356

6-2. Using the interior lights

■

Turning the door position
on

Press the door-linked interior
light switch

The lights are turned on and off
according to whether the doors are
opened/closed.

■

Turning the lights on/off

Touch the light

The rear personal lights turn on/off
along with the interior lights.

■

Turning the lights on/off

Touch the light

■

Turning the lights on/off

Press the switch

The rear personal lights turn on/off
along with the interior lights.

Using the multimedia display,
one of 8 colors of following lights
can be selected. However, it
cannot be changed individually.



Inside door handle lights

Operating the interior
lights

Operating the front per-
sonal lights

Operating the rear per-
sonal lights

Changing the illumina-
tion color (if equipped)

357

6-2. Using the interior lights

6

Interior

 featur

es



Door trim ornament lights



Cup holder lights



Instrument panel ornament
lights

1

Select

.

2

Select “Illumination”.

3

Select the desired color.

■

Illuminated entry system

The lights automatically turn on/off

according to the power switch

mode, the presence of the elec-

tronic key, whether the doors are

locked/unlocked, and whether the

doors are open/closed.

■

To prevent the 12-volt battery

from being discharged

If the interior lights remain on when

the power switch is turned off, the

lights will go off automatically after

20 minutes.

■

When the interior lights or front

personal lights do not respond

as normal

●

When water, dirt, etc., have

adhered to the lens surface

●

When operated with a wet hand

●

When wearing gloves, etc.

■

The interior lights may turn on

automatically when

If any of the SRS airbags deploy

(inflate) or in the event of a strong

rear impact, the interior lights will

turn on automatically.
The interior lights will turn off auto-

matically after approximately 20

minutes.
The interior lights can be turned off

manually. However, in order to help

prevent further collisions, it is rec-

ommended that they be left on until

safety can be ensured.
(The interior lights may not turn on

automatically depending on the

force of the impact and conditions of

the collision.)

■

Customization

Some functions can be customized.

(



P.512)

NOTICE

■

To prevent 12-volt battery dis-

charge

Do not leave the lights on longer

than necessary when the fuel cell

system is off.

■

Removing light lenses

Never remove the lens for the

interior lights and front personal

lights. Otherwise, the lights will be

damaged. If a lens needs to be

removed, contact your Toyota

dealer.

358

6-3. Using the storage features

6-3.Using the storage features

Auxiliary boxes

*

 (



P.360)

Cup holders (



P.359)

Console box (



P.360)

Glove box (



P.358)

*

: If equipped

Pull up the lever to open.

List of storage features

Location of the storage features

WARNING

■

Items that should not be left

in the storage spaces

Do not leave glasses, lighters or

spray cans in the storage spaces,

as this may cause the following

when cabin temperature becomes

high:

●

Glasses may be deformed by

heat or cracked if they come

into contact with other stored

items.

●

Lighters or spray cans may

explode. If they come into con-

tact with other stored items, the

lighter may catch fire or the

spray can may release gas,

causing a fire hazard.

Glove box

359

6-3. Using the storage features

6

Interior

 featur

es

1

Unlock with the mechanical
key

2

Lock with the mechanical key

■

Glove box light

The glove box light turns on when

the tail lights are on.

■

Trunk opener main switch

The trunk opener main switch is

located in the glove box. (



P.135)



Front



Rear (vehicles without rear
seat heater)

Press in and release the button.



Rear (vehicles with rear seat
heater)

Press in and release the button.

WARNING

■

Caution while driving

Keep the glove box closed. In the

event of sudden braking or sud-

den swerving, an accident may

occur due to an occupant being

struck by the open glove box or

the items stored inside.

Cup holders

WARNING

■

Items unsuitable for the cup

holder

Do not place anything other than

cups or beverage cans in the cup

holders. Inappropriate items must

not be stored in the cup holders

even if the lid is closed.

Other items may be thrown out of

the holders in the event of an

accident or sudden braking and

cause injury. If possible, cover hot

drinks to prevent burns.

■

When not in use

Keep the cup holders closed.

Injuries may result in the event of

an accident or sudden braking.

360

6-3. Using the storage features

Press a button to open the con-
sole box.



Overhead (vehicles without
electronic sunshade)

Push in and release the auxiliary
box.

This box is useful for temporarily
storing the small items.



Rear seat (vehicles with rear
seat heater)

Pull the armrest down then push
the knob and lift the lid to open
it.

Console box

WARNING

■

Caution while driving

Keep the console box closed.

Injuries may result in the event of

an accident or sudden braking.

Auxiliary boxes

WARNING

■

Caution while driving

Do not leave the auxiliary box

open while driving.

Items may fall out and cause

death or serious injury in case of

an accident or sudden stop.

■

Items unsuitable for storing

(overhead)

Do not store items heavier than

0.4 lb. (0.2 kg).

Doing so may cause the auxiliary

box to open and the items inside

may fall out, resulting in an acci-

dent.

361

6-3. Using the storage features

6

Interior

 featur

es



Side covers

Lift the side covers and remove it.



Type A



Type B



Luggage mat

1

Pull the strap upwards and lift
up the luggage mat.

2

Lift the luggage mat until it
engages with the hook.



Type A

The warning reflector can be
stowed underneath the luggage
mat.

Trunk features

Luggage mats

NOTICE

■

To prevent damage to the

hook for the luggage mat

Do not hang a grocery bag or any

other object from the hook.

Warning reflector

362

6-3. Using the storage features



Type B

Using a belt to hold a warning
reflector on the luggage mat.

363

6-4. Using the other interior features

6

Interior

 featur

es

6-4.Using the other interior features

*

: If equipped

1

Open

*

2

Close

*

*

: To stop the electronic sunshade

partway, lightly press the either
end of the switch.

■

The electronic sunshade can be

operated when

The power switch is in ON.

■

Jam protection function for the

electronic sunshade

●

If an object becomes jammed

between the electronic sunshade

and the sunshade frame while the

electronic sunshade is closing, the

electronic sunshade movement is

stopped and the electronic sun-

shade is opened slightly.

●

When the jam protection function

has operated, even if the

“CLOSE” side of the switch is

pressed again, the electronic sun-

shade will not move in the close

direction until the reverse opera-

tion has stopped completely.

●

The electronic sunshade may

operate in reverse if the electronic

sunshade is subject to an impact

due to the surroundings or the

driving conditions.

■

When the electronic sunshade

does not close normally

Perform the following initialization

procedure.

1

Turn the power switch to ON.

2

Press and hold the “CLOSE”

side of the switch.

It closes until it is near the fully

closed position and then stops. After

that, it operates in the opening

direction then closes to the fully

closed position.
If the switch is released at the incor-

rect time, the procedure will have to

be performed again from the begin-

ning.
If the automatic opening and closing

function does not work normally

even after performing the operations

above, have the vehicle inspected

by your Toyota dealer.

Electronic sunshade

*

Use the overhead switches
to operate the electronic
sunshade.

Operating the electronic
sunshade

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

364

6-4. Using the other interior features

The USB Type-C charging ports
are used to supply 3 A of elec-
tricity at 5 V to external devices.
The USB Type-C charging ports
are for charging only. They are
not designed for data transfer or
other purposes.
Depending on the external
device, it may not charge prop-
erly. Refer to the manual
included with the device before
using a USB charging port.
Refer to “MULTIMEDIA
OWNER’S MANUAL” for USB
Type-A information.

■

Using the USB Type-C
charging ports



In the console box

Open the console box.



Rear of the console box

Open the lid.

WARNING

■

Opening and closing the elec-

tronic sunshade

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when the elec-

tronic sunshade is being oper-

ated.

●

Do not let a child operate the

electronic sunshade. Closing

the electronic sunshade on

someone can cause death or

serious injury.

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

●

The jam protection function may

not work if something gets

caught just before the electronic

sunshade is fully closed. Also,

the jam protection function is

not designed to operate while

the switch is being pressed.

Take care so that your fingers,

etc., do not get caught.

■

To prevent burns or injuries

Do not touch the area between

the underside of the panoramic

moon roof and the electronic sun-

shade. Your hand may get caught

and you could injure yourself.

Also, if the vehicle is left in direct

sunlight for a long time, the under-

side of the panoramic moon roof

could become very hot and could

cause burns.

Other interior features

USB Type-C charging
ports

365

6-4. Using the other interior features

6

Interior

 featur

es

■

The USB Type-C charging ports

can be used when

The power switch is in ACC or ON.

■

Situations in which the USB

Type-C charging ports may not

operate correctly

●

If a device which consumes more

than 3 A at 5 V is connected

●

If a device designed to communi-

cate with a personal computer,

such as a USB memory device, is

connected

●

If the connected external device is

turned off (depending on device)

●

If the temperature inside the vehi-

cle is high, such as after the vehi-

cle has been parked in the sun

■

About connected external

devices

Depending on the connected exter-

nal device, charging may occasion-

ally be suspended and then start

again. This is not a malfunction.

A portable device can be
charged by just placing Qi stan-
dard wireless charge compatible
portable devices according to
the Wireless Power Consortium,
such as smartphones and
mobile batteries, etc., on the
charge area.
This function cannot be used
with portable devices that are
larger than the charging area.

NOTICE

■

To prevent damage to the

USB Type-C charging ports

●

Do not insert foreign objects into

the ports.

●

Do not spill water or other liq-

uids into the ports.

●

When the USB Type-C charging

ports are not in use, close the

lids. If a foreign object or liquid

enters a port may cause a short

circuit.

●

Do not apply excessive force to

or impact the USB Type-C

charging ports.

●

Do not disassemble or modify

the USB Type-C charging ports.

■

To prevent damage to exter-

nal devices

●

Do not leave external devices in

the vehicle. The temperature

inside the vehicle may become

high, resulting in damage to an

external device.

●

Do not push down on or apply

unnecessary force to an exter-

nal device or the cable of an

external device while it is con-

nected.

■

To prevent 12-volt battery dis-

charge

Do not use the USB Type-C

charging ports for a long period of

time with the fuel cell system

stopped.

Wireless charger (if
equipped)

366

6-4. Using the other interior features

Also, depending on the portable
device, it may not operate as
normal. Please read the opera-
tion manual for portable devices
to be used.

■

The “Qi” symbol

The “Qi” symbol is a trademark
of the Wireless Power Consor-
tium.

■

Name for all parts

Power supply switch

Operation indicator light

Charging tray

Charge area

*

*

: Compatible portable devices and

the wireless charger contain
charging coils. The charging coil
inside the wireless charger can

move within the area around the
center of the charging tray.
When the charging coil inside a
portable device is detected within
the charging area, the charging
coil in the wireless charger will
move near the other coil and
charging will begin. If the
charging coil inside the portable
device is moved out of the
charging area, charging will be
stopped automatically.
Additionally, if 2 or more portable
devices are placed on the
charging tray at the same time,
each charging coil may not be
detected correctly and charging
may not be possible.

■

Using the wireless charger

1

Press the power supply
switch of the wireless char-
ger.

Switches on and off with each

press of the power supply switch.
When turned on, the operation indi-

cator light (green) comes on.
Even with the fuel cell system off,

the on/off state of the power supply

switch is memorized.

2

Place the charging side of
the portable device down.

Place the portable device so that it

is centered in the charging area

with its charging surface facing the

367

6-4. Using the other interior features

6

Interior

 featur

es

wireless charger.
Depending on the portable device,

its charging coil may not be in the

center of the device. In this case,

place the portable device so that its

charging coil is centered in the

charging area.
While charging, the operation indi-

cator light (orange) will be illumi-

nated.
If charging does not begin, move

the portable device as close to the

center of the charging area as pos-

sible.
If charging is not performed, the

operation indicator light will slowly

illuminate in green and orange

alternatively and a sound of

charging coil operation may be

heard repeatedly.
When charging is complete, the

operation indicator light (green)

comes on.

■

Recharging function



When charging is complete
and after a fixed time in the
charge suspension state,
charging restarts.



If a portable device is moved
significantly within the
charging area, the charging
coil may disconnect and
charging may temporarily be
stopped. However, if a
charging coil is detected

within the charging area, the
charging coil inside the wire-
less charger will move near
the other coil and charging
will resume.

■

Lighting conditions of oper-
ation indicator light

*1

:While in standby, charging power

is not output. If a metal object is
placed on the charging tray in
this state, the object will not heat
up.

*2

:Depending on the portable

device, there are cases where
the operation indicator light will
continue being lit up orange even
after the charging is complete.



When the operation indicator
light flashes

When an error occurs, the opera-
tion indicator light flashes an
orange color.
Handle the error based on the fol-

Operation

indicator

light

Conditions

Turning off

When the Wireless
charger power supply
is off

Green
(comes
on)

On Standby (charging
possible state)

*1

When charging is com-
plete

*2

Orange
(comes
on)

When placing the por-
table device on the
charging area (detect-
ing the portable device)

Charging

368

6-4. Using the other interior features

lowing tables.
• Flashing repeatedly once every

second (Orange)

• Repeatedly flashes 3 times con-

tinuously (Orange)

• Repeatedly flashes 4 times con-

tinuously (Orange)

■

The wireless charger can be

operated when

The power switch is in ACC or ON.

■

Usable portable devices

●

Qi standard wireless charge stan-

dard can be used on compatible

devices. However, not all Qi stan-

dard devices and compatibility are

guaranteed.

●

Starting with mobile phones and

smartphones, it is aimed for low

power electrically supplied porta-

ble devices of no more than 5W.

■

Using the smart key system

During charging, when the smart

key system searches for an elec-

tronic key, charging may be tempo-

rarily suspected.

■

When covers and accessories

are attached to portable devices

Do not charge in situations where

cover and accessories not able to

handle Qi are attached to the porta-

ble device. Depending on the type

of cover (including the certain genu-

ine manufacture parts) and acces-

sory, it may not be possible to

charge. When charging is not per-

formed even with the portable

device placed on the charge area,

Suspected

causes

Handling method

Vehicle to char-
ger communica-
tion failure.

If the fuel cell
system is operat-
ing, stop the fuel
cell system and
then restart it. If
the power switch
is in ACC, start
the fuel cell sys-
tem.

Suspected

causes

Handling method

A foreign sub-
stance is
between the por-
table device and
charge area.

Remove the for-
eign substance
from between
portable device
and the charge
area.

The portable
device is out of
sync due to the
device being
shifted from the
center of the
charge area.

Place the porta-
ble device near
the center of the
charge area.
Also, if a case or
cover is installed
to the portable
device, remove
it.

Suspected

causes

Handling method

Temperature ris-
ing within the
wireless charger.

Stop charging,
remove the por-
table device from
the charging tray,
and wait for the
temperature to
decrease before
attempting to
begin charging
again.

369

6-4. Using the other interior features

6

Interior

 featur

es

remove the cover and accessories.

■

While charging, noise enters

the AM radio

Turn off the wireless charger and

confirm that the noise has

decreased. If the noise decreases,

continuously pushing the power

supply switch of the wireless char-

ger for 2 seconds, the frequency of

the charger can be changed and the

noise can be reduced. Also, on that

occasion, the operation indicator

light will flash orange 2 times.

■

Important points of the wire-

less charger

When charging, the wireless

charging device and portable device

will get warmer, however this is not

a malfunction.

When a portable device gets warm

while charging, charging may stop

due to the protection function on the

portable device side. In this case,

when the temperature of the porta-

ble device drops significantly,

charge again.

■

Operation sounds

Operation sounds may be heard

when the power switch is pressed to

change to ACC or ON, or when a

portable device is being detected.

This does not indicate a malfunc-

tion.

■

Certification



P.566

WARNING

■

Caution while driving

When charging a portable device,

for safety reasons, the driver

should not operate the main part

of the portable device while driv-

ing.

■

Precautions for when driving

Do not charge small, lightweight

portable devices, such as wireless

earbuds, while driving. Light-

weight devices may fly off of the

charging tray, possibly leading to

an accident.

■

Caution regarding interfer-

ence with electronic devices

People with implantable cardiac

pacemakers, cardiac resynchroni-

zation therapy-pacemakers or

implantable cardioverter defibrilla-

tors, as well as any other electri-

cal medical device, should consult

their physician about the usage of

the wireless charger. The opera-

tions of the wireless charger may

have an affect on medical

devices.

■

To prevent damage or burns

Observe the following precau-

tions.

Failure to do so may result in a

possibility of equipment failure

and damage, catch fire, burns due

to overheat.

●

Do not insert any metallic

objects between the charging

area and the portable device

while charging

●

Do not place containers with liq-

uid such as water on the wire-

less charger.

●

Do not attach stickers, metallic

objects, etc., to the charger area

or portable device

●

Do not hit or apply a strong

force

●

Do not attempt to dismantle for

disassembly or modifications

●

Do not charge portable devices

other than designated

370

6-4. Using the other interior features

WARNING

●

Do not allow magnetic objects

to come near the wireless char-

ger

●

Do not perform charging if the

charging area is dirty

●

Do not cover with cloth, etc.,

and charge

NOTICE

■

Conditions in which the func-

tion may not operate cor-

rectly

In the following conditions, it may

not operate correctly

●

The portable device is fully

charged

●

When a portable device is being

charged by a wired connection

●

There is foreign matter between

the charge area and portable

device

●

When the temperature near the

charging tray is 95°F (35°C) or

more due to being in direct sun-

light, etc.

●

The temperature of the portable

device gets higher from

charging

●

The charging surface of the por-

table device is facing up

●

When a portable device is larger

than the charging tray

●

The small portable device such

as foldable type is placed in an

area misaligned from the

charge area

●

The camera lens protrudes 0.12

in. (3 mm) or more from the sur-

face of the portable device

●

Near a TV tower, electric power

plant, gas station, radio station,

large display, airport or other

facility that generates strong

radio waves or electrical noise

●

The electronic key is not inside

the vehicle

●

When any of the following

objects are caught between the

device and charging surface,

resulting in a gap of 0.08 in. (2

mm) or more between the

charging surface of a portable

device and the charging area:

• Thick cases or covers

• Thick decorations

• A case or cover with convex

shape around the camera lens

• Accessories, such as finger

rings, straps, etc.

●

When the portable device is in

contact with, or is covered by

the following metallic objects

• Cards to which aluminum foil is

attached

• Cigarette boxes that have alu-

minum foil inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

• Metallic decorations

• Metallic cases or covers

• A case which has magnet in it

on the charging side of the por-

table device

●

When other wireless keys (that

emit radio waves) are being

used nearby

371

6-4. Using the other interior features

6

Interior

 featur

es

Pull the armrest down for use.

An assist grip installed on the
ceiling can be used to support
your body while sitting on the
seat.

NOTICE

●

When 2 or more portable

devices are placed on the

charging tray at the same time

In addition, excluding the above-
mentioned, when the charger
does not perform normally or the
operation display lamp is flashing
continuously, it is considered that
the wireless charger is malfunc-
tioning. Contact authorized Toyota
dealer.

■

To prevent failure or damage

to data

●

Do not bring magnetic cards,

such as credit cards, or mag-

netic recording media, etc.,

close to the charger while

charging, otherwise, data may

disappear under the influence of

magnetism. Also, do not bring

precision instruments such as

wrist watches, etc., close to the

charger, as such objects may

break.

●

Do not perform charging with a

contactless smart card, such as

a credit card, between the

charging surface of a portable

device and the charging area.

The IC chip in the card may

become extremely hot, possibly

damaging the portable device or

smart card.

Be extra careful to not charge a

portable device with a case or

cover which a contactless smart

card can be inserted.

●

Do not leave portable devices in

the cabin. The temperature

inside the cabin may become

high, when under the sun, and

cause damage to the device.

■

To prevent 12-volt battery dis-

charge

When the fuel cell system is

stopped, do not use the wireless

charger for a long time.

Armrest

NOTICE

■

To prevent damage to the

armrest

Do not place too much strain on

the armrest.

Assist grips
