465

5-5. Using an external device

Au
dio
sy
stem

WARNING

■

While driving

Do not connect iPod or operate the controls. Doing so may cause an acci-
dent, resulting in death or serious injury.

NOTICE

■

To prevent damage to iPod or its terminal

●

Do not leave iPod in the vehicle. The temperature inside the vehicle may
become high.

●

Do not push down or apply unnecessary pressure to the iPod while it is
connected.

●

Do not insert foreign objects into the port.

466

5-5. Using an external device

Listening USB memory device



P. 444

Connecting a USB memory enables you to enjoy music from the
vehicle speakers. Press the “MODE” button until “USB” is dis-
played.

Connecting a USB memory

Control panel

Changing the audio source/
playback
Tune/scroll knob
Selecting a file
Selecting a song, fast-forward-
ing or rewinding
Random play or back button
Repeat play

Selecting a folder
Displaying folder list
Displaying text message
Power/volume knob
Press: Turning the audio sys-
tem on or off
Turn: Adjusting the volume

4
5

6
7
8
9

467

5-5. Using an external device

Au
dio
sy
stem

■

Selecting folders one at a time

Press

(<FOLDER) or

(FOLDER>) to select the

desired folder.

■

Selecting a folder and file from folder list

Press

(LIST).

The folder list will be displayed.

Turn and press the tune/scroll knob to select a folder and file.

To return to the previous display, press

(BACK).

■

Returning to the first folder

Press and hold

(<FOLDER) until you hear a beep.

Turn the tune/scroll knob or press the “<” or “>” button of “SEEK
TRACK” to select the desired file.

Selecting a folder

Selecting a file

468

5-5. Using an external device

Press and hold the “<” or “>” button of “SEEK TRACK”.

Pressing

(RDM) changes modes in the following order:

Folder random



All folder random



Off

Pressing

(RPT) changes modes in the following order:

File repeat



Folder repeat



Off

: Available except when RDM (random play) is selected

Press

(TEXT) to display or hide the album title.

If there are continuing texts,

is displayed.

Press and hold the button to display the remaining texts.

Fast-forwarding and rewinding files

Random play

Repeat play

Switching the display

469

5-5. Using an external device

Au
dio
sy
stem

■

USB memory functions

●

Depending on the USB memory that is connected to the system, the device
itself may not be operable and certain functions may not be available. If the
device is inoperable or a function is unavailable due to a malfunction (as
opposed to a system specification), disconnecting the device and recon-
necting it once again may resolve the problem.

●

If the USB memory still does not begin operation after being disconnected
and reconnected, format the memory.

■

Display



P. 454

■

Error messages

If an error message is displayed, refer to the following table and take the
appropriate measures. If the problem is not rectified, take the vehicle to any
authorized Toyota retailer or Toyota authorized repairer, or any reliable
repairer.

■

USB memory

●

Compatible devices
USB memory that can be used for MP3 and WMA playback

●

Compatible device formats
The following device formats can be used:
• USB communication formats: USB2.0 FS (12mbps)
• File formats: FAT12/16/32 (Windows)
• Correspondence class: Mass storage class
MP3 and WMA files written in any format other than those listed above may
not play correctly, and their file names and folder names may not be dis-
played correctly.
Items related to standards and limitations are as follows:
• Maximum directory hierarchy: 8 levels (including the root)
• Maximum number of folders in a device: 999 (including the root)
• Maximum number of files in a device: 9999
• Maximum number of files per folder: 255

Message

Cause/Correction procedures

“ERROR”

This indicates a problem in the USB memory
or its connection.

“NO MUSIC”

This indicates that no MP3/WMA files are
included in the USB memory.

470

5-5. Using an external device

●

MP3 and WMA files
MP3 (MPEG Audio LAYER3) is a standard audio compression format.
Files can be compressed to approximately 1/10 of their original size by
using MP3 compression.
WMA (Windows Media Audio) is a Microsoft audio compression format.
This format compresses audio data to a size smaller than that of the MP3
format.
There is a limit to the MP3 and WMA file standards and to the media/for-
mats recorded by them that can be used.

●

MP3 file compatibility
• Compatible standards

MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3)

• Compatible sampling frequencies

MPEG1 LAYER3: 32, 44.1, 48 (kHz)
MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz)

• Compatible bit rates (compatible with VBR)

MPEG1 LAYER3: 32—320 (kbps)
MPEG2 LSF LAYER3: 8—160 (kbps)

• Compatible channel modes: stereo, joint stereo, dual channel and mon-

aural

●

WMA file compatibility
• Compatible standards

WMA Ver. 7, 8, 9

• Compatible sampling frequencies

32, 44.1, 48 (kHz)

• Compatible bit rates (only compatible with 2-channel playback)

Ver. 7, 8: CBR 48—192 (kbps)
Ver. 9: CBR 48—320 (kbps)

471

5-5. Using an external device

Au
dio
sy
stem

●

File names
The only files that can be recognized as MP3/WMA and played are those
with the extension .mp3 or .wma.

●

ID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track
title, artist name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags.
(The number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.

●

MP3 and WMA playback
• When a device containing MP3 or WMA files is connected, all files in the

USB memory device are checked. Once the file check is finished, the first
MP3 or WMA file is played. To make the file check finish more quickly, we
recommend that you do not include any files other than MP3 or WMA
files or create any unnecessary folders.

• When the USB device is connected and the audio source is changed to

USB memory mode, the USB device will start playing the first file in the
first folder. If the same device is removed and reinserted (and the con-
tents have not been changed), the USB memory will resume play from
the same point in which it was last used.

●

Extensions
If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be skipped (not played).

472

5-5. Using an external device

●

Playback
• To play MP3 files with steady sound quality, we recommend a fixed bit

rate of at least 128 kbps and a sampling frequency of 44.1 kHz.

• There is a wide variety of freeware and other encoding software for MP3

and WMA files on the market, and depending on the status of the encod-
ing and the file format, poor sound quality or noise at the start of playback
may result. In some cases, playback may not be possible at all.

• Microsoft, Windows, and Windows Media are registered trademarks of

Microsoft Corporation in the U.S.A. and other countries.
This product is protected by certain intellectual property rights of
Microsoft. Use or distribution of such technology outside of this product is
prohibited without a license from Microsoft.

WARNING

■

While driving

Do not connect USB memory or operate the controls. Doing so may cause
an accident, resulting in death or serious injury.

NOTICE

■

To prevent damage to USB memory or its terminal

●

Do not leave USB memory in the vehicle. The temperature inside the vehi-
cle may become high.

●

Do not push down or apply unnecessary pressure to the USB memory
while it is connected.

●

Do not insert foreign objects into the port.

473

5-5. Using an external device

Au
dio
sy
stem

Using the AUX port



P. 444

■

Operating portable audio devices connected to the audio system

The volume can be adjusted using the vehicle’s audio controls. All other
adjustments must be made on the portable audio device itself.

■

When using a portable audio device connected to the power outlet

Noise may occur during playback. Use the power source of the portable
audio device.

This port can be used to connect a portable audio device and lis-
ten to it using the vehicle’s speakers. Press the “MODE” button
until “AUX” is displayed.

Connecting a portable player

474

5-6. Using Bluetooth

devices

Bluetooth

audio/phone



◆

Bluetooth

audio

The Bluetooth

audio system enables you to enjoy music played on

a portable digital audio player (portable player) from the vehicle
speakers via wireless communication.
This audio system supports Bluetooth

, a wireless data system

capable of playing portable audio music without cables. If your por-
table player does not support Bluetooth

, the Bluetooth

audio sys-

tem will not function.

◆

Bluetooth

phone (hands-free phone system)

This system supports Bluetooth

, which allows you to make or

receive calls without using cables to connect a cellular phone and
the system, and without operating the cellular phone.



: If equipped

The following can be performed using Bluetooth

wireless com-

munication:

475

5-6. Using Bluetooth

devices

Au
dio
sy
stem

Device registration/connection flow

1. Register the Bluetooth

device to be used with audio

system (



P. 480)

2. Connect the registered Bluetooth

device to be used

(



P. 481, 482)

5. Use Bluetooth

audio

(



P. 489)

5. Use Bluetooth

phone

(



P. 491)

3. Set automatic connection of the device

(



P. 483)

4. Check Bluetooth

connection condition

(



P. 476)

To be used for audio

To be used for hands-free phone

476

5-6. Using Bluetooth

devices

Power/volume knob
Press: Turning the audio sys-
tem on or off
Turn: Adjusting the volume
Bluetooth

connection condi-

tion

If “BT” is not displayed, the
Bluetooth

audio/phone cannot

be used.

Display
A message, name, number, etc. is displayed.
Lower-case characters and special characters may not be dis-
played.
Tune/scroll knob
Displays set up menu or selects items such as menu and number
Turn: Selects an item
Press: Displays set up menu or inputs the selected item
Selects speed dials (Bluetooth

phone operation)

On-hook switch
Turns the hands-free system off/ends a call/refuses a call
Off-hook switch
Turns the hands-free system on/starts a call
Press and hold: Displays information that is too long to be dis-
played at one time on the display (Bluetooth

audio operation)

Audio unit

Microphone

5
6

477

5-6. Using Bluetooth

devices

Au
dio
sy
stem

To enter a menu, press the tune/scroll knob and navigate menus by
using the knob.

: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Menu list of the Bluetooth

audio/phone

First menu

Second menu

Third menu

Operation details

“Bluetooth

”

“Pairing”

Registering a
Bluetooth

device

“List phone”

Listing the registered
cellular phones

“List audio”

Listing the registered
portable players

“Passkey”

Changing the pass-
key

“BT power”

Setting automatic
connection of the
device on or off

“Bluetooth

info”

“Device name”
“Device address”

Displaying the
device status

“Display setting”

Setting the auto-
matic connection
confirmation display
to on or off

“Reset”

Initializing the set-
tings

478

5-6. Using Bluetooth

devices

■

Bluetooth

audio/phone system functions

Depending on the Bluetooth

device, certain functions may not be available.

First menu

Second menu

Third menu

Operation details

“TEL”

“Phonebook”

“Add contacts”

Adding a new num-
ber

“Add SD”

Registering a speed
dial

“Delete call
history”

Deleting a number
stored in the call his-
tory

“Delete contacts”

Deleting a number
stored in the phone-
book

“Delete other PB”

Deleting a phone-
book’s data

“HF sound
setting”

“Call volume”

Setting call volume

“Ringtone
volume”

Setting ring tone vol-
ume

“Ringtone”

Setting the ring tone

“Transfer
history”

Transferring the call
histories

479

5-6. Using Bluetooth

devices

Au
dio
sy
stem

Using the steering wheel switches

Volume
The voice guidance volume
cannot be adjusted using this
button.
Off-hook switch
Turns the hands-free system
on/start a call
On-hook switch
Turns the hands-free system
off/ends a call/refuse a call

The steering wheel switches can be used to operate a connected
cellular phone, or portable digital audio player (portable player).

Operating Bluetooth

phone using the steering wheel switches

480

5-6. Using Bluetooth

devices

Registering a Bluetooth

device

Press the tune/scroll knob and select “Bluetooth

” using the knob.

Press the knob and select “Pairing” using the knob.
A passkey will be displayed.
SSP (Secure Simple Pairing) incompatible Bluetooth

devices:

Input the passkey into the device.
SSP (Secure Simple Pairing) compatible Bluetooth

devices:

Select “YES” to register the device. Depending on the type of
device, it may register automatically.

If a Bluetooth

device has both music player and cellular phone func-

tions, both functions will be registered at the same time. When delet-
ing the device, both functions will be deleted at the same time.
If the off-hook switch is pressed and the “TEL” mode is entered when
no phones have been registered, the registration screen will be auto-
matically displayed.

: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Before using the Bluetooth

audio/phone, it is necessary to reg-

ister a Bluetooth

device in the system. You can register up to 5

Bluetooth

devices.

How to register a Bluetooth

device

Content .. 27 28 29 30 ..
