2-1. Instrument cluster

Vehicle

statu

s information an

d in
dicator

economy.



Drive Info Items

Select to change the display of the
drive information.



TRIP A/B Items

Select to change the display of the
drive information of TRIP A/B.



REV indicator/Rev peak

Select to enable/disable display.
The engine speed at which the
REV indicator is displayed can be
changed.



Pop-up display

Select to enable/disable pop-up
displays for each relevant system.



Default settings

Select to reset the meter display
settings to the default setting.

■

Display contents (Side)



Fuel economy/Driving range



Driving support system infor-
mation display



Navigation system-linked dis-
play (if equipped)



Audio system-linked display



Drive information



Drive information of Trip A/B



Tire Pressure (



P.279)



AWD Control



Engine coolant temperature
gauge/Engine oil tempera-
ture gauge/Engine oil pres-

sure gauge



Boost gauge



G-force

Changing items to be displayed
on the side multi-information
displays. (



P.79)

■

Changing contents in a
page



P.78

■

Changing contents to be
displayed on the side
multi-information displays

Press the

meter

control switch to select a
page.

To enable page edit, press

and hold the

Press the

meter

control switch to select the
desired side multi-information
display to be changed.

Press the

meter

control switch for the side
that

is displayed to move

to a content list screen that
enables to select display/not
display each items.

Press

control

switch to select a content and

select

to set for dis-

play/not display the item.

■

Fuel economy/Driving
range



Fuel economy

Content of multi-informa-
tion display (Side)

2-1. Instrument cluster

Use the displayed values as a ref-
erence only.

Current fuel consumption

Displays instantaneous current fuel
consumption.

Average fuel economy (after
start)

The average fuel economy display
can be changed in

. (



P.78)

• Average fuel economy (after

start)

Displays the average fuel con-
sumption since engine start.
• Average fuel economy (after

reset)

Displays average fuel consumption
since display was reset.
To reset the average fuel economy

display, press and hold the

meter control switch.



Driving range

Displays driving range with remain-
ing fuel. Use the displayed values
as a reference only.
This distance is computed based
on your average fuel consumption.
As a result, the actual distance that
can be driven may differ from that
displayed.

When only a small amount of fuel is
added to the tank, the display may
not be updated.
When refueling, turn the engine
switch off. If the vehicle is refueled
without turning the engine switch
off, the display may not be updated.

■

Driving support system
information display

Select to display the operational
status of the following systems:



Dynamic radar cruise control
(



P.177)



LTA (Lane Tracing Assist)
(



P.165)



LDA (Lane Departure Alert)
(



P.170)



PCS (Pre-Collision System)
(



P.155)

■

Audio system-linked dis-
play

Displays the audio source or
track.

■

Drive information

Drive information 1
Drive information 2

Displays the following depend-
ing on which drive information
type and drive information items

2-1. Instrument cluster

Vehicle

statu

s information an

d in
dicator

were selected in

. (



P.78)



Average speed: Displays the
average vehicle speed since
engine start



Trip distance: Displays the
distance driven since engine
start



Trip time: Displays the
elapsed time since engine
start

■

Drive information of TRIP
A/B

Drive information of trip A/B 1
Drive information of trip A/B 2

Displays the following depend-
ing on which drive information
type and drive information items
were selected in

. (



P.78)



Average speed: Displays the
average vehicle speed of trip
A/B



Trip distance: Displays the
distance driven of trip A/B



Trip time: Displays the
elapsed time of trip A/B

■

AWD Control

The illustration used is intended as
an example, and may differ from the
image that is actually displayed on
the multi-information display.

Torque distribution display

Displays the drive status of each
wheel in 6 steps from 0 to 5.

■

Engine coolant tempera-
ture gauge/engine oil tem-
perature gauge/engine oil
pressure gauge

Engine coolant temperature
gauge

Displays the engine coolant tem-
perature. The display will flash if the
engine coolant temperature
exceeds 248 °F (120 °C).

Engine oil temperature
gauge

Displays the engine oil tempera-
ture. The display will flash if the

2-1. Instrument cluster

engine oil temperature exceeds
284 °F (140 °C).

Engine oil pressure gauge

Displays the engine oil pressure. A
buzzer will sound and warning
message will be displayed if the
engine oil pressure becomes low.
(



P.317)

This display is intended for use as a
guideline. Depending on factors
such as the road surface condition,
temperature and vehicle speed, the
display may not show the actual
condition of the vehicle.

■

Boost gauge

Boost gauge

Displays the boost pressure. The
display will change color if the
specified pressure is exceeded.

■

G-force

Displays lateral G-forces on the
vehicle.
Also displays, around the
periphery of the G-force display,
the left and right steering
amount, accelerator pedal input,
and brake fluid pressure.
This display is intended for use
as a guideline. Depending on
factors such as the road surface
condition, temperature and vehi-

cle speed, the display may not
show the actual condition of the
vehicle.

Record of the maximum
G-forces
Acceleration G-force on the
vehicle
Accelerator pedal input
Brake fluid pressure
Steering amount
Current G-force value (ana-
lyzed value of front/rear and
left/right G-forces)



Resetting the record of maxi-
mum G-forces

The display resets when the engine
is started.



Peak hold function

If lateral G-forces of 0.5 G or
greater are generated, the G-force
value display will be held for 2 sec-
onds.

■

G-force display

The G-force values may not be zero

even when the vehicle is parked,

such as when it is parked on an

incline.

2-1. Instrument cluster

Vehicle

s information an

d in
dicat

■

Vehicle functions and set-
tings that can be changed



P.371

■

Meter display settings



P.78

■

Suspension of the settings dis-

play

●

Some settings cannot be changed

while driving. When changing set-

tings, park the vehicle in a safe

place.

●

If a warning message is displayed,

operation of the settings display

will be suspended.

Audio system screen

Select

on the main menu.

Select “Trip information”.

Select “Current” or “History”.

■

Current fuel consumption

Resetting the consumption
data

Settings display

WARNING

■

Cautions during setting up

the display

If the engine is running when

changing the display settings,

ensure that the vehicle is parked

in a place with adequate ventila-

tion. In a closed area such as a

garage, exhaust gases including

harmful carbon monoxide (CO)

may collect and enter the vehicle.

This may lead to death or a seri-

ous health hazard.

NOTICE

■

During setting up the display

To prevent battery discharge,

ensure that the engine is running

while setting up the display fea-

tures.

Fuel consumption

information

Fuel consumption informa-
tion can be displayed on the
audio system screen.

System components

Displaying fuel consump-
tion screen

2-1. Instrument cluster

Fuel consumption in the past
15 minutes
Current fuel consumption
Average vehicle speed since
the engine was started.
Elapsed time since the
engine was started.
Cruising range

Use the displayed average fuel
consumption as a reference.
The image is an example only, and
may vary slightly from actual condi-
tions.

■

History fuel consumption

Best recorded fuel consump-
tion
Latest fuel consumption
Previous fuel consumption
record
Resetting the history data
Updating the latest fuel con-
sumption data

Use the displayed average fuel
consumption as a reference.
The image is an example only, and
may vary slightly from actual condi-
tions.

■

Updating the history data

Update the latest fuel consumption

by selecting “Update” to measure

the current fuel consumption again.

■

Resetting the data

The fuel consumption data can be

deleted by selecting “Clear data”.

■

Cruising range

Displays the estimated maximum

distance that can be driven with the

quantity of fuel remaining.
This distance is computed based on

your average fuel consumption.

As a result, the actual distance that

can be driven may differ from that

displayed.

Before driv

ing

Before driving

3-1. Key information

Keys ...............................

3-2. Opening, closing and

locking the doors

Side doors......................

Back door.......................

Smart key system ..........

3-3. Adjusting the seats

Front seats ..................

101

Rear seats...................

102

Head restraints............

103

3-4. Adjusting the steering

wheel and mirrors

Steering wheel ............

107

Inside rear view mirror

..................................

108

Outside rear view mirrors

..................................

109

3-5. Opening and closing the

windows

Power windows ...........

111

3-6. Favorite settings

My Settings .................

114

3-1. Key information

3-1.Key information

The following keys are provided
with the vehicle.

Electronic keys

• Operating the smart key system

(



P.96)

• Operating the wireless remote

control function (



P.87)

Mechanical keys
Key number plate

■

When riding in an aircraft

When bringing an electronic key

onto an aircraft, make sure you do

not press any buttons on the elec-

tronic key while inside the aircraft

cabin. If you are carrying an elec-

tronic key in your bag, etc., ensure

that the buttons are not likely to be

pressed accidentally. Pressing a

button may cause the electronic key

to emit radio waves that could inter-

fere with the operation of the air-

craft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2

years.

●

If the battery becomes low, an

alarm will sound in the cabin and a

message will be shown on the

multi-information display when the

engine is stopped.

●

To reduce key battery depletion

when the electronic key is to not

be used for long periods of time,

set the electronic key to the bat-

tery-saving mode. (



P.97)

●

As the electronic key always

receives radio waves, the battery

will become depleted even if the

electronic key is not used. The fol-

lowing symptoms indicate that the

electronic key battery may be

depleted. Replace the battery

when necessary. (



P.299)

• The smart key system or the wire-

less remote control does not oper-

ate.

• The detection area becomes

smaller.

• The LED indicator on the key sur-

face does not turn on.

●

You can replace the battery by

yourself (



P.299). However, as

there is a danger that the elec-

tronic key may be damaged, it is

recommended that replacement is

carried out by your Toyota dealer.

●

To avoid serious deterioration, do

not leave the electronic key within

3 ft. (1 m) of the following electri-

cal appliances that produce a

magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones

and battery chargers

• Recharging cellular phones or

cordless phones

• Table lamps

• Induction cookers

●

If the electronic key is near the

vehicle for longer than necessary,

even if the smart key system is not

operated, the key battery may

become depleted faster than nor-

mal.

■

Replacing the battery



P.299

■

The electronic key function is

suspended when

The electronic key function may be

suspended when the electronic key

Keys

The keys

3-1. Key information

Before driv

ing

is kept unmoved in a same location

for a certain period, such as it is left

on a same place. This is to reduce

battery consumption. The function

will be restored automatically when

the electronic key is moved, such as

it is picked up.

■

If “A New Key has been Regis-

tered Contact Your Dealer for

Details” is shown on the

multi-information display

This message will be displayed

each time the driver’s door is

opened when the doors are

unlocked from the outside for

approximately 10 days after a new

electronic key has been registered.

If this message is displayed but you

have not had a new electronic key

registered, ask your Toyota dealer to

check if an unknown electronic key

(other than those in your posses-

sion) has been registered.

The keys are equipped with the
following wireless remote con-
trol:

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject

them to strong shocks or bend

them.

●

Do not expose the keys to high

temperatures for long periods of

time.

●

Do not get the keys wet or wash

them in an ultrasonic washer

etc.

●

Do not attach metallic or mag-

netic materials to the keys or

place the keys close to such

materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or any-

thing else to the surface of the

key.

●

Do not place the keys near

objects that produce magnetic

fields, such as TVs, audio sys-

tems and induction cookers, or

medical electrical equipment,

such as low-frequency therapy

equipment.

●

Do not place the keys near

medical electrical equipment

such as low-frequency therapy

equipment or microwave ther-

apy equipment, and do not

receive medical attention with

the keys on your person.

■

Carrying the electronic key

on your person

Carry the electronic key 3.9 in.

(10 cm) or more away from elec-

tric appliances that are turned on.

Radio waves emitted from electric

appliances within 3.9 in. (10 cm)

of the electronic key may interfere

with the key, causing the key to

not function properly.

■

In case of a smart key system

malfunction or other

key-related problems



P.341

■

When an electronic key is lost



P.341

Wireless remote control

3-1. Key information

Locks the doors (

Unlocks the doors (

Opens the windows

(



P.89)

Sounds the alarm

: This setting must be customized

at your Toyota dealer.

■

Panic mode

When

is pressed for longer

than about one second, an alarm

will sound intermittently and the

vehicle lights will flash to deter any

person from trying to break into or

damage your vehicle.
To stop the alarm, press any button

on the wireless remote control.

To take out the mechanical key,
slide the release lever and
take the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one

side. If the key cannot be
inserted in a lock cylinder, turn it
over and re-attempt to insert it.
After using the mechanical key,
store it in the electronic key.
Carry the mechanical key
together with the electronic key.
If the electronic key battery is
depleted or the entry function
does not operate properly, you
will need the mechanical key.
(



P.341)

■

If you lose your mechanical

keys



P.341

■

If a wrong key is used

The key cylinder rotates freely, iso-

lated from the internal mechanism.

Using the mechanical key

3-2. Opening, closing and locking the doors

Before driv

ing

3-2.Opening, closing and locking the doors

■

Smart key system

Carry the electronic key to
enable this function.

Grip the driver’s door handle
to unlock the door. Holding
the driver’s door handle for
approximately 2 seconds
unlocks all the doors. Grip
the front passenger’s door
handle to unlock all the
doors.

Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for 3
seconds after the doors are locked.

: The door unlock settings can be

changed. (



P.89, 371)

Touch the lock sensor (the
indentation on the side of the
front door handle) to lock all
the doors.

Check that the door is securely
locked.

■

Wireless remote control

Locks all the doors

Check that the door is securely
locked.

Unlocks all the doors

Pressing the button unlocks the
driver’s door. Pressing the button
again within 5 seconds unlocks the
other doors.
Press and hold to open the win-
dows.

: This setting must be customized

at your Toyota dealer.

■

Switching the door unlock func-

tion

It is possible to set which doors the

entry function unlocks using the

wireless remote control.

Turn the engine switch off.

When the indicator light on the

key surface is not on, press and
hold

for approxi-

mately 5 seconds while pressing
and holding

The setting changes each time an

operation is performed, as shown

below. (When changing the setting

continuously, release the buttons,

wait for at least 5 seconds, and

repeat step

Side doors

Unlocking and locking the
doors from the outside

3-2. Opening, closing and locking the doors

For vehicles with an alarm: To pre-

vent unintended triggering of the

alarm, unlock the doors using the

wireless remote control and open

and close a door once after the set-

tings have been changed. (If a door

is not opened within 60 seconds
after

is pressed, the doors will

be locked again and the alarm will

automatically be set.)

In case that the alarm is triggered,

immediately stop the alarm. (



P.65)

■

Operation signals

A buzzer sounds and the emer-

gency flashers flash to indicate that

the doors have been

locked/unlocked using the entry

function or wireless remote control.

(Locked: Once; Unlocked: Twice)
A buzzer sounds to indicate that the

windows are operating.

■

Security feature

If a door is not opened within

approximately 60 seconds after the

vehicle is unlocked using the entry

function or wireless remote control,

the security feature automatically

locks the vehicle again.

■

When the door cannot be

locked by the lock sensor on

the surface of the front door

handle

If the doors cannot be locked by

touching the lock sensor with a fin-

ger, touch the lock sensor with the

palm of your hand.
If you are wearing gloves, remove

them.

■

Door lock buzzer

If an attempt to lock the doors using

the entry function or wireless remote

control is made when a door is not

fully closed, a buzzer will sound

continuously for 5 seconds. Fully

close the door to stop the buzzer,

and lock the doors again.

■

Alarm (if equipped)

Locking the doors will set the alarm

system. (



P.65)

■

Conditions affecting the opera-

tion of the smart key system or

wireless remote control



P.97

Multi-informa-

tion display/Beep

Unlocking func-

tion

Exterior: Beeps 3

times

Interior: Pings

once

Holding the
driver’s door
handle unlocks
only the driver’s
door.

Holding the front
passenger’s
door handle
unlocks all the
doors.

Exterior: Beeps

twice

Interior: Pings

once

Holding either
front door handle
unlocks all the
doors.

3-2. Opening, closing and locking the doors

Before driv

ing

■

If the smart key system or the

wireless remote control does

not operate properly

Use the mechanical key to lock and

unlock the doors. (



P.341)

Replace the key battery with a new

one if it is depleted. (



P.299)

■

If the battery is discharged

The doors cannot be locked and

unlocked using the smart key sys-

tem or wireless remote control. Lock

or unlock the doors using the

mechanical key. (



P.341)

■

Rear seat reminder function

In order to remind you not to forget

luggage, etc. in the rear seat, when

the engine switch is turned off after

any of the following conditions are

met, a buzzer will sound and a mes-

sage will be displayed on the

multi-information display for approx-

imately 6 seconds.

●

The engine is started within

approximately 10 minutes after

opening and closing a rear door.

●

A rear door has been opened and

closed after the engine was

started.

However, if a rear door is opened

and then closed within approxi-

mately 2 seconds, the rear seat

reminder function may not operate.
The rear seat reminder function

determines that luggage, etc. has

been placed in a rear seat based on

opening and closing of a rear door.

Therefore, depending on the situa-

tion, the rear seat reminder function

may not operate and you may still

forget luggage, etc. in the rear seat,

or it may operate unnecessarily.

■

Customization

Some functions can be customized.

(



P.371)

WARNING

■

To prevent an accident

Observe the following precautions

while driving the vehicle.

Failure to do so may result in a

door opening and an occupant

being thrown out of the vehicle,

resulting in death or serious injury.

●

Ensure that all doors are prop-

erly closed and locked.

●

Do not pull the inside door han-

dle while driving.

Be especially careful of the front

doors, as the doors may be

opened even if the inside lock

buttons are in the locked posi-

tion.

●

Set the rear door child-protector

locks when children are seated

in the rear seats.

■

When opening or closing a

door

Check the surroundings of the

vehicle such as whether the vehi-

cle is on an incline, whether there

is enough space for a door to

open and whether a strong wind

is blowing. When opening or clos-

ing the door, hold the door handle

tightly to prepare for any unpre-

dictable movement.

■

When using the wireless

remote control and operating

the power windows

Operate the power windows after

checking to make sure that there

is no possibility of any passenger

having any of their body parts

caught in the windows. Also, do

not allow children to operate the

wireless remote control. It is pos-

sible for children and other pas-

sengers to get caught in the

power windows.

3-2. Opening, closing and locking the doors

■

Door lock switches (to
lock/unlock)

Locks all the doors

Unlocks all the doors

■

Inside lock buttons

Locks the door

Unlocks the door

The front doors can be opened by
pulling the inside handle even if the
lock buttons are in the lock position.

■

Locking the front doors from

the outside without a key

Move the inside lock button to

the lock position.

Close the door.

The door cannot be locked if the

engine switch is in ACC or ON, or

the electronic key is left inside the

vehicle.

The key may not be detected cor-

rectly and the door may be locked.

■

Open door warning buzzer

If a door or the hood is not fully

closed, a buzzer will sound when

the vehicle speed reaches 3 mph (5

km/h).
The open door(s) or hood is indi-

cated on the multi-information dis-

play.

The door cannot be opened
from inside the vehicle when
lock is set.

Unlock

Lock

These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.

Unlocking and locking the
doors from the inside

Rear door child-protector
lock

3-2. Opening, closing and locking the doors

Before driv

ing

Back door

The back door can be
locked/unlocked and
opened by the following
procedures.

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Caution while driving

●

Keep the back door closed

while driving. If the back door is

left open, it may hit near-by

objects while driving or luggage

may be unexpectedly thrown

out, causing an accident.

In addition, exhaust gases may

enter the vehicle, causing death

or a serious health hazard.

Make sure to close the back

door before driving.

●

Before driving the vehicle, make

sure that the back door is fully

closed. If the back door is not

fully closed, it may open unex-

pectedly while driving, causing

an accident.

●

Never let anyone sit in the lug-

gage compartment. In the event

of sudden braking or a collision,

they are susceptible to death or

serious injury.

■

When children are in the vehi-

cle

●

Do not allow children to play in

the luggage compartment.

If a child is accidentally locked

in the luggage compartment,

they could have heat exhaus-

tion or other injuries.

●

Do not allow a child to open or

close the back door.

Doing so may cause the back

door to move unexpectedly, or

cause the child’s hands, head,

or neck to be caught by the

closing back door.

■

Operating the back door

●

Remove any heavy loads, such

as snow and ice, from the back

door before opening it. Failure

to do so may cause the back

door to suddenly shut again

after it is opened.

●

When opening or closing the

back door, thoroughly check to

make sure the surrounding area

is safe.

●

If anyone is in the vicinity, make

sure they are safe and let them

know that the back door is

about to open or close.

●

Use caution when opening or

closing the back door in windy

weather as it may move

abruptly in strong wind.

●

The back door may suddenly

shut if it is not opened fully. It is

more difficult to open or close

the back door on an incline than

on a level surface, so beware of

the back door unexpectedly

opening or closing by itself.

Make sure that the back door is

fully open and secure before

using the luggage compartment.

3-2. Opening, closing and locking the doors

■

Entry function

Press the button to unlock
the back door.

The door cannot be unlocked for 3
seconds after the door is locked.

Press the button to lock the
back door.

Check that the door is securely
locked.

■

Wireless remote control



P.89

■

Operation signals



P.90

■

Door lock switches



P.92

■

Open

Raise the back door while push-

WARNING

●

When closing the back door,

take extra care to prevent your

fingers etc. from being caught.

●

When closing the back door,

make sure to press it lightly on

its outer surface. If the back

door handle is used to fully

close the back door, it may

result in hands or arms being

caught.

●

Do not pull on the back door

damper stay to close the back

door, and do not hang on the

back door damper stay. Doing

so may cause hands to be

caught or the back door damper

stay to break, causing an acci-

dent.

●

If a bicycle carrier or similar

heavy object is attached to the

back door, it may suddenly shut

again after being opened, caus-

ing someone’s hands, head or

neck to be caught and injured.

When installing an accessory

part to the back door, using a

genuine Toyota part is recom-

mended.

Unlocking and locking the
back door from the out-
side

Unlocking and locking the
back door from the inside

Opening/closing the back
door

Content .. 3 4 5 6 ..
