou

e ari

(Flashes or

illuminated)

(If equipped)

PCS warning light

When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-Col-
lision System)



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily
unavailable, corrective action may be necessary.



Follow the instructions displayed on the multi-infor-
mation display. (



P. 340, 670)

If the PCS (Pre-Collision System) or VSC (Vehicle Stabil-
ity Control) system is disabled, the PCS warning light will
illuminate.



P. 352

(yellow)

(If equipped)

Cruise control warning light

Indicates a malfunction in the cruise control



P. 389

Slip indicator light

Indicates a malfunction in:
• The VSC system;
• The trailer sway control system (If equipped);
• The TRC system;
• Active TRC system (If equipped);
• The downhill assist control system (If equipped);
• The hill-start assist control;
• The Multi-terrain Select (If equipped); or
• The Crawl Control (If equipped).
The light will flash when any of the above systems other
than the Multi-terrain Select are operating.



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

Warning light

Warning light/Details/Actions

660

8-2. Steps to take in an emergency

(If equipped)

Automatic transmission fluid temperature warning light

• Indicates that the automatic transmission fluid tempera-

ture is too high if the light comes on.



Immediately stop the vehicle in a safe place, shift the
shift lever to P and wait until the light goes off. If the
light goes off, you may start the vehicle again. If the
warning light do not go off, contact any authorized
Toyota retailer or Toyota authorized repairer, or any
reliable repairer.

• Indicates a malfunction in the automatic transmission

system if the light flashes.



Immediately stop the vehicle in a safe place, shift the
shift lever to P and contact any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer.

(If equipped)

KDSS warning light

Indicates a malfunction in KDSS



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

(If equipped)

Low AdBlue™ level warning light

Indicates that the engine may not be restarted due to
AdBlue™ level is low.



Have AdBlue™ refilled at any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer.

(If equipped)

(Comes on or

flashes)

Fuel system warning light (warning buzzer)

• The amount of accumulated water in the fuel filter has

reached the specified level if the light flashes.



P. 592

• Malfunction in the fuel system if the light comes on.



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

The buzzer will sound at the same time the warning light
flashes.

Open door warning light (warning buzzer)

Indicates that a door, the hood or the glass hatch is not
fully closed



Check that all the doors, the hood, the back door and
the glass hatch are closed.

Warning light

Warning light/Details/Actions

661

8-2. Steps to take in an emergency

hen
trou

e ari

Low fuel level warning light

Vehicles without sub fuel tank:
Indicates that remaining fuel is approximately 14.6 L (3.8
gal., 3.2 Imp.gal.) or less if the light comes on.

Vehicles with sub fuel tank:
Indicates that remaining fuel is approximately 22.5 L (5.9
gal., 4.9 Imp.gal.) or less if the light comes on.

Indicates a malfunction in the fuel pump of the sub fuel
tank if the light flashes.



Refuel the vehicle.

(If equipped)

(Flashes)

Stop & Start cancel indicator

Indicates a malfunction in the Stop & Start system
(The Stop & Start cancel indicator will come on when the
system is canceled:



P. 392)



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

Driver’s and front passenger’s seat belt reminder light
(warning buzzer)

Warns the driver and/or front passenger to fasten their
seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

(If equipped)

Rear passengers’ seat belt reminder light (warning
buzzer)

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

(If equipped)

Low engine oil level warning light

Indicates that engine oil level is low (This warning light
may come on if the vehicle is stopped on a slope. Move
the vehicle to a level surface and check to see if the light
goes off.)



Check the level of engine oil and add more oil if nec-
essary.

(If equipped)

Master warning light

A buzzer sounds and the warning light comes on and
flashes to indicate that the master warning system has
detected a malfunction.



P. 670

Warning light

Warning light/Details/Actions

662

8-2. Steps to take in an emergency

(If equipped)

Tire pressure warning light

When the light comes on:
Low tire inflation pressure such as
• Natural causes (



P. 668)

• Flat tire (



P. 676, 693)



Adjust the tire inflation pressure to the specified
level.
The light will turn off after a few minutes. In case the
light does not turn off even if the tire inflation pres-
sure is adjusted, have the system checked by any
authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer.

When the light comes on after blinking for 1 minute:
Malfunction in the tire pressure warning system



Have the system checked by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer.

(If equipped)

Low windshield washer fluid warning light

Low level of washer fluid



Fill the tank.

(If equipped)

LED headlight warning light

Indicates a malfunction in the LED headlights
The LED headlights will not normally illuminate when there
is a malfunction, however it may be able to illuminate
depending on the nature of the problem.



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

(If equipped)

Automatic headlight leveling system warning light

Indicates a malfunction in the automatic headlight leveling
system



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

(Flashes)

(If equipped)

Toyota parking assist-sensor indicator (warning
buzzer)

Indicates a malfunction in Toyota parking assist-sensor



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

Warning light

Warning light/Details/Actions

663

8-2. Steps to take in an emergency

hen
trou

e ari

(If equipped)

Toyota parking assist-sensor indicator (warning
buzzer)

Indicates that Toyota parking assist-sensor is dirty or cov-
ered with ice.



Clean the sensors.

(If equipped)

DPF system warning light

The amount of accumulated deposit in the DPF system
has reached the specified level if the light comes on.
Regenerate the filter.



P. 295

Malfunction in the DPF system if the light flashes.



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

Parking brake indicator light (warning buzzer)

Warns the driver to release parking brake.



Release the parking brake.

(If equipped)

(Comes on)

Brake Override System/Drive-Start Control warning
light

When a buzzer does not sounds:
Indicates that the accelerator and brake pedals are being
depressed simultaneously, and the Brake Override Sys-
tem is operating.



Release the accelerator pedal and depress the brake
pedal.

(If equipped)

(Flashes)

Brake Override System/Drive-Start Control warning
light

When a buzzer sounds:
Indicates a malfunction in:
• The Brake Override system
• The Drive-Start Control



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer immediately.

• Indicates that the shift position was changed and Drive-

Start Control (if equipped) was operated while depress-
ing the accelerator pedal.



Momentarily release the accelerator pedal.

(Orange)

(If equipped)

LDA indicator (warning buzzer)

Indicates a malfunction in the LDA (Lane Departure Alert
with Yaw Assist Function)



Follow the instructions displayed on the multi-infor-
mation display. (



P. 363)

Warning light

Warning light/Details/Actions

664

8-2. Steps to take in an emergency

: Vehicles with the multi-information display type B: This light illuminates

on the multi-information display.

: Open door warning buzzer:

The open door warning buzzer sounds to alert one or more of the doors is
not fully closed (with the vehicle having reached a speed of 5 km/h [3
mph]).

: Driver’s and front passenger’s seat belt warning buzzer:

The driver’s and front passenger’s seat belt warning buzzer sounds to
alert the driver and front passenger that his or her seat belt is not fas-
tened. If the seat belt is unfastened, the buzzer sounds intermittently for a
certain period of time after the vehicle reaches a certain speed.

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear
passenger that his or her seat belt is not fastened. If the seat belt is
unfastened, the buzzer sounds intermittently for a certain period of time,
after the seat belt is fastened and unfastened and the vehicle reaches a
certain speed.

: The corner and center indicators flash after the indicator for the malfunc-

tioning sensor flashes and the vehicle indicator turns off while the buzzer
sounds for approximately 7 seconds.

: The corner and center indicators turn on and remain on after the indicator

for the malfunctioning sensor turns on and the vehicle indicator turns off
while the buzzer sounds for approximately 7 seconds.

: Parking brake engaged warning buzzer:

A buzzer will sound if the vehicle is driven at a speed of approximately 5
km/h (3 mph) or more.

665

8-2. Steps to take in an emergency

hen
trou

e ari

After taking the specified steps to correct the suspected problem,
check that the warning light turns off.

Smart entry & start system warning light and buzzer procedures
(vehicles with the multi-information display type A)

Interior

buzzer

Exterior

buzzer

Warning

light

Details/Actions

Continu-
ous

(Flashes in

yellow)

Indicates that the driver’s door was
opened and closed while the electronic
key was not in the vehicle, the shift lever
was not in P (automatic transmission) or
N (manual transmission) and the engine
switch was not turned off.



Shift the shift lever to P (automatic
transmission) or N (manual trans-
mission).
Bring the electronic key back into
the vehicle.

Once

3 times

(Flashes in

yellow)

Indicates that the driver’s door has been
opened or closed with the engine switch
in any mode other than off, the shift lever
was in P (automatic transmission) or N
(manual transmission) and the electronic
key outside of the detection area.



Turn the engine switch off.
Bring the electronic key back into
the vehicle.

Once

Sounds
once for
5 sec-
onds

(Flashes in

yellow)

Indicates that the engine switch in any
mode other than off, the shift lever was
in P (automatic transmission), the elec-
tronic key outside of the detection area
and attempt to lock the vehicle with
smart entry & start system.



Turn the engine switch off.
Bring the electronic key back into
the vehicle.

666

8-2. Steps to take in an emergency

Once

Sounds
3 times

(Flashes in

yellow)

Indicates that a door other than the
driver’s door has been opened or closed
with the engine switch in any mode other
than off, the shift lever was in P (auto-
matic transmission) or N (manual trans-
mission) and the electronic key outside
of the detection area.



Turn the engine switch off.
Bring the electronic key back into
the vehicle.

Once



(Flashes in

yellow for

15 seconds)

Indicates the electronic key is not pres-
ent when attempting to start the engine.



Confirm the location of the elec-
tronic key

9 times



(Flashes in

yellow)

Indicate that an attempt was made to
drive when the regular key was not
inside the vehicle.



Bring the electronic key back into
the vehicle.

Once



(Flashes in

yellow for 15

seconds)

Indicate that the electronic key battery is
low.



Replace the battery. (



P. 619)

Once



(Flashes

quickly in green

for 15 seconds)

Indicate that the steering lock has not
been released.



Release the steering lock.
(



P. 276)

Once



(Flashes in

yellow for 60

seconds)

• When the door were unlocked with

the mechanical key and then the
engine switch was pressed, the
electronic key could not be detected
in the vehicle.

• The electronic key could not be

detected in the vehicle even after
the engine switch was pressed two
consecutive times.



Touch the electronic key to the
engine switch while depressing the
brake pedal (automatic transmis-
sion) or clutch pedal (manual
transmission).

Interior

buzzer

Exterior

buzzer

Warning

light

Details/Actions

667

8-2. Steps to take in an emergency

hen
trou

e ari

Carrying out the corresponding action turns the warning light off.

■

Front passenger detection sensor and passenger seat belt reminder

●

If luggage is placed on the front passenger seat, the front passenger detec-
tion sensor may cause the warning light to flash, even if a passenger is not
sitting in the seat.

●

If a cushion is placed on the seat, the sensor may not detect a passenger,
and the warning light may not operate properly.

■

If the low speed four-wheel drive indicator light or the center differential
lock indicator light blinks

Take the specified steps. (



Refer to the “Off-road driving Owner’s manual”)

Other warning light

Warning light

Warning light/Details/Actions

(If equipped)

Go to service warning light (warning buzzer)

Indicates a malfunction in the electronic engine control
system or electronic throttle control system.



Have the vehicle inspected by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable
repairer

(If equipped)

Engine oil maintenance indicator

When the indicator flashes:
Indicates that the engine oil is scheduled to be changed
Comes on approximately 25000 km (15000 miles) after
the engine oil is changed. (The indicator will not work
properly unless the oil maintenance data has been reset.)



Check the engine oil and change if necessary. After
changing the engine oil, the oil change system
should be reset. (



P. 582)

When the warning light is illuminated:
Indicates that the engine oil and oil filter should be
changed



Have the engine oil and oil filter checked and/or
changed by any authorized Toyota retailer or Toyota
authorized repairer, or any reliable repairer. After
changing the engine oil, the oil change system
should be reset. (



P. 582)

668

8-2. Steps to take in an emergency

■

When the tire pressure warning light comes on (vehicles with the tire
pressure warning system)

Inspect the appearance of the tire to check that the tire is not punctured.
If the tire is punctured:



P. 676, 693

If the tire is not punctured:
Carry out the following procedure after the tire temperature has lowered suffi-
ciently.

●

Check the tire inflation pressure and adjust to the appropriate level.

●

If the warning light does not go out even after several minutes, check that
the tire inflation pressure is at the specified level and carry out initialization.
(



P. 603)

The warning light may come on again if the above operations are conducted
without first allowing the tire temperature to lower sufficiently.

■

The tire pressure warning light may come on due to natural causes
(vehicles with the tire pressure warning system)

The tire pressure warning light may come on due to natural causes such as
natural air leaks and tire inflation pressure changes caused by temperature.
In this case, adjusting the tire inflation pressure will turn off the warning light
(after a few minutes).

■

When a tire is replaced with a spare tire (vehicles with a spare tire and
the tire pressure warning system)

The tire pressure warning light will turn on if the tire inflation pressure of the
spare tire is low. If a tire goes flat, the tire pressure warning light will not turn
off even though the flat tire has been replaced with the spare tire.

■

Conditions that the tire pressure warning system may not function prop-
erly (vehicles with the tire pressure warning system)



P. 606

■

If the tire pressure warning light frequently comes on after blinking for 1
minute (vehicles with the tire pressure warning system)

If the tire pressure warning light frequently comes on after blinking for 1 min-
ute when the engine switch is turned to the “ON” position (vehicles without a
smart entry & start system) or IGNITION ON mode (vehicles with a smart
entry & start system), have it checked by any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer.

■

Warning buzzer

In some cases, the buzzer may not be heard because of noisy place or an
audio sound.

669

8-2. Steps to take in an emergency

hen
trou

e ari

WARNING

■

If both the ABS and the brake system warning lights remain on

Stop your vehicle in a safe place immediately and contact any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer. The
vehicle will become extremely unstable during braking, and the ABS system
may fail, which could cause an accident resulting in death or serious injury.

■

When the power steering system warning light comes on

The steering wheel may become extremely heavy.
If the steering wheel becomes heavier than usual when operating, hold
firmly and operate using more force than usual.

■

If the tire pressure warning light comes on (vehicles with the tire pres-
sure warning system)

Be sure to observe the following precautions. Failure to do so could cause a
loss of vehicle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire infla-
tion pressure immediately.

●

If the tire pressure warning light comes on even after tire inflation pressure
adjustment, it is probable that you have a flat tire. Check the tires. If a tire
is flat, change it with the spare tire and have the flat tire repaired by the
nearest authorized Toyota retailer or Toyota authorized repairer, or any
reliable repairer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you
could lose control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur (vehicles with the tire
pressure warning system)

The tire pressure warning system may not activate immediately.

NOTICE

■

To ensure the tire pressure warning system operates properly (vehi-
cles with the tire pressure warning system)

Do not install tires with different specifications or makers, as the tire pres-
sure warning system may not operate properly.

■

If the fuel filter warning light comes on (if equipped)

Never drive the vehicle with the warning light on. Continued driving with
water accumulated in the fuel filter will damage the fuel injection pump.

670

8-2. Steps to take in an emergency

If a warning message is displayed



Master warning light

The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the multi-
information display.

Multi-information display
Handling method

Follow the instructions of the mes-
sage on the multi-information dis-
play.

If any of the warning messages are shown again after the following
actions have been performed, contact any authorized Toyota retailer
or Toyota authorized repairer, or any reliable repairer.



: If equipped

The multi-information display shows warnings of system mal-
functions, incorrectly performed operations, and messages that
indicate a need for maintenance. When a message is shown,
perform the correction procedure appropriate to the message.

2
3

671

8-2. Steps to take in an emergency

hen
trou

e ari

The warning lights and warning buzzers operate as follows depending
on the content of the message. If a message indicates the need for
inspection by a dealer, have the vehicle inspected by any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer
immediately.

The operation of the warning lights and warning buzzers may differ
from those stated. in this case, perform the correction procedure
according to the displayed message.

: A buzzer sounds the first time a message is shown on the multi-informa-

tion display.

Messages and warnings

System

warning

light

Warning

buzzer

Warning

Comes on Comes on

Sounds

Indicates an important situation, such
as when a system related to driving is
malfunctioning or that danger may
result if the correction procedure is not
performed

Comes on



Sounds



Comes on

or flashes

Sounds

Indicates an important situation, such
as when the systems shown on the
multi-information display may be mal-
functioning

Flashes



Sounds

Indicates a situation, such as when
damage to the vehicle or danger may
result

Comes on



Does not

sound

Indicates a condition, such as mal-
function of electrical components, their
condition, or indicates the need for
maintenance

Flashes



Does not

sound

Indicates a situation, such as when an
operation has been performed incor-
rectly, or indicates how to perform an
operation correctly

672

8-2. Steps to take in an emergency

■

System warning lights

The master warning light does not come on or flash in the following cases.
Instead, a separate system warning light will come on along with a message
or image shown on the multi-information display.

●

Malfunction in the ABS
The ABS warning light comes on. (



P. 658)

●

Indicates that the PCS (Pre-Collision System) is not currently functional
The PCS warning light comes on or flashes. (if equipped) (



P. 659)

●

Indicates that remaining fuel is low or that there is a malfunction in the fuel
tank system

The low fuel level warning light comes on. (



P. 661)

: Vehicles with diesel engine

●

Indicates that a door, the hood or the glass hatch is not fully closed while the
vehicle is stopped.
The Open door warning light comes on. (



P. 660)

■

If “Oil Pressure Low Stop in a Safe Place See Owner’s Manual” is shown
(if equipped)

Indicates abnormal engine oil pressure.
Immediately stop the vehicle in a safe place and contact any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer. Continu-
ing to drive the vehicle may be dangerous.

■

If a message instructing to refer to the Owner’s Manual is displayed

●

If the following message is shown, there may be a malfunction.
Immediately stop the vehicle in a safe place and contact any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer. Con-
tinuing to drive the vehicle may be dangerous.
• “Braking power low stop in a safe place See owner’s manual”

●

If “DPF full Manual regeneration required See owner’s manual” is shown,
following the instruction, accordingly. (if equipped) (



P. 295)

●

If a message relevant to the AdBlue™ is displayed, follow the instructions
accordingly. (If equipped) (



P. 595)

■

If “High transmission fluid temperature” is shown, it indicates that the
automatic transmission fluid temperature is too high. (vehicles with an
automatic transmission)

Immediately stop the vehicle in a safe place, shift the shift lever to P and wait
until the warning message and light go off. If the warning message and light
go off, you may start the vehicle again. If the warning message and light do
not go off, contact any authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer.

673

8-2. Steps to take in an emergency

hen
trou

e ari

■

If “Fuel Filter Maintenance Required” is shown (diesel engine)

Indicates a malfunction in the fuel system. Have the vehicle inspected by any
authorized Toyota retailer or Toyota authorized repairer, or any reliable
repairer immediately.

■

If “Drain Water from Fuel Filter” is shown (diesel engine)

Indicates that the amount of accumulated water in the fuel filter has reached
the specified level. (



P. 592)

■

If “Emissions too high Unable to restart engine Check AdBlue Visit your
dealer” is shown (If equipped)

If the engine is stopped, it cannot be restarted. Without stopping the engine,
contact any authorized Toyota retailer or Toyota authorized repairer, or any
reliable repairer immediately. (



P. 293)

■

If “Check air suspension system” is shown (vehicles with the rear height
control air suspension)

Immediately stop the vehicle in a safe place and contact any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer.
Continuing to drive the vehicle may be dangerous.
Refer to the “Off-road driving Owner’s manual” for more information regarding
rear height control air suspension.

■

If “Shift to P position when parked” is shown (if equipped)

Message is displayed when the driver’s door is opened without turning the
engine switch to off with the shift lever in any position other than P.
Shift the shift lever to P.

■

If “Auto power off to conserve battery” is shown (if equipped)

Power was turned off due to the automatic power off function.
Next time when starting the engine, increase the engine speed slightly and
maintain that level for approximately 5 minutes to recharge the battery.

■

When a message that indicates the need for the shift lever operation is
shown (if equipped)

To prevent the shift lever from being operated incorrectly or the vehicle from
moving unexpectedly, a message that requires shifting the shift lever may be
shown on the multi-information display. In that case, follow the instruction of
the message and shift the shift lever.

■

When “Headlight System Malfunction Visit Your Dealer” is displayed on
the multi-information display (if equipped)

The following systems may be malfunctioning. Have the vehicle inspected by
any authorized Toyota retailer or Toyota authorized repairer, or any reliable
repairer immediately.

●

The LED headlight system

●

The automatic headlight leveling system

●

AHB (Automatic High Beam)

674

8-2. Steps to take in an emergency

■

If a message that indicates the malfunction of front camera is displayed
(if equipped)

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 340, 657)

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert with Yaw Assist Function)

●

AHB (Automatic High Beam)

●

RSA (Road Sign Assist)

●

Dynamic radar cruise control

■

If a message that indicates the malfunction of radar sensor is displayed
(if equipped)

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 340, 657)

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert with Yaw Assist Function)

●

Dynamic radar cruise control

■

If “Radar Cruise Control Unavailable” is shown (if equipped)

The dynamic radar cruise control system is suspended temporarily or until the
problem shown in the message is resolved. (causes and coping methods:



P. 340)

■

If “Oil Maintenance Required Soon” is shown (if equipped)

Indicates that the engine oil is scheduled to be changed. (The indicator will
not work properly unless the message has been reset.)
Check the engine oil, and change if necessary. After changing the engine oil,
the message should be reset. (



P. 582)

■

If “Oil Maintenance Required” is shown (if equipped)

Indicates that the engine oil should be changed. (The indicator will not work
properly unless the message has been reset.)
Check and change the engine oil, and oil filter by any authorized Toyota
retailer or Toyota authorized repairer, or any reliable repairer. After changing
the engine oil, the message should be reset. (



P. 582)

■

If “Engine Oil Level Low Add or Replace” is shown

Indicates that engine oil level is low.
Check the level of engine oil, and add if necessary.
This message may appear if the vehicle is stopped on a slope.
Move the vehicle to a level surface and check to see if the message disap-
pears.

■

If a following message is shown, take appropriate action and confirm
that the message has disappeared. (if equipped)

●

“Crawl Not Available Select L4 and Shift to [D] or [R] Position”

●

“Crawl Not Available Check System Operation Conditions”

: Refer to the “Off-road driving Owner’s manual”.

Toyota Land Cruiser Prado (2023 year). Manual in english - page 41
