2-1. Instrument cluster

Vehicle

statu

s information an

d in
dicator

■

Meter display settings that
can be changed



Language

Select to change the language dis-
played.



Units

Select to change the units of mea-
sure displayed.



Meter Type

Select to change the meter type.



Dial Type

Select to change the display of the
speedometer or tachometer.



Eco Driving Indicator Light

Select to enable/disable the Eco
Driving Indicator Light.



Fuel economy display
Select to change the average fuel
consumption display to any of the
following: trip average/total aver-
age/tank average. (



P.90)



Select to display/not display the
audio system linked display.



Select to change the displayed con-
tent of the following:
• Drive information type
Select to change the drive informa-
tion type display between trip infor-
mation/total information.
• Drive information items
Select to set the first and second

items of the drive information dis-
play to any of the following: aver-
age vehicle
speed/distance/elapsed time.



Pop-up display

Select to enable/disable pop-up
displays for each relevant system.



Multi-information display off

Select to turn the multi-information
display off.
To turn the multi-information display
on again, press any of the following
meter control switches



Default setting

Select to reset the meter display
settings to the default setting.

■

Vehicle functions and set-
tings that can be changed



P.449

■

Suspension of the settings dis-

play

●

Some settings cannot be changed

while driving. When changing set-

tings, park the vehicle in a safe

place.

●

If a warning message is displayed,

operation of the settings display

will be suspended.

Settings display

2-1. Instrument cluster

Displays suggestions to the
driver in the following situations.
To select a response to a dis-
played suggestion, use the
meter control switches.

■

Suggestion to enable the
power back door (if
equipped)

If the power back door system is
disabled (setting on

set to

off) and the power back door
switch on the instrument panel
is operated, a suggestion mes-
sage will be displayed asking if
you wish to enable the power
back door system.
To enable the power back door

system, select “Yes”.

After enabling the power back door
system, press the power back door
switch again to open or close the
power back door.

■

Suggestion to turn off the
headlights

If the headlights are left on for a
certain amount of time after the
engine switch has been turned
off, if the headlight switch is in
the “AUTO” position, a sugges-
tion message will be displayed
asking if you wish to turn the
headlights off.
To turn the headlights off, select
“Yes”.

If the driver's door is opened after
the engine switch is turned off, this
suggestion message will not be dis-
played.

WARNING

■

Cautions during setting up

the display

If the engine is running when

changing the display settings,

ensure that the vehicle is parked

in a place with adequate ventila-

tion. In a closed area such as a

garage, exhaust gases including

harmful carbon monoxide (CO)

may collect and enter the vehicle.

This may lead to death or a seri-

ous health hazard.

NOTICE

■

During setting up the display

To prevent battery discharge,

ensure that the engine is running

while setting up the display fea-

tures.

Suggestion function (if
equipped)

2-1. Instrument cluster

Vehicle

statu

s information an

d in
dicator

Audio system screen

Select

on the main menu.

Select “Trip information”.

Select “Current” or “History”.

■

Current fuel consumption

Resetting the consumption
data

Fuel consumption in the past
15 minutes
Current fuel consumption
Average vehicle speed since
the engine was started.
Elapsed time since the
engine was started.
Cruising range

Use the displayed average fuel
consumption as a reference.
The image is an example only, and
may vary slightly from actual condi-
tions.

■

History fuel consumption

Best recorded fuel consump-
tion
Latest fuel consumption
Previous fuel consumption
record
Resetting the history data
Updating the latest fuel con-
sumption data

Use the displayed average fuel
consumption as a reference.
The image is an example only, and
may vary slightly from actual condi-
tions.

Fuel consumption

information

Fuel consumption informa-
tion can be displayed on the
audio system screen.

System components

Displaying fuel consump-
tion screen

2-1. Instrument cluster

■

Updating the history data

Update the latest fuel consumption

by selecting “Update” to measure

the current fuel consumption again.

■

Resetting the data

The fuel consumption data can be

deleted by selecting “Clear data”.

■

Cruising range

Displays the estimated maximum

distance that can be driven with the

quantity of fuel remaining.
This distance is computed based on

your average fuel consumption.
As a result, the actual distance that

can be driven may differ from that

displayed.

Before driv

ing

Before driving

3-1. Key information

Keys ...............................

3-2. Opening, closing and

locking the doors

Side doors...................

103

Back door....................

108

Smart key system .......

118

3-3. Adjusting the seats

Front seats ..................

123

Rear seats...................

124

Head restraints............

126

3-4. Adjusting the steering

wheel and mirrors

Steering wheel ............

128

Inside rear view mirror

..................................

129

Outside rear view mirrors

..................................

130

3-5. Opening and closing the

windows

Power windows ...........

132

Moon roof....................

135

3-6. Favorite settings

My Settings .................

138

3-1. Key information

3-1.Key information

The following keys are provided
with the vehicle.



Vehicles without a smart key
system

Keys

Operating the wireless remote con-
trol function (



P.100)

Key number plate



Vehicles with a smart key sys-
tem

Electronic keys

• Operating the smart key system

(



P.118)

• Operating the wireless remote

control function (



P.100)

Mechanical keys
Key number plate

■

When riding in an aircraft

When bringing a key or an elec-

tronic key onto an aircraft, make

sure you do not press any buttons

on the key or the electronic key

while inside the aircraft cabin. If you

are carrying a key or an electronic

key in your bag, etc., ensure that the

buttons are not likely to be pressed

accidentally. Pressing a button may

cause the key or the electronic key

to emit radio waves that could inter-

fere with the operation of the air-

craft.

■

Key battery depletion



Vehicles without a smart key sys-

tem

●

The standard battery life is 1 to 2

years.

●

The battery will become depleted

even if the key is not used. The

following symptoms indicate that

the key battery may be depleted.

Replace the battery when neces-

sary. (



P.368)

• The wireless remote control does

not operate.

• The detection area becomes

smaller.



Vehicles with a smart key system

●

The standard battery life is 1 to 2

years.

●

If the battery becomes low, an

alarm will sound in the cabin and a

message will be shown on the

multi-information display when the

engine is stopped.

●

To reduce key battery depletion

when the electronic key is to not

be used for long periods of time,

set the electronic key to the bat-

tery-saving mode. (



P.119)

●

As the electronic key always

receives radio waves, the battery

will become depleted even if the

electronic key is not used. The fol-

lowing symptoms indicate that the

electronic key battery may be

depleted. Replace the battery

Keys

The keys

3-1. Key information

Before driv

ing

when necessary. (



P.368)

• The smart key system or the wire-

less remote control does not oper-

ate.

• The detection area becomes

smaller.

• The LED indicator on the key sur-

face does not turn on.

●

To avoid serious deterioration, do

not leave the electronic key within

3 ft. (1 m) of the following electri-

cal appliances that produce a

magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones

and battery chargers

• Recharging cellular phones or

cordless phones

• Table lamps

• Induction cookers

●

If the electronic key is near the

vehicle for longer than necessary,

even if the smart key system is not

operated, the key battery may

become depleted faster than nor-

mal.

■

Replacing the battery



P.368

■

Confirmation of the registered

key number

The number of keys already regis-

tered to the vehicle can be con-

firmed. Ask your Toyota dealer for

details.

■

If “A New Key has been Regis-

tered Contact Your Dealer for

Details” is shown on the

multi-information display (vehi-

cles with a smart key system)

This message will be displayed

each time the driver’s door is

opened when the doors are

unlocked from the outside for

approximately 10 days after a new

electronic key has been registered.

If this message is displayed but you

have not had a new electronic key

registered, ask your Toyota dealer to

check if an unknown electronic key

(other than those in your posses-

sion) has been registered.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject

them to strong shocks or bend

them.

●

Do not expose the keys to high

temperatures for long periods of

time.

●

Do not get the keys wet or wash

them in an ultrasonic washer

etc.

●

Vehicles with a smart key sys-

tem: Do not attach metallic or

magnetic materials to the keys

or place the keys close to such

materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or any-

thing else to the surface of the

key.

●

Vehicles with a smart key sys-

tem: Do not place the keys near

objects that produce magnetic

fields, such as TVs, audio sys-

tems and induction cookers.

●

Vehicles with a smart key sys-

tem: Do not place the keys near

medical electrical equipment

such as low-frequency therapy

equipment or microwave ther-

apy equipment, and do not

receive medical attention with

the keys on your person.

100

3-1. Key information

The keys are equipped with the
following wireless remote con-
trol:



Vehicles without a smart key
system

Locks the doors (



P.103)

Unlocks the doors (



P.103)

Opens the windows

(



P.103)

Sounds the alarm (



P.100)



Vehicles with a smart key sys-
tem

Locks the doors (



P.103)

Unlocks the doors (



P.103)

Opens the windows

and

moon roof

*1, 2

(



P.103)

Opens and closes the power
back door

(



P.112)

Sounds the alarm (



P.100)

:This setting must be customized

at your Toyota dealer.

:If equipped

■

Panic mode



Vehicles without a smart key sys-

tem

When

is pressed for longer

than about one second, an alarm

will sound intermittently and the

vehicle lights will flash to deter any

person from trying to break into or

damage your vehicle.
To stop the alarm, press any button

on the wireless remote control.

NOTICE

■

Carrying the electronic key

on your person (vehicles with

a smart key system)

Carry the electronic key 3.9 in.

(10 cm) or more away from elec-

tric appliances that are turned on.

Radio waves emitted from electric

appliances within 3.9 in. (10 cm)

of the electronic key may interfere

with the key, causing the key to

not function properly.

■

In case of a smart key system

malfunction or other

key-related problems (vehi-

cles with a smart key system)



P.417

■

When an electronic key is lost

(vehicles with a smart key

system)



P.417

Wireless remote control

101

3-1. Key information

Before driv

ing



Vehicles with a smart key system

When

is pressed for longer

than about one second, an alarm

will sound intermittently and the

vehicle lights will flash to deter any

person from trying to break into or

damage your vehicle.
To stop the alarm, press any button

on the electronic key.

■

Conditions affecting the opera-

tion of the smart key system or

wireless remote control



Vehicles without a smart key sys-

tem

The wireless remote control function

may not operate normally in the fol-

lowing situations:

●

When the wireless key battery is

depleted

●

Near a TV tower, electric power

plant, gas station, radio station,

large display, airport or other facil-

ity that generates strong radio

waves or electrical noise

●

When carrying a portable radio,

cellular phone or other wireless

communication devices

●

When the wireless key is in con-

tact with, or is covered by a metal-

lic object

●

When a wireless key (that emits

radio waves) is being used nearby

●

If window tint with a metallic con-

tent or metallic objects are

attached to the rear window



Vehicles with a smart key system



P.119

To take out the mechanical key,
slide the release button and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one
side. If the key cannot be
inserted in a lock cylinder, turn it
over and re-attempt to insert it.
After using the mechanical key,
store it in the electronic key.
Carry the mechanical key
together with the electronic key.
If the electronic key battery is
depleted or the entry function
does not operate properly, you
will need the mechanical key.
(



P.417)

Using the mechanical key
(vehicles with a smart key
system)

102

3-1. Key information

■

If you lose your mechanical

keys



P.417

■

If a wrong key is used

The key cylinder rotates freely, iso-

lated from the internal mechanism.

103

3-2. Opening, closing and locking the doors

Before driv

ing

3-2.Opening, closing and locking the doors

■

Smart key system (if
equipped)

Carry the electronic key to
enable this function.

Grip the driver’s door handle
to unlock the door. Holding
the driver’s door handle for
approximately 2 seconds
unlocks all the doors. Grip
the front passenger’s door
handle to unlock all the
doors.

Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for 3
seconds after the doors are locked.

: The door unlock settings can be

changed. (



P.104, 449)

Touch the lock sensor (the
indentation on the side of the
front door handle) to lock all
the doors.

Check that the door is securely
locked.

■

Wireless remote control



Vehicles without a smart key
system

Locks all the doors

Check that the door is securely
locked.

Unlocks all the doors

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Press and hold to open the win-
dows



Vehicles with a smart key sys-
tem

Locks all the doors

Check that the door is securely
locked.

Unlocks all the doors

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the

Side doors

Unlocking and locking the
doors from the outside

104

3-2. Opening, closing and locking the doors

other doors.
Press and hold to open the win-
dows

and moon roof

*1, 2

:This setting must be customized

at your Toyota dealer.

:If equipped

■

Key

Turning the key operates the
doors as follows:



Vehicles without a smart key
system

Unlocks all the doors

Turning the key unlocks the driver’s
door. Turning the key again unlocks
the other doors.
Turn and hold to open the win-
dows

Locks all the doors

Turn and hold to close the win-
dows

: This setting must be customized

at your Toyota dealer.



Vehicles with a smart key sys-
tem

The doors can also be locked
and unlocked with the mechani-
cal key. (



P.418)

■

Switching the door unlock func-

tion (vehicles with a smart key

system)

It is possible to set which doors the

entry function unlocks using the

wireless remote control.

Turn the engine switch off.

When the indicator light on the

key surface is not on, press and
hold

(if equipped) or

for approximately 5 sec-

onds while pressing and holding

The setting changes each time an

operation is performed, as shown

below. (When changing the setting

continuously, release the buttons,

wait for at least 5 seconds, and

repeat step

For vehicles with an alarm: To pre-

vent unintended triggering of the

alarm, unlock the doors using the

wireless remote control and open

and close a door once after the set-

tings have been changed. (If a door

is not opened within 60 seconds
after

is pressed, the doors will

Multi-informa-

tion display/Beep

Unlocking func-

tion

Beeps 3 times

Holding the
driver’s door
handle unlocks
only the driver’s
door.

Holding the front
passenger’s
door handle
unlocks all the
doors.

Beeps twice

Holding either
front door handle
unlocks all the
doors.

105

3-2. Opening, closing and locking the doors

Before driv

ing

be locked again and the alarm will

automatically be set.)

In case that the alarm is triggered,

immediately stop the alarm. (



P.69)

■

Impact detection door lock

release system

In the event that the vehicle is sub-

ject to a strong impact, all the doors

are unlocked. Depending on the

force of the impact or the type of

accident, however, the system may

not operate.

■

Operation signals

A buzzer sounds and the emer-

gency flashers flash to indicate that

the doors have been

locked/unlocked using the entry
function

or wireless remote control.

(Locked: Once; Unlocked: Twice)
A buzzer sounds to indicate that the
windows and moon roof

are operat-

ing.

: If equipped

■

Security feature

If a door is not opened within

approximately 60 seconds after the

vehicle is unlocked using the entry
function

or wireless remote control,

the security feature automatically

locks the vehicle again.

: If equipped

■

When the door cannot be

locked by the lock sensor on

the surface of the front door

handle (vehicles with a smart

key system)

If the doors cannot be locked by

touching the lock sensor with a fin-

ger, touch the lock sensor with the

palm of your hand.
If you are wearing gloves, remove

them.

■

Door lock buzzer



Vehicles without a smart key sys-

tem

If an attempt to lock the doors using

the wireless remote control is made

when a door is not fully closed, a

buzzer will sound continuously for

10 seconds. Fully close the door to

stop the buzzer, and lock the doors

again.



Vehicles with a smart key system

If an attempt to lock the doors using

the entry function or wireless remote

control is made when a door is not

fully closed, a buzzer will sound

continuously for 5 seconds. Fully

close the door to stop the buzzer,

and lock the doors again.

■

Alarm (if equipped)

Locking the doors will set the alarm

system. (



P.69)

■

Conditions affecting the opera-

tion of the smart key system (if

equipped) or wireless remote

control



Vehicles without a smart key sys-

tem



P.101



Vehicles with a smart key system



P.119

■

If the smart key system (if

equipped) or the wireless

remote control does not oper-

ate properly



Vehicles without a smart key sys-

tem

Replace the key battery with a new

one if it is depleted. (



P.368)

106

3-2. Opening, closing and locking the doors



Vehicles with a smart key system

Use the mechanical key to lock and

unlock the doors. (



P.418)

Replace the key battery with a new

one if it is depleted. (



P.368)

■

If the battery is discharged

(vehicles with a smart key sys-

tem)

The doors cannot be locked and

unlocked using the smart key sys-

tem or wireless remote control. Lock

or unlock the doors using the

mechanical key. (



P.418)

■

Rear seat reminder function

In order to remind you not to forget

luggage, etc. in the rear seat, when

the engine switch is turned off after

any of the following conditions are

met, a buzzer will sound and a mes-

sage will be displayed on the

multi-information display for approx-

imately 6 seconds.

●

The engine is started within

approximately 10 minutes after

opening and closing a rear door.

●

A rear door has been opened and

closed after the engine was

started.

However, if a rear door is opened

and then closed within approxi-

mately 2 seconds, the rear seat

reminder function may not operate.
The rear seat reminder function

determines that luggage, etc. has

been placed in a rear seat based on

opening and closing of a rear door.

Therefore, depending on the situa-

tion, the rear seat reminder function

may not operate and you may still

forget luggage, etc. in the rear seat,

or it may operate unnecessarily.

■

Customization

Some functions can be customized.

(



P.449)

WARNING

■

To prevent an accident

Observe the following precautions

while driving the vehicle.

Failure to do so may result in a

door opening and an occupant

being thrown out of the vehicle,

resulting in death or serious injury.

●

Ensure that all doors are prop-

erly closed and locked.

●

Do not pull the inside door han-

dle while driving.

Be especially careful of the front

doors, as the doors may be

opened even if the inside lock

buttons are in the locked posi-

tion.

●

Set the rear door child-protector

locks when children are seated

in the rear seats.

■

When opening or closing a

door

Check the surroundings of the

vehicle such as whether the vehi-

cle is on an incline, whether there

is enough space for a door to

open and whether a strong wind

is blowing. When opening or clos-

ing the door, hold the door handle

tightly to prepare for any unpre-

dictable movement.

■

When using the wireless

remote control or the key and

operating the power win-

dows or moon roof (if

equipped)

Operate the power windows or

moon roof after checking to make

sure that there is no possibility of

any passenger having any of their

body parts caught in the windows

or moon roof. Also, do not allow

children to operate the wireless

remote control or the key. It is

possible for children and other

passengers to get caught in the

power windows or moon roof.

107

3-2. Opening, closing and locking the doors

Before driv

ing

■

Door lock switches (to
lock/unlock)

Locks all the doors

Unlocks all the doors

■

Inside lock buttons

Locks the door

Unlocks the door

The front doors can be opened by
pulling the inside handle even if the
lock buttons are in the lock position.

■

Locking the front doors from

the outside without a key

Move the inside lock button to

the lock position.

Close the door.



Vehicles without a smart key sys-

tem

The door cannot be locked if the key

is in the engine switch.



Vehicles with a smart key system

The door cannot be locked if the

engine switch is in ACC or ON, or

the electronic key is left inside the

vehicle.
The key may not be detected cor-

rectly and the door may be locked.

■

Open door warning buzzer

If a door or the hood is not fully

closed, a buzzer will sound when

the vehicle speed reaches 3 mph (5

km/h).
The open door(s) or hood is indi-

cated on the multi-information dis-

play.

The door cannot be opened
from inside the vehicle when
lock is set.

Unlock

Lock

These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.

The following functions can be
set or canceled:

Unlocking and locking the
doors from the inside

Rear door child-protector
lock

Automatic door locking
and unlocking systems

108

3-2. Opening, closing and locking the doors

For instructions on customizing,
refer to P.449.

Function

Operation

Speed linked
door locking
function

All doors are auto-
matically locked
when vehicle
speed is approxi-
mately 12 mph (20
km/h) or higher.

Shift position
linked door
locking func-
tion

All doors are auto-
matically locked
when shifting the
shift lever out of P.

Shift position
linked door
unlocking
function

All doors are auto-
matically unlocked
when shifting the
shift lever to P.

Driver’s door
linked door
unlocking
function

All doors are auto-
matically unlocked
when driver’s door
is opened.

Back door

The back door can be
locked/unlocked and
opened/closed by the fol-
lowing procedures.

WARNING

Observe the following precau-

tions. Failure to do so may result

in death or serious injury.

■

Before driving the vehicle

Before driving the vehicle, make

sure that the back door is fully

closed. If the back door is not fully

closed, it may open unexpectedly

while driving, causing an acci-

dent.

■

Caution while driving

●

Keep the back door closed

while driving.

If the back door is left open, it may

hit near-by objects while driving or

luggage may be unexpectedly

thrown out, causing an accident.
In addition, exhaust gases may

enter the vehicle, causing death

or a serious health hazard. Make

sure to close the back door before

driving.

●

Never let anyone sit in the lug-

gage compartment. In the event

of sudden braking, sudden

swerving or a collision, they are

susceptible to death or serious

injury.

■

When children are in the vehi-

cle

●

Do not allow children to play in

the luggage compartment.

If a child is accidentally locked in

the luggage compartment, they

could have heat exhaustion or

other injuries.

Content .. 4 5 6 7 ..
