Toyota Camry Hybrid (2023 year). Manual in english

110

2. Instrument cluster

■

PCS (Pre-Collision System) (



P. 252)

The following pre-collision system settings can be changed:

■

DRCC (Dynamic Radar Cruise Control) (



P. 287)

■

BSM (Blind Spot Monitor) function (if equipped) (



P. 310)

■

RCTA (Rear Cross Traffic Alert) function (if equipped)
(



P. 326)

■

RCD (Rear Camera Detection) function (if equipped) (



P. 335)

Item

Settings

Details

PCS

Select to enable/disable the pre-
collision system.

Off

Warning sensitivity

Early

Select to change the warning
timing.

Middle

Late

Item

Settings

Details

Curve

speed

reduction

Strong

Select to change the vehicle
speed reduction strength.

Weak

Off

Item

Settings

Details

BSM

Select to enable/disable the
Blind Spot Monitor function.

Off

Item

Settings

Details

RCTA

Select to enable/disable the Rear
Cross Traffic Alert function.

Off

Item

Settings

Details

RCD

Select to enable/disable the rear
camera detection.

Off

111

2. Instrument cluster

Instrument cluster

■

RSA (Road Sign Assist) (if equipped) (



P. 282)

The following RSA settings can be changed:

Item

Settings

Details

RSA

Select to enable/disable the
RSA.

Off

Notification method

Excess

speed

notification

Select a notification method used
to warn the driver if the vehicle
speed exceeds the speed dis-
played on the speed limit sign on
the multi-information display.
Available methods:
• No notification
• Display only
• Display and buzzer

Other notifications

Select a notification method used
to  warn  the  driver  if  the  system
detects  the  vehicle  approaching
to  the  no-entry  road  when  a  do
not enter sign is displayed on the
multi-information display.
Available methods:
• No notification
• Display only
• Display and buzzer

Excess speed noti-
fication level

5 mph (10 km/h)

Select  a  speed  threshold  over
which the excess speed notifica-
tion  will  start  to  operate  when  a
speed  limit  sign  is  displayed  on
the multi-information display.

3 mph (5 km/h)

1 mph (2 km/h)

112

2. Instrument cluster

■

Vehicle settings

Item

Settings

Details

BSM (Blind Spot Monitor) (if equipped) (



P. 310)

Outside rear view
mirror

indicator

brightness

Bright

Select to change the brightness
of the outside rear view mirror
indicators.

Dim

Notification  timing
for  presence  of
approaching  vehi-
cle (sensitivity)

Early

Select to change the notification
timing for an approaching vehi-
cle.

Middle

Late

Only when vehicle
detected in blind
spot

RCTA (Rear Cross Traffic Alert) (if equipped) (



P. 326)

RCTA buzzer vol-
ume

1 (Low)

Select to change the volume of
the RCTA buzzer.

2 (Medium)

3 (Loud)

TPWS (Tire pressure warning system) (



P. 445)

Set pressure (tire pressure warning sys-
tem initialization)

Select to initialize the tire pres-
sure warning system. To per-
form initialization, press and hold
the

switch.

Before performing initialization,
make sure to adjust the inflation
pressure of each tire to the spec-
ified level. (



P. 446)

Change  wheel  (change  the  tire  pres-
sure  warning  system  sensor  ID  code
set)
(vehicles  without  a  tire  inflation  pres-
sure display function)

Select  to  change  the  tire  pres-
sure  warning  system  sensor  ID
code set.
To enable this function, a second
set of tire pressure warning sys-
tem  sensor  ID  codes  must  be
registered  by  a  Toyota  dealer.
For information regarding chang-
ing  the  registered  ID  code  set,
contact your Toyota dealer.
(



P. 448)

113

2. Instrument cluster

Instrument cluster

■

Meter settings

Change wheel (register tire pressure
warning system sensor ID codes)
(vehicles with a tire inflation pressure
display function)

Select to register the ID codes of
the tire pressure sensors to the
tire pressure warning system. To
register the ID codes, press and
hold the

switch.

(



P. 448)

Rear seat reminder
(



P. 159)

Select to enable/disable the rear
seat reminder.

Off

Scheduled maintenance display

Maintenance data reset

Select to reset the message indi-
cating maintenance is required,
after the required maintenance is
performed. (



P. 420)

Item

Settings

Details

Item

Settings

Details

Language

Select to change the language
displayed.

Units

Select to change the units of
measure displayed.

(EV indicator)

Select to enable/disable the EV
indicator. (



P. 80)

Off

Drive information
(total [after reset])

Average vehicle
speed

Select to change the display
between average speed/elapsed
time.

Elapsed time

Pop-up display

Incoming calls

Select to enable/disable the pop-
up display.

Brightness adjust-
ment

Default setting

Select to reset the meter display
settings to the default setting.

114

2. Instrument cluster

■

Odometer

Displays the total distance the vehicle has been driven.

■

Trip meter A/trip meter B

Displays the distance the vehicle has been driven since the meter
was last reset. Trip meters A and B can be used to record and dis-
play different distances independently.

To reset, display the desired trip meter and press and hold the “ODO/
TRIP” switch.

Displays suggestions to the driver in the following situations. To select
a response to a displayed suggestion, use the meter control switches.

The suggestion function can be turned on/off.
(Customizable features:



P. 569)

■

Suggestion to turn off the headlights

If the headlights are left on for a certain amount of time after the
power switch has been turned off, if the headlight switch is in the
“AUTO” position, a suggestion message will be displayed asking if
you wish to turn the headlights off. To turn the headlights off, select
“Yes”.

If a front door is opened after the power switch is turned off, this sugges-
tion message will not be displayed.

Odometer/trip meter

Suggestion function

115

2. Instrument cluster

Instrument cluster

■

Suspension of the settings display

●

Some settings cannot be changed while driving. When changing settings,
park the vehicle in a safe place.

●

If a warning message is displayed, operation of the settings display will be
suspended.

■

Tire pressure (vehicles with a tire inflation pressure display function)

●

It may take a few minutes to display the tire inflation pressure after the
power switch is turned to ON mode. It may also take a few minutes to dis-
play the tire inflation pressure after inflation pressure has been adjusted.

●

“---” may be displayed if the tire position information cannot be determined
due to unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may
also be different from the values measured using a tire pressure gauge.

■

Liquid crystal display

Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

■

Customization

Some functions can be customized. (



P. 109, 569)

116

2. Instrument cluster

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra
attention to the safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as
you may fail to see pedestrians, objects on the road, etc. ahead of the
vehicle.

■

The information display at low temperatures

Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the information display
monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or injury.

■

Cautions during setting up the display

As the hybrid system needs to be operating during setting up the display,
ensure that the vehicle is parked in a place with adequate ventilation. In a
closed area such as a garage, exhaust gases including harmful carbon
monoxide (CO) may collect and enter the vehicle. This may lead to death or
a serious health hazard.

NOTICE

■

While setting up the display

To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while setting up the display features.

117

2. Instrument cluster

Instrument cluster

The multi-information display presents the driver with a variety of driv-
ing-related data, such as the current outside temperature. The multi-
information display can also be used to change the display settings
and other settings.

Indicators (



P. 94)

Driving assist system status display area

Displays the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (



P. 287)

• LTA (Lane Tracing Assist) (



P. 267)

Speed limit display (vehicles with a navigation system)
(U.S.A. only)/RSA (Road Sign Assist) (if equipped) (



P. 282)

Clock

For clock settings, refer to “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

RSA (Road Sign Assist) (if equipped) (



P. 282)

Speedometer

The speedometer display can be enabled/disabled in

on the multi-

information display. (



P. 126)

Multi-information display (7-inch display)

Summary of functions

118

2. Instrument cluster

Content display area

A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.

• Menu icon content (



P. 120)

• Suggestion function (



P. 133)

• Warning message (



P. 507)

Odometer/trip meter (



P. 133)

Shift position (



P. 216)

Outside temperature (



P. 100)

Menu icons (



P. 120)

“ODO/TRIP” switch (



P. 119)

Meter control switches (



P. 119)

119

2. Instrument cluster

Instrument cluster

◆

Using the content display area

The content display area is operated using the meter control
switches.

Scroll screens

, change the

displayed content

and move

the cursor
Press: Enter/Set
Press and hold: Reset/Dis-
play the next screen
Return to the previous
screen

Pressing and holding the switch will display the first screen of the
selected menu icon.

Call sending/receiving and history display

Linked with the hands-free system, sending or receiving call is dis-
played. For details regarding the hands-free system, refer to “NAVIGA-
TION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

: When the screen can be scrolled or different content can be displayed,

a mark, such as an arrow, will be displayed to suggest which switch to
operate.

◆

Using the odometer/trip meter

Items in this area are operated using the “ODO/TRIP” switch.
Press: Change displayed item

Each time the switch is pressed,
the displayed item will be
changed.

Press and hold: Reset

Display the desired trip meter
and press and hold the switch to
reset the trip meter.

Using the multi-information display

120

2. Instrument cluster

Select a menu icon to display its content.

Warning message display (



P. 507)

This menu icon will be displayed only when a warning message can be
displayed.
Select to display warning messages and measures to be taken if a mal-
function is detected.

Eco-friendly driving information (



P. 121)

Select to display fuel consumption data in various forms.

Driving assist system information

Select to perform the following:
Display the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (



P. 287)

• LTA (Lane Tracing Assist) (



P. 267)

• RSA (Road Sign Assist) (if equipped) (



P. 282)

Display the following navigation system-linked information (if equipped):

• Route guidance
• Compass display

Audio system-linked display

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Vehicle information

Select to perform the following:
Display the following information:

• Energy monitor (



P. 142)

• Tire inflation pressure (



P. 445)

Enable/Disable the following systems:

• Intuitive parking assist (if equipped) (



P. 317)

• BSM (Blind Spot Monitor) function (



P. 310)

• RCTA (Rear Cross Traffic Alert) function (



P. 326)

This function can also be enabled/disabled on

Settings display (



P. 126)

Select to change the meter display settings and other settings.

Menu icons

121

2. Instrument cluster

Instrument cluster

■

Fuel consumption

Current fuel consumption

Displays the instantaneous cur-
rent fuel consumption.

Average fuel economy (after
start)

Displays the average fuel con-
sumption since hybrid system
start.

Driving range

Displays the driving range with remaining fuel.

2, 3

Gadget

The following items can be displayed by changing the settings for gad-
get content and fuel economy type on

. (



P. 126)

Eco-friendly driving information (

)

Displayable item

Content

Gadget
content

Fuel economy

type

Average
vehicle
speed

Trip
(after start)

Displays the average vehicle speed since
hybrid system start.

Total
(after reset)

Displays the average vehicle speed since the
display was reset.

Distance

Trip
(after start)

Displays the distance driven since vehicle
start.

Total
(after reset)

Displays the distance driven since the display
was reset.

Elapsed
time

Trip
(after start)

Displays the elapsed time since hybrid system
start.

Total
(after reset)

Displays the elapsed time since the display
was reset.

122

2. Instrument cluster

Average fuel economy

Displayed item (listed below) can be changed on the fuel economy type
screen of

. (



P. 126)

●

Total (after reset)

Displays the average fuel consumption since the display was reset.

1, 5

●

Tank (after refuel)

Displays the average fuel consumption since the vehicle was refu-
eled.

1, 2

: Use the displayed fuel consumption as a reference only.

: When only a small amount of fuel is added to the tank, the display may

not be updated.
When refueling, turn the power switch off. If the vehicle is refueled with-
out turning the power switch off, the display may not be updated.

: This distance is computed based on your average fuel consumption. As

a result, the actual distance that can be driven may differ from that dis-
played.

: The default setting is no display.

: This display can be reset by pressing and holding

while it is dis-

played.

123

2. Instrument cluster

Instrument cluster

■

Eco guide

The Eco guide displays a guide for eco-friendly acceleration and
scores which represent an evaluation of how the vehicle has been
driven ecologically in different states.

ECO Accelerator Guidance
Eco score

●

ECO Accelerator Guidance
Eco area

Indicates that the vehicle is
being driven in an Eco-friendly
manner.

Power area

Indicates that the Eco-friendly
driving range is being exceeded
(during full power driving, etc.)

Eco driving ratio based on acceleration
Zone of Eco acceleration

Suggests a range in which Eco-friendly acceleration can be performed.
The zone of Eco acceleration changes according to situations, such as
starting off or cruising.
Eco-friendly acceleration can be achieved by keeping the Eco driving
ratio based on acceleration bar within the zone of Eco acceleration.
(



P. 194)

124

2. Instrument cluster

●

Eco score

The following 3 Eco driving methods are evaluated in 5 levels:
Smooth start-off acceleration, driving without sudden acceleration,
and smooth stopping. When the vehicle is stopped, an Eco score
out of 100 points will be displayed.

Eco start status
Eco cruise status
Eco stop status
Score result

How to read the bar display:

• After the hybrid system is started, the Eco score will not be dis-

played until the vehicle speed exceeds approximately 20 mph
(30 km/h).

• The Eco score will be reset each time the hybrid system is

started.

• When the hybrid system is stopped, the total score of the current

trip will be displayed.

Not yet evaluated

Low

High

125

2. Instrument cluster

Instrument cluster

■

Speedometer display/Driving range

Speedometer display

Displays the vehicle speed.

Driving range

Displays  the  driving  range  with
remaining fuel.
When  only  a  small  amount  of
fuel is added to the tank, the dis-
play may not be updated.
When  refueling,  turn  the  power
switch  off.  If the  vehicle  is  refu-
eled  without  turning  the  power
switch  off,  the  display  may  not
be updated.
This distance is computed based on your average fuel consumption. As
a result, the actual distance that can be driven may differ from that dis-
played.

Toyota Camry Hybrid (2023 year). Manual in english - page 7
