3-5. Opening, closing the windows and moon roof

3-5.Opening, closing the windows and moon roof

The power windows can be
opened and closed using the
switches.
Operating the switch moves the
windows as follows:

Closing

One-touch closing

Opening

One-touch opening

: To stop the window partway,

operate the switch in the opposite
direction.

■

The power windows can be

operated when

The power switch is in ON

■

Operating the power windows

after turning the hybrid system

off

The power windows can be oper-

ated for approximately 45 seconds

even after the power switch is

turned to ACC or turned off. They

cannot, however, be operated once

either front door is opened.

■

Jam protection function

If an object becomes jammed

between the window and the win-

dow frame while the window is clos-

ing, window movement is stopped

and the window is opened slightly.

■

Catch protection function

If an object becomes caught

between the door and window while

the window is opening, window

movement is stopped.

■

When the side window cannot

be opened or closed

When the jam protection function or

catch protection function operates

unusually and the side window can-

not be opened or closed, perform

the following operations with the

power window switch of that door.

●

Stop the vehicle. With the power

switch in ON, within 4 seconds of

the jam protection function or

catch protection function activat-

ing, continuously operate the

power window switch in the one-

touch closing direction or one-

touch opening direction so that the

side window can be opened and

closed.

●

If the side window cannot be

opened and closed even when

performing the above operations,

perform the following procedure

for function initialization.

Turn the power switch to ON.

Pull and hold the power window

switch in the one-touch closing

direction and completely close

the side window.

Release the power window

switch for a moment, resume

pulling the switch in the one-

touch closing direction, and hold

it there for approximately 6 sec-

onds or more.

Press and hold the power win-

dow switch in the one-touch

opening direction. After the side

window is completely opened,

continue holding the switch for

an additional 1 second or more.

Power windows

Opening and closing the
power windows

161

3-5. Opening, closing the windows and moon roof

Before

driving

Release the power window

switch for a moment, resume

pushing the switch in the one-

touch opening direction, and

hold it there for approximately 4

seconds or more.

Pull and hold the power window

switch in the one-touch closing

direction again. After the side

window is completely closed,

continue holding the switch for a

further 1 second or more.

If you release the switch while the

window is moving, start again from

the beginning.

If the window reverses and cannot

be fully closed or opened, have the

vehicle inspected by your Toyota

dealer.

■

Door lock linked window opera-

tion

●

The power windows can be

opened and closed using the
mechanical key.

(



P.528)

●

The power windows can be

opened using the wireless remote
control.

(



P.113)

: These settings must be custom-

ized at your Toyota dealer.

■

Power windows open warning

buzzer

A buzzer sounds and a message is

shown on the multi-information dis-

play in the instrument cluster when

the power switch is turned off and

the driver’s door is opened with the

power windows open.

■

Customization

Some functions can be customized.

(



P.561)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Closing the windows

●

The driver is responsible for all

the power window operations,

including the operation for the

passengers. In order to prevent

accidental operation, especially

by a child, do not let a child

operate the power windows. It is

possible for children and other

passengers to have body parts

caught in the power window.

Also, when riding with a child, it

is recommended to use the win-

dow lock switch. (



P.162)

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when a window

is being operated.

●

When using the wireless remote

control or mechanical key and

operating the power windows,

operate the power window after

checking to make sure that

there is no possibility of any

passenger having any of their

body parts caught in the win-

dow. Also do not let a child

operate window by the wireless

remote control or mechanical

key. It is possible for children

and other passengers to get

caught in the power window.

●

When exiting the vehicle, turn

the power switch off, carry the

key and exit the vehicle along

with the child. There may be

accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

162

3-5. Opening, closing the windows and moon roof

This function can be used to
prevent children from acciden-
tally opening or closing a pas-
senger window.
Press the switch.

The indicator

will come on and

the passenger windows will be
locked.
The passenger windows can still be
opened and closed using the
driver’s switch even if the lock
switch is on.

■

The power windows can be

operated when

The power switch is in ON.

■

When the 12-volt battery is dis-

connected

The window lock switch is disabled.

If necessary, press the window lock

switch after reconnecting the 12-volt

battery.

WARNING

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

●

The jam protection function may

not work if something gets

jammed just before the window

is fully closed. Be careful not to

get any part of your body

jammed in the window.

■

Catch protection function

●

Never use any part of your body

or clothing to intentionally acti-

vate the catch protection func-

tion.

●

The catch protection function

may not work if something gets

caught just before the window is

fully opened. Be careful not to

get any part of your body or

clothing caught in the window.

Preventing accidental
operation (window lock
switch)

163

3-5. Opening, closing the windows and moon roof

Before

driving

Opening

Closing

■

The power back window can be

operated when

The power switch is in ON.

■

Operating the power back win-

dows after turning the hybrid

system off

The power back windows can be

operated for approximately 43 sec-

onds after the power switch is

turned to ACC or off. They cannot,

however, be operated once either

front door is opened.

Power back window

WARNING

■

Caution while driving

Keep the back window closed.
This not only keeps personal

belongings from being thrown out,

but also prevents exhaust gases

from entering the vehicle.

Opening and closing the
power back windows

WARNING

■

Closing the back window

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

●

The driver is responsible for all

the power back window opera-

tions, including the operation for

the passengers. In order to pre-

vent accidental operation, espe-

cially by a child, do not let a

child operate the power back

window. It is possible for chil-

dren and other passengers to

have body parts caught in the

power back window.

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when a window

is being operated.

●

When exiting the vehicle, turn

the power switch off, carry the

key and exit the vehicle along

with the child. There may be

accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

164

3-5. Opening, closing the windows and moon roof

: If equipped

■

Opening and closing the
electronic sunshade

Opens the electronic sun-
shade

Slide and hold the

switch back-

ward momentary and the sunshade
will automatically open. The elec-
tronic sunshade will fully open auto-
matically.

Closes the electronic sun-
shade

Slide and hold the

switch for-

ward. The electronic sunshade will
fully close automatically.
If the panoramic moon roof is not
fully closed, it will close fully before
the electronic sunshade closes.

: Quickly slide and release the

switch in either direction to stop
the electronic sunshade partway.

■

Tilting the panoramic moon
roof up and down

Press the

switch to tilt the

panoramic moon roof up.

When the panoramic moon roof is
tilted up, the electronic sunshade
will open to the half-open position
of the roof.

: Lightly press the

switch again

to stop the panoramic moon roof
partway.

Press and hold the

switch to

tilt the panoramic moon roof
down.

The panoramic moon roof can be
tilted down only when it is in the til-
tup position.

■

Opening and closing the
panoramic moon roof

Opens the panoramic moon
roof

Slide and hold the

switch back-

ward. The panoramic moon roof
and electronic sunshade will open

Panoramic moon roof

Use the overhead switches
to operate the panoramic
moon roof and electronic
sunshade.

Operating the electronic
sunshade and panoramic
moon roof

165

3-5. Opening, closing the windows and moon roof

Before

driving

automatically.
The panoramic moon roof can be
opened from the tilt-up position.

: Quickly slide and release the

switch in either direction to stop
the panoramic moon roof part-
way.

Closes the panoramic moon
roof

Slide and hold the

switch for-

ward. The panoramic moon roof will
fully close automatically.

■

The panoramic moon roof can

be operated when

The power switch is in ON.

■

Operating the panoramic moon

roof after turning the hybrid

system off

The panoramic moon roof and elec-

tronic sunshade can be operated for

approximately 45 seconds after the

power switch is turned to ACC or

OFF. They cannot, however, be

operated once either front door is

opened.

■

Jam protection function

If an object is detected between the

panoramic moon roof and the frame

in the following situations, travel is

stopped and the panoramic moon

roof opens slightly.

●

The panoramic moon roof is clos-

ing or tilting down.

●

The electronic sunshade is clos-

ing.

■

Closing both the panoramic

moon roof and electronic sun-

shade

Slide the

switch forward.

The electronic sunshade will close

to the half-open position and pause.

The panoramic moon roof will then

fully close. Then the electronic sun-

shade will fully close.

■

Door lock linked panoramic

moon roof operation

●

The panoramic moon roof can be

opened and closed using the
mechanical key.

(



P.528)

●

The panoramic moon roof can be

opened using the wireless remote
control.

(



P.111)

●

The alarm may be triggered if the

alarm is set and the panoramic

moon roof is closed using the door

lock linked panoramic moon roof

operation function. (



P.82)

: These settings must be custom-

ized at your Toyota dealer.

■

When the panoramic moon roof

does not close normally

Perform the following procedure:

Stop the vehicle.

Operate the

switch forward

to close the panoramic moon
roof.

166

3-5. Opening, closing the windows and moon roof

Slide the

switch forward and

hold it for 15 seconds. After
about 10 seconds the glass
should move forward toward the
hard stops and stall, then
reverse to close position.

Within 5 seconds, Slide and hold
the

switch forward again.

The sunshade will go to fully
open position and stop. The
moon roof will then follow, to fully
open then close. The sunshade
will then close.

If the panoramic moon roof does not
fully close even after performing the
above procedure correctly, have the
vehicle inspected by your Toyota
dealer.

■

Panoramic moon roof open

reminder function

A buzzer sounds and a message is

shown on the multi-information dis-

play when the power switch is

turned to OFF and the driver’s door

is opened with the panoramic moon

roof open.

■

Customization

Some functions can be customized.

(



P.561)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Opening and closing the elec-

tronic sunshade

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when the elec-

tronic sunshade is being oper-

ated.

●

Do not let a child operate the

electronic sunshade. Closing

the electronic sunshade on

someone can cause death or

serious injury.

■

Opening the panoramic moon

roof

●

Do not allow any passengers to

put their hands or head outside

the vehicle while it is moving.

●

Do not sit on top of the pan-

oramic moon roof.

■

Opening and closing the pan-

oramic moon roof

●

The driver is responsible for

panoramic moon roof opening

and closing operations.

In order to prevent accidental

operation, especially by a child,

do not let a child operate the

panoramic moon roof. It is pos-

sible for children and other pas-

sengers to have body parts

caught in the panoramic moon

roof.

167

3-5. Opening, closing the windows and moon roof

Before

driving

WARNING

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when the pan-

oramic moon roof is being oper-

ated.

●

When using the wireless remote

control or mechanical key and

operating the panoramic moon

roof, operate the panoramic

moon roof after checking to

make sure that there is no pos-

sibility of any passenger having

any of their body parts caught in

the panoramic moon roof. Also,

do not let a child operate pan-

oramic moon roof by the wire-

less remote control or

mechanical key. It is possible for

children and other passengers

to get caught in the panoramic

moon roof.

●

When exiting the vehicle, turn

the power switch to OFF, carry

the key and exit the vehicle

along with the child. There may

be accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

●

The jam protection function may

not work if something gets

caught just before the pan-

oramic moon roof or electronic

sunshade is fully closed. Also,

the jam protection function is

not designed to operate while

the switch is being pressed.

Take care so that your fingers,

etc. do not get caught.

■

To prevent burns or injuries

Do not touch the area between

the underside of the panoramic

moon roof and the electronic sun-

shade. Your hand may get caught

and you could injure yourself.

Also, if the vehicle is left in direct

sunlight for a long time, the under-

side of the panoramic moon roof

could become very hot and could

cause burns.

NOTICE

■

To prevent damage to the

panoramic moon roof

●

Before opening the panoramic

moon roof, make sure that there

are no foreign objects, such as

stones or ice, around the open-

ing.

●

Do not hit the surface or edge of

the panoramic moon roof with

hard objects.

●

The panoramic moon roof

opens outside the vehicle,

thereby increasing the height of

the vehicle. Please use caution

when opening or driving with the

panoramic moon roof open

(pulling into low garages, etc.)

169

ing

Driving

4-1. Before driving

Driving the vehicle.......

171

Cargo and luggage .....

178

Vehicle load limits .......

180

Trailer towing...............

181

Dinghy towing .............

194

4-2. Driving procedures

Power (ignition) switch

195

Automatic transmission

200

Turn signal lever..........

204

Parking brake..............

205

Brake Hold ..................

208

4-3. Operating the lights and

wipers

Headlight switch..........

211

Fog light switch ...........

214

AHB (Automatic High

Beam)........................

214

Light bar ......................

218

Windshield wipers and

washer.......................

218

4-4. Refueling

Opening the fuel tank cap

..................................

222

4-5. Using the driving support

systems

Toyota Safety Sense 2.5

..................................

225

PCS (Pre-Collision System)

..................................

230

LTA (Lane Tracing Assist)

..................................

242

RSA (Road Sign Assist)

..................................

253

Dynamic radar cruise con-

trol with full-speed range

..................................

256

BSM (Blind Spot Monitor)

..................................

267

Intuitive parking assist.

274

RCTA (Rear Cross Traffic

Alert)..........................

281

PKSB (Parking Support

Brake)........................

287

Parking Support Brake func-

tion (static objects) ....

292

Parking Support Brake func-

tion (rear-crossing vehi-
cles)...........................

295

Toyota parking assist moni-

tor ..............................

297

Panoramic view monitor

..................................

310

Multi-terrain Monitor ....

344

Electronically modulated air

suspension ................

355

170

Driving mode select switch

..................................

358

Four-wheel drive system

..................................

361

AUTO LSD system......

363

Rear differential lock system

..................................

364

Crawl Control ..............

365

Multi-terrain Select ......

369

Downhill assist control sys-

tem ............................

372

Driving assist systems

374

Trailer brake controller

380

Trailer Backup Guide ..

383

Active front spoiler ......

388

4-6. Driving tips

Hybrid Electric Vehicle driv-

ing tips.......................

390

Off-road precautions ...

392

Winter driving tips .......

395

171

4-1. Before driving

ing

4-1.Before driving

■

Starting the hybrid system



P.195

■

Driving

With the brake pedal
depressed, shift the shift
lever to D.

If the parking brake is set,
release the parking brake.
(



P.205)

If the parking brake is in automatic

mode, the parking brake is release

automatically when shifting the shift

lever to any position other than P.

(



P.206)

Gradually release the brake
pedal and gently depress the
accelerator pedal to acceler-
ate the vehicle.

■

Stopping

With the shift lever in D,
depress the brake pedal.

If necessary, set the parking
brake.

If the vehicle is to be stopped for an

extended period of time, shift the

shift lever to P. (



P.200)

■

Parking the vehicle

With the shift lever in D,
depress the brake pedal to
stop the vehicle completely.

Set the parking brake
(



P.205), and shift the shift

lever to P. (



P.200)

Check the parking brake indicator

is illuminated.

Turn the power switch to OFF
to stop the hybrid system.

Lock the door, making sure
that you have the electronic
key on your person.

If parking on a hill, block the wheels

as needed.

■

Starting off on a steep
uphill

With the brake pedal
depressed, shift the shift
lever to D.

The hill-start assist control will be

activated.

Pull the parking brake switch
and parking brake is set man-
ually. (



P.205)

Release the brake pedal and
gently depress the accelera-
tor pedal to accelerate the
vehicle.

Press the parking brake
switch and parking brake is
released manually. (



P.205)

Parking brake automatic release

function. (



P.207)

■

For fuel-efficient driving

Keep in mind that Hybrid Electric

Vehicle are similar to conventional

vehicles, and it is necessary to

refrain from activities such as sud-

den acceleration. (



P.390)

■

Driving in the rain

●

Drive carefully when it is raining,

Driving the vehicle

The following procedures
should be observed to
ensure safe driving:

Driving procedure

172

4-1. Before driving

because visibility will be reduced,

the windows may become fogged-

up, and the road will be slippery.

●

Drive carefully when it starts to

rain, because the road surface will

be especially slippery.

●

Refrain from high speeds when

driving on an expressway in the

rain, because there may be a

layer of water between the tires

and the road surface, preventing

the steering and brakes from

operating properly.

■

Engine speed while driving

In the following conditions, the

engine speed may become high

while driving.
This is due to automatic up-shifting

control or down-shifting implementa-

tion to meet driving conditions. It

does not indicate sudden accelera-

tion.

●

The vehicle is judged to be driving

uphill or downhill

●

When the accelerator pedal is

released

●

When the brake pedal is

depressed while “TOW HAUL”

mode or “TOW+” mode is selected

■

Restraining the hybrid system

output (Brake Override System)

●

When the accelerator and brake

pedals are depressed at the same

time, the hybrid system output

may be restrained.

●

A warning message is displayed

on the multi-information display

while the system is operating.

■

Breaking in your new Toyota

To extend the life of the vehicle,

observing the following precautions

is recommended:

●

For the first 200 miles (300 km):

Avoid sudden stops.

●

For the first 500 miles (800 km):

Do not tow a trailer.

●

For the first 1000 miles (1600 km):

• Do not drive at extremely high

speeds.

• Avoid sudden acceleration.

• Do not drive continuously in low

gears.

• Do not drive at a constant speed

for extended periods.

■

Operating your vehicle in a for-

eign country

Comply with the relevant vehicle

registration laws and confirm the

availability of the correct fuel.

(



P.542)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

When starting the vehicle

Always keep your foot on the

brake pedal while stopped with

the “READY” indicator is illumi-

nated. This prevents the vehicle

from creeping.

■

When driving the vehicle

●

Do not drive if you are unfamil-

iar with the location of the brake

and accelerator pedals to avoid

depressing the wrong pedal.

• Accidentally depressing the

accelerator pedal instead of the

brake pedal will result in sudden

acceleration that may lead to an

accident.

• When backing up, you may twist

your body around, leading to dif-

ficulty in operating the pedals.

Make sure to operate the pedals

properly.

• Make sure to keep a correct

driving posture even when mov-

ing the vehicle only slightly. This

allows you to depress the brake

and accelerator pedals properly.

173

4-1. Before driving

ing

WARNING

• Depress the brake pedal using

your right foot. Depressing the

brake pedal using your left foot

may delay response in an emer-

gency, resulting in an accident.

●

The driver should pay extra

attention to pedestrians when

the vehicle is powered only by

the electric motor (traction

motor). As there is no engine

noise, the pedestrians may mis-

judge the vehicle’s movement.

Even though the vehicle is

equipped with the acoustic vehi-

cle alerting system, drive with

care as pedestrians in the vicin-

ity may still not notice the vehi-

cle if the surrounding area is

noisy.

●

Do not drive the vehicle over or

stop the vehicle near flammable

materials.

The exhaust system and

exhaust gases can be

extremely hot. These hot parts

may cause a fire if there is any

flammable material nearby.

●

During normal driving, do not

turn off the hybrid system. Turn-

ing the hybrid system off while

driving will not cause loss of

steering or braking control, how-

ever, power assist to the steer-

ing will be lost. This will make it

more difficult to steer smoothly,

so you should pull over and stop

the vehicle as soon as it is safe

to do so.

In the event of an emergency,

such as if it becomes impossible

to stop the vehicle in the normal

way:



P.494

●

Use engine braking (downshift)

to maintain a safe speed when

driving down a steep hill.

Using the brakes continuously

may cause the brakes to over-

heat and lose effectiveness.

(



P.200)

●

Do not adjust the positions of

the steering wheel, the seat, or

the inside or outside rear view

mirrors while driving.

Doing so may result in a loss of

vehicle control.

●

Always check that all passen-

gers’ arms, heads or other parts

of their body are not outside the

vehicle.

●

Do not drive in excess of the

speed limit. Even if the legal

speed limit permits it, do not

drive over 85 mph (140 km/h)

unless your vehicle has high-

speed capability tires. Driving

over 85 mph (140 km/h) may

result in tire failure, loss of con-

trol and possible injury. Be sure

to consult a tire dealer to deter-

mine whether the tires on your

vehicle are high-speed capabil-

ity tires or not before driving at

such speeds.

●

On vehicles with electronically

modulated air suspension, if

you drive through deep water

over about 20 in. (500 mm) in

depth, put the vehicle height in

the “HI” mode using the height

control switch and then change

to manual mode by pushing the

height control mode select

switch. Drive your vehicle at 18

mph (30 km/h) or less. Do not

stop in the water to prevent

water from entering within the

vehicle. Do not drive through

water deeper than about 28 in.

(700 mm) even if the vehicle

height is in “HI” mode. (



P.355)

174

4-1. Before driving

WARNING

■

When driving on slippery

road surfaces

●

Sudden braking, acceleration

and steering may cause tire

slippage and reduce your ability

to control the vehicle.

●

Sudden acceleration, engine

braking due to shifting, or

changes in engine speed could

cause the vehicle to skid.

●

After driving through a puddle,

lightly depress the brake pedal

to make sure that the brakes

are functioning properly. Wet

brake pads may prevent the

brakes from functioning prop-

erly. If the brakes on only one

side are wet and not functioning

properly, steering control may

be affected.

■

When shifting the shift lever

●

Do not let the vehicle roll back-

ward while a forward driving

position is selected, or roll for-

ward while the shift lever is in R.

Doing so may result in an acci-

dent or damage to the vehicle.

●

Do not shift the shift lever to P

while the vehicle is moving.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Do not shift the shift lever to R

while the vehicle is moving for-

ward.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Do not shift the shift lever to a

driving position while the vehicle

is moving backward.

Doing so can damage the trans-

mission and may result in a loss

of vehicle control.

●

Moving the shift lever to N while

the vehicle is moving will disen-

gage the hybrid system. Engine

braking is not available with the

hybrid system disengaged.

●

Be careful not to shift the shift

lever with the accelerator pedal

depressed. Shifting the shift

lever to any positions other than

P or N may lead to unexpected

rapid acceleration of the vehicle

that may cause an accident and

result in death or serious injury.

■

If you hear a squealing or

scraping noise (brake pad

wear indicators)

Have the brake pads checked and

replaced by your Toyota dealer, or

any reliable repairer as soon as

possible.

Rotor damage may result if the

pads are not replaced when

needed.

It is dangerous to drive the vehicle

when the wear limits of the brake

pads and/or those of the brake

discs are exceeded.

■

When the vehicle is stopped

●

Do not depress the accelerator

pedal unnecessarily.

If the shift lever is any position

other than P or N, the vehicle

may accelerate suddenly and

unexpectedly, causing an acci-

dent.

●

In order to prevent accidents

due to the vehicle rolling away,

always keep depressing the

brake pedal while stopped with

the “READY” indicator is illumi-

nated, and apply the parking

brake as necessary.

175

4-1. Before driving

ing

WARNING

●

If the vehicle is stopped on an

incline, in order to prevent acci-

dents caused by the vehicle roll-

ing forward or backward, always

depress the brake pedal and

securely apply the parking

brake as needed.

●

Avoid revving or racing the

engine.

Running the engine at high

speed while the vehicle is

stopped may cause the exhaust

system to overheat, which could

result in a fire if combustible

material is nearby.

■

When the vehicle is parked

●

Do not leave glasses, cigarette

lighters, spray cans, or soft

drink cans in the vehicle when it

is in the sun.

Doing so may result in the fol-

lowing:

• Gas may leak from a cigarette

lighter or spray can, and may

lead to a fire.

• The temperature inside the

vehicle may cause the plastic

lenses and plastic material of

glasses to deform or crack.

• Soft drink cans may fracture,

causing the contents to spray

over the interior of the vehicle,

and may also cause a short cir-

cuit in the vehicle’s electrical

components.

●

Do not leave cigarette lighters in

the vehicle. If a cigarette lighter

is in a place such as the glove

box or on the floor, it may be lit

accidentally when luggage is

loaded or the seat is adjusted,

causing a fire.

●

Do not attach adhesive discs to

the windshield or windows. Do

not place containers such as air

fresheners on the instrument

panel or dashboard. Adhesive

discs or containers may act as

lenses, causing a fire in the

vehicle.

●

Do not leave a door or window

open if the curved glass is

coated with a metallized film

such as a silver-colored one.

Reflected sunlight may cause

the glass to act as a lens, caus-

ing a fire.

●

Always apply the parking brake,

shift the shift lever to P, stop the

hybrid system and lock the vehi-

cle. Do not leave the vehicle

unattended while the hybrid

system is operating.

If the vehicle is parked with the

shift lever in P but the parking

brake is not set, the vehicle may

start to move, possibly leading

to an accident.

●

Do not touch the exhaust pipes

while the “READY” indicator is

illuminated or immediately after

turning the hybrid system off.

Doing so may cause burns.

●

4WD models: If the shift lever is

moved before the “4L” indicator

turns on/off, the transfer mode

may not be shifted completely.

The transfer mode disengages

both the front and rear drivesh-

afts from the powertrain and

allows the vehicle to move

regardless of the shift position.

(At this time, the indicator blinks

and the buzzer sounds.)

Therefore, the vehicle is free to

roll even if the automatic trans-

mission is in P. You or someone

else could be seriously injured.

You must complete the shifting

of the transfer mode. (



P.361)

Toyota Tundra Hybrid (2023 year). Manual in english - page 10
