Toyota Sequoia Hybrid (2023 year). Manual in english

546

7-2. Steps to take in an emergency

Stop the hybrid system. Set
the parking brake and shift
the shift lever to P.

Remove the mud, snow or
sand from around the rear
wheels.

Place wood, stones or some
other material under the rear
wheels to help provide trac-
tion.

Restart the hybrid system.

Shift the shift lever to D or R
and release the parking
brake. Then, while exercising
caution, depress the acceler-
ator pedal.

■

When it is difficult to free the

vehicle

Try the followings.

●

Turn off the TRAC

(



P.383)

●

Using the rear differential lock

(



P.372)

●

Switching the front-wheel drive
control switch

(



P.369)

●

Using Crawl Control

(



P.373)

●

Using Multi-terrain Select

(



P.377)

: If equipped

If the vehicle becomes

stuck

Carry out the following pro-
cedures if the tires spin or
the vehicle becomes stuck
in mud, dirt or snow:

Recovering procedure

WARNING

■

When attempting to free a

stuck vehicle

If you choose to push the vehicle

back and forth to free it, make

sure the surrounding area is clear

to avoid striking other vehicles,

objects or people. The vehicle

may also lunge forward or lunge

back suddenly as it becomes free.

Use extreme caution.

■

When shifting the shift lever

Be careful not to shift the shift

lever with the accelerator pedal

depressed.

This may lead to unexpected

rapid acceleration of the vehicle

that may cause an accident

resulting in death or serious injury.

NOTICE

■

To avoid damaging the trans-

mission and other compo-

nents

●

Avoid spinning the rear wheels

and depressing the accelerator

pedal more than necessary.

●

If the vehicle remains stuck

even after these procedures are

performed, the vehicle may

require towing to be freed.

547

Vehicle

specifications

Vehicle specifications

8-1. Specifications

Maintenance data (fuel, oil

level, etc.)..................

548

Fuel information ..........

558

Tire information ...........

560

8-2. Customization

Customizable features

570

8-3. Initialization

Items to initialize .........

581

548

8-1. Specifications

8-1.Specifications

■

2WD models

:Unladen vehicles

:Vehicles without TRD Sport Package

:Vehicles with TRD Sport Package

■

4WD models

Maintenance data (fuel, oil level, etc.)

Dimensions and weight

Overall length

208.1 in. (5285 mm)

Overall width

79.8 in. (2021 mm)

Overall height

18 inch tires

74.41 in. (1890 mm)

20 inch tires

74.21 in. (1885 mm)

74.49 in. (1892 mm)

22 inch tires

74.21 in. (1885 mm)

Wheelbase

122.0 in. (3100 mm)

Front tread

68.5 in. (1741 mm)

68.6 in. (1742 mm)

Rear tread

68.4 in. (1737 mm)

Overall length

208.1 in. (5285 mm)

Overall width

79.8 in. (2021 mm)

Overall height

18 inch tires

74.13 in. (1883 mm)

74.33 in. (1888 mm)

74.57 in. (1894 mm)

77.68 in. (1973 mm)

*4, 5

20 inch tires

74.21 in. (1885 mm)

74.45 in. (1891 mm)

74.41 in. (1890 mm)

22 inch tires

74.45 in. (1891 mm)

Wheelbase

122.0 in. (3100 mm)

Front tread

68.6 in. (1742 mm)

69.6 in. (1767 mm)

Rear tread

68.4 in. (1737 mm)

69.4 in. (1762 mm)

549

8-1. Specifications

Vehicle

specifications

:Unladen vehicles

:SR5 models and SR5 models with TRD Off Road Package

:Limited models with TRD Off Road Package

:TRD Pro models

:Vehicles with roof rack

:Vehicles with TRD Sport Package

:Limited models

:Platinum models

:Except TRD Pro models

: The model code is indicated on the Certification Label. (



P.549)

■

Vehicle identification num-

ber

The vehicle identification num-

ber (VIN) is the legal identifier

for your vehicle. This is the pri-

mary identification number for

your Toyota. It is used in regis-

tering the ownership of your

vehicle.
This number is stamped on the

front right frame.

This number is also on the top
left of the instrument panel.

Vehicle capacity weight

Model code

Driving system

Seating

capacity

Vehicle capacity weight

(Occupants + luggage)

VXKH80L-GKVLZA

2WD

1420 lb. (645 kg)

VXKH80L-GKVSZA

1475 lb. (670 kg)

VXKH80L-GKVZZA

1345 lb. (610 kg)

VXKH85L-GKVLZA

4WD

1360 lb. (615 kg)

VXKH85L-GKVLZA

1315 lb. (595 kg)

VXKH85L-GKVSZA

1420 lb. (645 kg)

VXKH85L-GKVZZA

1290 lb. (585 kg)

Seating capacity

Seating capacity

Vehicles with separated

type second seats

Vehicles with bench type

second seat

7 (Front 2, Rear 5)

8 (Front 2, Rear 6)

Vehicle identification

550

8-1. Specifications

This number is also stamped
under the right-hand front seat.

This number is also on the Certi-
fication Label.

Engine

Model

V35A-FTS

Type

6-cylinder V type, 4-cycle, gasoline (with
turbocharger)

Bore and stroke

3.37



3.94 in. (85.5



100.0 mm)

Displacement

210.2 cu.in. (3445 cm

)

Valve clearance

Automatic adjustment

Drive belt tension

Automatic adjustment

Fuel

Fuel type

Unleaded gasoline only

Octane rating

87 (Research Octane Number 91) or
higher

Fuel tank capacity
(Reference)

22.5 gal. (85.0 L, 18.7 Imp.gal.)

551

8-1. Specifications

Vehicle

specifications

■

Oil capacity (Drain and refill
[Reference

])

: The engine oil capacity is a refer-

ence quantity to be used when
changing the engine oil. Warm up
and turn off the engine, wait more
than 8 minutes, and check the oil
level on the dipstick.

■

Engine oil selection

“Toyota Genuine Motor Oil” is
used in your Toyota vehicle. Use
Toyota approved “Toyota Genu-
ine Motor Oil” or equivalent to
satisfy the following grade and
viscosity.
Oil grade:

ILSAC GF-6A multigrade engine
oil
Recommended viscosity: SAE
0W-20

Outside temperature

SAE 0W-20 is the best choice
for good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.

Electric motor (traction motor)

Type

Permanent magnet synchronous motor

Maximum output

36 kW

Maximum torque

184 ft·lbf (250 N·m, 25.5 kgf·m)

Hybrid battery (traction battery)

Type

Nickel-Metal hydride battery

Voltage

7.2 V/module

Capacity

6.5 Ah

Quantity

40 modules

Nominal voltage

288 V

Lubrication system

With filter

7.7 qt. (7.3 L, 6.4 Imp.
qt.)

Without
filter

7.4 qt. (7.0 L, 6.2 Imp.
qt.)

552

8-1. Specifications

Oil viscosity (0W-20 is explained
here as an example):
• The 0W in 0W-20 indicates

the characteristic of the oil
which allows cold startability.
Oils with a lower value before
the W allow for easier starting
of the engine in cold weather.

• The 20 in 0W-20 indicates the

viscosity characteristic of the
oil when the oil is at high tem-
perature.

How to read oil container label:
The International Lubricant

Specification Advisory Commit-
tee (ILSAC) Certification Mark is
added to some oil containers to
help you select the oil you
should use.

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Toyota dealer.

Cooling system

Capacity

Gasoline
engine

15.3 qt. (14.5 L, 12.8 Imp.qt.)

Intercooler 4.6 qt. (4.4 L, 3.9 Imp.qt.)

Power con-
trol unit

2.2 qt. (2.1 L, 1.8 Imp.qt.)

Coolant type

Use either of the following:



“Toyota Super Long Life Coolant”



Similar high-quality ethylene glycol-based non-
silicate, non-amine, non-nitrite, and non-borate
coolant with long-life hybrid organic acid tech-
nology

Do not use plain water alone.

Ignition system (spark plug)

Make

DENSO EC22HPR-D7

Gap

0.027 in. (0.7 mm)

553

8-1. Specifications

Vehicle

specifications

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Toyota dealer.

Your Toyota vehicle is filled with “Toyota Genuine ATF WS” at the
factory.
Use Toyota approved “Toyota Genuine ATF WS” or an equivalent of
matching quality to satisfy the above specification. Please contact
your Toyota dealer for further details.

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system

Open voltage at 68°F (20°C):

12.0 V or higher
(Turn the power switch off and turn on the
high beam headlights for 30 seconds.)

Charging rates

5 A max.

Automatic transmission

Fluid capacity

12.4 qt. (11.7 L, 10.3 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

NOTICE

■

Automatic transmission fluid type

Using transmission fluid other than the above type may cause abnormal

noise or vibration, or damage the transmission of your vehicle.

Transfer (4WD models)

Oil capacity

2.17 qt. (2.05 L, 1.80 Imp.qt.)

Oil type and viscosity

Toyota Genuine ATF WS

554

8-1. Specifications

Your Toyota vehicle is filled with “Toyota Genuine Differential Gear
Oil” at the factory.
Use Toyota approved “Toyota Genuine Differential Gear Oil” or an
equivalent oil of matching quality to satisfy the above specification.
Please contact your Toyota dealer for further details.

:Minimum pedal clearance when depressed with a force of 110 lbf (490 N,

50 kgf) while the hybrid system is running.

:Make sure to confirm that the brake warning light (yellow) does not illumi-

nate. (If the brake warning light illuminates, refer to P.509.)

Differential

Oil capacity

Front (4WD
models)

1.4 qt. (1.29 L, 1.1 Imp.qt.)

Rear



Without rear differential lock system
6.0 qt. (5.73 L, 5.0 Imp.qt.)



With rear differential lock system
5.8 qt. (5.51 L, 4.8 Imp.qt.)

Oil type and viscosity

Toyota Genuine Differential Gear Oil LT
75W-85 GL-5 or equivalent

Brakes

Pedal clearance

3.6 in. (90.8 mm) Min.

Pedal free play

0.04



0.24 in. (1



6 mm)

Brake pad wear limit

0.04 in. (1 mm)

Parking brake indicator

When pulling the parking brake switch for
1 to 2 seconds: comes on
When pushing the parking brake switch for
1 to 2 seconds: turns off

Fluid type

• FMVSS No.116 DOT 3 or SAE J1703
• FMVSS No.116 DOT 4 or SAE J1704

555

8-1. Specifications

Vehicle

specifications



18-inch tires (type A)

: When vehicle is loaded or towing a trailer: Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the recommended cold tire inflation pressure.



18-inch tires (type B)

: When vehicle is loaded or towing a trailer: Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the recommended cold tire inflation pressure.

Steering

Free play

Less than 1.2 in. (30 mm)

Tires and wheels

Tire size

265/70R18 116T, 245/75R18 112T (spare)

Tire inflation pressure
(Recommended cold tire
inflation pressure)

35 psi (240 kPa, 2.4 kgf/cm

or bar)

36 psi (250 kPa, 2.5 kgf/cm

or bar) (spare)

Wheel size



7 1/2 J, 18



7J (spare)

Wheel nut torque

Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)

Tire size

265/70R18 116T, 265/70R18 116T (spare)

Tire inflation pressure
(Recommended cold tire
inflation pressure)

35 psi (240 kPa, 2.4 kgf/cm

or bar)

Wheel size



7 1/2 J, 18



7J (spare)

Wheel nut torque

Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)

556

8-1. Specifications



18-inch tires (type C)

: When vehicle is loaded or towing a trailer: Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the recommended cold tire inflation pressure.



20-inch tires

: When vehicle is loaded or towing a trailer: Add 3 psi (20 kPa, 0.2 kgf/cm

or bar) to the recommended cold tire inflation pressure.



22-inch tires

Tire size

285/65R18 116T, 265/70R18 116T (spare)

Tire inflation pressure
(Recommended cold tire
inflation pressure)

35 psi (240 kPa, 2.4 kgf/cm

or bar)

Wheel size



8 1/2 J, 18



7J (spare)

Wheel nut torque

Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)

Tire size

265/60R20 112H, 245/75R18 112T (spare)

Tire inflation pressure
(Recommended cold tire
inflation pressure)

36 psi (250 kPa, 2.5 kgf/cm

or bar)

Wheel size



8J, 18



7J (spare)

Wheel nut torque

Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)

Tire size

265/50R22 112H, 245/75R18 112T (spare)

Tire inflation pressure
(Recommended cold tire
inflation pressure)

Front:
38 psi (260 kPa, 2.6 kgf/cm

or bar)

Rear:
42 psi (290 kPa, 2.9 kgf/cm

or bar)

Spare:
36 psi (250 kPa, 2.5 kgf/cm

or bar)

557

8-1. Specifications

Vehicle

specifications

A: Wedge base bulbs (amber)

Wheel size



8J, 18



7J (spare)

Wheel nut torque

Steel wheels:
154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheels:
97 ft·lbf (131 N·m, 13.4 kgf·m)

Light bulbs

Light bulbs

Bulb No.

Type

Exterior

Front turn signal/parking
lights

7444NA

28/8

558

8-1. Specifications

■

Gasoline quality

In very few cases, driveability prob-

lems may be caused by the brand of

gasoline you are using. If driveability

problems persist, try changing the

brand of gasoline. If this does not

correct the problem, consult your

Toyota dealer.

■

Recommendation of the use of

gasoline containing detergent

additives

●

Toyota recommends the use of

gasoline that contains detergent

additives to avoid build-up of

engine deposits.

●

All gasoline sold in the U.S.A. con-

tains minimum detergent additives

to clean and/or keep clean intake

systems, per EPA’s lowest addi-

tives concentration program.

●

Toyota strongly recommends the

use of Top Tier Detergent Gaso-

line. For more information on Top

Tier Detergent Gasoline and a list

of marketers, please go to the offi-

cial website www.toptiergas.com.

■

Recommendation of the use of

low emissions gasoline

Gasolines containing oxygenates

such as ethers and ethanol, as well

as reformulated gasolines, are avail-

able in some cities. These fuels are

typically acceptable for use, provid-

ing they meet other fuel require-

ments.
Toyota recommends these fuels,

since the formulations allow for

reduced vehicle emissions.

■

Non-recommendation of the

use of blended gasoline

●

Use only gasoline containing up to
15% ethanol.
DO NOT use any flex-fuel or gas-
oline that could contain more than
15% ethanol, including from any
pump labeled E30 (30% ethanol

), E50 (50% ethanol

), E85

(85% ethanol

) (which are only

some examples of fuel containing
more than 15% ethanol).

●

If you use gasohol in your vehicle,

be sure that it has an octane rat-

ing no lower than 87.

●

Toyota does not recommend the

use of gasoline containing metha-

nol.

Fuel information

You must only use unleaded
gasoline.
Select octane rating 87
(Research Octane Number
91) or higher. Use of
unleaded gasoline with an
octane rating lower than 87
may result in engine knock-
ing. Persistent knocking
can lead to engine damage.

At minimum, the gasoline you
use should meet the specifi-
cations of ASTM D4814 in the
U.S.A.

559

8-1. Specifications

Vehicle

specifications

■

Non-recommendation of the

use of gasoline containing MMT

Some gasoline contains an octane

enhancing additive called MMT

(Methylcyclopentadienyl Manga-

nese Tricarbonyl).
Toyota does not recommend the use

of gasoline that contains MMT. If

fuel containing MMT is used, your

emission control system may be

adversely affected.
The malfunction indicator lamp on

the instrument cluster may come on.

If this happens, contact your Toyota

dealer for service.

■

If your engine knocks

●

Consult your Toyota dealer.

●

You may occasionally notice light

knocking for a short time while

accelerating or driving uphill. This

is normal and there is no need for

concern.

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If

improper fuels are used, the

engine will be damaged.

●

Do not use leaded gasoline.

Leaded gasoline can cause

damage to your vehicle’s three-

way catalytic converters caus-

ing the emission control system

to malfunction.

●

Do not use gasohol other than

the type previously stated.

Other gasohol may cause fuel

system damage or vehicle per-

formance problems.

●

Using unleaded gasoline with

an octane number or rating

lower than the level previously

stated will cause persistent

heavy knocking.

At worst, this will lead to engine

damage.

■

Fuel-related poor driveability

If poor driveability (poor hot start-

ing, vaporization, engine knock-

ing, etc.) is encountered after

using a different type of fuel, dis-

continue the use of that type of

fuel.

■

When refueling with gasohol

Take care not to spill gasohol. It

can damage your vehicle’s paint.

560

8-1. Specifications

Tire size (



P.561)

DOT and Tire Identification Number (TIN) (



P.561)

Location of treadwear indicators (



P.474)

Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands
which form the plies in a tire.

Radial tires or bias-ply tires

A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a
bias-ply tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A
tube type tire has a tube inside the tire and the tube maintains the air pres-
sure.

Load limit at maximum cold tire inflation pressure (



P.474)

Maximum cold tire inflation pressure (



P.555)

This means the pressure to which a tire may be inflated.

Uniform tire quality grading

For details, see “Uniform Tire Quality Grading” that follows.

Summer tires or all season tires (



P.475)

Tire information

Typical tire symbols

561

8-1. Specifications

Vehicle

specifications

An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a
summer tire.



Type A

DOT symbol

Tire Identification Number
(TIN)

Tire size code

Manufacturer’s optional tire
type code (3 or 4 letters)

Tire manufacturer’s identifi-
cation mark

Manufacturing week

Manufacturing year

: The DOT symbol certifies that the

tire conforms to applicable Fed-
eral Motor Vehicle Safety Stan-
dards.



Type B

DOT symbol

Tire Identification Number
(TIN)

Tire manufacturer’s identifi-
cation mark

Manufacturer’s code

Manufacturing week

Manufacturing year

: The DOT symbol certifies that the

tire conforms to applicable Fed-
eral Motor Vehicle Safety Stan-
dards.

■

Typical tire size information

The illustration indicates typical
tire size.

Typical DOT and Tire
Identification Number
(TIN)

Tire size

Toyota Sequoia Hybrid (2023 year). Manual in english - page 34
