Toyota C-HR (2023 year). Manual in english

1-2. Child safety

■

When installing a child restraint system to a front passenger
seat

For the safety of a child, install a child restraint system to a rear
seat. When installing a child restraint system to a front passenger
seat is unavoidable, adjust the seat as follows and install the child
restraint system.

●

Adjust the seatback angle to
the most upright position.

When installing a forward-facing
child  seat,  if  there  is  a  gap
between  the  child  seat  and  the
seatback,  adjust  the  seatback
angle  until  good  contact  is
achieved.

●

Move the seat fully rearward.

●

If the passenger seat height can be adjusted, move it to the
upper most position.

●

If  the  head  restraint  interferes  with  your  child  restraint  system,
and  the  head  restraint  can  be  removed,  remove  the  head
restraint.  Otherwise,  put  the  head  restraint  in  the  upper  most
position.

When using a child restraint system

WARNING

■

When using a child restraint system

Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Vehicles  without  an  airbag  manual
on-off switch:
Never  use  a  rear-facing  child  restraint
system  on  the  front  passenger  seat.
The  force  of  the  rapid  inflation  of  the
front passenger airbag can cause death
or serious injury to children in the event
of an accident.

1-2. Child safety

Fo
r s

ty a
nd

se
cu

rity

WARNING

■

When using a child restraint system

Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Vehicles  with  an  airbag  manual  on-off
switch:
Never  use  a  rear-facing  child  restraint
system  on  the  front  passenger  seat
when the airbag manual on-off switch is
on. (



P. 55)

The force of the rapid inflation of the
front passenger airbag can cause death
or serious injury to children in the event
of an accident.

●

There is a label(s) on the passenger
side sun visor, indicating it is forbidden
to attach a rear-facing child restraint
system to the front passenger seat.
Details of the label(s) are shown in the
illustration below.

1-2. Child safety

WARNING

■

When using a child restraint system

●

Only put a forward-facing child restraint
system on the front seat when unavoid-
able.  When  installing  a  forward-facing
child  restraint  on  the  front  passenger
seat, move the seat as far back as pos-
sible.  Failing  to  do  so  may  result  in
death  or  serious  injury  if  the  airbags
deploy (inflate).

●

Do  not  allow  the  child  to  lean  his/her
head or any part of his/her body against
the door or the area of the seat, front or
rear pillars, or roof side rails from which
the  SRS  side  airbags  or  SRS  curtain
shield airbags deploy even if the child is
seated in the child restraint system. It is
dangerous if the SRS side airbags and
curtain  shield  airbags  inflate,  and  the
impact  could  cause  death  or  serious
injury to the child.

1-2. Child safety

Fo
r s

ty a
nd

se
cu

rity

WARNING

■

When using a child restraint system

●

When a junior seat is installed, always ensure that the shoulder belt is
positioned across the center of the child’s shoulder. The belt should be
kept away from the child’s neck, but not so that it could fall off the child’s
shoulder.

●

Use child restraint system suitable to the age and size of the child and
install it to the rear seat.

●

If  the  driver’s  seat  interferes  with  the
child  restraint  system  and  prevents  it
from being attached correctly, attach the
child  restraint  system  to  the  right-hand
rear  seat  (left-hand  drive  vehicles)  or
the left-hand rear seat (right-hand drive
vehicles). (



P. 70, 80, 88)

1-2. Child safety

: Guadelope, Martinique and F. Guiana

■

Child restraint system compatibility for each seating position

Compatibility of each seating position with child restraint systems
(



P. 68) displays the type of child restraint systems that can be

used and possible seating positions for installation using symbols.
Also, the recommended child restraint system that is suitable for
your child can be selected.
Otherwise, check [Recommended child restraint systems and Com-
patibility table] for recommended child restraint systems. (



P. 73)

Check the selected child restraint system together with the follow-
ing [Before confirming the compatibility of each seating position
with child restraint systems].

■

Before confirming the compatibility of each seating position
with child restraint systems

Checking the child restraint system standards.
Use a child restraint system that conforms to UN(ECE) R44

UN(ECE) R129

1, 2

The following approval mark is displayed on child restraint sys-
tems which are conformed.
Check for an approval mark attached to the child restraint sys-
tem.

Child restraint system compatibility for each seating position
(Except for Reunion and Latin American countries

)

1-2. Child safety

Fo
r s

ty a
nd

se
cu

rity

Example of the displayed
regulation number

UN(ECE) R44 approval
mark

The  weight  range  of  the
child  who  is  applicable  for
an UN(ECE) R44 approval
mark is indicated.
UN(ECE)  R129  approval
mark

The  height  range  of  the
child  who  is  applicable  as
well  as  available  weights
for  an  UN(ECE)  R129
approval mark is indicated.

: UN(ECE) R44 and UN(ECE) R129 are U.N. regulations for child

restraint systems.

: The child restraint systems mentioned in the table may not be avail-

able outside of the EU area.

: The displayed mark may differ depending on the product.

Checking the category of the child restraint system.
Check the approval mark of the child restraint system for which
of the following categories the child restraint system is suitable.
Also, if there are any uncertainties, check the user’s guide
included with the child restraint system or contact the retailer of
the child restraint system.

• “universal”
• “semi-universal”
• “restricted”
• “vehicle specific”

1-2. Child safety

■

Compatibility of each seating position with child restraint sys-
tems



Left-hand drive vehicles



Right-hand drive vehicles

Deactivation of front passenger airbag.

Vehicles without airbag manual on-off switch:
Never use a rearward-facing child restraint system on the
front passenger seat.
Vehicles with airbag manual on-off switch:
Activation of front passenger airbag.
Never use a rearward-facing child restraint system on the
front passenger seat when the airbag manual on-off
switch is on.

Suitable for “universal” category child restraint system
fixed with the seat belt.

Suitable for recommended child restraint systems given
on recommended child restraint systems information
(



P. 73).

1-2. Child safety

Fo
r s

ty a
nd

se
cu

rity

: Move the front seat fully rearward. If the passenger seat height can be

adjusted, move it to the upper most position.

: Adjust the seatback angle to the

most upright position.
When  installing  a  forward-facing
child  seat,  if  there  is  a  gap
between  the  child  seat  and  the
seatback,  adjust  the  seatback
angle  until  good  contact  is
achieved.

: If the head restraint interferes with your child restraint system, and the

head restraint can be removed, remove the head restraint.
Otherwise, put the head restraint in the upper most position.

: Vehicles without airbag manual on-off switch:

Use only a front-facing child restraint system.
Vehicles with airbag manual on-off switch:
Use only a front-facing child restraint system when the airbag manual
on-off switch is on.

Suitable for i-Size and ISOFIX child restraint system.

Includes a top tether anchorage point.

Not suitable for child restraint system.

1-2. Child safety

When securing some types of child restraint systems in rear seat, it
may not be possible to properly use the seat belts in positions next to
the child restraint without interfering with it or affecting seat belt effec-
tiveness. Be sure your seat belt fits snugly across your shoulder and
low on your hips. If it does not, or if it interferes with the child restraint,
move to a different position. Failure to do so may result in death or
serious injury.

●

When installing a child restraint in the rear seats, adjust the front
seat so that it does not interfere with the child or child restraint
system.

●

When installing a child seat with support base, if the child seat
interferes with the seatback when latching it into the support
base, adjust the seatback rearward until there is no interference.

●

If  the  seat  belt  shoulder
anchor  is  ahead  of  the  child
seat  belt  guide,  move  the
seat cushion forward.

●

When installing a junior seat, if the child in your child restraint
system is in a very upright position, adjust the seatback angle to
the most comfortable position. And if the seat belt shoulder
anchor is ahead of the child seat belt guide, move the seat cush-
ion forward.

1-2. Child safety

Fo
r s

ty a
nd

se
cu

rity

■

Detail information for child restraint systems installation

: All universal categories (group 0, 0+, I, II and III).

Toyota suggests the users to use

and

seating positions.

Seating position

Seat position number

Without

airbag

manual

on-off

switch

Airbag manual

on-off switch

OFF

Left

Right

Seating position suitable for
universal belted (Yes/No)

Yes

Forward

facing

only

Yes

Forward

facing

only

Yes

i-Size seating position
(Yes/No)

Yes

Seating position suitable for
lateral fixture (L1/L2/No)

Suitable rearward facing
fixture (R1/R2X/R2/R3/No)

R1,

R2X,

R1,

R2X,

Suitable forward facing fix-
ture (F2X/F2/F3/No)

F2X,

F2, F3

F2X,

F2, F3

Suitable junior seat fixture
(B2/B3/No)

B2, B3 B2, B3

1-2. Child safety

ISOFIX child restraint systems are divided into different “fixture”.
The child restraint system can be used in the seating positions for
“fixture” mentioned in the table above. For kind of “fixture” relation,
confirm the following table.
If your child restraint system has no kind of “fixture” (or if you can-
not find information in the table below), please refer to the child
restraint system “vehicle list” for compatibility information or ask the
retailer of your child seat.

Mass

groups

Child weight

Size

class

Fixture

Description

up to 10 kg

(22 lb.)

Rearward-facing infant seat

Left lateral-facing infant seat
(Carrycot)

Right lateral-facing infant seat
(Carrycot)

up to 13 kg

(28 lb.)

Full-size,

rearward-facing

child

restraint systems

Reduced-size, rearward-facing child
restraint systems



R2X

Reduced-size, rearward-facing child
restraint systems

Rearward-facing infant seat

9 to 18 kg

(20 to 39 lb.)

Full-height,

forward-facing

child

restraint systems

Reduced-height, forward-facing child
restraint systems

F2X

Reduced-height, forward-facing child
restraint systems

Full-size,

rearward-facing

child

restraint systems

Reduced-size, rearward-facing child
restraint systems

15 to 25 kg

(34 to 55 lb.)



B2, B3 Junior seat

III

22 to 36 kg

(48 to 79 lb.)

1-2. Child safety

Fo
r s

ty a
nd

se
cu

rity

■

Recommended child restraint systems information

: Be sure to attach the seat belt through the SecureGuard. (



P. 73)

The child restraint systems mentioned in the table may not be avail-
able outside the EU countries and United Kingdom.

●

When

using

the

child

restraint system with Secu-
reGuard, be sure to guide the
lap belt into SecureGuard
as shown in the illustration.

Recommended

child restraint

Ssstem

Size

Direction of

travel

Fixation

fixed with

lower

anchorages

fixed with a

seat belt

MAXI COSI
CABRIOFIX

Up to 13 kg

(Up to 28 lb.)

Rearward-

facing use

only

Not

applicable

Yes

BRITAX
TRIFIX 2
i-SIZE

76 to 105 cm

Forward-

facing use

only

Yes

Not

applicable

9 to 18 kg

(20 to 39 lb.)

TOYOTA
KIDFIX
i-SIZE

100 to 150 cm

Forward-

facing use

only

Yes

15 to 36 kg

(34 to 79 lb.)

TOYOTA
MAXI PLUS

15 to 36 kg

(34 to 79 lb.)

Forward-

facing use

only

Yes

1-2. Child safety

■

Child restraint system compatibility for each seating position

Compatibility of each seating position with child restraint systems
(



P. 76) displays the type of child restraint systems that can be

used and possible seating positions for installation using symbols.
Check the selected child restraint system together with the follow-
ing [Before confirming the compatibility of each seating position
with child restraint systems].

■

Before confirming the compatibility of each seating position
with child restraint systems

Checking the child restraint system standards.
Use a child restraint system that conforms to UN(ECE) R44

UN(ECE) R129

1, 2

The following approval mark is displayed on child restraint sys-
tems which are conformed.
Check for an approval mark attached to the child restraint sys-
tem.

Example of the displayed
regulation number

UN(ECE) R44 approval
mark

The  weight  range  of  the
child  who  is  applicable  for
an UN(ECE) R44 approval
mark is indicated.
UN(ECE)  R129  approval
mark

The  height  range  of  the
child  who  is  applicable  as
well  as  available  weights
for  an  UN(ECE)  R129
approval mark is indicated.

Child restraint system compatibility for each seating position
(For Reunion)

1-2. Child safety

Fo
r s

ty a
nd

se
cu

rity

: UN(ECE) R44 and UN(ECE) R129 are U.N. regulations for child

restraint systems.

: The child restraint systems mentioned in the table may not be avail-

able outside of the EU area.

: The displayed mark may differ depending on the product.

• “universal”
• “semi-universal”
• “restricted”
• “vehicle specific”

1-2. Child safety

■

Compatibility of each seating position with child restraint sys-
tems

1, 2, 3

Suitable for “universal” category child restraint system
fixed with the seat belt.

Suitable for i-Size and ISOFIX child restraint system.

Includes a top tether anchorage point.

Not suitable for child restraint system.

Never use a rear-facing child restraint system on the front
passenger seat.

1-2. Child safety

Fo
r s

ty a
nd

se
cu

rity

: Move the front seat fully rearward. If the passenger seat height can be

adjusted, move it to the upper most position.

: Adjust the seatback angle to the

: If the head restraint interferes with your child restraint system, and the

head restraint can be removed, remove the head restraint.
Otherwise, put the head restraint in the upper most position.

: Use only a front-facing child restraint system.

Toyota C-HR (2023 year). Manual in english - page 4
