Toyota Tundra Hybrid (2023 year). Manual in english

176

4-1. Before driving

WARNING

■

When taking a nap in the vehi-

cle

Always turn the hybrid system off.

Otherwise, if you accidentally

move the shift lever or depress

the accelerator pedal, this could

cause an accident or fire due to

hybrid system overheating. Addi-

tionally, if the vehicle is parked in

a poorly ventilated area, exhaust

gases may collect and enter the

vehicle, leading to death or a seri-

ous health hazard.

■

When braking

●

When the brakes are wet, drive

more cautiously.

Braking distance increases

when the brakes are wet, and

this may cause one side of the

vehicle to brake differently than

the other side. Also, the parking

brake may not securely hold the

vehicle.

●

If the electronically controlled

brake does not operate, do not

follow other vehicles closely and

avoid hills or sharp turns that

require braking.

In this case, braking is still pos-

sible, but the brake pedal

should be depressed more

firmly than usual. Also, the brak-

ing distance will increase. Have

your brakes fixed immediately.

●

The brake system consists of 2

or more individual hydraulic sys-

tems; if one of the systems fails,

the other will still operate. In this

case, the brake pedal should be

depressed more firmly than

usual and the braking distance

will increase. Have your brakes

fixed immediately.

■

If the vehicle becomes stuck

Do not spin the wheels exces-

sively when a driven wheel is up

in the air, or the vehicle is stuck in

sand, mud, etc. This may damage

the driveline components or pro-

pel the vehicle forward or back-

ward, causing an accident.

NOTICE

■

When driving the vehicle

●

Do not depress the accelerator

and brake pedals at the same

time during driving, as this may

restrain the hybrid system out-

put.

●

Do not use the accelerator

pedal or depress the accelera-

tor and brake pedals at the

same time to hold the vehicle on

a hill.

■

When parking the vehicle

Always set the parking brake and

shift the shift lever to P. Failure to

do so may cause the vehicle to

move or the vehicle may acceler-

ate suddenly if the accelerator

pedal is accidentally depressed.

■

Avoiding damage to vehicle

parts

●

Do not turn the steering wheel

fully in either direction and hold

it there for an extended period

of time.

Doing so may damage the

power steering motor.

●

When driving over bumps in the

road, drive as slowly as possible

to avoid damaging the wheels,

underside of the vehicle, etc.

177

4-1. Before driving

ing

When the following unusual
operation is performed with the
accelerator pedal depressed,
the hybrid system output may be
restrained.
• When the shift lever is shifted

to R

• When the shift lever is shifted

from P or R to forward drive
shift position such as D

When the system operates, a mes-
sage appears on the multi-informa-
tion display. Read the message and
follow the instruction.

: Depending on the situation, the

shift position may not be
changed.

■

Drive-Start Control (DSC)

When the TRAC is turned off

(



P.376), sudden start restraint

control also does not operate. If

your vehicle have trouble escaping

from the mud or fresh snow due to

sudden start restraint operation,

deactivate TRAC (



P.376) so that

the vehicle may become able to

escape from the mud or fresh snow.
Also, sudden start restraint control

will not operate in the following con-

ditions:

●

When the front-wheel drive control

switch is in “4H” or “4L” position.

(4WD models only)

●

When AUTO LSD mode, the drive

start control does not operate. (if

equipped)

●

When Multi-terrain Select is

selected. (if equipped)

NOTICE

■

If you get a flat tire while driv-

ing

A flat or damaged tire may cause

the following situations. Hold the

steering wheel firmly and gradu-

ally depress the brake pedal to

slow down the vehicle.

●

It may be difficult to control your

vehicle.

●

The vehicle will make abnormal

sounds or vibrations.

●

The vehicle will lean abnor-

mally.

Information on what to do in case

of a flat tire (



P.515)

■

When encountering flooded

roads

Do not drive on a road that has

flooded after heavy rain, etc.

Doing so may cause the following

serious damage to the vehicle:

●

Engine stalling

●

Short in electrical components

●

Engine damage caused by

water immersion

In the event that you drive on a

flooded road and the vehicle

becomes flooded or stuck in mud

or sand, be sure to have your Toy-

ota dealer check the following:

●

Brake function

●

Changes in quantity and quality

of oil and fluid used for the

engine, transmission, transfer

(4WD vehicles), differential, etc.

●

Lubricant condition for the pro-

peller shaft, bearings and sus-

pension joints (where possible),

and the function of all joints,

bearings, etc.

Sudden start restraint
control (Drive-Start Con-
trol [DSC])

178

4-1. Before driving

Cargo capacity depends on the
total weight of the occupants.
(Cargo capacity) = (Total load
capacity) — (Total weight of
occupants)
Steps for Determining Correct
Load Limit —
(1) Locate the statement “The
combined weight of occupants
and cargo should never exceed
XXX kg or XXX lbs.” on your
vehicle’s placard.
(2) Determine the combined
weight of the driver and passen-
gers that will be riding in your
vehicle.
(3) Subtract the combined
weight of the driver and passen-
gers from XXX kg or XXX lbs.
(4) The resulting figure equals
the available amount of cargo
and luggage load capacity.
For example, if the “XXX”
amount equals 1400 lbs. and
there will be five 150 lb passen-
gers in your vehicle, the amount
of available cargo and luggage
load capacity is 650 lbs. (1400 −

750 (5



150) = 650 lbs.)

(5) Determine the combined
weight of luggage and cargo
being loaded on the vehicle.
That weight may not safely
exceed the available cargo and
luggage load capacity calcu-
lated in Step 4.
(6) If your vehicle will be towing
a trailer, load from your trailer
will be transferred to your vehi-
cle. Consult this manual to
determine how this reduces the
available cargo and luggage
load capacity of your vehicle.
(



P.180)

Cargo capacity

Total load capacity (vehicle
capacity weight) (



P.541)

When 2 people with the com-
bined weight of A lb. (kg) are rid-
ing in your vehicle, which has a
total load capacity (vehicle
capacity weight) of B lb. (kg),
the available amount of cargo
and luggage load capacity will

Cargo and luggage

Take notice of the following
information about storage
precautions, cargo capacity
and load:

Capacity and distribution

Calculation formula for
your vehicle

179

4-1. Before driving

ing

be C lb. (kg) as follows:

lb. (kg) - A

lb. (kg) = C

lb.

(kg)

:A =Weight of people

:B =Total load capacity

:C =Available cargo and luggage

load

In this condition, if 3 more passen-
gers with the combined weight of D
lb. (kg) get on, the available cargo
and luggage load will be reduced E
lb. (kg) as follows:

C lb. (kg) - D

lb. (kg) = E

lb.

(kg)

:D =Additional weight of people

:E =Available cargo and luggage

load

As shown in the example above,
if the number of occupants
increases, the cargo and lug-
gage load will be reduced by an
amount that equals the
increased weight due to the
additional occupants. In other
words, if an increase in the num-
ber of occupants causes an
excess of the total load capacity
(combined weight of occupants
plus cargo and luggage load),
you must reduce the cargo and
luggage on your vehicle.

WARNING

■

Things that must not be car-

ried in the luggage compart-

ment

The following things may cause a

fire if loaded in the luggage com-

partment:

●

Receptacles containing gaso-

line

●

Aerosol cans

■

Storage precautions

Observe the following precau-

tions.

Failure to do so may prevent the

pedals from being depressed

properly, may block the driver’s

vision, or may result in items hit-

ting the driver or passengers, pos-

sibly causing an accident.

●

Do not stack anything behind

the front seats higher than the

seatbacks.

●

Do not place cargo or luggage

in or on the following locations.

• At the feet of the driver

• On the front passenger or rear

seats (when stacking items)

• On the instrument panel

• On the dashboard

• On the auxiliary box or tray that

has no lid

●

Secure all items in the occupant

compartment.

●

Never allow anyone to ride in

the rear deck. It is not designed

for passengers. They should

ride in their seats with their seat

belts properly fastened. Other-

wise, they are much more likely

to suffer death or serious bodily

injury, in the event of sudden

braking, sudden swerving or an

accident.

■

Capacity and distribution

●

Do not exceed the maximum

axle weight rating or the total

vehicle weight rating.

180

4-1. Before driving

WARNING

●

Even if the total load of occu-

pant’s weight and the cargo

load is less than the total load

capacity, do not apply the load

unevenly. Improper loading may

cause deterioration of steering

or braking control which may

cause death or serious injury.

Vehicle load limits

Vehicle load limits include
total load capacity, seating
capacity, TWR (Trailer
Weight Rating) and cargo
capacity.



Total load capacity (vehicle
capacity weight):



P.541

Total load capacity means the
combined weight of occu-
pants, cargo and luggage.



Seating capacity:



P.541

Seating capacity means the
maximum number of occu-
pants whose estimated aver-
age weight is 150 lb. (68 kg)
per person.
Even if the number of occu-
pants are within the seating
capacity, do not exceed the
total load capacity.



TWR (Trailer Weight Rat-
ing):



P.186

TWR means the maximum
gross trailer weight (trailer
weight plus its cargo weight)
that your vehicle is able to tow.



Cargo capacity

Cargo capacity may increase
or decrease depending on the
weight and the number of
occupants.

181

4-1. Before driving

ing

■

Total load capacity and seating

capacity

These details are also described on

the tire and loading information

label. (



P.547)

WARNING

■

Overloading the vehicle

Do not overload the vehicle.

It may not only cause damage to

the tires, but also degrade steer-

ing and braking ability, resulting in

an accident.

Trailer towing

Your vehicle is designed pri-
marily as a passenger-and-
load-carrying vehicle. Tow-
ing a trailer can have an
adverse impact on handling,
performance, braking, dura-
bility, and fuel consumption.
For your safety and the
safety of others, you must
not overload your vehicle or
trailer. You must also
ensure that you are using
appropriate towing equip-
ment, that the towing equip-
ment has been installed
correctly and used prop-
erly, and that you employ
the requisite driving habits.

Vehicle-trailer stability and
braking performance are
affected by trailer stability,
brake performance and set-
ting, trailer brakes, the hitch
and hitch systems.

To tow a trailer safely, use
extreme care and drive the
vehicle in accordance with
your trailer’s characteris-
tics and operating condi-
tions.

Toyota warranties do not
apply to damage or mal-
function caused by towing a
trailer for commercial pur-
poses.

182

4-1. Before driving

■

Trailer brake controller



P.380

■

Before towing

Check that the following conditions

are met:

●

Ensure that your vehicle’s tires

are properly inflated. (



P.547)

●

Trailer tires are inflated according

to the trailer manufacturer’s rec-

ommendation.

●

All trailer lights work as required

by law.

●

All lights work each time you con-

nect them.

●

The trailer ball is set at the proper

height for the coupler on the

trailer.

●

The trailer is level when it is

hitched. Do not drive if the trailer

is not level, and check for

improper tongue weight, overload-

ing, worn suspension, or other

possible causes.

●

The trailer cargo is securely

loaded.

●

The rear view mirrors conform to

all applicable federal, state/provin-

cial or local regulations. If they do

not, install rear view mirrors

appropriate for towing purposes.

Contact your Toyota dealer for
further information about addi-
tional requirements such as a
towing kit, etc.

WARNING

■

Trailer towing precautions

To tow a trailer safely, use

extreme care and drive the vehi-

cle in accordance with the trailer’s

characteristics and operating con-

ditions. Failure to do so could

cause an accident resulting in

death or serious injury. Vehicle

stability and braking performance

are affected by trailer stability,

brake setting and performance,

and the hitch. Your vehicle will

handle differently when towing a

trailer.

■

To avoid accident or injury

●

Do not exceed the TWR,

unbraked TWR, GCWR, GVWR

or GAWR.

●

If the gross trailer weight is over

2000 lb. (900 kg), a sway con-

trol device with sufficient capac-

ity is required.

●

If the gross trailer weight is over

5000 lb. (2200 kg), a weight dis-

tributing hitch with sufficient

capacity is required.

●

Adjust the tongue weight within

the appropriate range. Place

heavier loads as close to the

trailer axle as possible.

●

Do not exceed 65 mph (104

km/h), the posted towing speed

limit or the speed limit for your

trailer as set forth in your trailer

owner’s manual, whichever is

lowest. Slow down sufficiently

before making a turn, in cross

winds, on wet or slippery sur-

face, etc., to help avoid an acci-

dent. If you experience a

vehicle-trailer instability from

reducing a certain speed, slow

down and make sure you keep

your vehicle speed under the

speed of which you experience

the instability.

183

4-1. Before driving

ing

WARNING

●

Do not make jerky, abrupt or

sharp turns.

●

Do not apply the brakes sud-

denly as you may skid, resulting

in jackknifing and loss of vehicle

control. This is especially true

on wet or slippery surfaces.

●

Do not exceed the trailer hitch

assembly weight, gross vehicle

weight, gross axle weight and

trailer tongue weight capacities.

●

Do not use the following sys-

tems when your vehicles is tow-

ing a trailer or another vehicle.

• PCS (Pre-Collision System)

• Dynamic radar cruise control

with full-speed range

Except when the following condi-

tions are all met,

• When the other vehicle is a

trailer properly attached and

connected to Toyota’s official

TBC ECU.

• When the vehicle is not being

driven on a slippery surface

such as an icy road or a very

wet road.

●

Do not use the following sys-

tems when your vehicles is tow-

ing a trailer or another vehicle.

• Cruise control (if equipped)

• LTA (Lane Tracing Assist)

If the vehicle detects that a trailer

is being towed, the lane centering

function of LTA is automatically

turned off.

●

Slow down and downshift

before descending steep or long

downhill grades. Do not make

sudden downshifts while

descending steep or long down-

hill grades.

●

Vehicle-trailer instability is more

likely on steep long downhills.

Before descending steep or

long downhill grades, slow

down and downshift. Do not

make sudden downshifts when

descending steep or long down-

hill grades. Avoid holding the

brake pedal down too long or

applying the brakes too fre-

quently. This could cause the

brakes to overheat and result in

reduced braking efficiency.

●

Do not tow a trailer when the

temporary spare tire is installed

on your vehicle.

■

When towing a trailer

Toyota recommends trailers with

brakes that conform to any appli-

cable federal and state/provincial

regulations.

●

If the gross trailer weight

exceeds unbraked TWR, trailer

brakes are required. Toyota rec-

ommends trailers with brakes

that conform to all applicable

federal and state/provincial reg-

ulations.

●

Never tap into your vehicle’s

hydraulic system, as this will

lower the vehicle’s braking

effectiveness.

●

Never tow a trailer without using

a safety chain securely attached

to both the trailer and the vehi-

cle. If damage occurs to the

coupling unit or hitch ball, there

is danger of the trailer wander-

ing into another lane.

184

4-1. Before driving

■

GCWR (Gross Combination
Weight Rating)

The maximum allowable gross
combination weight. The gross
combination weight is the sum
of the total vehicle weight
(including the occupants, cargo
and any optional equipment
installed on the vehicle) and the
weight of the trailer being towed
(including the cargo in the
trailer).

■

GVWR (Gross Vehicle
Weight Rating)

The maximum allowable gross
vehicle weight. The gross vehi-
cle weight is the total weight of
the vehicle. When towing a
trailer, it is the sum of the vehicle
weight (including the occu-
pants, cargo and any optional
equipment installed on the vehi-
cle) and the tongue weight.

■

GAWR (Gross Axle Weight
Rating)

The maximum allowable gross
axle weight. The gross axle
weight is the load placed on
each axle (front and rear).

Front GAWR

Rear GAWR

■

TWR (Trailer Weight Rating)

The maximum allowable gross
trailer weight. The gross trailer
weight is the sum of the trailer
weight and the weight of the
cargo in the trailer.
TWR is calculated assuming
base vehicle with one driver,
one front passenger, towing

Towing related terms

185

4-1. Before driving

ing

package (if available), hitch and
hitch systems (if required).

Additional optional equipment, pas-
sengers and cargo in the vehicle
will reduce the trailer weight rating
so as not to exceed GCWR, GVWR
and GAWR.
If the gross trailer weight exceeds
3000 lb. (1360 kg), it is recom-
mended to use a trailer with 2 or
more axles.

With brakes

■

Unbraked TWR (Unbraked
Trailer Weight Rating)

The trailer weight rating for tow-
ing a trailer without a trailer ser-
vice brake system.

Without brakes

■

Tongue Weight

The load placed on the trailer
hitch ball. (



P.187)

■

Kingpin Weight

The load placed on the 5th
wheel mount or the gooseneck
ball. (



P.187)



The gross trailer weight must
never exceed the TWR
described in the table.
(



P.186)



The gross combination weight
must never exceed the
GCWR described in the table.
(



P.186)



The gross vehicle weight
must never exceed the
GVWR indicated on the Certi-
fication Label. (



P.541)



The gross axle weight on
each axle must never exceed
the GAWR indicated on the

Weight limits

186

4-1. Before driving

Certification Label. (



P.541)



If the gross trailer weight is
over the unbraked TWR,
trailer service brakes are
required.



If the gross trailer weight is
over 2000 lb. (907 kg), a sway

control device with sufficient
capacity is required.



If the gross trailer weight is
over 5000 lb. (2268 kg), a
weight distributing hitch with
sufficient capacity is required.

Confirm that the gross trailer weight, gross combination weight,
gross vehicle weight, gross axle weight and tongue weight are all
within the limits.

■

GCWR

and TWR

:The model code is indicated on the Certification Label. (



P.541)

■

Unbraked TWR

1000 lb. (453 kg)

: These models meet the tow-vehicle trailering requirement of SAE Interna-

tional per SAE J2807.

GCWR, TWR, Unbraked TWR, Fifth wheel and Goose-
neck towing TWR

Model code

GCWR

TWR

VXKH70L-PSVLZA

17770 lb. (8030 kg)

11450 lb. (5190 kg)

VXKH70L-PSVZZA

17770 lb. (8030 kg)

11380 lb. (5160 kg)

VXKH71L-PRVLZA

17770 lb. (8030 kg)

11350 lb. (5145 kg)

VXKH71L-PRVZZA

17770 lb. (8030 kg)

11290 lb. (5120 kg)

VXKH75L-PSVLZA

17770 lb. (8030 kg)

11170 lb. (5065 kg)

VXKH75L-PSVUZA

17000 lb. (7710 kg)

10340 lb. (4690 kg)

VXKH75L-PSVZZA

17600 lb. (7980 kg)

11020 lb. (4995 kg)

VXKH76L-PRVLZA

17770 lb. (8030 kg)

11040 lb. (5005 kg)

VXKH76L-PRVZZA

17770 lb. (8030 kg)

10960 lb. (4970 kg)

187

4-1. Before driving

ing



A recommended tongue
weight or kingpin weight var-
ies in accordance with the
types of trailers or towing as
described below.



To ensure the recommended
values shown below, the
trailer must be loaded by
referring to the following
instructions.

1.Conventional Towing
The gross trailer weight should
be distributed so that the tongue
weight is 9% to 11%. (Tongue
Weight/Gross trailer weight x
100 = 9% to 11%)

Gross trailer weight

Tongue Weight

If using a weight distributing hitch
when towing, return the front axle to
the same weight as before the
trailer connection.
If front axle weight cannot be mea-
sured directly, measure the front
fender height above the front axle
before connection. Adjust weight
distributing hitch torque until front

fender is returned to the same
height as before connection.
Do not reduce front fender height
below original measurement.
The gross trailer weight, gross axle
weight and tongue weight can be
measured with platform scales
found at a highway weighing sta-
tion, building supply company,
trucking company, junk yard, etc.

2.Fifth wheel Towing or Goose-
neck Towing
The gross trailer weight should
be distributed so that the kingpin
weight is 14% to 16%. (Kingpin
weight/Gross trailer weight x
100 = 14% to 16%)

Gross trailer weight

Kingpin weight

The gross trailer weight and kingpin
weight can be measured with plat-
form scales found at a highway
weighing station, building supply
company, trucking company, junk
yard, etc.
Current fifth wheel trailer designs
are not compatible with short bed.

Trailer Tongue Weight and
Trailer Kingpin Weight

188

4-1. Before driving

Trailer hitch assemblies have
different weight capacities. Toy-
ota recommends the use of Toy-
ota hitch/bracket for your
vehicle. For details, contact your
Toyota dealer.



If you wish to install a trailer
hitch, contact your Toyota
dealer.



Use only a hitch that con-
forms to the gross trailer
weight requirement of your
vehicle.



Follow the directions supplied
by the hitch manufacturer.



Lubricate the hitch ball and
kingpin with a light coating of
grease.



Remove the hitch ball when-
ever you are not towing a
trailer. Remove the trailer
hitch if you do not need it.
After removing the hitch, seal

any mounting holes in the
vehicle body to prevent entry
of any substances into the
vehicle.

Use the correct trailer ball for
your application.

NOTICE

■

When towing a fifth wheel

trailer

Be careful not to hit the cabin or

bed with the trailer while making a

sharp turn.

Hitch

WARNING

■

Hitch

Trailer hitch assemblies have dif-

ferent weight capacities estab-

lished by the hitch manufacturer.

Even though the vehicle may be

physically capable of towing a

higher weight, the operator must

determine the maximum weight

rating of the particular hitch

assembly and never exceed the

maximum weight rating specified

for the trailer-hitch. Exceeding the

maximum weight rating set by the

trailer-hitch manufacturer can

cause an accident resulting in

death or serious personal injuries.

NOTICE

■

When installing a trailer hitch

Use only the position recom-

mended by your Toyota dealer.

Do not install the trailer hitch on

the bumper; this may cause body

damage.

Selecting trailer ball

189

4-1. Before driving

ing

Trailer ball load rating

Matches or exceeds the gross
trailer weight rating of the trailer.

Shank length

Protrudes beyond the bottom of the
lock washer and nut at least 2
threads.

Shank diameter

Matches the ball mount hole diame-
ter size.

Ball diameter

Matches the size of the trailer cou-
pler. Most couplers are stamped
with the required trailer ball size.

Weight carrying ball position:
58.3 in. (1481 mm)

Hitch receiver pin hole posi-
tion: 46.4 in. (1178.9 mm)

■

Matching trailer ball height to

trailer coupler height

No matter which class of tow hitch

applies, for a more safer trailer

hookup, the trailer ball setup must

be the proper height for the coupler

on the trailer.

Coupler

Trailer ball

Use the wire harness located in
the rear end of the vehicle.
The tow lighting system is
designed for 64 watts/5 amps of
electrical current per side (right
and left) for the trailer brake/turn
light functions.
Please contact your Toyota
dealer with any questions or
concerns.

Trailer class

Typical trailer

ball size

2 5/16 in.

II and III

2 in.

1 7/8 in.

Positions for towing hitch
receiver

Connecting trailer lights

190

4-1. Before driving

■

Auto current cut-off function

In case of over current, the auto cut-

off function stops the power flowing

to the trailer lights to prevent dam-

age to the vehicle’s electrical sys-

tem.
This function is activated when the

rated current of any of the following

trailer light circuit components is

exceeded:

●

Stop/turn signal light (right): maxi-

mum 5 A

●

Stop/turn signal light (left): maxi-

mum 5 A

■

When the auto current cut func-

tion is activated

If a trailer light does not come on

due to the activation of the auto cur-

rent cut function, the light system

will need to be reset.
Follow the reset procedure shown

below.

●

If a tail light does not come on,

turn off the headlight switch.

●

If the right-side stop/turn signal

light does not come on, put the

turn signal in the off position or

remove foot from the brake pedal.

●

If the left-side stop/turn signal light

does not come on, put the turn

signal in the off position or remove

foot from the brake pedal.

If the emergency flashers do not

operate, press the emergency

flasher switch to turn them off.
After the light system is reset, oper-

ate the light switches again to see if

the lights operate normally.
If the lights do not operate normally,

have the vehicle inspected by your

Toyota dealer.

■

Trailer lights operation check

function

Use the meter control switches to

start the function. (



P.96)

Press

to select

Press

to select “Trailer

Light Check”, and then press

Press

to start the trailer light

check.

The light check operates in the cycle

of Brake lights



Left turn lights



Right turn lights.

■

The trailer light check is opera-

tional when

The trailer light check operates

when all of the following conditions

are met:

●

The vehicle is stopped.

●

The shift lever is shifted to P.

If a height control system is
installed in your vehicle, you
have to connect and disconnect

NOTICE

■

Do not directly splice trailer

lights

Do not directly splice trailer lights.

Directly splicing trailer lights may

damage your vehicle’s electrical

system and cause a malfunction.

Connecting and discon-
necting a trailer (vehicles
with electronically modu-
lated air suspension)

191

4-1. Before driving

ing

your trailer more carefully.



Connecting

Set the height control of elec-
tronically modulated air sus-
pension system to “N” mode.

Turn off the hybrid system, or
set the electronically modu-
lated air suspension system
to manual mode. (



P.355)

Connect the trailer.

Restart the hybrid system.

Press the height control
mode select switch to cancel
the manual mode condition
that was set on step

Check that the “MAN.” indica-
tor turns off. Set the height
control of electronically mod-
ulated air suspension sys-
tem to “N” mode.



Disconnecting

Set the height control of elec-
tronically modulated air sus-
pension system to “N” mode.

Set the electronically modu-
lated air suspension system
to manual mode.

Turn off the hybrid system.

Set the supporting leg of the
trailer on the ground and
raise the hitch by 4 in. (100
mm).

Restart the hybrid system.

Press the height control
mode select switch to cancel
the manual mode condition

that was set on step

Check that the “MAN.” indica-
tor turns off.

Wait until vehicle height is
stabilized.

Make sure the hitch is dis-
connected. If the hitch does
not disconnect, raise the
hitch higher and repeat steps

through

. Move the vehi-

cle forward in “LO” mode
where the hitch does not
touch anything in “N” mode.
Set the height control of elec-
tronically modulated air sus-
pension system to “N” mode.

Your vehicle will handle differ-
ently when towing a trailer. To
help avoid an accident, death or
serious injury, keep the following
in mind when towing:



Speed limits for towing a
trailer vary by state or prov-
ince. Do not exceed the
posted towing speed limit.



Toyota recommends that the
vehicle-trailer speed limit is 65
mph (104 km/h) on a flat,
straight, dry road. Do not
exceed this limit, the posted
towing speed limit or the
speed limit for your trailer as
set forth in your trailer owner’s
manual, whichever is lowest.
Instability of the towing vehi-
cle-trailer combination (trailer

Trailer towing tips

Toyota Tundra Hybrid (2023 year). Manual in english - page 11
