530

7-2. Steps to take in an emergency

Remove the center wheel
ornament by pushing from
the reverse side.

Lay down the tire with the
valve stem facing up and
install the holding bracket.
Turn the jack handle exten-
sion clockwise to take up
slack in the chain.

Check to ensure the holding
bracket is centered in the
wheel hub.

While raising, secure the tire,
taking care that the tire goes
straight up without catching
on any surrounding part, to
prevent it from flying forward
during a collision or sudden
braking.

Tightening torque:

34.7 ft•lbf (46.6 N•m, 4.8 kgf•m)

Confirm it is not loose after
tightening:

Push and pull the tire

Try rotating

Visually check to ensure tire is not
hung on surrounding parts.
If looseness or misassembly exists,
repeat step

and step

Repeat step

, any time the

tire is lowered or disturbed.

Stow the tools and jack
securely.

■

The temporary spare tire

●

The temporary spare tire is identi-

fied by the “TEMPORARY USE

ONLY” marking on the disc wheel

and/or tire sidewall.

Use the temporary spare tire tem-

porarily, and only in an emer-

gency.

●

Make sure to check the tire infla-

tion pressure of the temporary

spare tire. (



P.555)

■

When using the temporary

spare tire

As the temporary spare tire is not

equipped with the tire pressure

warning valve and transmitter, low

inflation pressure of the spare tire

will not be indicated by the tire pres-

sure warning system. Also, if you

Stowing the flat tire, jack
and all tools

531

7-2. Steps to take in an emergency

Whe

n tr

ouble

rises

replace the temporary spare tire

after the tire pressure warning light

comes on, the light remains on.

■

If you have a flat rear tire on a

road covered with snow or ice

Install the temporary spare tire on

one of the front wheels of the vehi-

cle. Perform the following steps and

fit tire chains to the rear tires:

Replace a front tire with the tem-

porary spare tire.

Replace the flat rear tire with the

tire removed from the front of the

vehicle.

Fit tire chains to the rear tires.

WARNING

■

When using the temporary

spare tire

●

Remember that the temporary

spare tire provided is specifi-

cally designed for use with your

vehicle. Do not use your tempo-

rary spare tire on another vehi-

cle.

●

Do not use more than one tem-

porary spare tires simultane-

ously.

●

Replace the temporary spare

tire with a standard tire as soon

as possible.

●

Avoid sudden acceleration,

abrupt steering, sudden brak-

ing and shifting operations that

cause sudden engine braking.

■

When the spare tire is

attached

The vehicle speed may not be

correctly detected, and the follow-

ing systems may not operate cor-

rectly:

• ABS & Brake assist

• VSC

• TRAC

• AUTO LSD (if equipped)

• PCS (Pre-Collision System)

• Automatic High Beam (if

equipped)

• LTA (Lane Tracing Assist)

• Dynamic radar cruise control

with full-speed range

• EPS

• Trailer Sway Control

• Tire pressure warning system

• BSM (Blind Spot Monitor)

• Panoramic view monitor (if

equipped)

• Multi-terrain Monitor (if

equipped)

• Toyota parking assist monitor (if

equipped)

• Intuitive parking assist

• PKSB (Parking Support Brake)

• Navigation system (if equipped)

Also, not only can the following

system not be utilized fully, but it

may even negatively affect the

drive-train components:
• 4WD system (if equipped)

■

Speed limit when using the

temporary spare tire

Do not drive at speeds in excess

of 50 mph (80 km/h) when a tem-

porary spare tire is installed on

the vehicle.
The temporary spare tire is not

designed for driving at high

speeds. Failure to observe this

precaution may lead to an acci-

dent causing death or serious

injury.

532

7-2. Steps to take in an emergency

One of the following may be the
cause of the problem:



The electronic key may not be
functioning properly.
(



P.535)



There may not be sufficient
fuel in the vehicle’s tank.
Refuel the vehicle.



There may be a malfunction
in the immobilizer system.
(



P.83)



The hybrid system may be
malfunctioning due to an elec-
trical problem such as elec-
tronic key battery depletion or
a blown fuse. However,
depending on the type of mal-
function, an interim measure
is available to start the hybrid
system. (



P.533)



The temperature of the hybrid
battery (traction battery) may
be extremely low (below

NOTICE

■

Do not drive the vehicle with

a flat tire

Do not continue driving with a flat

tire.

Driving even a short distance with

a flat tire can damage the tire and

the wheel beyond repair.

■

Driving with tire chains and

the temporary spare tire

Do not fit tire chains to the tempo-

rary spare tire.

Tire chains may damage the vehi-

cle body and adversely affect driv-

ing performance.

■

When stowing the flat tire

Ensure that there is no object

caught between the tire and the

vehicle underbody.

■

When replacing the tires

When removing or fitting the

wheels, tires or the tire pressure

warning valve and transmitter,

contact your Toyota dealer as the

tire pressure warning valve and

transmitter may be damaged if not

handled correctly.

■

To avoid damage to the tire

pressure warning valves and

transmitters

When a tire is repaired with liquid

sealants, the tire pressure warn-

ing valve and transmitter may not

operate properly. If a liquid seal-

ant is used, contact your Toyota

dealer or other qualified service

shop as soon as possible. Make

sure to replace the tire pressure

warning valve and transmitter

when replacing the tire. (



P.478)

If the hybrid system

will not start

Reasons for the hybrid sys-
tem not starting vary
depending on the situation.
Check the following and
perform the appropriate
procedure:

The hybrid system will not
start even though the cor-
rect starting procedure is
being followed. (



P.212)

533

7-2. Steps to take in an emergency

Whe

n tr

ouble

rises

approximately -31°F [-35°C]).
(



P.212)

One of the following may be the
cause of the problem:



The 12-volt battery may be
discharged. (



P.538)



The 12-volt battery terminal
connections may be loose or
corroded. (



P.471)

One of the following may be the
cause of the problem:



The 12-volt battery may be
discharged. (



P.538)



One or both of the 12-volt bat-
tery terminals may be discon-
nected. (



P.471)

Contact your Toyota dealer if the
problem cannot be repaired, or if
repair procedures are unknown.

When the hybrid system does
not start, the following steps can
be used as an interim measure
to start the hybrid system if the
power switch is functioning nor-

mally.
Do not use this starting proce-
dure except in case of emer-
gency.

Pull the parking brake switch
to check that the parking
brake is set. (



P.222)

Parking brake indicator will come

on.

Shift the shift lever to P.

Turn the power switch to
ACC.

Press and hold the power
switch for about 15 seconds
while depressing the brake
pedal firmly.

Even if the hybrid system can be
started using the above steps, the
system may be malfunctioning.
Have the vehicle inspected by your
Toyota dealer.

The interior lights and
headlights are dim, or the
horn does not sound or
sounds at a low volume.

The interior lights and
headlights do not turn on,
or the horn does not
sound.

Emergency start function

534

7-2. Steps to take in an emergency

Remove the cover inside the
luggage compartment.

After removing the cover, pull
the lever to unlock the fuel
door and it will be ready to
open as usual.

If you lose your keys

New genuine keys can be
made by your Toyota dealer
using other key and the key
number stamped on your
key number plate.

Keep the plate in a safe
place such as your wallet,
not in the vehicle.

NOTICE

■

When an electronic key is lost

If the electronic key remains lost,

the risk of vehicle theft increases

significantly. Visit your Toyota

dealer immediately with all

remaining electronic keys that

were provided with your vehicle.

If the fuel door cannot

be opened

If the fuel door opener
switch cannot be operated,
the following procedure can
be used to open the fuel
door.

Opening the fuel door

535

7-2. Steps to take in an emergency

Whe

n tr

ouble

rises

■

When the electronic key does

not work properly

●

Make sure that the smart key sys-

tem has not been deactivated in

the customization setting. If it is

off, turn the function on.

(Customizable features:



P.570)

●

Check if battery-saving mode is

set. If it is set, cancel the function.

(



P.141)

NOTICE

■

When opening the fuel filler

door manually

●

Do not open the fuel filler door

manually except in an emer-

gency. Fuel may overflow.

●

Using the lever to open the fuel

filler door may not allow for an

adequate reduction in fuel tank

pressure before refueling. To

prevent fuel from spilling out,

turn the cap slowly when remov-

ing it.

●

During refueling, fuel may spill

out from the filler opening due to

air being discharged from inside

the fuel tank. Therefore, fill the

fuel tank carefully and slowly.

If the electronic key

does not operate prop-

erly

If communication between
the electronic key and vehi-
cle is interrupted (



P.141)

or the electronic key cannot
be used because the battery
is depleted, the smart key
system and wireless remote
control cannot be used. In
such cases, the doors can
be opened and the hybrid
system can be started by
following the procedure
below.

NOTICE

■

In case of a smart key system

malfunction or other key-

related problems

Take your vehicle with all the elec-

tronic keys provided with your

vehicle to your Toyota dealer.

536

7-2. Steps to take in an emergency

Use the mechanical key
(



P.114) in order to perform the

following operations:

Locks all the doors

Unlocks all the doors

Turning the key unlocks the driver’s
door. Turning the key again unlocks
the other doors.

■

Key linked functions

Closes the windows and the
moon roof

the panoramic moon

roof

. (turn and hold)

Opens the windows and the
moon roof

the panoramic moon

roof

. (turn and hold)

These settings must be customized

at your Toyota dealer.

: If equipped

Ensure that the shift lever is
in P and depress the brake
pedal.

Touch the Toyota emblem
side of the electronic key to
the power switch.

When the electronic key is

detected, a buzzer sounds and the

power switch will turn to ON.
When the smart key system is

deactivated in customization set-

ting, the power switch will turn to

Locking and unlocking
the doors

WARNING

■

When using the mechanical

key and operating the power

windows and the moon roof

(if equipped) or the pan-

oramic moon roof (if

equipped)

Operate the power window or the

moon roof or the panoramic moon

roof after checking to make sure

that there is no possibility of any

passenger having any of their

body parts caught in the window

or the moon roof or the panoramic

moon roof.

Also, do not allow children to

operate the mechanical key. It is

possible for children and other

passengers to get caught in the

power window or the moon roof or

the panoramic moon roof.

Starting the hybrid sys-
tem

537

7-2. Steps to take in an emergency

Whe

n tr

ouble

rises

ACC.

Firmly depress the brake
pedal and check that

shown on the multi-informa-
tion display.

Press the power switch
shortly and firmly.

In the event that the hybrid sys-
tem still cannot be started, con-
tact your Toyota dealer.

■

Stopping the hybrid system

Shift the shift lever to P, set the park-

ing brake, shift the shift lever to P

and press the power switch as you

normally do when stopping the

hybrid system.

■

Electronic key battery

As the above procedure is a tempo-

rary measure, it is recommended

that the electronic key battery be

replaced immediately when the bat-

tery is depleted. (



P.493)

■

Alarm

Using the mechanical key to lock

the doors will not set the alarm sys-

tem. If a door is unlocked using the

mechanical key when the alarm sys-

tem is set, the alarm may be trig-

gered. (



P.84)

■

Changing power switch modes

Release the brake pedal and press

the power switch in step

above.

The hybrid system does not start

and modes will be changed each

time the switch is pressed. (



P.215)

538

7-2. Steps to take in an emergency

If you have a set of jumper (or
booster) cables and a second
vehicle with a 12-volt battery,
you can jump start your vehicle
by following the steps below.

Confirm that the electronic
key is being carried.

When connecting the jumper (or

booster) cables, depending on the

situation, the alarm may activate

and doors locked. (



P.85)

Open the hood (



P.464) and

fuse box cover.

Push claw to completely release

the lock, and them lift up the cover.

Open the exclusive jump
starting terminal cover.

Remove the engine cover.

Lift the edge of the cover to disen-

gage the fixed pins, and then pull

the cover towards you to remove it.

Connect a positive jumper cable clamp to   on your vehicle and
connect the clamp on the other end of the positive cable to   on
the second vehicle. Then, connect a negative cable clamp to

If the vehicle 12-volt

battery is discharged

The following procedures
may be used to start the
hybrid system if the vehi-
cle’s 12-volt battery is dis-
charged.
You can also call your Toy-
ota dealer or a qualified
repair shop.

Restarting the hybrid sys-
tem

539

7-2. Steps to take in an emergency

Whe

n tr

ouble

rises

on the second vehicle and connect the clamp at the other end of
the negative cable to .

Exclusive jump starting terminal (your vehicle)

Positive (+) battery terminal (second vehicle)

Negative (-) battery terminal (second vehicle)

Solid, stationary, unpainted metallic point away from the battery
and any moving parts as shown in the illustration

Start the engine of the sec-
ond vehicle. Increase the
engine speed slightly and
maintain at that level for
approximately 5 minutes to
recharge the 12-volt battery
of your vehicle.

Open and close any of the
doors of your vehicle with the
power switch OFF.

Maintain the engine speed of
the second vehicle and start
the hybrid system of your
vehicle by turning the power
switch to ON.

Once the vehicle’s hybrid
system has started, remove

the jumper cables in the
exact reverse order from
which they were connected.

When the engine cover

installing, reverse the step
removed.

Close the exclusive jump

starting terminal cover, and
reinstall the fuse box cover to
its original position.

Once the engine starts, have the
vehicle inspected at your Toyota
dealer as soon as possible.

540

7-2. Steps to take in an emergency

■

Starting the hybrid system

when the battery is discharged

The hybrid system cannot be started

by push-starting.

■

To prevent 12-volt battery dis-

charge

●

Turn off the headlights and the

audio system while the hybrid sys-

tem is off.

●

Turn off any unnecessary electri-

cal components when the vehicle

is running at a low speed for an

extended period, such as in heavy

traffic.

■

When the 12-volt battery is

removed or discharged

●

Information stored in the ECU is

cleared. When the 12-volt battery

is depleted, have the vehicle

inspected at your Toyota dealer.

●

Some systems may require initial-

ization. (



P.581)

■

When removing the 12-volt bat-

tery terminals

When the 12-volt battery terminals

are removed, the information stored

in the ECU is cleared. Before

removing the 12-volt battery termi-

nals, contact your Toyota dealer.

■

Charging the 12-volt battery

The electricity stored in the 12-volt

battery will discharge gradually even

when the vehicle is not in use, due

to natural discharge and the drain-

ing effects of certain electrical appli-

ances. If the vehicle is left for a long

time, the 12-volt battery may dis-

charge, and the hybrid system may

be unable to start. (The 12-volt bat-

tery recharges automatically while

the hybrid system is operating.)

■

When recharging or replacing

the 12-volt battery

●

In some cases, it may not be pos-

sible to unlock the doors using the

smart key system when the 12-

volt battery is discharged. Use the

wireless remote control or the

mechanical key to lock or unlock

the doors.

●

The hybrid system may not start

on the first attempt after reinstall-

ing the 12-volt battery. In that

case, start the hybrid system in

the same manner as when the

electronic key does not operate

properly (



P.536). This is not a

malfunction, as the hybrid system

will start normally on the second

attempt.

●

The power switch mode is memo-

rized by the vehicle. When the 12-

volt battery is reconnected, the

system will return to the mode it

was in before the 12-volt battery

was discharged. Before discon-

necting the 12-volt battery, turn

the power switch off.

If you are unsure what mode the

power switch was in before the

12-volt battery discharged, be

especially careful when recon-

necting the 12-volt battery.

●

Some systems may require initial-

ization. (



P.581)

■

When replacing the 12-volt bat-

tery

●

Use a 12-volt battery that con-

forms to European regulations.

●

Use a battery that the case size is

same as the previous one (LN2),

20 hours rate capacity (20HR) is

equivalent (55Ah) or greater, and

performance rating (CCA) is

equivalent (345A) or greater.

• If the sizes differ, the 12-volt bat-

tery cannot be properly secured.

• If the 20 hour rate capacity is low,

even if the time period where the

vehicle is not used is a short time,

the 12-volt battery may discharge

and hybrid system may not be

able to start.

●

Use a ventilation type calcium bat-

tery

●

Use a 12-volt battery with a han-

dle. If a 12-volt battery without a

handle is used, removal is more

541

7-2. Steps to take in an emergency

Whe

n tr

ouble

rises

difficult.

●

When removing the 12-volt bat-

tery:



P.471

●

After replacing, firmly attach the

following items to the exhaust hole

of the 12-volt battery.

• Use the exhaust hose that was

attached to the 12-volt battery

before replacing and confirm that

it is firmly connected to the hole

section of the vehicle.

• Use the exhaust hole plug

included with the 12-volt battery

replaced or the one installed on

the battery prior to the replaced.

(Depending on the 12-volt battery

to be replace, the exhaust hole

may be plugged.)

For details, consult your Toyota
dealer.

Exhaust hole cap

Exhaust hole

Exhaust hose

WARNING

■

When removing the 12-volt

battery terminals

Always remove the negative (-)

terminal first. If the positive (+) ter-

minal contacts any metal in the

surrounding area when the posi-

tive (+) terminal is removed, a

spark may occur, leading to a fire

in addition to electrical shocks

and death or serious injury.

■

Avoiding 12-volt battery fires

or explosions

Observe the following precautions

to prevent accidentally igniting the

flammable gas that may be emit-

ted from the 12-volt battery:

●

Make sure each jumper cable is

connected to the correct termi-

nal and that it is not unintention-

ally in contact with any other

than the intended terminal.

●

Do not allow the other end of

the jumper cable connected to

the “+” terminal to come into

contact with any other parts or

metal surfaces in the area, such

as brackets or unpainted metal.

●

Do not allow the + and - clamps

of the jumper cables to come

into contact with each other.

●

Do not smoke, use matches,

cigarette lighters or allow open

flame near the 12-volt battery.

■

12-volt battery precautions

The 12-volt battery contains poi-

sonous and corrosive acidic elec-

trolyte, while related parts contain

lead and lead compounds.

Observe the following precautions

when handling the 12-volt battery:

542

7-2. Steps to take in an emergency

WARNING

●

When working with the 12-volt

battery, always wear safety

glasses and take care not to

allow any 12-volt battery fluids

(acid) to come into contact with

skin, clothing or the vehicle

body.

●

Do not lean over the 12-volt bat-

tery.

●

In the event that 12-volt battery

fluid comes into contact with the

skin or eyes, immediately wash

the affected area with water and

seek medical attention. Place a

wet sponge or cloth over the

affected area until medical

attention can be received.

●

Always wash your hands after

handling the 12-volt battery sup-

port, terminals, and other bat-

tery-related parts.

●

Do not allow children near the

12-volt battery.

■

After recharging the 12-volt

battery

Have the 12-volt battery

inspected at your Toyota dealer

as soon as possible. If the 12-volt

battery is deteriorating, continued

use may cause the 12-volt battery

to emit a malodorous gas, which

may be detrimental to the health

of passengers.

■

When replacing the 12-volt

battery

●

For information regarding 12-

volt battery replacement, con-

tact your Toyota dealer.

●

After replacing, securely attach

the exhaust hose and exhaust

hole plug to the exhaust hole of

the replaced 12-volt battery. If

not properly installed, gases

(hydrogen) may leak into the

vehicle interior, and there is the

possible danger of the gas ignit-

ing and exploding.

NOTICE

■

When handling jumper cables

When connecting the jumper

cables, ensure that they do not

become entangled in the cooling

fan.

543

7-2. Steps to take in an emergency

Whe

n tr

ouble

rises

■

If the engine coolant tem-
perature gauge enters the
red zone or “Engine Cool-
ant Temp High Stop in a
Safe Place See Owner’s
Manual” is shown on the
multi-information display

Stop the vehicle in a safe
place and turn off the air con-
ditioning system, and then
stop the hybrid system.

If you see steam:
Carefully lift the hood after
the steam subsides.
If you do not see steam:
Carefully lift the hood.

After the hybrid system has
cooled down sufficiently,
inspect the hoses, engine
radiator core (radiator) and
intercooler radiator core
(radiator) for any leaks.

If a large amount of coolant leaks,

immediately contact your Toyota

dealer.

Cooling fan

Radiator

Intercooler radiators

The coolant level is satisfac-
tory if it is between the “F” or
“FULL” and “L” or “LOW”
lines on the reservoir.

If your vehicle overheats

The following may indicate that your vehicle is overheating.



The needle of the engine coolant temperature gauge (



P.93)

enters the red zone or a loss of engine (hybrid system) power is
experienced. (For example, the vehicle speed does not
increase.)



“Engine Coolant Temp High Stop in a Safe Place See Owner’s
Manual” is shown on the multi-information display.



Steam comes out from under the hood.

Correction procedures

544

7-2. Steps to take in an emergency



Engine

Reservoir

“F” line

“L” line



Intercooler

Reservoir

“F” line

“L” line



Power control unit

Reservoir

“FULL” line

“LOW” line

Add coolant if necessary.

Water can be used in an emer-

gency if coolant is unavailable.
If water was added in an emer-

gency, have the vehicle inspected

at your Toyota dealer as soon as

possible.



Engine



Intercooler



Power control unit

545

7-2. Steps to take in an emergency

Whe

n tr

ouble

rises

Start the hybrid system to
check that the radiator cool-
ing fan operates and to check
for coolant leaks from the
radiator or hoses.

If the fan is not operating:
Stop the hybrid system
immediately and contact your
Toyota dealer.
If the fan is operating:
Have the vehicle inspected at
the nearest Toyota dealer.

Check if “Engine Coolant
Temp High Stop in a Safe
Place See Owner’s Manual”
is shown on the multi-infor-
mation display.

If the message does not disappear:

Stop the hybrid system and contact

your Toyota dealer.
If the message is not displayed:

Have the vehicle inspected at the

nearest Toyota dealer.

WARNING

■

When inspecting under the

hood of your vehicle

Observe the following precau-

tions.

Failure to do so may result in seri-

ous injury such as burns.

●

If steam is seen coming from

under the hood, do not open the

hood until the steam has sub-

sided. The engine compart-

ment may be very hot.

●

After the hybrid system has

been turned off, check that the

“READY” indicator is off. When

the hybrid system is operating,

the gasoline engine may auto-

matically start, or the cooling fan

may suddenly operate even if

the gasoline engine stops. Do

not touch or approach rotating

parts such as the fan, which

may lead to fingers or clothing

(especially a tie, a scarf or a

muffler) getting caught, resulting

in serious injury.

●

Do not loosen the coolant reser-

voir caps, while the hybrid sys-

tem and radiator are hot.

High temperature steam or

coolant could spray out.

NOTICE

■

When adding coolant

Add coolant slowly after the

hybrid system has cooled down

sufficiently. Adding cool coolant to

a hot hybrid system too quickly

can cause damage to the hybrid

system.

■

To prevent damage to the

cooling system

Observe the following precau-

tions:

●

Avoid contaminating the coolant

with foreign matter (such as

sand or dust, etc.).

●

Do not use any coolant additive.

Content .. 31 32 33 34 ..
