289

4-5. Using the driving support systems

riv

ing

●

When there are spinning objects near
your vehicle such as the fan of an air

conditioning unit

●

When water is splashed or sprayed

toward the rear bumper, such as from

a sprinkler

●

Moving objects (flags, exhaust fumes,

large rain droplets or snowflakes, rain
water on the road surface, etc.)

●

When the distance between your vehi-
cle and a guardrail, wall, etc., that

enters the detection area is short

●

Gratings and gutters

●

When a sensor or the area around a
sensor is extremely hot or cold

●

If the suspension has been modified
or tires of a size other than specified

are installed

●

If the front of the vehicle is raised or

lowered due to the carried load

: If equipped

■

Parking Support Brake func-
tion (static objects)



P.294

■

Parking Support Brake func-
tion (rear-crossing vehicles)



P.297

PKSB (Parking Support
Brake)

The Parking Support Brake
system consists of the follow-
ing functions that operate
when driving at a low speed or
backing up, such as when
parking. When the system
determines that the possibility
of a collision with a detected
object is high, a warning oper-
ates to urge the driver to take
evasive action. If the system
determines that the possibility
of a collision with a detected
object is extremely high, the
brakes are automatically
applied to help avoid the colli-
sion or help reduce the impact
of the collision.

PKSB (Parking Support
Brake) system

290

4-5. Using the driving support systems

WARNING

■

Cautions regarding the use of

the system

Do not overly rely on the system, as

doing so may lead to an accident.
Always drive while checking the
safety of the surroundings of the vehi-

cle.
Depending on the vehicle and road
conditions, weather, etc., the system

may not operate.
The detection capabilities of sensors
and radars are limited. Always drive

while checking the safety of the sur-

roundings of the vehicle.

●

The driver is solely responsible for

safe driving. Always drive carefully,
taking care to observe your sur-

roundings. The Parking Support

Brake system is designed to pro-
vide support to lessen the severity

of collisions. However, it may not

operate in some situations.

●

The Parking Support Brake system

is not designed to stop the vehicle
completely. Additionally, even if the

system has stopped the vehicle, it

is necessary to depress the brake
pedal immediately as brake control

will be canceled after approximately

2 seconds.

●

It is extremely dangerous to check

the system operations by intention-
ally driving the vehicle into the

direction of a wall, etc. Never

attempt such actions.

■

When to disable the Parking Sup-

port Brake

In the following situations, disable the

Parking Support Brake as the system

may operate even though there is no
possibility of a collision.

●

When inspecting the vehicle using
a chassis roller, chassis dynamo or

free roller

●

When loading the vehicle onto a

boat, truck or other transport vessel

●

If the suspension has been modi-

fied or tires of a size other than

specified are installed

●

If the front of the vehicle is raised or

lowered due to the carried load

●

When equipment that may obstruct

a sensor is installed, such as a tow-
ing eyelet, bumper protector (an

additional trim strip, etc.), bicycle

carrier, or snow plow

●

When using automatic car washing

devices

●

If the vehicle cannot be driven in a

stable manner, such as when the
vehicle has been in an accident or

is malfunctioning

●

When the vehicle is driven in a

sporty manner or off-road

●

When the tires are not properly

inflated

●

When the tires are very worn

●

When a tire chains, compact spare
tire or an emergency tire puncture

repair kit is used

NOTICE

■

If “PKSB Unavailable” is dis-
played on the multi-information

display and the PKSB OFF indi-

cator is on

If this message is displayed immedi-

ately after the engine switch is

changed to ON, operate the vehicle
carefully, paying attention to your sur-

roundings. It may be necessary to

drive the vehicle for a certain amount
of time before the system returns to

normal. (If the system is not return to

normal after driving for a while, clean
the sensors and their surrounding

area on the bumpers.)

291

4-5. Using the driving support systems

riv

ing

The Parking Support Brake can be
enabled/disabled on the multi-infor-
mation display. All of the Parking
Support Brake functions (static
objects and rear-crossing vehicles)
are enabled/disabled simultane-
ously.
Use the meter control switches to
enable/disable the parking support
brake. (



P.95, 101)

Press

(4.2-inch display)

(7-inch display) of

the meter control switch to

select

Press

(4.2-inch display)

(7-inch display) of

the meter control switch to

select

and then press

When the Parking Support Brake is dis-
abled, the PKSB OFF indicator (



P.82)

illuminates.

To re-enable the system when it was

disabled, select

on the multi-infor-

mation display, select

and then

On. If disabled using this method, the
system will not be re-enabled by turning
the engine switch off and then to ON.

If the engine output restriction con-
trol or brake control operates, a
buzzer will sound and a message
will be displayed on the multi-infor-
mation display and head-up display
(if equipped) to alert the driver.

Depending on the situation, engine out-
put restriction control will operate to
either limit acceleration or restrict out-
put as much as possible.



Engine output restriction control
is operating (acceleration restric-
tion)

Acceleration greater than a certain
amount is restricted by the system.
Multi-information display: “Object
Detected Ahead Speed Reduced”
Head-up display (if equipped): No
warning displayed
PKSB OFF indicator: Not illuminated
Buzzer: Does not sound



Engine output restriction control
is operating (output restricted as
much as possible)

The system has determined that stron-
ger-than-normal brake operation is nec-
essary.
Multi-information display and head-up
display (if equipped): “BRAKE!”
PKSB OFF indicator: Not illuminated
Buzzer: Short beep



Brake control is operating

The system determined that emer-
gency braking is necessary.

Enabling/Disabling the Park-
ing Support Brake

Display and buzzer for
engine output restriction
control and brake control

292

4-5. Using the driving support systems

Multi-information display and head-up
display (if equipped): “BRAKE!”
PKSB OFF indicator: Not illuminated
Buzzer: Short beep



Vehicle stopped by system oper-
ation

The vehicle has been stopped by brake
control operation.
Multi-information display and head-up
display (if equipped): “Switch to Brake”
(If the accelerator pedal is not
depressed, “Press Brake Pedal” will be
displayed.)
PKSB OFF indicator: Illuminated
Buzzer: Short beep

If the Parking Support Brake deter-
mines that a collision with a
detected object is possible, the
engine output will be restricted to
restrain any increase in the vehicle
speed. (Engine output restriction
control: See figure 2.)
Additionally, if the accelerator pedal
continues to be depressed, the
brakes will be applied automatically
to reduce the vehicle speed. (Brake
control: See figure 3.)



Figure 1: When the PKSB (Park-
ing Support Brake) is not operat-
ing

Engine output

Braking force

Time



Figure 2: When engine output
restriction control operates

Engine output

Braking force

Time

Engine output restriction control

begins operating (System deter-
mines that possibility of collision
with detected object is high)



Figure 3: When engine output
restriction control and brake con-
trol operates

System overview

293

4-5. Using the driving support systems

riv

ing

Engine output

Braking force

Time

Engine output restriction control

begins operating (System deter-
mines that possibility of collision
with detected object is high)

Brake control begins operating

(System determines that possi-
bility of collision with detected
object is extremely high)

■

If the Parking Support Brake has

operated

If the vehicle is stopped due to operation
of the Parking Support Brake, the Park-

ing Support Brake will be disabled and

the PKSB OFF indicator will illuminate. If
the Parking Support Brake operates

unnecessarily, brake control can be can-

celed by depressing the brake pedal or
waiting for approximately 2 seconds for

it to automatically be canceled. Then,

the vehicle can be operated by depress-
ing the accelerator pedal.

■

Re-enabling the Parking Support

Brake

To re-enable the Parking Support Brake
when it is disabled due to operation of

the Parking Support Brake, either

enable the system again (



P.291), or

turn the engine switch off and then back

to ON. Additionally, if the object
becomes no longer in the traveling

direction of the vehicle or if the traveling

direction of the vehicle changes (such
as changing from moving forward to

backing up, or from backing up to mov-

ing forward), the system will be re-
enabled automatically.

■

If “PKSB Unavailable” is displayed

on the multi-information display

and the PKSB OFF indicator is on

If the vehicle is stopped due to operation

of the Parking Support Brake, the Park-

ing Support Brake will be disabled and
the PKSB OFF indicator will illuminate.

●

A sensor may be covered with water
drops, ice, snow, dirt, etc. Remove the

water drops, ice, snow, dirt, etc., from

the sensor to return the system to nor-
mal.

Also, due to ice forming on a sensor at

low temperatures, a warning message
may be displayed or the sensor may

not be able to detect an object. Once

the ice melts, the system will return to
normal.

●

If this message is displayed, a sensor
on the front or rear bumper may be

dirty. Clean the sensors and their sur-

rounding area on the bumpers.

●

If this message continues to be dis-

played even after cleaning the sensor,
or is displayed even though the sen-

sor is clean, have the vehicle

inspected by any authorized Toyota
retailer or Toyota authorized repairer,

or any reliable repairer.

294

4-5. Using the driving support systems

: If equipped

This function will operate in situations such as the following if an object is
detected in the traveling direction of the vehicle.

■

When traveling at a low speed and the brake pedal is not
depressed, or is depressed late

Parking Support Brake function (static objects)

If the sensors detect a static object, such as a wall, in the traveling
direction of the vehicle and the system determines that a collision
may occur due to the vehicle suddenly moving forward due to an
accidental accelerator pedal operation, the vehicle moving the unin-
tended direction due to the wrong shift position being selected, or
while parking or traveling at low speeds, the system will operate to
lessen the impact with the detected static object and reduce the
resulting damage.

Examples of function operation

295

4-5. Using the driving support systems

riv

ing

■

When the accelerator pedal is depressed excessively

■

When the vehicle moves in the unintended direction due to the
wrong shift position being selected



P.277

Types of sensors

WARNING

■

To ensure the system can oper-

ate properly



P.279

■

If the Parking Support Brake

function (static objects) oper-
ates unnecessarily, such as at a

railroad crossing



P.293

■

Notes when washing the vehicle



P.279

296

4-5. Using the driving support systems

■

The Parking Support Brake func-

tion (static object) will operate
when

The function will operate when the

PKSB OFF indicator is not illuminated or
flashing (



P.82, 409) and all of the fol-

lowing conditions are met:

●

Engine output restriction control

• The Parking Support Brake is

enabled.

• The vehicle speed is approximately 15

km/h (9 mph) or less.

• There is a static object in the traveling

direction of the vehicle and approxi-

mately 2 to 4 m (6 to 13 ft.) away.

• The Parking Support Brake deter-

mines that a stronger-than-normal

brake operation is necessary to avoid

a collision.

●

Brake control

• Engine output restriction control is

operating.

• The Parking Support Brake deter-

mines that an immediate brake opera-
tion is necessary to avoid a collision.

■

The Parking Support Brake func-

tion (static objects) will stop oper-

ating when

The function will stop operating if any of

the following conditions are met:

●

Engine output restriction control

• The Parking Support Brake is dis-

abled.

• The system determines that the colli-

sion has become avoidable with nor-
mal brake operation.

• The static object is no longer approxi-

mately 2 to 4 m (6 to 13 ft.) away from
the vehicle or in the traveling direction

of the vehicle.

●

Brake control

• The Parking Support Brake is dis-

abled.

• Approximately 2 seconds have

elapsed since the vehicle was

stopped by brake control.

• The brake pedal is depressed after

the vehicle is stopped by brake con-

trol.

• The static object is no longer approxi-

mately 2 to 4 m (6 to 13 ft.) away from

the vehicle or in the traveling direction

of the vehicle.

■

Re-enabling the Parking Support
Brake function (static objects)



P.293

■

Detection range of the Parking Sup-

port Brake function (static objects)

The detection range of the Parking Sup-

port Brake function (static objects) dif-

fers from the detection range of the
Toyota parking assist-sensor. (



P.282)

Therefore, even if the Toyota parking

assist-sensor detects an object and pro-
vides a warning, the Parking Support

Brake function (static objects) may not

start operating.

■

Objects which the system may not
be properly detected



P.280

■

Toyota parking assist-sensor

buzzer

Regardless of whether the Toyota park-

ing assist-sensor function is enabled or

not (



P.278), if the Parking Support

Brake function (static objects) is enabled

(



P.291), the front or rear sensors

detect an object and brake control and
engine output restriction control are per-

formed, the Toyota parking assist-sen-

sor buzzer will sound to notify the driver
of the approximate distance to the

object.

■

Situations in which the system may

not operate properly



P.280

■

Situations in which the system may

operate even if there is no possibil-

ity of a collision



P.281

297

4-5. Using the driving support systems

riv

ing

: If equipped

This function will operate in situations such as the following if a vehicle is
detected in the traveling direction of the vehicle.

■

When reversing, a vehicle is approaching and the brake pedal is not
depressed, or is depressed late



P.273

■

The Parking Support Brake func-

tion (rear-crossing vehicles) will
operate when

The function will operate when the

PKSB OFF indicator is not illuminated or
flashing (



P.82, 409) and all of the fol-

lowing conditions are met:

●

Engine output restriction control

• The Parking Support Brake is

enabled.

Parking Support Brake function (rear-crossing vehi-
cles)

If a rear radar sensor detects a vehicle approaching from the right
or left at the rear of the vehicle and the system determines that the
possibility of a collision is high, this function will perform brake
control to reduce the likelihood of an impact with the approaching
vehicle.

Examples of function operation

Types of sensors

WARNING

■

To ensure the system can oper-

ate properly



P.273

298

4-5. Using the driving support systems

• The vehicle speed is approximately 15

km/h (9 mph) or less.

• Vehicles which are approaching from

the right or left at the rear of the vehi-
cle at a traveling speed of approxi-

mately 8 km/h (5 mph) or more.

• The shift lever is in R.
• The Parking Support Brake deter-

mines that a stronger than normal

brake operation is necessary to avoid
a collision with an approaching vehi-

cle.

●

Brake control

• Engine output restriction control is

operating.

• The Parking Support Brake deter-

mines that an emergency brake oper-

ation is necessary to avoid a collision
with an approaching vehicle.

■

The Parking Support Brake func-

tion (rear-crossing vehicles) will

stop operating when

The function will stop operating if any of

the following conditions are met:

●

Engine output restriction control

• The Parking Support Brake is dis-

abled.

• The collision becomes avoidable with

normal brake operation.

• A vehicle is no longer approaching

from the right or left at the rear of the

vehicle.

●

Brake control

• The Parking Support Brake is dis-

abled.

• Approximately 2 seconds have

elapsed since the vehicle was

stopped by brake control.

• The brake pedal is depressed after

the vehicle is stopped by brake con-

trol.

• A vehicle is no longer approaching

from the right or left at the rear of the

vehicle.

■

Re-enabling the Parking Support
Brake function (rear-crossing vehi-

cles)



P.293

■

Detection area of the Parking Sup-
port Brake function (rear-crossing

vehicles)

The detection area of the Parking Sup-
port Brake function (rear-crossing vehi-

cles) differs from the detection area of

the RCTA function (



P.286). Therefore,

even if the RCTA function detects a

vehicle and provides an alert, the Park-

ing Support Brake function (rear-cross-
ing vehicles) may not start operating.

■

Conditions under which the system

will not detect a vehicle



P.287

■

RCTA buzzer

Regardless of whether the RCTA func-

tion is enabled or not (



P.284), if the

Parking Support Brake function is
enabled (



P.291) and brake control is

performed, a buzzer will sound to notify

the driver.

■

Situations in which the system may
not operate properly



P.287

■

Situations in which the system may

operate even if there is no possibil-
ity of a collision



P.288

299

4-5. Using the driving support systems

riv

ing

: If equipped

Each time the switch is pressed,
the system changes between
power mode, normal mode, and
ECO drive mode.

Normal mode

Provides an optimal balance of fuel
economy, quietness, and dynamic per-
formance. Suitable for normal driving.

Power mode

Controls the transmission and engine to
provide quick, powerful acceleration.
Making it suitable for when agile driving
response is desired, such as when driv-
ing on roads with many curves.
When the power mode is selected,
power mode indicator comes on.

Eco drive mode

Helps the driver accelerate in an eco-
friendly manner and improve fuel econ-
omy through moderate throttle charac-

teristics and by controlling the operation
of the air conditioning system (heat-
ing/cooling).
When the Eco drive mode is selected,
Eco drive mode indicator comes on.

■

Operation of the air conditioning
system in Eco drive mode

Eco drive mode controls the heat-

ing/cooling operations and fan speed of
the air conditioning system to enhance

fuel efficiency. To improve air condition-

ing performance, perform the following
operations:

●

Turn off air conditioning eco mode
(vehicles with an automatic air condi-

tioning system) (



P.318)

●

Adjust the fan speed (



P.312, 317)

●

Turn off Eco drive mode

■

Automatic deactivation of power
mode

If the engine switch is turned off after

driving in power mode, the drive mode
will be changed to normal mode.

Driving mode select
switch

The driving modes can be
selected to suit driving condi-
tion.

Selecting a drive mode

300

4-5. Using the driving support systems

: If equipped

■

If “Exhaust Filter Full See Owner’s

Manual” is shown on the multi-
information display

●

The message may be displayed while
high load driving with particulate mat-

ter accumulating.

●

Engine output (engine speed) is

restricted when a certain amount of

particulate matter accumulates, how-
ever, it is possible to drive the vehicle

unless the malfunction indicator lamp

comes on.

●

Particulate matter can accumulate

more quickly if the vehicle is fre-
quently driven short trips or at low

speeds, or if the engine is regularly

started in an extremely cold environ-
ment. Excessive accumulation of par-

ticulate matter can be prevented by

periodically driving long distances
continuously with intermittent releas-

ing of the accelerator pedal, such as

when driving on highways and free-
ways.

■

If the malfunction indicator lamp

comes on or “Engine Maintenance

Required Visit Your Dealer” is
shown on the multi-information

display

The amount of accumulated particulate
matter has exceeded a certain level.

Have the vehicle inspected by any

authorized Toyota retailer or Toyota
authorized repairer, or any reliable

repairer immediately.

GPF (Gasoline Particu-
late Filter) system

The GPF system collects par-
ticulate matter in the exhaust
gas by using an exhaust gas
filter.

The system will operate to
regenerate the filter automati-
cally, depending on the vehicle
conditions.

NOTICE

■

To prevent the GPF system from
not operating properly

●

Do not use fuel other than the spec-

ified type

●

Do not modify the exhaust pipes

301

4-5. Using the driving support systems

riv

ing

■

ABS (Anti-lock Brake System)

Helps to prevent wheel lock when
the brakes are applied suddenly, or
if the brakes are applied while driv-
ing on a slippery road surface

■

Brake assist

Generates an increased level of
braking force after the brake pedal
is depressed when the system
detects a panic stop situation

■

VSC (Vehicle Stability Control)

Helps the driver to control skidding
when swerving suddenly or turning
on slippery road surfaces.

■

Trailer Sway Control

Helps the driver to control trailer
sway by selectively applying brake
pressure for individual wheels and
reducing driving torque when trailer
sway is detected.

■

TRC (Traction Control)

Helps to maintain drive power and
prevent the drive wheels from spin-
ning when starting the vehicle or
accelerating on slippery roads

■

Active Cornering Assist (ACA)

Helps to prevent the vehicle from
drifting to the outer side by perform-
ing inner wheel brake control when
attempting to accelerate while turn-
ing

■

Hill-start assist control

Helps to reduce the backward
movement of the vehicle when
starting on an uphill

■

EPS (Electric Power Steering)

Employs an electric motor to
reduce the amount of effort needed
to turn the steering wheel.

■

Emergency brake signal

When the brakes are applied sud-
denly, the emergency flashers auto-
matically flash to alert the vehicle
behind.

■

The Secondary Collision
Brake

When the SRS airbag sensor
detects a collision and the system
operates, the brakes and brake
lights are automatically controlled
to reduce the vehicle speed and
help reduce the possibility of further
damage due to a secondary colli-
sion.

Driving assist systems

To keep driving safety and per-
formance, the following sys-
tems operate automatically in
response to various driving sit-
uations. Be aware, however,
that these systems are supple-
mentary and should not be
relied upon too heavily when
operating the vehicle.

Summary of the driving
assist systems

302

4-5. Using the driving support systems

■

When the TRC/VSC/Trailer Sway

Control systems are operating

The slip indicator light will flash while the

TRC/VSC/Trailer Sway Control systems

are operating.

■

Disabling the TRC system

If the vehicle gets stuck in mud, dirt or
snow, the TRC system may reduce
power from the engine to the wheels.

Pressing

to turn the system off may

make it easier for you to rock the vehicle
in order to free it.
To turn the TRC system off, quickly

press and release

The “Traction Control Turned OFF” will
be shown on the multi-information dis-
play.

Press

again to turn the system

back on.

“Traction Control Turned OFF”

■

Turning off both TRC, VSC and

Trailer Sway Control systems

To turn the TRC, VSC and Trailer Sway

Control systems off, press and hold

for more than 3 seconds while the vehi-
cle is stopped.
The VSC OFF indicator light will come
on and the “Traction Control Turned
OFF” will be shown on the multi-infor-
mation display.

Press

again to turn the system

back on.

: On vehicles with PCS (Pre-Collision

System), PCS will also be disabled
(only Pre-Collision warning is avail-
able). The PCS warning light will
come on and a message will be dis-
played on the multi-information dis-
play. (



P.228)

■

When the message is displayed on
the multi-information display show-
ing that TRC has been disabled

even if

has not been pressed

TRC is temporary deactivated. If the

information continues to show, contact
any authorized Toyota retailer or Toyota

authorized repairer, or any reliable

repairer.

■

Operating conditions of hill-start
assist control

When all of the following conditions are

met, the hill-start assist control will oper-
ate:

●

Vehicles with a Multidrive: The shift

lever is in a position other than P or N

(when starting off forward/backward
on an upward incline).

●

Vehicles with a manual transmission:
The shift lever is in a position other

than R when starting off forward on an

upward incline, or the shift lever is in
R when starting off backward on an

upward incline.

●

The vehicle is stopped

303

4-5. Using the driving support systems

riv

ing

●

The accelerator pedal is not
depressed

●

The parking brake is not engaged

●

Engine switch is turned to ON

■

Automatic system cancelation of

hill-start assist control

The hill-start assist control will turn off in

any of the following situations:

●

Vehicles with a Multidrive: The shift

lever is shifted to P or N.

●

Vehicles with a manual transmission:

The shift lever is shifted to R when

starting off forward on an upward
incline, or the shift lever is shifted to

other than R when starting off back-

ward on an upward incline.

●

The accelerator pedal is depressed

●

The parking brake is engaged

●

2 seconds at maximum elapsed after
the brake pedal is released

●

Engine switch is turned to OFF

■

Sounds and vibrations caused by
the ABS, brake assist, VSC, Trailer

Sway Control, TRC and hill-start

assist control systems

●

A sound may be heard from the

engine compartment when the brake
pedal is depressed repeatedly, when

the engine is started or just after the

vehicle begins to move. This sound
does not indicate that a malfunction

has occurred in any of these systems.

●

Any of the following conditions may

occur when the above systems are

operating. None of these indicates
that a malfunction has occurred.

• Vibrations may be felt through the

vehicle body and steering.

• A motor sound may be heard also

after the vehicle comes to a stop.

• The brake pedal may pulsate slightly

after the ABS is activated.

• The brake pedal may move down

slightly after the ABS is activated.

■

Active Cornering Assist operation
sounds and vibrations

When the Active Cornering Assist is

operated, operation sounds and vibra-
tions may be generated from the brake

system, but this is not a malfunction.

■

EPS operation sound

When the steering wheel is operated, a
motor sound (whirring sound) may be

heard. This does not indicate a malfunc-

tion.

■

Automatic reactivation of TRC,
Trailer Sway Control and VSC sys-

tems

After turning the TRC, Trailer Sway Con-
trol and VSC systems off, the systems

will be automatically re-enabled in the

following situations:

●

When the engine switch is turned off

●

If only the TRC system is turned off,

the TRC will turn on when vehicle

speed increases.
If both the TRC and VSC systems are

turned off, automatic re-enabling will

not occur when vehicle speed
increases.

■

Operating conditions of Active Cor-

nering Assist

The system operates when the following
occurs.

●

TRC/VSC can operate

●

The driver is attempting to accelerate

while turning

●

The system detects that the vehicle is

drifting to the outer side

●

The brake pedal is released

■

Reduced effectiveness of the EPS

system

The effectiveness of the EPS system is

reduced to prevent the system from

overheating when there is frequent
steering input over an extended period

of time. The steering wheel may feel

heavy as a result. Should this occur,
refrain from excessive steering input or

stop the vehicle and turn the engine off.

The EPS system should return to nor-
mal within 10 minutes.

304

4-5. Using the driving support systems

■

Operating conditions of emergency
brake signal

When the following conditions are met,

the emergency brake signal will oper-
ates:

●

The emergency flashers are off

●

Actual vehicle speed is over 55 km/h

(35 mph)

●

The system judges from the vehicle

deceleration that it is a sudden brak-
ing operation.

■

Automatic system cancelation of

emergency brake signal

The emergency brake signal will be can-
celed in any of the following situations:

●

The emergency flashers are turned
on.

●

The system judges from the vehicle
deceleration that is not a sudden brak-

ing operation.

■

Secondary Collision Brake operat-

ing conditions

The system operates when the SRS air-

bag sensor detects a collision while the

vehicle is in motion.
However, the system does not operate

when components are damaged.

■

Secondary Collision Brake auto-

matic cancelation

The system is automatically canceled in

any of the following situations.

●

The vehicle speed drops approxi-

mately 0 km/h (0 mph)

●

A certain amount of time elapses

during operation

●

The accelerator pedal is depressed a

large amount

WARNING

■

The ABS does not operate effec-
tively when

●

The limits of tire gripping perfor-

mance have been exceeded (such
as excessively worn tires on a snow

covered road).

●

The vehicle hydroplanes while driv-

ing at high speed on wet or slick

roads.

■

Stopping distance when the ABS

is operating may exceed that of
normal conditions

The ABS is not designed to shorten

the vehicle’s stopping distance.
Always maintain a safe distance from

the vehicle in front of you, especially

in the following situations:

●

When driving on dirt, gravel or

snow-covered roads

●

When driving with tire chains

●

When driving over bumps in the

road

●

When driving over roads with pot-

holes or uneven surfaces

■

TRC/VSC may not operate effec-

tively when

Directional control and power may not
be achievable while driving on slip-

pery road surfaces, even if the

TRC/VSC system is operating. Drive
the vehicle carefully in conditions

where stability and power may be

lost.

■

Active Cornering Assist does not

operate effectively when

●

Do not overly rely on Active Corner-

ing Assist. Active Cornering Assist

may not operate effectively when
accelerating down slopes or driving

on slippery road surfaces.

●

When Active Cornering Assist fre-

quently operates, Active Cornering

Assist may temporarily stop operat-
ing to ensure proper operation of

the brakes, TRC and VSC.

Content .. 16 17 18 19 ..
