515

8-1. Specifications

8

Vehicle

 specifications

Pneumatic tire

A mechanical device made of rubber, chemi-
cals, fabric and steel or other materials, that,
when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid
that sustains the load

Radial ply tire

A pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread

Reinforced tire

A tire designed to operate at higher loads and at
higher inflation pressures than the correspond-
ing standard tire

Section width

The linear distance between the exteriors of the
sidewalls of an inflated tire, excluding elevations
due to labeling, decoration, or protective bands

Sidewall

That portion of a tire between the tread and
bead

Sidewall separation

The parting of the rubber compound from the
cord material in the sidewall

Snow tire

A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when using
the snow traction test as described in ASTM F-
1805-00, Standard Test Method for Single
Wheel Driving Traction in a Straight Line on
Snow-and Ice-Covered Surfaces, and which is
marked with an Alpine Symbol (

) on at least

one sidewall

Test rim

The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire

Tread

That portion of a tire that comes into contact
with the road

Tread rib

A tread section running circumferentially around
a tire

Tread separation

Pulling away of the tread from the tire carcass

Tire related term

Meaning

516

8-1. Specifications

*

: Table 1



 Occupant loading and distribution for vehicle normal load for

various designated seating capacities

Treadwear indicators
(TWI)

The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire
assembly securely during testing

Designated seating

capacity, Number of

occupants

Vehicle normal load,

Number of occupants

Occupant distribution in

a normally loaded vehi-

cle

2 through 4

2

2 in front

5 through 10

3

2 in front, 1 in second

seat

11 through 15

5

2 in front, 1 in second

seat, 1 in third seat, 1 in

fourth seat

16 through 20

7

2 in front, 2 in second

seat, 2 in third seat, 1 in

fourth seat

Tire related term

Meaning

517

8-2. Customization

8

Vehicle

 specifications

8-2.Customization

■

Changing using the Multi-
media Display

1

select

 on the main menu.

2

Select “Vehicle customize”
on the sub menu.

3

Select the item to change the
settings of from the list.

Various setting can be changed.

Refer to the list of settings that can

be changed for details.
For functions that can be turned
on/off, select

 (ON)/



(OFF).
The settings, such as the volume

and sensor sensitivity can be

changed by dragging the round

icon on the display.

■

Changing using the multi-
information display (with 7-
inch display)

1

Press

 or

 of the meter

control switches and select

.

2

Press

 or

 of the meter

control switches, select the
item.

3

To switch the function on and
off, press

 to switch to the

desired setting.

4

To perform detailed setting of
functions that support
detailed settings, press and
hold

 and display the set-

ting screen.

The method of performing detailed

setting differs for each screen.

Please refer to the advice sentence

displayed on the screen.
To go back to the previous screen

or exit the customize mode, press

.

■

Changing using the multi-
information display (with
12.3-inch display)

1

Press and hold

 to display

the cursor on the content dis-
play area (center) of the
multi-information display.

2

Press

 or

 of the meter

control switches to select



and press

.

3

Press

 or

 of the meter

control switches, select the
item.

4

To switch the function on and
off, press

 to switch to the

desired setting.

5

To perform detailed setting of
functions that support

Customizable features

Your vehicle includes a vari-
ety of electronic features
that can be personalized to
suit your preferences. The
settings of these features
can be changed using the
multi-information display,
navigation/multimedia sys-
tem, or at your Toyota
dealer.

Customizing vehicle fea-
tures

518

8-2. Customization

detailed settings, press and
hold

 and display the set-

ting screen.

The method of performing detailed

setting differs for each screen.

Please refer to the advice sentence

displayed on the screen.
To go back to the previous screen

or exit the customize mode, press

.

■

When customizing using the

navigation/multimedia system

or multi-information display

Stop the vehicle in a safe place,

apply the parking brake, and shift

the shift lever to P. Also, to prevent

12-volt battery discharge, leave the

hybrid system operating while cus-

tomizing the features.

Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further
details.

Vehicles with navigation system or multimedia system: Settings

that can be changed using the navigation system or multimedia sys-
tem

Settings that can be changed using the multi-information display
Settings that can be changed by your Toyota dealer

Definition of symbols: O = Available, – =Not available

■

Predictive efficient drive

*1

 (



P.73)

*1

:Vehicles with navigation system

*2

*2

:This function can only be used in the mainland U.S.A. It cannot be used

in other states and territories, including Alaska and Hawaii.

WARNING

■

During customization

As the hybrid system needs to be

operating during customization,

ensure that the vehicle is parked

in a place with adequate ventila-

tion. In a closed area such as a

garage, exhaust gases including

harmful carbon monoxide (CO)

may collect and enter the vehicle.

This may lead to death or a seri-

ous health hazard.

NOTICE

■

During customization

To prevent 12-volt battery dis-

charge, ensure that the hybrid

system is operating while custom-

izing features.

Customizable Features

Function

Default setting

Customized

setting

Predictive efficient drive

On

Off

O

–

–

A

B
C

A

B

C

519

8-2. Customization

8

Vehicle

 specifications

■

Alarm

*

 (



P.81)

*

: For Canada

■

Gauges, meters and multi-information display (with 7-inch
display) (



P.93, 105)

Function

Default setting

Customized

setting

Activates the alarm when the
doors are unlocked using the
mechanical key

On

Off

–

–

O

Function

*1

Default setting

Customized

setting

Language

*2

“English”
(English)

“Français can-

adien” (Cana-

dian French)

–

O

–

“Español mexi-

cano” (Mexi-

can Spanish)

Units

*2

miles (MPG

US)

km (km/L)

–

O

–

km (L/100 km)

miles (MPG

Imperial)

Speedometer display

*3

Analog

Digital

–

O

–

EV indicator

On

Off

–

O

–

“Eco Guidance” (ECO Accel-
erator Guidance)

On

Off

–

O

–

“Fuel Economy”

“Total Aver-

age”

“Trip Average”

–

O

–

“Tank Aver-

age”

Audio system linked display

On

Off

–

O

–

Energy monitor

On

Off

–

O

–

AWD system display

On

Off

–

O

–

Drive information type

Trip

Total

–

O

–

A

B

C

A

B

C

520

8-2. Customization

*1

:For details about each function:



P.110

*2

:The default setting varies according to country.

*3

:Vehicles with 7-inch display only

■

Gauges, meters and multi-information display (with 12.3-inch
display) (



P.99, 115)

Drive information items (first
item)

Distance

Average

Speed

–

O

–

Total Time

Drive information items (sec-
ond item)

Total Time

Average

Speed

–

O

–

Distance

“Trip Summary”

“ECO Guid-

ance”

“Drive Info”

–

O

–

Pop-up display

On

Off

–

O

–

Multi-Information display off

Off

On

–

O

–

Convenience Services (Sug-
gestion function)

On

On (when the

vehicle is

stopped)

O

–

O

Off

Function

*1

Default setting

Customized

setting

Language

“English”
(English)

“Français can-

adien” (Cana-

dian French)

–

O

–

“Español mexi-

cano” (Mexi-

can Spanish)

Units

*2

miles (MPG

US)

km (km/L)

–

O

–

km (L/100 km)

miles (MPG

Imperial)

Function

*1

Default setting

Customized

setting

A

B

C

A

B

C

521

8-2. Customization

8

Vehicle

 specifications

Meter Type

*3

–

O

–

*3

Meter Style

smart

casual

–

O

–

tough

sporty

Tachometer display

*4

Hybrid system

indicator

Speedometer

–

O

–

EV indicator

On

Off

–

O

–

Fuel Economy

The average

fuel economy

after starting

The average

fuel economy

since the func-

tion was reset

–

O

–

ECO Guidance (ECO Accel-
erator Guidance)

On

Off

–

O

–

Drive information items (first
item)

Distance

Average

Speed

–

O

–

Total Time

Drive information items (sec-
ond item)

Total Time

Average

Speed

–

O

–

Distance

TRIP A information items

Distance

Average

Speed

–

O

–

Total time

TRIP B information items

Average

Speed

Distance

–

O

–

Total time

Pop-up display

On

Off

–

O

–

Function

*1

Default setting

Customized

setting

A

B

C

522

8-2. Customization

*1

:For details about each function:



P.121

*2

:The default setting varies according to country.

*3

:The on/off operation of the widget can be changed.

*4

:The setting may not be changed depending on currently selected meter

type.

■

Door lock (



P.135, 483)

■

Rear seat reminder (



P.138)

Convenience Services (Sug-
gestion function)

On

On (when the

vehicle is

stopped)

O

–

O

Off

Function

Default setting

Customized

setting

Unlocking using a key

Driver’s door

unlocked in

first step, all

doors

unlocked in

second step

All doors

unlocked in

first step

–

–

O

Automatic door locking func-
tion

Shift position

linked door

locking opera-

tion

Off

O

–

O

Speed linked

door locking

operation

Automatic door unlocking
function

Shift position

linked door

unlocking
operation

Off

O

–

O

Driver’s door

linked door

unlocking
operation

Function

Default setting

Customized

setting

Rear seat reminder function

On

Off

–

O

–

Function

*1

Default setting

Customized

setting

A

B

C

A

B

C

A

B

C

523

8-2. Customization

8

Vehicle

 specifications

■

Smart key system

*

 and wireless remote control (



P.132, 155)

*

: If equipped

■

Smart key system

*1

 (



P.155)

*1

:If equipped

*2

:This setting can be changed when the smart door unlocking setting is set

to Driver’s door.

Function

Default setting

Customized

setting

Operation signal (emer-
gency flashers)

On

Off

O

–

O

Operation buzzer volume

5

Off

O

–

O

1 to 7

Time elapsed before the
automatic door lock function
is activated if a door is not
opened after being unlocked

60 seconds

Off

O

–

O

30 seconds

120 seconds

Open door reminder buzzer
(When locking the vehicle)

On

Off

–

–

O

Function

Default setting

Customized

setting

Smart key system

On

Off

–

–

O

Smart door unlocking

Driver’s door

All the doors

O

–

O

Number of consecutive door
lock operations

2 times

As many as

desired

–

–

O

Time elapsed before unlock-
ing all the door when gripping
and holding the driver’s door
handle

*2

2 seconds

Off

–

–

O

1.5 seconds

2.5 seconds

A

B

C

A

B

C

524

8-2. Customization

■

Wireless remote control (



P.132)

*

: If equipped

■

Power back door

*1

 (



P.145)

Function

Default setting

Customized

setting

Wireless remote control

On

Off

–

–

O

Unlocking operation

Driver’s door

unlocked in

first step, all

doors

unlocked in

second step

All doors

unlocked in

first step

O

–

O

Theft deterrent panic mode

On

Off

–

–

O

Locking operation when door
opened

On

Off

O

–

O

The function that activates
the

 switch of the wire-

less remote control when
locking the door

*

 (



P.145)

On (Unlocking

all the door)

Off

–

–

O

On (Unlocking

back door

only)

Function

Default setting

Customized

setting

Power back door operations

On

Off

–

O

–

Operations of the power
back door switch on the
instrument panel

Press and hold

One short

press

–

–

O

 switch of the wireless

remote control operation

Press and hold

One short

press

–

–

O

Push twice

Off

Operation buzzer volume

3

1

–

O

–

2

Operation buzzer while the
back door is operating

*2

Off

On

–

–

O

A

B

C

A

B

C

525

8-2. Customization

8

Vehicle

 specifications

*1

:If equipped

*2

:The operation buzzer that sounds when the back door begins to operate

cannot be turned off.

*3

:The open position is set by the power back door switch. (



P.154)

*4

:When the towing hitch is installed, Hands Free Power Back Door does

not work.

■

Driving position memory

*

 (



P.163)

*

: If equipped

■

Power windows, and moon roof

*

 or panoramic moon roof

*



(



P.183, 186, 189)

Opening angle

5

1 to 4

–

O

–

User setting

*3

Power back door open oper-
ation when the back door
opener switch is pressed

On

Off

–

–

O

Back door closing assist

On

Off

–

–

O

Hands Free Power Back
Door

*1, 4

On

Off

–

O

–

Function

Default setting

Customized

setting

Function to prevent contact
between the head restraint
and ceiling (while moving to
memory location)

On

Off

–

–

O

Function

Default setting

Customized

setting

Key linked operation (open)

Off

On

–

–

O

Key linked operation (close)

Off

On

–

–

O

Wireless remote control
linked operation (open)

Off

On

–

–

O

Function

Default setting

Customized

setting

A

B

C

A

B

C

A

B

C

526

8-2. Customization

*

: If equipped

■

Moon roof

*

 (



P.186)

*

: If equipped

■

Lights (



P.237)

*

: Except for Canada

Wireless remote control
linked operation signal
(buzzer)

On

Off

–

–

O

Side windows open warning
function

On

Off

–

–

O

Sliding roof open warning
function

On

Off

–

–

O

Function

Default setting

Customized

setting

Automatic mode

On

Off

–

–

O

Opening direction when
using the key linked opera-
tion

Slide

Tilt up

–

–

O

Opening direction when
using the wireless remote
control linked operation

Slide

Tilt up

–

–

O

Function

Default setting

Customized

setting

Daytime Running Lights

*

On

Off

O

–

O

Light reminder buzzer

On

Off

–

–

O

Function

Default setting

Customized

setting

A

B

C

A

B

C

A

B

C

527

8-2. Customization

8

Vehicle

 specifications

■

Automatic light control system

*

 (



P.237)

*

: If equipped

■

Rear window wiper (



P.247)

■

PCS (Pre-Collision System) (



P.257)

*

: The system is automatically enabled each time the power switch is turned

to ON.

Function

Default setting

Customized

setting

Light sensor sensitivity

Standard

Brighter

O

–

O

Bright

Dark

Darker

Time elapsed before head-
lights automatically turn off
after doors are closed

30 seconds

Off

O

–

O

60 seconds

90 seconds

Windshield wiper linked
headlight illumination

On

Off

–

–

O

Function

Default setting

Customized

setting

Back door opening linked
rear window wiper stop func-
tion

Off

On

–

–

O

Washer linked rear window
wiper operation

On

Off

–

–

O

Shift position linked rear win-
dow wiper operation
(



P.248)

Only once

Off

–

–

O

Continuous

Function

Customized setting

PCS (Pre-Collision System)

*

On, Off

–

O

–

Adjust alert timing

Early, Middle, Late

–

O

–

A

B

C

A

B

C

A

B

C

528

8-2. Customization

■

LTA (Lane Tracing Assist) (



P.268)

■

RSA (Road Sign Assist)

*

 (



P.279)

*

: If equipped

■

BSM (Blind Spot Monitor)

*

 (



P.293)

*

: If equipped

Function

Customized setting

Lane centering function

On, Off

–

O

–

Alert sensitivity

High, Standard

–

O

–

Vehicle sway warning func-
tion

On, Off

–

O

–

Vehicle sway warning sensi-
tivity

High, Standard, Low

–

O

–

Function

Customized setting

RSA (Road Sign Assist)

On, Off

–

O

–

Excess speed notification
method

No notification, Display only,

Display and buzzer

–

O

–

Excess speed notification
level

1 mph (2 km/h), 3 mph (5

km/h), 5 mph (10km/h)

–

O

–

Other notifications method
(No-entry notification)

No notification, Display only,

Display and buzzer

–

O

–

Function

Default setting

Customized

setting

BSM (Blind Spot Monitor)

On

Off

–

O

–

Outside rear view mirror indi-
cator brightness

Bright

Dim

–

O

–

Alert timing for presence of
approaching vehicle (sensi-
tivity)

Intermediate

Early

–

O

–

Late

Only when

vehicle

detected in

blind spot

A

B

C

A

B

C

A

B

C

529

8-2. Customization

8

Vehicle

 specifications

■

RCTA (Rear Crossing Traffic Alert) function

*1

 (



P.307)

*1

:If equipped

*2

:This setting is linked with the buzzer volume of the intuitive parking

assist.

■

Intuitive parking assist

*1

 (



P.298)

*1

:If equipped

*2

:This setting is linked with the buzzer volume of the RCTA (Rear Crossing

Traffic Alert) function.

■

PKSB (Parking Support Brake)

*

 (



P.312)

*

: If equipped

■

Automatic air conditioning system (



P.342)

Function

Default setting

Customized

setting

RCTA (Rear Crossing Traf-
fic Alert) function

On

Off

–

O

–

Buzzer volume

*2

Level 2

Level 1

–

O

–

Level 3

Function

Default setting

Customized

setting

Intuitive parking assist

On

Off

–

O

O

Buzzer volume

*2

2

1

–

O

O

3

Function

Default setting

Customized

setting

PKSB (Parking Support
Brake) function

On

Off

–

O

–

Function

Default setting

Customized

setting

A/C Auto switch operation

On

Off

O

–

O

Switching to the outside air
mode when the vehicle is
parked

On

Off

–

–

O

A

B

C

A

B

C

A

B

C

A

B

C

530

8-2. Customization

■

Illumination (



P.352)

*1

:Vehicles with smart key system only

*2

:If equipped

■

Vehicle customization

●

When the speed linked door locking function and shift position linked door

locking function are both on, the door lock operates as follows.

• If the vehicle is started with all the doors locked, the speed linked door

locking function would not operate.

• If the vehicle is started with any door unlocked, the speed linked door lock-

ing function will operate.

• When shifting the shift lever to any position other than P, all the doors will

be locked.

●

When the smart key system is off, the selecting door to unlock cannot be

customized.

●

When the doors remain closed after unlocking the doors and the auto-

matic door lock function is activated, the signals will be generated in

accordance with the Operation signal (buzzer) and the Operation signal

(emergency flashers) settings.

Function

Default setting

Customized

setting

Time elapsed before the inte-
rior lights turn off

15 seconds

Off

O

–

O

7.5 seconds

30 seconds

Operation after the power
switch is turned off

On

Off

–

–

O

Operation when the doors
are unlocked

On

Off

–

–

O

Operation when you
approach the vehicle with the
electronic key on your per-
son

*1

On

Off

–

–

O

Footwell lighting

*2

On

Off

–

–

O

A

B

C
