If you think something is wrong

●

Fluid leaks under the vehicle.
(Water dripping from the air conditioning after use is normal.)

●

Flat-looking tires or uneven tire wear

●

Engine coolant temperature gauge needle continually points higher
than normal.

●

Changes in exhaust sound

●

Excessive tire squeal when cornering

●

Strange noises related to the suspension system

●

Pinging or other noises related to the engine

●

Engine misses, stumbling or running roughly

●

Appreciable loss of power

●

Vehicle pulls heavily to one side when braking

●

Vehicle pulls heavily to one side when driving on a level road

●

Loss of brake effectiveness, spongy feeling, pedal almost touches
the floor

If you notice any of the following symptoms, your vehicle proba-
bly needs adjustment or repair. Contact your Toyota dealer as
soon as possible.

Visible symptoms

Audible symptoms

Operational symptoms

481

Fuel pump shut off system

Follow the procedure below to restart the engine after the system is
activated.

Vehicles without a smart key system:
Turn the engine switch to the “ACC” or “LOCK” position.
Vehicles with a smart key system:
Turn the engine switch to ACCESSORY or turn it off.
Restart the engine.

To minimize the risk of fuel leakage when the engine stalls or
when an airbag inflates upon collision, the fuel pump shut off
system stops supply of fuel to the engine.

NOTICE

■

Before starting the engine

Inspect the ground under the vehicle.
If you find that fuel has leaked onto the ground, the fuel system has been
damaged and is in need of repair. Do not restart the engine.

482

If a warning light turns on or a warning

buzzer sounds

Calmly perform the following actions if any of the warning lights
comes on or flashes. If a light comes on or flashes, but then
goes off, this does not necessarily indicate a malfunction in the
system. However, if this continues to occur, have the vehicle
inspected by your Toyota dealer.

Warning light and warning buzzer list

Warning light

Warning light/Details/Actions

(U.S.A.)

(Canada)

Brake system warning light

• Low brake fluid
• Malfunction in the brake system



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer.

(U.S.A.)

(Canada)

Malfunction indicator lamp

Indicates a malfunction in:
• The emission control system;
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control system.



Have the vehicle inspected by your Toyota dealer
immediately.

SRS warning light

Indicates a malfunction in:
• The SRS airbag system;
• The front passenger occupant classification system; or
• The seat belt pretensioner system



Have the vehicle inspected by your Toyota dealer
immediately.

(U.S.A.)

(Canada)

ABS warning light

Indicates a malfunction in:
• The ABS; or
• The brake assist system



Have the vehicle inspected by your Toyota dealer
immediately.

483

Slip indicator light

Indicates a malfunction in:
• The VSC system;
• Trailer Sway Control system (if equipped);
• The TRAC system;
• The hill-start assist control system (if equipped);
• The active traction control system (if equipped);
• The AUTO LSD system; or
• The Crawl Control system (if equipped)



Have the vehicle inspected by your Toyota dealer
immediately.

(Flashes rapidly)

Rear differential lock indicator light

Indicates a malfunction in the rear differential lock system



Have the vehicle inspected by your Toyota dealer
immediately.

(Flashes)

Low speed four-wheel drive indicator light

Indicates a malfunction in the four-wheel drive system



Have the vehicle inspected by your Toyota dealer
immediately.

Low fuel level warning light

Indicates remaining fuel is approximately 3.2 gal. (12.0 L,
2.6 Imp.gal.) or less



Refuel the vehicle.

Seat belt reminder light (warning buzzer)

Warns the driver and/or front passenger to fasten their
seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

(U.S.A.)

(Canada)

Parking brake indicator (warning buzzer)

Warns the driver to release parking brake.



Release the parking brake.

Master warning light (warning buzzer)

A buzzer sounds and the warning light comes on and
flashes to indicate that the master warning system has
detected a malfunction.



P. 489

Warning light

Warning light/Details/Actions

484

: The buzzer sounds when Multi-terrain Select or active traction control is

equipped.

: 4WD models only

Tire pressure warning light

When the light comes on:

Low tire inflation pressure such as

• Natural causes (

• Flat tire (



Adjust the tire inflation pressure to the specified

level.

The light will turn off after a few minutes. In case

the light does not turn off even if the tire inflation

pressure is adjusted, have the system checked by

your Toyota dealer.

When the light comes on after blinking for 1 minute:

Malfunction in the tire pressure warning system.



Have the system checked by your Toyota dealer.

(Flashes or illumi-

nates)

PCS warning light

When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-Col-
lision System).



Have the vehicle inspected by your Toyota dealer
immediately.

When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily
unavailable, corrective action may be necessary.



Follow the instructions displayed on the multi-infor-
mation display. (

P. 243, 489)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability
Control) system is disabled, the PCS warning light will illu-
minate.



P. 257

(Yellow)

LDA (Lane Departure Alert) indicator

The indicator comes on and a warning message is dis-
played to indicate that the LDA (Lane Departure Alert)
system is not available temporarily or has detected a mal-
function.



P. 499, 500, 501

Warning light

Warning light/Details/Actions

485

: Driver’s seat belt buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or
her seat belt is not fastened. Once the engine switch is turned to the “ON”
position (vehicles without smart entry & start system) or IGNITION ON
mode (vehicles with smart entry & start system), the buzzer sounds. If the
seat belt is still unfastened, the buzzer sounds intermittently for a certain
period of time after the vehicle reaches a certain speed.
Front passenger’s seat belt buzzer:

The front passenger's seat belt warning buzzer sounds to alert the front
passenger that his or her seat belt is not fastened. If the seat belt is unfas-
tened, the buzzer sounds intermittently for a certain period of time after the
vehicle reaches a certain speed.

: Parking brake engaged warning buzzer:

A buzzer will sound if the vehicle is driven at a speed of approximately
3 mph (5 km/h) or more.

: If equipped

■

SRS warning light

This warning light system monitors the airbag sensor assembly, front impact
sensors, side impact sensors (front), side impact sensors (rear), driver’s seat
position sensor, driver’s seat belt buckle switch, front passenger occupant
classification system (ECU and sensors), “AIR BAG ON” indicator light, “AIR
BAG OFF” indicator light, front passenger’s seat belt buckle switch, seat belt
pretensioners assemblies, airbags, interconnecting wiring and power
sources. (

P. 38)

■

Front passenger detection sensor, seat belt reminder and warning
buzzer

●

If luggage is placed on the front passenger seat, the front passenger detec-
tion sensor may cause the warning light to flash and the warning buzzer to
sound even if a passenger is not sitting in the seat.

●

If a cushion is placed on the seat, the sensor may not detect a passenger,
and the warning light may not operate properly.

486

■

If the malfunction indicator lamp comes on while driving

First check the following:

●

Is the fuel tank empty?
If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?
If it is, tighten it securely.

The light will go off after several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.

■

When the tire pressure warning light comes on (if equipped)

Check the tire inflation pressure and adjust to the appropriate level. Push-

ing the tire pressure warning reset switch will not turn off the tire pressure

warning light.

■

The tire pressure warning light may come on due to natural causes

(if equipped)

The tire pressure warning light may come on due to natural causes such

as natural air leaks and tire inflation pressure changes caused by tem-

perature. In this case, adjusting the tire inflation pressure will turn off the

warning light (after several minutes).

■

When a tire is replaced with a spare tire (vehicles with the tire pres-

sure warning system)

The temporary spare tire is not equipped with a tire pressure warning

valve and transmitter. If a tire goes flat, the tire pressure warning light will

not turn off even though the flat tire has been replaced with the temporary

spare tire. Replace the temporary spare tire with the repaired tire and

adjust the tire inflation pressure. The tire pressure warning light will go off

after several minutes.

■

Conditions that the tire pressure warning system may not function

properly (if equipped)



P. 436

■

If the tire pressure warning light frequently comes on after blinking

for 1 minute (if equipped)

If the tire pressure warning light frequently comes on after blinking for 1

minute when the engine switch is turned to “ON” position (vehicles with-

out a smart key system) or IGNITION ON mode (vehicles with a smart

key system), have it checked by your Toyota dealer.

■

Warning buzzer

In some cases, the buzzer may not be heard because of noisy place or an
audio sound.

487

WARNING

■

If both the ABS and the brake system warning lights remain on

Stop your vehicle in a safe place immediately and contact your Toyota
dealer. The vehicle will become extremely unstable during braking, and the
ABS system may fail, which could cause an accident resulting in death or
serious injury.

■

If the tire pressure warning light comes on (if equipped)

Be sure to observe the following precautions. Failure to do so could cause a
loss of vehicle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire infla-
tion pressure immediately.

●

If the tire pressure warning light comes on even after tire inflation pressure
adjustment, it is probable that you have a flat tire. Check the tires. If a tire
is flat, change it with the spare tire and have the flat tire repaired by the
nearest Toyota dealer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you
could lose control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur (vehicles with the tire
pressure warning system)

The tire pressure warning system may not activate immediately.

■

Maintenance of the tires (vehicles with the tire pressure warning

system)

Each tire, including the spare (if provided), should be checked monthly

when cold and inflated to the inflation pressure recommended by the

vehicle manufacturer on the vehicle placard or tire inflation pressure

label (tire and load information label). (If your vehicle has tires of a dif-

ferent size than the size indicated on the vehicle placard or tire inflation

pressure label [tire and load information label], you should determine

the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire

pressure monitoring system (TPMS-tire pressure warning system) that

illuminates a low tire pressure telltale (tire pressure warning light)

when one or more of your tires is significantly under-inflated. Accord-

ingly, when the low tire pressure telltale (tire pressure warning light)

illuminates, you should stop and check your tires as soon as possible,

and inflate them to the proper pressure. Driving on a significantly

under-inflated tire causes the tire to overheat and can lead to tire fail-

ure. Under-inflation also reduces fuel efficiency and tire tread life, and

may affect the vehicle’s handling and stopping ability.

488

WARNING

Please note that the TPMS (tire pressure warning system) is not a sub-

stitute for proper tire maintenance, and it is the driver’s responsibility to

maintain correct tire pressure, even if under-inflation has not reached

the level to trigger illumination of the TPMS low tire pressure telltale (tire

pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warn-

ing system) malfunction indicator to indicate when the system is not

operating properly. The TPMS (tire pressure warning system) malfunc-

tion indicator is combined with the low tire pressure telltale (tire pressure

warning light). When the system detects a malfunction, the telltale will

flash for approximately one minute and then remain continuously illumi-

nated. This sequence will continue upon subsequent vehicle start-ups

as long as the malfunction exists. When the malfunction indicator is illu-

minated, the system may not be able to detect or signal low tire pres-

sure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a vari-

ety of reasons, including the installation of replacement or alternate tires

or wheels on the vehicle that prevent the TPMS (tire pressure warning

system) from functioning properly. Always check the TPMS (tire pres-

sure warning system) malfunction telltale after replacing one or more

tires or wheels on your vehicle to ensure that the replacement or alter-

nate tires and wheels allow the TPMS (tire pressure warning system) to

continue to function properly.

NOTICE

■

To ensure the tire pressure warning system operates properly (if

equipped)

Do not install tires with different specifications or makers, as the tire

pressure warning system may not operate properly.

489

If a warning message is displayed

Master warning light

The  master  warning  light  also
comes  on  or  flashes  in  order  to
indicate  that  a  message  is  cur-
rently being displayed on the multi-
information display.

Multi-information display

If any of the warning light comes on again after the following actions
have been performed, contact your Toyota dealer.

If a warning is shown on the multi-information display, stay calm
and perform the following actions:

Warning message and warning buzzer list

Warning message

Details/Actions

Indicates the following:

• The brake fluid level is low; or,
• The brake system is malfunctioning



Immediately stop the vehicle in a safe place
and contact your Toyota dealer.

(U.S.A.)

(Canada)

(U.S.A.)

(Canada)

490

(If equipped)

Indicates that the automatic transmission fluid
temperature is too high.

A buzzer also sounds.



Immediately stop the vehicle in a safe
place, shift the shift lever to P and wait until
the message and light go off.
If the message and light go off, you may
start the vehicle again.
If the message and light do not go off, con-
tact your Toyota dealer.

Indicates that the engine coolant temperature is
too high.

A buzzer also sounds.



P. 534

Indicates abnormal engine oil pressure.
The warning light may come on if the engine oil
pressure is too low.

A buzzer also sounds.



Immediately stop the vehicle in a safe place
and contact your Toyota dealer.

Indicates a malfunction in the vehicle’s charging
system.



Immediately stop the vehicle in a safe place
and contact your Toyota dealer. Continuing
to drive the vehicle may be dangerous.

Warning message

Details/Actions

491

Indicates a malfunction in:

• The ABS; or
• The brake assist system
A buzzer also sounds.



Have the vehicle inspected by your Toyota
dealer.

Indicates a malfunction in:

• The VSC system;
• Trailer Sway Control system (if equipped);
• The TRAC system;
• The hill-start assist control system (if

equipped);

• The active traction control system (if

equipped);

• The AUTO LSD system; or
• The Crawl Control system (if equipped)



Have the vehicle inspected by your Toyota
dealer.

(If equipped)

Indicates a malfunction in the tire pressure moni-
toring system.

The tire pressure warning light comes on after
flashing for 1 minute.



Have the vehicle inspected by your Toyota
dealer.

Warning message

Details/Actions

(U.S.A.)

(Canada)

(U.S.A.)

(Canada)

(Flashes and then
remains on)

492

(If equipped)

Indicates a malfunction in the cruise control sys-
tem.

Press the “ON-OFF” button once to deactivate
the system, and then press the button again to
reactivate the system.
A buzzer also sounds.



Have the vehicle inspected by your Toyota
dealer.

(If equipped)

Indicates a malfunction in the dynamic radar
cruise control system.

Press the “ON-OFF” button once to deactivate
the system, and then press the button again to
reactivate the system.
A buzzer also sounds.



Have the vehicle inspected by your Toyota
dealer.

Indicates a malfunction in the Brake Override
System.

A buzzer also sounds.



Have the vehicle inspected by your Toyota
dealer immediately.

(2GR-FKS engine only)

Indicates that the engine oil level is low.

A buzzer also sounds.



Check the level of engine oil, and add if
necessary.
This message may appear if the vehicle is
stopped on a slope.
Move the vehicle to a level surface and
check to see if the message disappears.

Warning message

Details/Actions

493

Indicates that the accelerator and brake pedals
are being depressed simultaneously, and the
Brake Override System is operating. (

P. 170)



Release the accelerator pedal and depress
the brake pedal.

(If equipped)

Indicates that the tire inflation pressure is low.



Check the tire inflation pressure, and
adjust to the appropriate level.

(Canada only)

Indicates that the washer fluid level is low.



Add washer fluid.

Indicates that remaining fuel is approximately
3.2 gal. (12.0 L, 2.6 Imp.gal.) or less



Refuel the vehicle.

Warning message

Details/Actions

(Flashes)

494

(4WD models only)

Indicates that the transfer mode may not suc-
cessfully change.



Operate the front-wheel drive control
switch again. (

P. 303)

(4WD models only)

Indicates that the front differential oil temperature
is too high.



Drop  your  speed  or  stop  the  vehicle  until
the  message  and  light  go  off.  If  the  mes-
sage  and  light  do  not  go  off,  contact  your
Toyota dealer.

(4WD models only)

Indicates that the front differential oil temperature
is too high.



Turn the front-wheel drive control switch to
“2WD” (

P. 303) and drop your speed or

stop the vehicle until the message and light
go off. If the message and light do not go
off, contact your Toyota dealer.

(If equipped)

Indicates that the Crawl Control is canceled while
in use.

A buzzer also sounds.



Use the Crawl Control under the proper
operating conditions. (
