3-2. Opening, closing and locking the doors and trunk

Before driv

ing

■

Trunk opener switch

Press and hold the trunk opener
switch.

■

Smart key system

While carrying the electronic
key, press the button on the
trunk lid.
When all of the doors are
unlocked, the trunk lid can be
opened while not carrying an
electronic key. However, as the
doors will be locked when the
vehicle is driven (at a vehicle
speed of 3 mph [5 km/h] or
more), the trunk will not be able

WARNING

●

: Do not disassemble

●

: Do not dispose of in

fire

●

Do not pull on the trunk damper

stay to close the trunk, and do

not hang on the trunk damper

stay.

Doing so may cause hands to

be caught or the trunk damper

stay to break, causing an acci-

dent.

NOTICE

■

Using the trunk

When closing the trunk lid, do not

strongly push down on the trunk

lid. Doing so may dent the trunk

lid.

■

Trunk damper stays

The trunk lid is equipped with

damper stays that hold the trunk

lid in place. Observe the following

precautions.

Failure to do so may cause dam-

age to trunk damper stays, result-

ing in a malfunction.

●

Do not attach any foreign

objects such as stickers, plastic

sheets and adhesives to

damper stay rods.

●

Do not touch damper stay rods

with gloves or other fabric items.

●

Do not attach any accessories

other than genuine Toyota parts

to the trunk lid.

●

Do not apply lateral force to

damper stays or place your

hand on it.

Opening/closing the trunk

110

3-2. Opening, closing and locking the doors and trunk

to be opened until a door is
opened.

■

Wireless remote control

Press and hold the switch.

A buzzer sounds.

■

Trunk light

The trunk light turns on when the

trunk is opened.

■

Function to prevent the trunk

being locked with the electronic

key inside

●

When both side doors are locked,

closing the trunk lid with the elec-

tronic key left inside the trunk will

sound an alarm.

In this case, the trunk lid can be

opened by pressing the trunk

release button on the trunk lid.

●

If the spare electronic key is put in

the trunk with both side doors

locked, the key confinement pre-

vention function is activated so the

trunk can be opened. In order to

prevent theft, take all electronic

keys with you when leaving the

vehicle.

●

If the electronic key is put in the

trunk with both side doors locked,

the key may not be detected

depending on the location of the

key and the surrounding radio

wave conditions. In this case, the

key confinement prevention func-

tion cannot be activated, causing

the doors to lock when the trunk is

closed. Make sure to check where

the key is before closing the trunk.

●

The key confinement prevention

function cannot be activated if

either door is unlocked. In this

case, open the trunk using the

trunk opener.

■

Internal trunk release lever

The trunk lid can be opened by pull-

ing the glow-in-the-dark lever

located on the inside of the trunk lid

upward.
The lever will continue to glow for

some time after the trunk lid is

closed.

■

If the smart key system or the

wireless remote control does

not operate properly

Replace the key battery with a new

one if it is depleted. (



P.328)

■

Customization

Some functions can be customized.

(



P.400)

111

3-2. Opening, closing and locking the doors and trunk

Before driv

ing

■

Antenna location

Antennas outside the cabin
Antennas inside the cabin
Antenna outside the trunk
Antenna inside the trunk

■

Effective range (areas within

which the electronic key is

detected)

When locking or unlocking the
doors

The system can be operated when
the electronic key is within about 1.3



2.6 ft. (0.4



0.8 m) of an outside

door handle. (Only the doors detect-
ing the key can be operated.)

When opening the trunk

The system can be operated when
the electronic key is within about 1.3



2.6 ft. (0.4



0.8 m) of the trunk

release button.

When starting the engine or
changing engine switch modes

The system can be operated when
the electronic key is inside the vehi-
cle.

■

Alarms and warning messages

An alarm sounds and warning mes-

sages are displayed on the

multi-information display to protect

against unexpected accidents or

theft of the vehicle resulting from

erroneous operation. When a warn-

ing message is displayed, take

appropriate measures based on the

displayed message. (



P.357)

When only an alarm sounds, cir-

cumstances and correction proce-

dures are as follows.

●

When an exterior alarm sounds

once for 5 seconds

Smart key system

The following operations
can be performed simply by
carrying the electronic key
on your person, for example
in your pocket. The driver
should always carry the
electronic key.



Locks and unlocks the
doors (



P.105)



Opens the trunk (



P.109)



Starts the engine (



P.145)

C
D

112

3-2. Opening, closing and locking the doors and trunk

●

When an exterior alarm sounds

once for 2 seconds

●

When an interior alarm sounds

continuously

■

Battery-saving function

The battery-saving function will be

activated in order to prevent the

electronic key battery and the vehi-

cle battery from being discharged

while the vehicle is not in operation

for a long time.

●

In the following situations, the

smart key system may take some

time to unlock the doors.

• The electronic key has been left

within approximately 6 ft. (2 m) of

the outside of the vehicle for 10

minutes or longer.

• The smart key system has not

been used for 5 days or longer.

●

If the smart key system has not

been used for 14 days or longer,

the doors cannot be unlocked at

the passenger door. In this case,

take hold of the driver’s door han-

dle, or use the wireless remote

control or mechanical key, to

unlock the doors.

■

Electronic Key Battery-Saving

Function

When battery-saving mode is set,

battery depletion is minimized by

stopping the electronic key from

receiving radio waves.

Press

twice while pressing and

holding

. Confirm that the elec-

tronic key indicator flashes 4 times.
While the battery-saving mode is
set, the smart key system cannot be
used. To cancel the function, press
any of the electronic key buttons.

■

Conditions affecting operation

The smart key system uses weak

radio waves. In the following situa-

tions, the communication between

the electronic key and the vehicle

may be affected, preventing the

smart key system, wireless remote

control and engine immobilizer sys-

tem from operating properly.

(Ways of coping:



P.370)

●

When the electronic key battery is

Situation

Correction

procedure

An attempt was
made to lock the
vehicle while a door
was open.

Close both
side doors
and lock the
doors again.

Situation

Correction

procedure

The trunk was closed
while the electronic
key was still inside
the trunk and both
side doors were
locked.

Retrieve the
electronic
key from the
trunk and
close the
trunk lid.

Situation

Correction

procedure

The engine switch
was turned to ACC
while the driver’s
door was open (or
the driver’s door was
opened while the
engine switch was in
ACC).

Turn the
engine
switch off
and close
the driver’s
door.

The engine switch
was turned off while
the driver’s door was
open.

Close the
driver’s
door.

113

3-2. Opening, closing and locking the doors and trunk

Before driv

ing

depleted

●

Near a TV tower, electric power

plant, gas station, radio station,

large display, airport or other facil-

ity that generates strong radio

waves or electrical noise

●

When carrying a portable radio,

cellular phone, cordless phone or

other wireless communication

device

●

When the electronic key is in con-

tact with, or is covered by the fol-

lowing metallic objects

• Cards to which aluminum foil is

attached

• Cigarette boxes that have alumi-

num foil inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that

emit radio waves) are being used

nearby

●

When carrying the electronic key

together with the following devices

that emit radio waves

• Another vehicle’s electronic key or

a wireless key that emits radio

waves

• Personal computers or personal

digital assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic con-

tent or metallic objects are

attached to the rear window

●

When the electronic key is placed

near a battery charger or elec-

tronic devices

■

Note for the entry function

●

Even when the electronic key is

within the effective range (detec-

tion areas), the system may not

operate properly in the following

cases:

• The electronic key is too close to

the window or outside door han-

dle, near the ground, or in a high

place when the doors are locked

or unlocked.

• The electronic key is near the

ground or in a high place, or too

close to the rear bumper center

when the trunk is unlocked.

• The electronic key is on the instru-

ment panel, rear package tray or

floor, or in the door pockets or

glove box when the engine is

started or engine switch modes

are changed.

●

Do not leave the electronic key on

top of the instrument panel or near

the door pockets when exiting the

vehicle. Depending on the radio

wave reception conditions, it may

be detected by the antenna out-

side the cabin and the doors will

become lockable from the outside,

possibly trapping the electronic

key inside the vehicle.

●

As long as the electronic key is

within the effective range, the

doors may be locked or unlocked

by anyone. However, only the

doors detecting the electronic key

can be used to unlock the vehicle.

●

Even if the electronic key is not

inside the vehicle, it may be possi-

ble to start the engine if the elec-

tronic key is near the window.

●

The doors may unlock or lock if a

large amount of water splashes on

the door handle, such as in the

rain or in a car wash, when the

electronic key is within the effec-

tive range. (The doors will auto-

matically be locked after

approximately 60 seconds if the

doors are not opened and closed.)

●

If the wireless remote control is

used to lock the doors when the

electronic key is near the vehicle,

there is a possibility that the door

may not be unlocked by the entry

function. (Use the wireless remote

control to unlock the doors.)

●

Touching the door lock or unlock

sensor while wearing gloves may

prevent lock or unlock operation.

●

When the lock operation is per-

114

3-2. Opening, closing and locking the doors and trunk

formed using the lock sensor, rec-

ognition signals will be shown up

to three consecutive times. After

this, no recognition signals will be

given.

●

If the door handle becomes wet

while the electronic key is within

the effective range, the door may

lock and unlock repeatedly. In this

case, follow the following correc-

tion procedures to wash the vehi-

cle:

• Place the electronic key in a loca-

tion 6 ft. (2 m) or more away from

the vehicle. (Take care to ensure

that the key is not stolen.)

• Set the electronic key to bat-

tery-saving mode to disable the

smart key system. (



P.112)

●

If the electronic key is inside the

vehicle and a door handle

becomes wet during a car wash, a

message may be shown on the

multi-information display and a

buzzer will sound outside the vehi-

cle. To turn off the alarm, lock both

side doors.

●

The lock sensor may not work

properly if it comes into contact

with ice, snow, mud, etc. Clean

the lock sensor and attempt to

operate it again.

●

A sudden handle operation or a

handle operation immediately

after entering the effective range

may prevent the doors from being

unlocked. Touch the door unlock

sensor and check that the doors

are unlocked before pulling the

door handle again.

●

Unlocking the vehicle may take

more time if another electronic key

is within the effective range.

■

When the vehicle is not driven

for extended periods

●

To prevent theft of the vehicle, do

not leave the electronic key within

6 ft. (2 m) of the vehicle.

●

The smart key system can be

deactivated in advance. (



P.115)

●

Setting the electronic key to bat-

tery-saving mode helps to reduce

key battery depletion. (



P.112)

■

To operate the system properly

●

Make sure to carry the electronic

key when operating the system.

Do not get the electronic key too

close to the vehicle when operat-

ing the system from the outside of

the vehicle.

Depending on the position and hold-

ing condition of the electronic key,

the key may not be detected cor-

rectly and the system may not oper-

ate properly. (The alarm may go off

accidentally, or the door lock pre-

vention function may not operate.)

●

Do not leave the electronic key

inside the trunk.

The key confinement prevention

function may not operate, depend-

ing on the location of the key (the

inside edge of the Trunk), condi-

tions (inside a metal bag, close to

metallic objects) and the radio

waves in the surrounding area.

(



P.111)

■

If the smart key system does

not operate properly

●

Locking and unlocking the doors:



P.370

●

Starting the engine:



P.370

■

Customization

Some functions can be customized.

(



P.400)

■

If the smart key system has

been disabled

●

Locking and unlocking the doors:

Use the wireless remote control or

mechanical key. (



P.105, 370)

●

Starting the engine and changing

engine switch modes:



P.370

●

Stopping the engine:



P.147

115

3-2. Opening, closing and locking the doors and trunk

Before driv

ing

In the following situations, the
smart key system should be dis-
abled.



When people with implantable
cardiac pacemakers, cardiac
resynchronization therapy
pacemakers or implantable

cardioverter defibrillators ride
in the vehicle.



When the vehicle will not be
used for a long time, or the
smart key system is not used.



When storing an electronic
key near or inside the vehicle
cannot be avoided.

When the smart key system is
disabled, use the wireless
remote control to lock and
unlock the doors.
When starting the engine, it will
be necessary to hold the elec-
tronic key near the engine
switch. (



P.370)

■

Disabling the smart key
system

The smart key system can be
disabled by opening and closing
the doors or using the wireless
remote control.



Door opening/closing method

While sitting in the driver’s
seat, close the door.

Press

of the door lock

switch.

Within 5 seconds of perform-
ing step

, open the driver’s

door.

Within 5 seconds of perform-
ing step

, press

of the

door lock switch 2 times with
the door open.

Within 10 seconds of per-
forming step

, close and

WARNING

■

Caution regarding interfer-

ence with electronic devices

●

People with implantable car-

diac pacemakers, cardiac

resynchronization ther-

apy-pacemakers or implantable

cardioverter defibrillators should

keep away from the smart key

system antennas. (



P.111)

The radio waves may affect the

operation of such devices. If

necessary, the entry function

can be disabled. Ask your Toy-

ota dealer for details, such as

the frequency of radio waves

and timing of the emitted radio

waves. Then, consult your doc-

tor to see if you should disable

the entry function.

●

Users of any electrical medical

device other than implantable

cardiac pacemakers, cardiac

resynchronization ther-

apy-pacemakers or implantable

cardioverter defibrillators should

consult the manufacturer of the

device for information about its

operation under the influence of

radio waves.

Radio waves could have unex-

pected effects on the operation

of such medical devices.

The smart key system can be dis-

abled. (



P.115)

When to disable the smart
key system

116

3-2. Opening, closing and locking the doors and trunk

open the driver’s door 2
times.

Within 10 seconds of per-
forming step

, press

the door lock switch 2 times
with the door open.

Within 10 seconds of per-
forming step

, close and

open the driver’s door 1 time.

Within 5 seconds of perform-
ing step

, close the driver’s

door.

A buzzer will sound for approxi-

mately 2 seconds and the smart

key system will be disabled.



Wireless remote control
method

Open the driver’s door and
push the lock lever forward.

Press and hold

and

the wireless remote control at
the same time for 5 seconds
or more.

A buzzer will sound for approxi-

mately 2 seconds and the smart

key system will be disabled.

■

Enabling the smart key sys-
tem

The smart key system can be
enabled by performing the pro-

cedure used to disable it again.

When enabled a buzzer will sound.

■

Door opening/closing method

Make sure to firmly press the door

lock switch in steps

and

. If the

switch is pressed for a very short

time, the system may not be dis-

abled.

■

Wireless remote control

method

To use the wireless remote control

method to disable the smart key

system, it is necessary to register a

PIN code for the PIN code smart

entry. (



P.117)

■

When enabling the smart key

system

If the method used to disable the

smart key system is unknown, press

the engine switch.

●

If the wireless remote control sys-

tem was used, a buzzer inside the

vehicle will sound.

●

If the door opening/closing

method was used, the buzzer will

not sound.

■

Customization

Some functions can be customized.

(



P.400)

NOTICE

■

When disabling the smart key

system

When disabling or enabling the

system to accommodate persons

with implantable cardiac pace-

makers, cardiac resynchroniza-

tion therapy pacemakers or

implantable cardioverter defibrilla-

tors, always use the door open-

ing/closing method. If the wireless

remote control method is used,

the system may be enabled acci-

dentally.

117

3-2. Opening, closing and locking the doors and trunk

Before driv

ing

By registering a 5 digit PIN
code, all of the doors and the
fuel filler door can be unlocked
without an electronic key by
pressing the trunk opener
switch.

■

PIN code registration
method

Turn the engine switch off.

Close all of the doors and the
trunk.

Press and hold

of the

wireless remote control.

At this time, all of the doors and the

fuel filler door will lock.

Within 5 seconds of perform-
ing step

, press and hold

the trunk opener switch.

After 5 seconds or more, a buzzer

will sound.

Release

of the wireless

remote control and the trunk
opener switch.

Within 30 seconds after the
buzzer begins sounding,
press

of the wireless

remote control.

The buzzer will stop.

A PIN code can now be reg-
istered. Press the trunk
opener switch the same num-
ber of times as the first digit
of the PIN code.

For example: If registering 32468,

press the switch 3 times.

Wait for the buzzer to sound
1 time and then press the
switch the same number of
times as for the next digit.

For example: If registering 32468,

press the switch 2 times.

Repeat step

for the remain-

ing digits.

Within 30 seconds after the

buzzer begins sounding
intermittently, perform steps

through

again to confirm

the PIN code.

Registration is complete and all of

the doors and the fuel filler door will

unlock.

■

Unlocking method

Press the trunk opener switch
using the same procedure as
steps

through

■

PIN code registration

●

To prevent theft, the same digit for

all 5 digits and 12345 cannot be

registered as the PIN code. Also,

avoid using the same number as

on your license plate or other sim-

ple codes.

●

To use 0 as a digit, press the trunk

opener switch 10 times.

●

If a mistake is made during regis-

tration, unlock the doors or trunk

using the wireless remote control

to cancel registration. Then per-

form registration again, starting

from step

. However, if the mis-

take was made in step

, a

buzzer will sound and step

can

be performed again.

●

To clear the PIN code, perform the

registration procedure and enter

22222.

Unlocking the doors
using PIN code smart
entry

118

3-2. Opening, closing and locking the doors and trunk

●

After registering a new PIN code,

make sure to check that the doors

can be unlocked using the code.

●

If the smart key system has been

disabled using the wireless

remote control method, the PIN

code for the PIN code smart entry

cannot be cleared. (



P.115)

●

In the following cases, perform the

PIN code registration procedure

again.

• If the PIN code has been forgot-

ten.

• When you wish to change the PIN

code.

●

Make sure to change the PIN

code periodically.

●

If the vehicle has been loaned to

another person, make sure that

the PIN code has not been

changed or cleared. If the PIN

code has been changed or

cleared, perform PIN code regis-

tration again.

■

Unlocking method

●

If an electronic key is within a

detection area, operation of the

smart entry will be given priority.

●

If a mistake is made while entering

the PIN code, wait 5 seconds or

more before performing the proce-

dure again.

●

If the incorrect PIN code is

entered 5 times consecutively, a

buzzer will sound for approxi-

mately 2 seconds and operation

will not be possible for 5 minutes.

119

3-3. Adjusting the seats

Before driv

ing

3-3.Adjusting the seats

Seat position adjustment
lever
Seatback angle adjustment
lever
Vertical height adjustment
lever (driver’s side only)
Seatback fold lever

To get in and out of the rear
seats, use the seatback angle
adjustment lever or seatback
fold lever.

■

Before getting in or out of
the rear seats

Remove the seat belt from the
seat belt guide. (



P.27)

■

When getting in or out of
the rear seats



Driver’s side

Pull the seatback fold lever (

) or

lift the seatback angle adjust-
ment lever (

The seatback will fold forward.



Front passenger’s side

Pull the seatback fold lever (

) or

lift the seatback angle adjust-
ment lever (

The seatback will fold forward.
The seat can be slid forward and
backward.

■

After getting in or out of the
rear seats

Return the seatback to the
upright position until the seat
locks.

Front passenger seat only: The

Front seats

Adjustment procedure

Getting in and out of the
rear seats

120

3-3. Adjusting the seats

seat will lock in position at the point
where the seatback reaches the
upright position.

■

Seat dust cover

Always remove the seat dust cover

that may be attached at the time of

purchase before using the seat.

WARNING

■

Seat adjustment

To reduce the risk of sliding under

the lap belt during a collision, do

not recline the seat more than

necessary.
If the seat is too reclined, the lap

belt may slide past the hips and

apply restraint forces directly to

the abdomen, or your neck may

contact the shoulder belt, increas-

ing the risk of death or serious

injury in the event of an accident.
Adjustments should not be made

while driving as the seat may

unexpectedly move and cause

the driver to lose control of the

vehicle.

●

After adjusting the seat, make

sure that the seat is locked in

position.

●

Take care not to hit passengers

with the seat. When sliding the

seat rearward, make sure not to

squash the legs of the rear pas-

sengers.

●

When returning the seatback

upright, perform seatback angle

adjustment while holding down

the seatback.

●

Do not pull on or use the seat

belt guide to adjust or fold the

front seat.

●

Do not put your hands under the

seat or near the moving parts to

avoid injury. Fingers or hands

may become jammed in the

seat mechanism.

■

When driving the vehicle

Never operate the seat position

adjustment lever, seatback angle

adjustment lever or seatback fold

lever. Doing so could cause an

accident resulting in death or seri-

ous injury.

■

Getting in and out of the rear

seats

●

When getting in or out of the

rear seats, make sure not to get

your hands, legs, etc. squashed

in the movable or connecting

parts.

●

When getting in or out of the

rear seats, make sure not to trip

on the seat rails.

●

After getting in or out of the rear

seats, always make sure the

front seat is locked in position.

■

When operating the front seat

from the rear seat

Make sure that no passenger is

seated in the front seat.

NOTICE

■

When adjusting a front seat

When adjusting a front seat, make

sure that the head restraint does

not contact the headliner. Other-

wise, the head restraint and head-

liner may be damaged.

121

3-3. Adjusting the seats

Before driv

ing

Move the front seats forward.
(



P.119)

Fold the seatback down.



Lock release buttons

Press the seatback lock release
buttons and fold the seatback
down.
Press the button until the lock is
released.
To return the seatbacks to its origi-
nal position, lift it up until it locks.



Lock release straps

Pull the seatback lock release
straps in the trunk for the seatback
you wish to fold down.
To return the seatbacks to its origi-
nal position, lift it up until it locks.

NOTICE

■

When getting in and out the

vehicle

Do not rub your back against the

side support pad of backrest. Oth-

erwise surface of the side support

pad is damaged early. You can

move the seat backward to pre-

vent the contact.

Rear seats

The rear seatbacks can be
folded down.

Folding down the rear
seatbacks

122

3-3. Adjusting the seats

■

Seat dust cover

Always remove the seat dust cover

that may be attached at the time of

purchase before using the seat.

WARNING

Observe the following precau-

tions. Failure to do so may result

in death or serious injury.

■

When folding the rear seat-

backs down

●

Do not fold the seatbacks down

while driving.

●

Stop the vehicle on level

ground, set the parking brake

and shift the shift lever to P

(automatic transmission) or N

(manual transmission).

●

Do not allow anyone to sit on a

folded seatback or in the trunk

while driving.

●

Do not allow children to enter

the trunk.

■

After returning the rear seat-

back to the upright position

●

Push the rear seatback and

then check that it is securely

locked in position by lightly

pushing it back and forth.

If the seatback is not securely

locked, the red portion of the

seatback lock indicator will be

visible. Make sure that the red

portion is not visible.

●

Check that the seat belts are

not twisted or caught in the

seatback.

■

Before using the rear seat

belts

Always make sure that the seat

belt is not caught in the seatback

or twisted in one of the hooks that

secure the seatback. Failure to do

so may cause the seat belt to not

be fastened correctly or to

become ineffective in a collision,

resulting in death or serious injury.

123

3-3. Adjusting the seats

Before driv

ing

Pull the head restraints up.

Down

Push the head restraint down while
pressing the lock release button

■

Adjusting the height of the head

restraints

Make sure that the head restraints

are adjusted so that the center of

the head restraint is closest to the

top of your ears.

Pull the head restraint up while
pressing the lock release button

If the head restraint touches the
ceiling, making the removal diffi-
cult, change the seat height or
angle. (



P.119)

Align the head restraint with the
installation holes and push it
down to the lock position.
Press and hold the lock release

Head restraints

Head restraints are provided
for front seats.

WARNING

■

Head restraint precautions

Observe the following precautions

regarding the head restraints.

Failure to do so may result in

death or serious injury.

●

Use the head restraints

designed for each respective

seat.

●

Adjust the head restraints to the

correct position at all times.

●

After adjusting the head

restraints, push down on them

and make sure they are locked

in position.

●

Do not drive with the head

restraints removed.

Adjusting a head restraint
vertically

Removing the head
restraints

Installing the head
restraints

124

3-3. Adjusting the seats

button when lowering the
head restraint.

Content .. 5 6 7 8 ..
