Toyota C-HR (2023 year). Manual in english

307

4-2. Driving procedures

riv

■

Steering lock motor overheating prevention

To prevent the steering lock motor from overheating, the motor may be sus-
pended if the hybrid system is turned on and off repeatedly in a short period
of time. In this case, refrain from operating the hybrid system. After about 10
seconds, the steering lock motor will resume functioning.

■

When the “Entry & Start System Malfunction. See Owner’s Manual.” is
displayed on the multi-information display

The system may be malfunctioning. Have the vehicle inspected by any autho-
rized Toyota retailer or Toyota authorized repairer, or any reliable repairer
immediately.

■

If the “READY” indicator does not come on

In the event that the “READY” indicator does not come on even after perform-
ing the proper procedures for starting the vehicle, contact any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer immedi-
ately.

■

If the hybrid system is malfunctioning



P. 690

■

If the electronic key battery is depleted



P. 643

■

Operation of the power switch

●

If the switch is not pressed shortly and firmly, the power switch mode may
not change or the hybrid system may not start.

●

If attempting to restart the hybrid system immediately after turning the power
switch off, the hybrid system may not start in some cases. After turning the
power switch off, please wait a few seconds before restarting the hybrid sys-
tem.

■

If the smart entry & start system has been deactivated in a customized
setting



P. 744

308

4-2. Driving procedures

WARNING

■

When starting the hybrid system

Always start the hybrid system while sitting in the driver’s seat. Do not
depress the accelerator pedal while starting the hybrid system under any
circumstances.
Doing so may cause an accident resulting in death or serious injury.

■

Caution while driving

If a hybrid system failure occurs while the vehicle is moving, do not lock or
open the doors until the vehicle reaches a safe and complete stop. Activa-
tion of the steering lock in this circumstance may lead to an accident, result-
ing in death or serious injury.

■

Stopping the hybrid system in an emergency

●

If you want to stop the hybrid system in an emergency while driving the
vehicle, press and hold the power switch for more than 2 seconds, or
press it briefly 3 times or more in succession. (



P. 669)

However, do not touch the power switch while driving except in an emer-
gency. Turning the hybrid system off while driving will not cause loss of
steering or braking control, however, power assist to the steering will be
lost. This will make it more difficult to steer smoothly, so you should pull
over and stop the vehicle as soon as it is safe to do so.

●

If the power switch is operated while the vehicle is running, a warning
message will be shown on the multi-information display and a buzzer
sounds.

●

When  restarting  the  hybrid  system  after  an  emergency  shutdown  while
driving,  press the  power switch. When restarting the  hybrid system after
stopping  the  vehicle,  shift  the  shift  lever  to  P  and  then  press  the  power
switch.

309

4-2. Driving procedures

riv

NOTICE

■

To prevent 12-volt battery discharge

●

Do not leave the power switch in ACCESSORY or ON mode for long peri-
ods of time without the hybrid system on.

●

If “ACCESSORY” or “IGNITION ON” is displayed on the multi-information
display while the hybrid system is not operating, the power switch is not
off. Exit the vehicle after turning the power switch off.

●

Do not stop the hybrid system when the shift lever is in a position other
than P. If the hybrid system is stopped in another shift lever position, the
power switch will not be turned off but instead be turned to ACCESSORY
mode. If the vehicle is left in ACCESSORY mode, 12-volt battery dis-
charge may occur.

■

When starting the hybrid system

If the hybrid system becomes difficult to start, have your vehicle checked by
any authorized Toyota retailer or Toyota authorized repairer, or any reliable
repairer immediately.

■

Symptoms indicating a malfunction with the power switch

If the power switch seems to be operating somewhat differently than usual,
such as the switch sticking slightly, there may be a malfunction. Contact any
authorized Toyota retailer or Toyota authorized repairer, or any reliable
repairer immediately.

310

4-2. Driving procedures

EV drive mode

Turns EV drive mode on/off

When EV drive mode is turned on,
the  EV  drive  mode  indicator  will
come on.
Pressing  the  switch  when  in  EV
drive mode will return the vehicle to
normal  driving  (using  the  gasoline
engine  and  electric  motor  [traction
motor]).

■

Situations in which EV drive mode cannot be turned on

It may not be possible to turn EV drive mode on in the following situations. If it
cannot be turned on, a buzzer will sound and a message will be shown on the
multi-information display.

●

Vehicle speed is high.

●

The accelerator pedal is depressed firmly or the vehicle is on a hill, etc.

●

The temperature of the hybrid system is high.
The vehicle has been left in the sun, driven on a hill, driven at high speeds,
etc.

●

The temperature of the hybrid system is low.
The vehicle has been left in temperatures lower than about 0



C (32



F) for a

long period of time, etc.

●

The gasoline engine is warming up.

●

The hybrid battery (traction battery) is low.
The remaining battery level indicated in the energy monitor display is low.
(



P. 177)

●

The windshield defogger is in use.

In EV drive mode, electric power is supplied by the hybrid bat-
tery (traction battery), and only the electric motor (traction
motor) is used to drive the vehicle.
This mode allows you to drive in residential areas late at night,
or in indoor parking lots, etc., without concern for noises and
exhaust gas emissions.
When the acoustic vehicle alerting system is active, the vehicle
may produce sound.

311

4-2. Driving procedures

riv

■

Switching to EV drive mode when the gasoline engine is cold

If the hybrid system is started while the gasoline engine is cold, the gasoline
engine will start automatically after a short period of time in order to warm up.
In this case, you will become unable to switch to EV drive mode.
After the hybrid system has started and the “READY” indicator has illumi-
nated, press the EV drive mode switch before the gasoline engine starts to
switch to EV drive mode.

■

Automatic cancelation of EV drive mode

When driving in EV drive mode, the gasoline engine may automatically restart
in the following situations. When EV drive mode is canceled, a buzzer will
sound and the EV drive mode indicator will flash and go off.

●

The hybrid battery (traction battery) becomes low.
The remaining battery level indicated in the energy monitor display is low.
(



P. 177)

●

Vehicle speed is high.

●

The accelerator pedal is depressed firmly or the vehicle is on a hill, etc.

When it is possible to inform the driver of automatic cancelation in advance, a
prior notice screen will appear on the multi-information display.

■

Possible driving distance when driving in EV drive mode

EV drive mode’s possible driving distance ranges from a few hundred meters
to approximately 1 km (0.6 mile). However, depending on vehicle conditions,
there are situations when EV drive mode cannot be used. (The distance that
is possible depends on the hybrid battery [traction battery] level and driving
conditions.)

312

4-2. Driving procedures

■

Changing a driving mode when in EV drive mode

EV drive mode can be used in conjunction with “ECO” mode and “SPORT”
mode.
However, EV drive mode may be automatically canceled when used in con-
junction with “SPORT” mode.

■

Fuel economy

The hybrid system is designed to achieve the best possible fuel economy
during normal driving (using the gasoline engine and electric motor [traction
motor]). Driving in EV drive mode more than necessary may lower fuel econ-
omy.

WARNING

■

Caution while driving

When driving in EV drive mode, pay special attention to the area around the
vehicle. Because there is no engine noise, pedestrians, people riding bicy-
cles or other people and vehicles in the area may not be aware of the vehi-
cle starting off or approaching them, so take extra care while driving.
Therefore, take extra care while driving even if the acoustic vehicle alerting
system is active.

313

4-2. Driving procedures

riv

Hybrid transmission (2ZR-FXE engine)

While the power switch is in ON mode and the brake pedal
depressed

, shift the shift lever while pushing the shift release

button on the shift knob.

Shift the shift lever while pushing the shift release button on
the shift knob.

Shift the shift lever normally.

When shifting the shift lever between P and D, make sure that the
vehicle is completely stopped and the brake pedal is depressed.

: To shift the shift lever from P, the brake pedal must be depressed

before the shift release button is pushed. If the shift release button is
pushed first, the shift lock will not be released.

Shifting the shift lever

314

4-2. Driving procedures

: To improve fuel efficiency and reduce noises, set the shift lever in D for

normal driving.



P. 430

■

When driving with cruise control or dynamic radar cruise control with
full-speed range activated (if equipped)

Even when performing the following with the intent of enabling engine brak-
ing, engine braking will not activate because cruise control or dynamic radar
cruise control with full-speed range will not be canceled.

●

When switching the driving mode to sport mode while driving in D position.
(



P. 430)

■

Restraining sudden start (Drive-start Control)



P. 284

■

Shift lock system

The shift lock system is a system to prevent accidental operation of the shift
lever in starting.
The shift lever can be shifted from P only when the power switch is in ON
mode and the brake pedal is being depressed.

Shift position purpose

Shift position

Objective or function

Parking the vehicle/starting the hybrid system

Reversing

Neutral

Normal driving

Position for engine braking

Selecting a driving mode

315

4-2. Driving procedures

riv

■

If the shift lever cannot be shifted from P

First, check whether the brake pedal is being depressed.
If the shift lever cannot be shifted with your foot on the brake pedal while
pressing the button on the shift knob, there may be a problem with the shift
lock system. Have the vehicle inspected by any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer immediately.
The following steps may be used as an emergency measure to ensure that
the shift lever can be shifted.
Releasing the shift lock:

Set the parking brake.
Turn the power switch off.
Depress the brake pedal.

■

About engine braking

When shift position B is selected, releasing the accelerator pedal will apply
engine braking.

●

When the vehicle is driven at high speeds, compared to ordinary gasoline-
fueled vehicles, the engine braking deceleration is felt less than that of other
vehicles.

●

The vehicle can be accelerated even when shift position B is selected.

If the vehicle is driven continuously in the B position, fuel efficiency will
become low. Usually, select the D position.

Remove the cover.
Remove the cover using flathead
screwdriver. To prevent damage to the
cover, tip the screwdriver with a rag.

Press the shift lock override button
while pressing the button on the shift
knob.
The shift lever can be shifted while the
button is pressed.

316

4-2. Driving procedures

WARNING

■

When driving on slippery road surfaces

Do not accelerate or shift the shift lever suddenly.
Sudden changes in engine braking may cause the vehicle to spin or skid,
resulting in an accident.

■

To prevent an accident when releasing the shift lock

Before pressing the shift lock override button, make sure to set the parking
brake and depress the brake pedal.
If the accelerator pedal is accidentally depressed instead of the brake pedal
when the shift lock override button is pressed and the shift lever is shifted
out of P, the vehicle may suddenly start, possibly leading to an accident
resulting in death or serious injury.

NOTICE

■

Hybrid battery (traction battery) charge

If the shift lever is in N, the hybrid battery (traction battery) will not be
charged. To help prevent the battery from discharging, avoid leaving the N
position selected for an extended period of time.

317

4-2. Driving procedures

riv

Hybrid transmission (M20A-FXS engine)

While the power switch is in ON mode and the brake pedal
depressed*, shift the shift lever while pushing the shift release
button on the shift knob.
Shift the shift lever while pushing the shift release button on
the shift knob.
Shift the shift lever normally.

When shifting the shift lever between P and D, make sure that the
vehicle is completely stopped and the brake pedal is depressed.

: To shift the shift lever from P, the brake pedal must be depressed

before the shift release button is pushed. If the shift release button is
pushed first, the shift lock will not be released.

Shifting the shift lever

318

4-2. Driving procedures

: To improve fuel efficiency and reduce noises, set the shift lever in D for

normal driving.

: By selecting shift ranges using S mode, you can control accelerating force

and engine braking force.



P. 430

To enter S mode, shift the shift lever to S position. Shift ranges can be
selected by operating the shift lever.

Upshifting
Downshifting

The selected shift range, from S1
to S6, will be displayed on the
multi-information display.
The initial shift range in S mode is
4.

Shift position purpose

Shift position

Objective or function

Parking the vehicle/starting the hybrid system

Reversing

Neutral

(Condition in which the power is not transmitted)

Normal driving

S mode driving

(



P. 318)

Selecting a driving mode

Selecting shift ranges in the S position

319

4-2. Driving procedures

riv

■

Shift ranges and their functions (S mode)

●

You can choose from 6 levels of accelerating force and engine braking
force.

●

A lower shift range will provide greater accelerating force and engine brak-
ing force than a higher shift range, and the engine revolutions will also
increase.

■

When driving with cruise control or dynamic radar cruise control with
full-speed range activated (if equipped)

●

While driving in S mode, downshifting to 5 or 4.

●

When switching the driving mode to sport mode while driving in D position.
(



P. 430)

■

Restraining sudden start (Drive-start Control)



P. 284

■

Shift lock system

■

If the shift lever cannot be shifted from P

Set the parking brake.
Turn the power switch off.
Depress the brake pedal.

320

4-2. Driving procedures

■

Downshift restriction warning buzzer (S mode)

To help ensure safety and driving performance, downshifting operation may
sometimes be restricted. In some circumstances, downshifting may not be
possible even when the shift lever is operated. (A buzzer will sound twice.)

■

S mode

●

When the shift range is S4 or lower, holding the shift lever toward “+” sets
the shift range to S6.

●

Automatically selects a higher shift range before the engine speed becomes
too high.

■

If the S indicator does not come on or the D indicator is displayed even
after shifting the shift lever to S

This may indicate a malfunction in the transmission system. Have the vehicle
inspected by any authorized Toyota retailer or Toyota authorized repairer, or
any reliable repairer immediately. (In this situation, the transmission will oper-
ate in the same manner as when the shift lever is in D.)

Remove the cover.
Remove the cover using flathead
screwdriver. To prevent damage to the
cover, tip the screwdriver with a rag.

Press the shift lock override button
while pressing the button on the shift
knob.
The shift lever can be shifted while the
button is pressed.

321

4-2. Driving procedures

riv

WARNING

■

When driving on slippery road surfaces

Do not accelerate or shift the shift lever suddenly.
Sudden changes in engine braking may cause the vehicle to spin or skid,
resulting in an accident.

■

To prevent an accident when releasing the shift lock

NOTICE

■

Hybrid battery (traction battery) charge

322

4-2. Driving procedures

Turn signal lever

Right turn
Lane change to the right (move
the lever partway and release
it)

The right hand signals will flash 3
times.

Lane change to the left (move
the lever partway and release
it)

The left hand signals will flash 3
times.

Left turn

■

Turn signals can be operated when

The power switch is in ON mode.

■

If the indicator flashes faster than usual

Check that a light bulb in the front or rear turn signal lights has not burned
out.

■

If the turn signals stop flashing before a lane change has been per-
formed

Operate the lever again.

■

Customization

The number of times the turn signals flash during a lane change can be
changed. (Customizable features:



P. 779)

Operating instructions

Toyota C-HR (2023 year). Manual in english - page 15
