4-1. Before driving

Weight carrying ball position:
37.5 in. (952.0 mm)
Hitch receiver pin hole posi-
tion: 31.6 in. (801.5 mm)

Please consult your dealer
when installing trailer lights, as
incorrect installation may cause
damage to the vehicle's lights.
Please take care to comply with
your state's laws when installing
trailer lights.

Your vehicle will handle differ-
ently when towing a trailer. Help
to avoid an accident, death or
serious injury, keep the following
in mind when towing:



Speed limits for towing a
trailer vary by state or prov-
ince. Do not exceed the
posted towing speed limit.



Toyota recommends that the
vehicle-trailer speed limit is 65
mph (104 km/h) on a flat,
straight, dry road. Do not
exceed this limit, the posted
towing speed limit or the
speed limit for your trailer as
set forth in your trailer owner’s
manual, whichever is lowest.
Instability of the towing vehi-
cle-trailer combination (trailer
sway) increases as speed
increases. Exceeding speed
limits may cause loss of con-
trol.



Before starting out, check the
trailer lights, tires and the
vehicle-trailer connections.
Recheck after driving a short
distance.



Practice turning, stopping and
reversing with the trailer
attached in an area away
from traffic until you become
accustomed to the feel of the
vehicle-trailer combination.



Reversing with a trailer
attached is difficult and

NOTICE

■

When installing a trailer hitch

Use only the position recom-

mended by your Toyota dealer.

Do not install the trailer hitch on

the bumper; this may cause body

damage.

Positions for towing hitch
receiver and hitch ball

Connecting trailer lights

NOTICE

■

Do not directly splice trailer

lights

Do not directly splice trailer lights.

Directly splicing trailer lights may

damage your vehicle’s electrical

system and cause a malfunction.

Trailer towing tips

159

4-1. Before driving

ing

requires practice. Grip the
bottom of the steering wheel
and move your hand to the
left to move the trailer to the
left. Move your hand to the
right to move the trailer to
right. (This is generally oppo-
site to reversing without a
trailer attached.) Avoid sharp
or prolonged turning. Have
someone guide you when
reversing to reduce the risk of
an accident.



As stopping distance is
increased when towing a
trailer, vehicle-to vehicle dis-
tance should be increased.
For each 10 mph (16 km/h) of
speed, allow at least one
vehicle and trailer length.



Avoid sudden braking as you
may skid, resulting in the
trailer jackknifing and a loss of
vehicle control. This is espe-
cially true on wet or slippery
surfaces.



Avoid jerky starts or sudden
acceleration.



Avoid jerky steering and
sharp turns, and slow down
before making turn.



Note that when making a turn,
the trailer wheels will be
closer than the vehicle wheels
to the inside of the turn. Com-
pensate by making a wider
than normal turning radius.



Slow down before making a

turn, in cross winds, on wet or
slippery surfaces, etc.
Increasing vehicle speed can
destabilize the trailer.



Take care when passing other
vehicles. Passing requires
considerable distance. After
passing a vehicle, do not for-
get the length of your trailer,
and be sure you have plenty
of room before changing
lanes.



To maintain engine braking
efficiency and charging sys-
tem performance when using
engine braking, do not put the
transmission in D. If in the M
mode, the transmission shift
range position must be in 6 or
lower. (



P.168)



Instability happens more fre-
quently when descending
steep or long downhill grades.
Before descending, slow
down and downshift. Do not
make sudden downshifts
while descending steep or
long downhill grades.



Avoid holding the brake pedal
down too long or applying the
brakes too frequently. This
could cause the brakes to
overheat and result in
reduced braking efficiency.



Due to the added load of the
trailer, your vehicle’s engine
may overheat on hot days (at
temperatures over 85°F
[30°C]) when driving up a long

160

4-1. Before driving

or steep grade. If the engine
coolant temperature gauge
indicates overheating, imme-
diately turn off the air condi-
tioning (if in use), pull your
vehicle off the road and stop
in a safe spot. (



P.423)



Always place wheel blocks
under both the vehicle’s and
the trailer’s wheels when
parking. Put the transmission
in P and apply the parking
brake. Avoid parking on a
slope, but if unavoidable, do
so only after performing the
following:

Apply the brakes and keep
them applied.

Have someone place wheel
blocks under both the vehi-
cle’s and trailer’s wheels.

When the wheel blocks are in
place, release the brakes
slowly until the blocks absorb
the load.

Shift into P and apply the
parking brake.

Turn off the engine.



When restarting after parking
on a slope:

With the transmission in P,
start the engine. Be sure to
keep the brake pedal
depressed.

Shift into a forward gear. If
reversing, shift into R.

If the parking brake is in man-
ual mode, release the park-
ing brake. (



P.172)

Release the brake pedal, and
slowly pull or back away from
the wheel blocks. Stop and
apply the brakes.

Have someone retrieve the
blocks.

162

4-2. Driving procedures

4-2.Driving procedures

Check that the parking brake
is set. (



P.172)

Check that the shift lever is in
P.

Do not press the shift lever button

after shifting the shit position to P.

Firmly depress the brake
pedal.

Turn the engine switch to
START to start the engine.

■

If the engine does not start

The engine immobilizer system may

not have been deactivated. (



P.68)

Contact your Toyota dealer.

■

When the steering lock cannot

be released

When starting the engine, the

engine switch may seem stuck in

OFF. To free it, turn the key while

turning the steering wheel slightly

left and right.

OFF (“LOCK” position)

The key can be removed. (The key
can be removed only when the shift
lever is in P.)

ACC (“ACC” position)

Some electrical components such
as the audio system can be used.

ON ( “ON” position)

Engine (ignition)

switch (vehicles with-

out a smart key sys-

tem)

Starting the engine

WARNING

■

When starting the engine

Always start the engine while sit-

ting in the driver’s seat. Do not

depress the accelerator pedal

while starting the engine under

any circumstances. Doing so may

cause an accident resulting in

death or serious injury.

NOTICE

■

When starting the engine

●

Do not crank the engine for

more than 30 seconds at a time.

This may overheat the starter

and wiring system.

●

Do not race a cold engine.

●

If the engine becomes difficult to

start or stalls frequently, have

your vehicle checked by your

Toyota dealer immediately.

Changing the engine
switch positions

163

4-2. Driving procedures

ing

All electrical components can be
used.

START ( “START” position)

For starting the engine.

■

Turning the key from ACC to

OFF

Shift the shift lever to P.

Push in the key and turn it to

OFF.

■

Key reminder function

A buzzer sounds if the driver’s door

is opened while the engine switch is

in OFF or ACC to remind you to

remove the key.

Check that the parking brake
is set. (



P.172)

Check that the shift lever is in
P.

Firmly depress the brake
pedal.

and a message will be dis-

played on the multi-information dis-

play.
If it is not displayed, the engine

cannot be started.

Press the engine switch
shortly and firmly.

When operating the engine switch,

one short, firm press is enough. It is

not necessary to press and hold the

switch.
The engine will crank until it starts

or for up to 30 seconds, whichever

is less.
Continue depressing the brake

pedal until the engine is completely

started.
The engine can be started from any

WARNING

■

Caution when driving

Do not turn the engine switch to

OFF while driving. If, in an emer-

gency, you must turn the engine

off while the vehicle is moving,

turn the engine switch only to

ACC to stop the engine. An acci-

dent may result if the engine is

stopped while driving. (



P.382)

NOTICE

■

To prevent battery discharge

Do not leave the engine switch in

ACC or ON for long periods of

time without the engine running.

Engine (ignition)

switch (vehicles with

a smart key system)

Performing the following
operations when carrying
the electronic key on your
person starts the engine or
changes engine switch
modes.

Starting the engine

164

4-2. Driving procedures

engine switch mode.

■

Engine switch illumination

According to the situation, the

engine switch illumination operates

as follows.

●

When a door is opened, or the

engine switch mode is changed

from ACC or ON to off, the engine

switch illumination comes on.

●

When depressing the brake pedal

with carrying the electronic key on

your person, the engine switch

illumination blinks.

●

When the engine switch mode is

in ACC or ON, the engine switch

illumination is constantly illumi-

nated.

■

If the engine does not start

●

The engine immobilizer system

may not have been deactivated.

(



P.68)

Contact your Toyota dealer.

●

If a message related to start-up is

shown on the multi-information

display, read the message and fol-

low the instructions.

■

If the battery is discharged

The engine cannot be started using

the smart key system. Refer to

P.419to restart the engine.

■

Electronic key battery depletion



P.98

■

Conditions affecting operation



P.119

■

Notes for the entry function



P.120

■

Electronic key battery



P.368

■

Operation of the engine switch

●

If the switch is not pressed shortly

and firmly, the engine switch

mode may not change or the

engine may not start.

●

If attempting to restart the engine

immediately after turning the

engine switch off, the engine may

not start in some cases. After turn-

ing the engine switch off, please

wait a few seconds before restart-

ing the engine.

■

Customization

If the smart key system has been

deactivated in a customized setting,

refer to P.417.

WARNING

■

When starting the engine

Always start the engine while sit-

ting in the driver’s seat. Do not

depress the accelerator pedal

while starting the engine under

any circumstances.

Doing so may cause an accident

resulting in death or serious injury.

NOTICE

■

When starting the engine

●

Do not race a cold engine.

●

If the engine becomes difficult to

start or stalls frequently, have

your vehicle checked by your

Toyota dealer immediately.

165

4-2. Driving procedures

ing

Stop the vehicle completely.

Set the parking brake
(



P.172), and shift the shift

lever to P.

Check the parking brake indicator

is illuminated.
Do not press the shift lever button

after shifting the shit position to P.

Press the engine switch.

The engine will stop, and the meter

display will be extinguished.

Release the brake pedal and
check that “ACCESSORY” or
“IGNITION ON” is not shown
on the multi-information dis-
play.

■

Automatic engine shut off fea-

ture

●

The vehicle is equipped with a

feature that automatically shuts off

the engine when the shift lever is

in P with the engine running for an

extended period.

●

The engine will automatically shut

off after approximately 1 hour if it

has been left running while the

shift lever is in P.

●

The timer for the automatic engine

shut off feature will reset if the

brake pedal is depressed or if the

shift lever is in a position other

than P.

●

After the vehicle is parked, if the

door is locked with the door lock

switch (



P.107) from the inside or

the mechanical key (



P.417) from

the outside, the automatic engine

shut off feature will be disabled.

The timer for the automatic engine

shut off feature will be re-enabled

if the driver’s door is opened.

NOTICE

■

Symptoms indicating a mal-

function with the engine

switch

If the engine switch seems to be

operating somewhat differently

than usual, such as the switch

sticking slightly, there may be a

malfunction. Contact your Toyota

dealer immediately.

Stopping the engine

WARNING

■

Stopping the engine in an

emergency

●

If you want to stop the engine in

an emergency while driving the

vehicle, press and hold the

engine switch for more than 2

seconds, or press it briefly 3

times or more in succession.

(



P.382)

However, do not touch the

engine switch while driving

except in an emergency. Turn-

ing the engine off while driving

will not cause loss of steering or

braking control, but the power

assist to these systems will be

lost. This will make it more diffi-

cult to steer and brake, so you

should pull over and stop the

vehicle as soon as it is safe to

do so.

●

If the engine switch is operated

while the vehicle is running, a

warning message will be shown

on the multi-information display

and a buzzer sounds.

●

To restart the engine after per-

forming an emergency shut-

down, shift the shift lever to N

and then press the engine

switch.

166

4-2. Driving procedures

Modes can be changed by
pressing the engine switch with
brake pedal released. (The
mode changes each time the
switch is pressed.)

OFF

The emergency flashers can be
used.

ACC

Some electrical components such
as the audio system can be used.
“ACCESSORY” will be displayed
on the multi-information display.

All electrical components can be
used.
“IGNITION ON” will be displayed on
the multi-information display.

:If the shift lever is in a position

other than P or the shift lever
button is pressed when turning
off the engine, the engine switch
will be turned to ACC, not to off.

:ACC mode can be enabled/dis-

abled on the customize menu.
(



P.449)

WARNING

■

When parking

Exhaust gases include harmful

carbon monoxide (CO), which is

colorless and odorless. Observe

the following precautions.
Failure to do so may cause

exhaust gases to enter the vehicle

and may lead to an accident

caused by light-headedness, or

may lead to death or a serious

health hazard.

●

If the vehicle is in a poorly venti-

lated area or a closed area,

such as a garage, stop the

engine.

●

Do not leave the vehicle with

the engine running for a long

time. If such a situation cannot

be avoided, park the vehicle in

an open space and ensure that

exhaust fumes do not enter the

vehicle interior.

●

Do not leave the engine running

in an area with snow build-up,

or where it is snowing. If snow-

banks build up around the vehi-

cle while the engine is running,

exhaust gases may collect and

enter the vehicle.

Changing engine switch
modes

167

4-2. Driving procedures

ing

■

Auto power off function

If the vehicle is left in ACC for more

than 20 minutes or ON (the engine

is not running) for more than an

hour with the shift lever is in P or the

shift lever button is not pressed, the

engine switch will automatically turn

off. However, this function cannot

entirely prevent battery discharge.

Do not leave the vehicle with the

engine switch in ACC or ON for long

periods of time when the engine is

not running.

■

When ACC customization is in

off

●

With the engine switch is turned

off, the multimedia system can still

be used for a certain time until the

battery saving function starts

operating.

●

When the safe exit assist is oper-

ating, a buzzer will sound and a

voice guidance will be given.

(vehicles with safe exit assist)

If the engine is stopped when
the shift lever is in a position
other than P or the shift lever
button is pressed, the engine

switch will not be turned off but
instead be turned to ACC. Per-
form the following procedure to
turn the switch off:

Check that the parking brake
is set.

Shift the shift lever to P.

Do not press the shift lever button

after shifting the shit position to P.

Check that “ACCESSORY” is
displayed on the multi-infor-
mation display and press the
engine switch shortly and
firmly.

Check that “ACCESSORY”
or “IGNITION ON” on the
multi-information display are
off.

NOTICE

■

To prevent battery discharge

●

Do not leave the engine switch

in ACC or ON for long periods of

time without the engine running.

●

If “ACCESSORY” or “IGNITION

ON” is displayed on the

multi-information display, the

engine switch is not off. Exit the

vehicle after turning the engine

switch off.

When stopping the engine
with the shift lever in a
position other than P

NOTICE

■

To prevent battery discharge

Do not stop the engine with the

shift lever in a position other P or

the shift lever button pressed. If

the engine is stopped with the

shift lever in a position other than

P or the shift lever button pressed,

the engine switch will not be

turned off but instead be turned to

ACC mode. If the vehicle is left in

ACC, battery discharge may

occur.

168

4-2. Driving procedures

: To improve fuel efficiency and

reduce noise, shift the shift lever
to D for normal driving.

■

To protect the continuously

variable transmission

If the transmission fluid tempera-

ture is high, “Transmission Oil Temp

High Stop in a Safe Place and See

Owner’s Manual” will be displayed

while driving, make sure to return to

D position driving and reduce speed

by easing off the accelerator pedal.

Stop the vehicle in a safe place, shift

the shift lever to P and let the engine

idle until the warning message goes

out.
When the warning message goes

out, the vehicle can be driven again.
If the warning message does not go

out after waiting a while, have your

vehicle inspected by your Toyota

dealer.

■

Restraining sudden start

(Drive-Start Control)



P.147

■

After recharging/reconnecting

the battery



P.421

:While the engine switch is in

ON and the brake pedal
depressed

, shift the shift lever

Continuously variable

transmission

Select the shift position
depending on your purpose
and situation.

Shift position purpose
and functions

Shift posi-

tion

Objective or function

Parking the vehi-

cle/starting the engine

Reversing

Neutral

(Condition in which the

power is not transmit-

ted)

Normal driving

10-speed sport sequen-

tial shiftmatic mode

driving (



P.170)

WARNING

■

When driving on slippery

road surfaces

Do not accelerate or shift the shift

gears suddenly.

Sudden changes in engine brak-

ing may cause the vehicle to spin

or skid, resulting in an accident.

Shifting the shift lever

169

4-2. Driving procedures

ing

while pushing the shift release
button on the shift knob.

:Shift the shift lever while

pushing the shift release button
on the shift knob.

:Shift the shift lever normally.

When shifting the shift lever
between P and D, make sure that
the vehicle is completely stopped
and the brake pedal is depressed.

: For the vehicle be able to be

shifted from P, the brake pedal
must be depressed before the
shift release button is pushed. If
the shift release button is pushed
first, the shift lock will not be
released.

■

Continuously variable transmis-

sion fail-safe control

The system detects malfunctioning

parts targeted (all of the solenoids

that perform the shifting function) by

the On-Board Diagnostics, and per-

forms fail-safe mechanisms, such

as restricting the shifting function or

transmission ratio control.

In this event, the malfunction indica-

tor lamp turns on.

■

Shift lock system

The shift lock system is a system to

prevent accidental operation of the

shift lever in starting.

The shift lever can be shifted from P

only when the engine switch is in

ON and the brake pedal is being

depressed.

■

If the shift lever cannot be

shifted from P

First, check whether the brake pedal

is being depressed.

If the shift lever cannot be shifted

with your foot on the brake pedal,

there may be a problem with the

shift lock system. Have the vehicle

inspected by your Toyota dealer

immediately.

The following steps may be used as

an emergency measure to ensure

that the shift lever can be shifted.

Releasing the shift lock:

Set the parking brake.

Turn the engine switch off.

Depress the brake pedal.

Ply the cover up with a flathead

screwdriver or equivalent tool.

To prevent damaging the cover,

wrap the tip of the flathead

screwdriver with a tape.

Press and hold the shift lock

override button and then push

the shift release button on the

shift knob.

The shift lever can be shifted while

the button is pressed.

170

4-2. Driving procedures

To enter 10-speed sport
sequential shiftmatic mode, shift
the shift lever to M position.
Gear steps can then be selected
by operating the shift lever,
allowing you to drive in the gear
step of your choosing.

Upshifting

Downshifting

The gear changes once every time
the shift lever is operated.

The selected gear step, from M1 to
M10, will be displayed on the
multi-information display.

However, even when in the M
position, the gear steps will be
automatically changed if the
engine speed is too high, or too
low.

■

Gear step functions

●

You can choose from 10 levels of

engine braking force.

●

A lower gear step will provide

greater engine braking force than

a higher gear step, and the engine

speed will also increase.

■

When the vehicle comes to a

stop with the shift lever in the M

position

●

The transmission will automati-

cally downshift to M1 once the

vehicle is stopped.

●

After a stop, the vehicle will start

off in M1.

●

When the vehicle is stopped, the

transmission is set at M1.

■

Downshifting restriction warn-

ing buzzer

To help ensure safety and driving

performance, downshifting opera-

tion may sometimes be restricted. In

some circumstances, downshifting

may not be possible even when the

shift lever is operated. (A buzzer will

sound twice.)

■

If the 10-speed sport sequential

shiftmatic mode indicator does

not come on even after shifting

the shift lever to M

This may indicate a malfunction in

the continuously variable transmis-

sion system. Have the vehicle

inspected by your Toyota dealer

immediately.

(In this situation, the transmission

will operate in the same manner as

when the shift lever is in D.)

WARNING

■

To prevent an accident when

releasing the shift lock

Before pressing the shift lock

override button, make sure to set

the parking brake and depress the

brake pedal.

If the accelerator pedal is acci-

dentally depressed instead of the

brake pedal when the shift lock

override button is pressed and the

shift lever is shifted out of P, the

vehicle may suddenly start, possi-

bly leading to an accident result-

ing in death or serious injury.

Changing gears in the M
position

171

4-2. Driving procedures

ing

Right turn

Lane change to the right
(move the lever partway and
release it)

The right hand signals will flash 3
times.

Lane change to the left
(move the lever partway and
release it)

The left hand signals will flash 3
times.

Left turn

■

Turn signals can be operated

when

The engine switch is in ON.

■

If the indicator flashes faster

than usual

Check that a light bulb in the front or

rear turn signal lights has not

burned out.

Turn signal lever

Operating instructions

172

4-2. Driving procedures

■

Using the manual mode

The parking brake can be set
and released manually.

Parking brake switch indica-
tor
Parking brake indicator light
(U.S.A.)
Parking brake indicator light
(Canada)

Pull the switch to set the
parking brake.

The parking brake indicator light
and the parking brake switch indi-
cator will turn on.
Pull and hold the parking brake
switch if an emergency occurs and
it is necessary to operate the park-
ing brake while driving.

Press the switch to release
the parking brake.

• Operate the parking brake switch

while depressing the brake pedal.

• Using the parking brake auto-

matic release function, the park-
ing brake can be released by
depressing the accelerator pedal.
When using this function, slowly
depress the accelerator pedal.
(



P.173)

Make sure that the parking brake
indicator light and the parking brake
switch indicator turn off.

If the parking brake indicator
light and the parking brake
switch indicator flash, oper-
ate the switch again.
(



P.398)

■

Turning the automatic
mode on

While the vehicle is stopped,
pull and hold the parking brake
switch until a buzzer sounds and
a message is shown on the
multi-information display.

Parking brake

The parking brake can be
set or released automati-
cally or manually.

In automatic mode, the
parking brake can be set or
released automatically
according to shift lever
operation. Also, even in
automatic mode, the park-
ing brake can be set or
released manually.

Operating instructions

173

4-2. Driving procedures

ing

When the automatic mode is
turned on, the parking brake
operates as follows.



When the shift lever is shifted
from P, the parking brake will
be released, and the parking
brake indicator light and the
parking brake switch indica-
tor will turn off.



When the shift lever is shifted
to P, the parking brake will be
set, and the parking brake
indicator light and the parking
brake switch indicator will turn
on.

Operate the shift lever with the
vehicle stopped and the brake
pedal depressed.

The auto function may not operate
if the shift lever is moved extremely
quickly or the brake pedal is not
firmly depressed. In this situation,
apply the parking brake manually.
(



P.172)

■

Turning the automatic
mode off

While the vehicle is stopped and
depressing the brake pedal,
press and hold the parking
brake switch until a buzzer

sounds and a message is
shown on the multi-information
display.

■

Parking brake operation

●

When the engine switch is not in

ON, the parking brake cannot be

released using the parking brake

switch.

●

When the engine switch is not in

ON, automatic mode (automatic

brake setting and releasing) is not

available.

■

Parking brake automatic

release function

When all of the following conditions

are met, the parking brake can be

released by depressing the acceler-

ator pedal.

●

The driver’s door is closed

●

The driver is wearing the seat belt

●

The shift lever is in a forward driv-

ing position or reverse driving

position

●

The malfunction indicator lamp or

brake system warning light is not

illuminated.

When depressing the accelerator

pedal, depress it slowly.
If the parking brake is not released

when the accelerator pedal is

depressed, release the parking

brake manually.
When the shift lever is shifted from

P, the parking brake will be released

automatically.

Toyota Corolla Cross (2023 year). Manual in english - page 10
