Toyota GR Supra (2022 year). Manual in english

132

3-1. CONTROLS



Adaptive variable suspension.



Steering.



Display in the instrument clus-
ter.



Cruise control.

When drive-ready state is
switched on, the NORMAL driv-
ing mode is selected automati-

cally.

■

Concept

Balanced tuning between
dynamic and efficient driving.

■

Concept

Dynamic tuning for higher agility
with an optimized chassis and
suspension.

■

Switching on

■

Concept

Customize settings can be
adjusted in the customize driv-
ing mode.

■

Configuration

Via Toyota Supra Command:

"My Vehicle"

"Vehicle settings"

"Configure SPORT INDIVID-
UAL"

Select the desired setting.

Reset Customize to the stan-
dard settings:

"Reset to SPORT STANDARD".

Overview

Displays in the instrument
cluster

The selected driving
mode is displayed in
the instrument cluster.

Driving modes

Button in the vehicle

Button

Driving

mode

Configu-

ration

SPORT

Custom-

ize

Driving modes in detail

NORMAL

SPORT

Press the button.

Customize

133

3-1. CONTROLS

CON

ROLS

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

The instrument cluster is a vari-
able display. When the sport
mode switch is used to change
the driving mode, the instrument
cluster displays change to
match the driving mode.

The display change in the instru-
ment cluster can be deactivated
via Toyota Supra Command.

Some of the displays in the
instrument cluster may differ
from the illustrations in this
Owner's Manual.

Fuel gauge P.139

Speedometer

Tachometer P.139
Status, Sport mode switch
P.131

Time P.60

Variable displays P.133

External temperature P.141

Engine coolant temperature
P.140

Vehicle messages P.134
Range P.141

Transmission display P.126

Variable displays P.133

Speed Limit Info P.143

In some areas of the instrument
cluster, various assistance sys-
tems, for example the cruise
control, can be displayed. The
displays may vary depending on
the equipment version and
country variant.

Displays

Vehicle features and
options

Instrument cluster

Concept

General information

Overview

Variable displays

134

3-1. CONTROLS

The display can be changed for
sport mode.

The driving mode will change to
sport mode.

The vehicle messages system
monitors functions in the vehicle
and notifies you of malfunctions
in the monitored systems.

A vehicle messages message is
displayed as a combination of
indicator or warning lights and
SMS text messages in the
instrument cluster and, if appli-
cable, in the Head-up Display.

In addition, an acoustic signal
may sound and an SMS text
message may appear on the
Control Display.

Press and hold the button on the
turn signal lever.

Some vehicle messages are
displayed continuously and are
not cleared until the malfunction
is eliminated. If several malfunc-
tions occur at once, the mes-
sages are displayed
consecutively.

The messages can be hidden
for approx. 8 seconds. After this
time, they are displayed again
automatically.

Some vehicle messages are
hidden automatically after
approx. 20 seconds. The vehicle
messages are stored and can
be displayed again later.

Via Toyota Supra Command:

"My vehicle"

Sport mode display

Concept

Changing the display

Push the sport mode
switch until SPORT is
displayed.

Vehicle messages

Concept

General information

Hiding vehicle messages

Continuous display

Temporary display

Displaying stored vehicle
messages

135

3-1. CONTROLS

CON

ROLS

"Vehicle status"

"Vehicle messages"

Select the SMS text mes-
sage.

SMS text messages in combina-
tion with a symbol in the instru-
ment cluster explain a vehicle
message and the meaning of
the indicator/warning lights.

Additional information, such as
the reason for an error or mal-
function or the required action,
can be called up via vehicle
messages.

With urgent messages the
added text will be automatically
displayed on the Control Dis-
play.

Depending on the vehicle mes-
sage, further help can be
selected.

Via Toyota Supra Command:

"My vehicle"

"Vehicle status"

"Vehicle messages"

Select the desired text mes-
sage.

Select desired setting

Certain messages displayed
while driving are displayed
again after drive-ready state is
switched off.

Indicator/warning lights in the
instrument cluster display the
status of some functions in the
vehicle and indicate when a
malfunction is present in the
monitored systems.

The indicator/warning lights can
light up in a variety of combina-
tions and colors.

Several of the lights are
checked for proper functioning
and light up temporarily when
drive-ready state is switched on.

Display

Vehicle messages

At least one vehicle
messages message is
displayed or is stored.

SMS text messages

Supplementary SMS text
messages

Messages after trip comple-
tion

Indicator/warning lights

Concept

General information

136

3-1. CONTROLS

Red lights

Safety belt reminder

Indicator light flashes or
is illuminated: safety
belt on the driver or
passenger side is not
buckled. The safety belt
reminder can also be
activated if objects are
placed on the front pas-
senger seat.

Make sure that the
safety belts are posi-
tioned correctly.

Airbag system

Airbag system and belt
tensioner are not work-
ing.

Have the vehicle
checked immediately
by your Toyota dealer.

Parking brake

The parking brake is
set.

For releasing the park-
ing brake, refer to page
121.

Brake system

Braking system
impaired. Continue to
drive moderately.

Have the vehicle
checked immediately
by your Toyota dealer.

Yellow lights

Anti-lock Braking System
ABS

Braking force boost
may not be working.
Avoid abrupt braking.
Take the longer brak-
ing distance into
account.

Have the system imme-
diately checked by your
Toyota dealer.

137

3-1. CONTROLS

CON

ROLS

VSC Vehicle Stability Con-
trol System

The indicator light
flashes: VSC controls
the drive and braking
forces. The vehicle is
stabilized. Reduce
speed and modify your
driving style to the driv-
ing circumstances.

The indicator light lights
up: VSC has malfunc-
tioned.

Have the system imme-
diately checked by a
dealer’s service center
or another qualified ser-
vice center or repair
shop.

VSC, refer to page 195.

VSC Vehicle Stability Con-
trol System is deactivated or
Traction mode is activated

VSC is deactivated or
Traction mode is acti-
vated.

VSC, refer to page 195,
and Traction mode,
refer to page 197.

Tire Pressure Monitor TPM

The indicator light lights
up: the Tire Pressure
Monitor reports a low
tire inflation pressure or
a flat tire. Follow the
information in the vehi-
cle message.

The indicator light
flashes and then con-
tinuously lights up: no
flat tire or loss of tire
inflation pressure can
be detected.



Interference caused
by systems or
devices with the
same radio fre-
quency: after leaving
the area of the inter-
ference, the system
automatically
becomes active
again.



A wheel without TPM
wheel electronics is
mounted: have it
checked by your Toy-
ota dealer as needed.



Malfunction: have the
system checked by
your Toyota dealer.

Tire Pressure Monitor,
refer to page 280.

138

3-1. CONTROLS

Steering system

Steering system may
not be working.

Have the system
checked by your Toyota
dealer.

Emissions



The warning light
lights up:

Emissions are deterio-
rating. Have the vehi-
cle checked as soon
as possible.



The warning light
flashes under certain
circumstances:

This indicates that
there is excessive mis-
firing in the engine.

Reduce the vehicle
speed and have the
system checked imme-
diately; otherwise, seri-
ous engine misfiring
within a brief period
can seriously damage
emission control com-
ponents, in particular
the catalytic converter.

Socket for Onboard
Diagnosis, refer to page
302.

Green lights

Turn signal

Turn signal switched
on.

Unusually rapid flash-
ing of the indicator light
indicates that a turn sig-
nal bulb has failed.

Turn signal, refer to
page 121.

Parking lights

Parking lights are
switched on.

Parking lights/low
beams, refer to page
153.

Low beams

Low beams are
switched on.

Parking lights/low
beams, refer to page
153.

Lane departure warning

The indicator light lights
up: the system is acti-
vated. A lane marking
was detected on at
least one side of the
vehicle and warnings
can be issued.

Lane departure warn-
ing, refer to page 182.

139

3-1. CONTROLS

CON

ROLS

The current fill level of the fuel
tank is displayed.

Vehicle tilt position may cause
the display to vary.

Information on refueling, refer to
page 262.

Always avoid engine speeds in
the red warning field. In this
range, the fuel supply is reduced
to protect the engine.

Depending on the vehicle equip-
ment, the shift position indica-
tors on the instrument cluster
indicates the maximum shift
point at which the best possible
acceleration can be achieved.

When the selected driving mode
is sport mode, a shift light will be
displayed.

Automatic high-beam

Automatic high-beam is
switched on.

High beams are
switched on and off
automatically depend-
ing on the traffic situa-
tion.

Automatic high-beam,
refer to page 156.

Blue lights

High beams

High beams are
switched on.

High beams, refer to
page 122.

Fuel gauge

Concept

General information

Display

An arrow beside the
fuel pump symbol
shows which side of the
vehicle the fuel filler
flap is on.

Indicator light in the
instrument cluster

The yellow indicator
light illuminates, once
the fuel reserve is
reached.

Tachometer

Shift lights

Concept

Functional requirement

140

3-1. CONTROLS

Select SPORT using the
sport mode switch.

Activate manual mode of the
transmission.

• Successive orange illumi-

nated fields indicate the
upcoming shift moment.

• The field lights up red. Do not

wait any further to shift.

When the maximum speed is
reached, the entire display
flashes red and the supply of
fuel is interrupted in order to
protect the engine.

For further information, see Idle
state, standby state, and
drive-ready state, refer to page
43.

Switching on shift lights

Display

Standby state and
drive-ready state

The lettering OFF in
the instrument cluster
indicates that
drive-ready state is
switched off and
standby state is
switched on.

The lettering READY in
the instrument cluster
indicates that the
drive-ready state is
switched on.

Engine coolant tempera-
ture

Display



When the engine
temperature is low:
Only the segments in
the low temperature
range will be illumi-
nated. Drive with
moderate engine
speed and vehicle
speed.



When the engine
temperature is nor-
mal: All segments to
the middle tempera-
ture range will be illu-
minated.



When the engine
temperature is high:
All segments to the
high temperature
range will be illumi-
nated. A warning
message will also be
displayed.

To check the coolant
level, refer to page 298.

141

3-1. CONTROLS

CON

TROLS

If the indicator drops to

+37°F/+3°C or lower, a signal

sounds.
A vehicle message is displayed.
There is an increased risk of ice

on roads.

The time is displayed in the

instrument cluster. Setting the

time and time format, refer to

page 60.

The range indicates the dis-

tance that can still be covered

with the current fuel level.

The estimated range available

with the remaining fuel is perma-

nently displayed in the instru-

ment cluster.
With a low remaining range, a

vehicle message is briefly dis-

played. With a sporty driving

style, for instance fast cornering,

the engine function is not always

ensured.
The vehicle message appears

continuously below a range of

approx. 30 miles/50 km.

The function displays the ser-

vice notifications and the corre-

sponding maintenance scopes.

After switching on drive-ready

Indicator light in the

instrument cluster

A red indicator light is

displayed.

External temperature

General information

Safety information

WARNING

Even at temperatures above

+37°F/+3°C there can be a risk of

icy roads, for instance on bridges

or shady sections of road. There

is a risk of an accident. Modify

your driving style to the weather

conditions at low temperatures.

Time

Range

Concept

General information

Safety information

NOTICE

With a driving range of less than

30 miles/50 km the engine may

no longer have sufficient fuel.

Engine functions are not ensured

anymore. There is a risk of dam-

age to property. Refuel promptly.

Service notifications

Concept

General information

142

3-1. CONTROLS

state, the instrument cluster
briefly displays available driving
distance or time to the next
scheduled maintenance.

More information on the type of
service required may be dis-
played on the Control Display.

Via Toyota Supra Command:

"My vehicle"

"Vehicle status"

"Service required"

Maintenance and service measures
and legally mandated inspections
are displayed.

Select an entry to call up
detailed information.

Enter the dates for the manda-
tory vehicle inspections.

Make sure that the vehicle's
date and time are set correctly.

Via Toyota Supra Command:

"My vehicle"

"Vehicle status"

"Service required"

"Date:"

Select the desired setting.

The system recommends the
most efficient gear for the cur-
rent driving situation.

Depending on the vehicle equip-
ment and country version, the
gear shift indicator is active in
the manual mode of the auto-
matic transmission.

Suggestions to shift gear up or
down are displayed in the instru-
ment cluster.

On vehicles without a gear shift
indicator, the engaged gear is
displayed.

Display

Detailed information on ser-
vice notifications

Symbols

Symbols

Description

No service is currently
required.

The time for recom-
mended maintenance
or a legally mandated
inspection is approach-
ing.

The time for recom-
mended maintenance
has already passed.

Entering appointment dates

Gear shift indicator

Concept

General information

Displaying

143

3-1. CONTROLS

CON

TROLS

Speed Limit Info shows the cur-

rent valid maximum speed in the

instrument cluster and the

Head-up Display.

The camera in the area of the

interior mirror detects traffic

signs at the edge of the road as

well as variable overhead sign

posts.
Traffic signs with extra symbols

are considered and compared

with the vehicle's onboard data.

The traffic sign will then be

either displayed or ignored

depending on the situation in the

instrument cluster and the

Head-up Display.
The system takes into account

any information that is stored in

the navigation system and also

displays speed limits present on

routes without signs.

The system is controlled by the

following sensors:

• Cameras behind the wind-

shield.

Additional information:

Sensors of the vehicle, refer to

page 40.

Depending on the vehicle equip-

ment, Speed Limit Info is dis-

played permanently in the

instrument cluster or via Toyota

Supra Command.

"My vehicle"

"System settings"

Example

Description

Efficient gear is set.

Shift into efficient gear.

Speed Limit Info

Concept

General information

Safety information

WARNING

The system cannot serve as a

substitute for the driver’s personal

judgment in assessing visibility

and traffic situation. There is a risk

of an accident. Adjust driving style

to traffic conditions. Watch traffic

closely and actively intervene

where appropriate.

Overview

Sensors

Displaying Speed Limit

Info

General information

Display via Toyota Supra

Command

144

3-1. CONTROLS

"Displays"

"Instrument panel"

"Road signs"

If the detected speed limit has
been exceeded, the indicator
light will flash.

Via Toyota Supra Command:

"My vehicle"

"System settings"

"Displays"

"Instrument panel"

Select desired setting:



"Warn when speeding": acti-
vating/deactivating the flash-
ing of the Speed Limit Info
display in the instrument clus-
ter and Head-up Display
when the currently valid
speed limit is exceeded.



"Excess speed display": the
speed limit that is detected by
the Speed Limit Info is dis-
played with a marking in the
speedometer in the instru-
ment cluster.

Additional information:
• Cameras, refer to page 40.

The system may not be fully
functional and may provide
incorrect information in the fol-
lowing situations:



When signs are fully or par-
tially concealed by objects,
stickers or paint.



When driving very close to the
vehicle in front of you.



If the speed limits or road data
stored in the navigation sys-
tem are incorrect.



If the speed limits vary with
the time of day and the day of
the week.



In areas not covered by the
navigation system.



When roads differ from the
navigation, such as due to
changes in road routing.



In case of electronic traffic
signs.

Display

Speed Limit Info

Current speed limit.

Speed Limit Info not
available.

Settings

System limits

System limits of the sensors

Functional limitations

145

3-1. CONTROLS

CON

ROLS



When passing buses or trucks
with traffic signs applied to
them.



If the traffic signs are
non-conforming.



When signs that are valid for
a parallel road are detected.



In the presence of coun-
try-specific signs and road
configurations.

The display can be operated
when necessary.



Entertainment source.



Current audio source.



List of most recent telephone
calls.

If necessary, the corresponding
menu will open on the Control
Display.

Items displayed may differ
depending on the specifications
of the vehicle.

The lists can be displayed and
operated using the buttons on
the steering wheel.

The Onboard Computer dis-
plays different vehicle data in
the instrument cluster, such as
average values.

Selection lists

Concept

Display

Displaying and using the
list

Button

Function

Change the entertain-
ment source.

Pressing the button
again will close the cur-
rently displayed list.

Show list of most
recent telephone calls.

Turn the thumbwheel:
select entertainment
source or list entry.

Press the thumbwheel
to confirm the setting.

The currently selected
list can be displayed
again in the instrument
cluster by turning the
thumbwheel.

Onboard Computer in the
instrument cluster

Concept

Calling up information

146

3-1. CONTROLS

Press and hold the button on the
turn signal lever.

Information is displayed in the
instrument cluster. Pressing the
button repeatedly displays addi-
tional information.

The following information can be
displayed on the Onboard Com-
puter:



Miles and trip miles.



Current drivable range.



Consumption display.



Average consumption and
average speed.

For some information of the
Onboard Computer, it is possi-
ble to set whether it can be
called up in the instrument clus-
ter.

Via Toyota Supra Command:

"My vehicle"

"System settings"

"Displays"

"Instrument panel"

"Onboard info"

Select the desired setting.

■

Displaying/resetting miles

■

Display

■

Concept

The range indicates the dis-
tance that can still be covered
with the current fuel level.

■

General information

The estimated range available
with the remaining fuel is perma-
nently displayed in the instru-
ment cluster.

With a low remaining range, a
vehicle message is briefly dis-
played. With a sporty driving

Information at a glance

Adjusting information for
Onboard Computer

Information in detail

Odometer and trip odometer

• Press the knob to dis-

play the trip miles.

When the drive-ready
state is switched off,
miles and trip miles are
displayed.
• Keep the knob

pressed down to
reset the trip miles.

Current drivable range

147

3-1. CONTROLS

CON

TROLS

style, for instance taking curves

aggressively, the engine func-

tion is not always ensured.
The vehicle message appears

continuously below a range of

approx. 30 miles/50 km.

■

Safety information

■

Display

■

Concept

The current consumption dis-

plays the current consumption

of fuel. Check whether you are

currently driving in an efficient

and environmentally friendly

manner.

■

General information

The current fuel consumption is

displayed on the instrument

cluster as a bar display.

■

Display

■

General information

Average speed and average

consumption are calculated for

the distance traveled since the

last reset in the Onboard Com-

puter.
Periods in which the vehicle is

parked with the engine manually

stopped are not included in the

calculation of the average

speed.

■

Resetting average values

Press and hold the button on the

turn signal lever.

NOTICE

With a driving range of less than

30 miles/50 km the engine may

no longer have sufficient fuel.

Engine functions are not ensured

anymore. There is a risk of dam-

age to property. Refuel promptly.

Consumption display

Average speed and average

consumption

Toyota GR Supra (2022 year). Manual in english - page 9
